Delfield ST4472N-S Specifications

Delfield
™
®
ST4472N Salad Top
Front-Breathing Self-Contained Compact Salad Top Refrigerators
Models
• ST4472N-12 Two section with doors twelve pan capacity
• STD4472N-12 Two section with drawers twelve pan capacity
STD4472N-12

Specifications

Exterior top is one-piece 22-gauge stainless steel with integral 2.12"
(5.1cm) square nosing at the front. Top has openings to accept 12 or 18
1/6-size 4"- 6" (10.2cm - 15.2cm) deep plastic pans. Adapter bars and 1/6
pans are supplied by Delfield. Temperature in top opening to maintain
33°F (1°C) to 41°F (5°C), with pans recessed 2.5" (6.4cm) at 86°F ambient
room temperature, meeting NSF 7 requirements. One 72" x 10" x .5" (183cm
x 25.4cm x 1.3cm) polyethylene cutting board treated with antimicrobial
agent is mounted on the top at the front edge.
Exterior back and bottom are two-piece 24-gauge galvanized steel.
Exterior ends are stainless steel.
Interior sides are thermoformed ABS plastic with shelf supports. Base is
fully insulated with high-density foamed in place environmentally friendly,
Kyoto Protocol Compliant, Non ODP (Ozone Depletion Potential), Non GWP
(Global Warming Potential) polyurethane.
Refrigeration system uses HFC-404A refrigerant. Compressor is 1/2 H.P.,
with condenser coil and condensate evaporator mounted on rear of the
cabinet. Evaporator coils and temperature control are located on the
interior rear wall of the cabinet. Refrigerant flow is controlled by a capillary
tube. Cabinet maintains an interior cabinet temperature of 36°F to 40°F
(2°C to 4°C).
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858

Standard Features

• Patented air screen ensures product stays cold without
drying it out
• All 4400 Series units are 100% front breathing, which allows
the unit to be pushed against a wall or built into a cabinet or
an existing line up
• Durable, rugged stainless steel sides, top and front
• Features Delfield's exclusive ABS interior (on sides). ABS
is extremely durable - it won't dent, chip or corrode and is
backed by a limited lifetime warranty
• Delfield supplies 1/6 size pans and adapter bars for top
opening
• Salad top refrigerators are standard with 10" wide,
dishwasher safe polyethylene cutting board treated with
anitmicrobial agent
• "D" prefix models feature Delfield's new drawer system.
Drawers are backed by a 10-year warranty on the track
assembly
• Environmentally friendly R404A refrigerant
• High density foamed in place environmentally friendly, Kyoto
Protocol Compliant, Non ODP (Ozone Depletion Potential),
Non GWP (Global Warming Potential) polyurethane keeps
energy costs low
• Black recessed quick grip handle
• Standard on 2" casters for easy cleaning and installation
• 7' cord and plug supplied
• Cord spring relief - prevents cord rollover
• One epoxy coated wire shelf standard, installed per door
section
• ACT solid state electronic control
• "ST" models have a 4" stainless steel backsplash
• One year parts and 90 day labor standard warranty.
ACT control. ACT electronic, solid state control, mounted on the exterior
rear of the cabinet, allows unit to maintain precise temperatures in heavy
duty conditions.
Electrical connections are 115 volt, 60 Hertz, single phase. Unit has a 7'
(2.1m) long electrical cord and NEMA 5-15P plug.
Casters: Equipment is mounted on 2" (5.08cm) diameter casters, with front
three locking. Equipment clearance above the floor is 2.5" (6.35cm).
The following applies to three door models only
Doors have a 24-gauge stainless steel exterior, with thermoformed ABS
plastic interior liner. Cabinet has one adjustable epoxy-coated wire shelf
per door opening.
The following applies to six drawer models only. Drawer fronts have a
24-gauge stainless steel exterior, with thermoformed ABS plastic interior
liner. Drawer frames and slides are 12-gauge stainless steel. Drawer slides
are 11-gauge stainless steel with Delrin bearings. Each section has two
drawers. Each top drawer holds one full size 12" x 20" (30.5cm x 50.8cm) pan
and three 1/9 size pans 4" - 6" (10.6cm -15.2cm) deep. Each bottom drawer
holds one 12" x 20" (30.5cm x 50.8cm) pan 4" (10.6cm) and three 1/9 size
deep pans. Pans supplied by others.
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
www.delfield.com
Options &
Accessories
• Flat lift off cover
• 18" wide single tier overshelf
• Stainless steel finish on back
• Plastic laminate on front
• Additional wire shelves
• Door lock
• Exterior thermometer
• Glass door(s)
• *220V/50 Hertz electrical system
* Inclusion of this option will
alter electrical specifications
of the unit.
