- Page 1 ORIGINAL INSTRUCTIONS >EN ELECTRIC LOG SPLITTER FFBE5TS USER GUIDE CAUTION: Read this manual before using this machine!
- Page 2 CONTENTS 1. SAFETY INSTRUCTIONS........................3 2. TECHNICAL SPECIFICATIONS......................8 3. ASSEMBLY.............................8 4. OPERATION............................13 5. MAINTENANCE...........................16 6. STORAGE.............................17 7. TROUBLE SHOOTING........................17 8. DISPOSAL............................17 9. DECLARATION OF CONFORMITY....................18 10. WARRANTY............................19 11. PRODUCT FAILURE........................20 12. WARRANTY EXCLUSIONS......................21...
- Page 3 1. SAFETY INSTRUCTIONS UNDERSTAND YOUR CUTTER Read and understand the owner’s manual and labels affixed to the log splitter. Learn its application and limitations as well as the specific potential hazards peculiar to it. DRUGS, ALCOHOL AND MEDICATION Do not operate the log splitter while under the influence of drugs, alcohol, or any medication that could affect your ability to use it properly.
- Page 4 Avoid use of free and inadequately insulated connections. Connections must be made with protected material suitable for outdoor use. AVOID ELECTRICAL SHOCK Check that the electric circuit is adequately protected and that it corresponds with the power, voltage and frequency of the motor. Check that there is a ground connection, and a regulation differential switch upstream.
- Page 5 DISCONNECT POWER Unplug when not in use, before making adjustments, changing parts, cleaning, or working on the log splitter; Consult technical manual before servicing. PROTECT THE ENVIRONMENT Take used oil to an authorized collection point or follow the stipulations in the country where the log splitter is used.
- Page 6 17. Do not use machines with electric motor if natural gas, petrol fumes or other inflammable vapors are present. 18. Check that the electric circuit is adequately protected and that it corresponds with the power, voltage and frequency of the motor, check that there is a ground connection, and a regulation differential switch upstream.
- Page 7 Wear eye protection Use hearing protection No trespassing No smoking in the working area Only the operator may stand within the operating range of the machine. Keep non-involved persons, as well as domestic and farm animals, out of the hazard area (minimum distance: 5m) Keep your work space tidy! Untidiness can lead to accidents.
- Page 8 This log splitter is only intended to be used to split logs! Serious injury may occur if this log splitter is used for any other purpose. 2. TECHNICAL SPECIFICATIONS Model FFBE5TS Voltage: 230V~ 50Hz Power consumption 1500W, S3 50% (5min on/5min off)
- Page 9 WARNING! If any parts are missing, do not operate this machine until the missing parts are replaced. Failure to do so could result in serious personal injury. Do not discard the packing materials until you have carefully inspected the log splitter, identified all parts, and satisfactorily operated your new log splitter.
- Page 10 Fig.1 3. Recommended oils We recommend use of the following oils for the hydraulic cylinder. SHELL TELLUS T22 ARAL VITAM GF22 SP ENERGOL HCP22 MOBILE DTE 11 OR equivalent DO NOT USE OTHER GRADE OILS 4. Application conditions This log splitter is a home use model. It is designed for operating under ambient temperature between +5 C and 40 C and use at altitudes no more than 1000mm.
- Page 11 fig.3 c) Connect back stand (13c) to connection pipe (c) and connect back stand (13d) to connection pipe (d) by bolts and nuts (fig.4). fig.4 d) Connect horizontal shaft (9b) to back stand (13c&13d) with bolts, assemble the wheel shaft (11) and wheels with four spring washers, the last fit wheel covers (fig.5).
- Page 12 Remove the accessories as shown in the figure from the carton and check the number of accessories, and then install according to the following steps: 1. Using the Allen wrench to make the two M8×16 screws through the two washer8 and the mounting hole for left side support plate, then tighten the screw holes corresponding to the bent legs( fig.
- Page 13 4、Install the stock support plate. Push the two M8×16 screws through mounting hole of the support plate and the stock support plate, tighten with two M8 nuts. Then push two M8×16 screws through the two mounting hole of the stock support plate, push two M8×50 bolts through the mounting hole of the left and right bent legs and mounting hole of the stock support plate on the other side, tighten with four M8 nuts.
- Page 14 was done by qualified mechanic with professional instruments. Unauthorized resetting will cause the hydraulic pump fail to output enough splitting pressure or RESULT IN SERIOUS INJURY AS WELL AS DAMAGE TO THE MACHINE. Fig.11 Make sure that the screws are tightened up properly before operation the log splitter! This log splitter is equipped with control system that requires to be operated by both hands of the user –...
- Page 15 attempt to split logs that exceed the capacity of the machine. Always set logs firmly on the log retaining plates and work table. Make sure logs will not twist, rock or slip while being split. Do not force the blade by splitting the log on the upper part.
- Page 16 Fig.15 5. MAINTENANCE Replacing hydraulic oil (fig.16) Replace the hydraulic oil in the log splitter after every 150 hours of use. Take following steps to replace it. 1. Make sure all moving parts stops and the log splitter is unplugged. 2.
- Page 17 6. STORAGE When you have finish working with your log splitter: 1. Disconnect the log splitter from the mains supply. 2. Tighten the oil yank cover / air bleeder, 3. Clean the unit down using a dry cloth. 4. Store in a dry and well-ventilated area. 7.
- Page 18 Tel : +33 (0)5.34.502.502 Fax : +33 (0)5.34.502.503 Declare that this machine: ELECTRIC LOGSPLITTER Model: FFBE5TS Serial number: 20230605974-20230606058 Is in conformity with the Directive 2006/42/EC and the regulations transposing it; Also in conformity with the following Directives: RoHS Directive (EU)2015/863 amending 2011/65/EU...
- Page 19 10. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identifed as defective by the designated distributor.
- Page 20 11. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine.
- Page 21 12. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
- Page 22 BUILDER SAS 32 rue Aristide Bergès - Z.I. du Casque - 31270 Cugnaux - France Made in PRC...
