- Page 1 Home Appliances Dishwashing User Manual Fullsize Dishwasher QW-GT35F444I-EN For Life...
- Page 3 CONTENTS CHAPTER-1: EXPLANATION OF PRODUCT Technical specifications Conformity with the standards and test data CHAPTER-2: SAFETY INFORMATION AND RECOMMENDATIONS Recycling Safety information Recommendations Items not suitable for dishwashing CHAPTER-3: INSTALLING THE MACHINE Positioning the machine Water connections Water inlet hose Water outlet hose Electrical connection Fitting the machine undercounter...
- Page 4 CHAPTER -1: EXPLANATION OF PRODUCT 1. Worktop 7. Rating plate 2. Upper basket with racks 8. Control Panel 3. Upper spray arm 9. Detergent and rinse-aid dispenser 4. Lower basket 10. Salt dispenser 5. Lower spray arm 11. Upper basket track latch 6.
- Page 5 CHAPTER -1: TECHNICAL SPECIFICATIONS Technical specifications Capacity 14 place settings Height 850 mm Height (without worktop) 820 mm Width 598 mm Depth 598 mm Net Weight 53 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 100 W...
- Page 6 CHAPTER -2: SAFETY INFORMATION AND RECOMMENDATIONS Recycling • The recyclable materials are used in certain components and packaging. • Plastic parts are marked with international abbreviations: (>PE< , >PS< , >POM<, >PP<, ) • Cardboard parts have been produced from recycled paper which should be disposed of into waste paper collection containers for recycling.
- Page 7 • Place knives and other sharp-ended objects in the cutlery basket in bladedown position. • If the supply cord is damaged, it must be replaced by SHARP, or its service agent. • If the EnergySave option is selected as “Yes”, the door will be opened at the end of the program.
- Page 8 CHAPTER -2: SAFETY INFORMATION AND RECOMMENDATIONS Recommendations • For energy and water saving, remove coarse residues on your dishes before placing the dishes into the machine. Start your machine after having fully loaded it. • Use the pre-wash programme only when necessary. •...
- Page 9 CHAPTER -3: INSTALLING THE MACHINE If the door of machine does not close properly, check if the machine is stable on the floor . Ifits’ not, adjust the feet and ensure its stable position. Water connection Indoor plumbing must be suitable for installing a dishwasher. Also, we recommend that you fit a filter at the entrance of your property so as to avoid any damage to your machine because of contamination (sand, clay, rust etc.) that might be occasionally carried in through the mains water supply or the indoor plumbing,...
- Page 10 CHAPTER -3: INSTALLING THE MACHINE Warning: When a drain hose longer than 4 m is used, the dishes might remain dirty. In that case, SHARP will not accept responsibility. Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current.
- Page 11 CHAPTER -3: INSTALLING THE MACHINE For safety purposes, we recommend that you disconnect the plug when the machine is not going to be used for an extended period of time. In order avoid electric shocks, do not unplug when your hands are wet. When disconnecting your machine from the mains supply, always pull from the plug.
- Page 12 CHAPTER -3: INSTALLING THE MACHINE Adjust the machine’s feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or bent.4 Product Without Insulation With Insulation All Product For 2nd Basket For 3rd Basket Height 820 mm...
- Page 13 CHAPTER -4: PREPARING THE MACHINE FOR USE Prior to using the machine for the first time • Check whether the electricity and supply water specifications match the values indicated by the installation instructions for the machine. • Remove all packaging materials inside the machine. •...
- Page 14 CHAPTER -4: PREPARING THE MACHINE FOR USE Adjusting salt consumption Water German French British Hardness Level Indicator hardness hardness hardness hardness level level dH level dF level dE L1 is seen on display. 6-11 10-20 7-14 L2 is seen on display. 12-17 21-30 15-21...
- Page 15 CHAPTER -4: PREPARING THE MACHINE FOR USE Combined detergents Combined detergents may include various properties. Before using the detergent, read the instructions carefully. Generally combined detergents produce sufficent results under certain conditions only. Points to consider when using this type of products: •...
- Page 16 The upper basket is for thin and narrow items. You are recommended to use the cutlery grid in order to obtain the best result. To avoid any possible injuries, long-handle and sharp-pointed dishes with their sharp points facing down or horizontally on the baskets.
- Page 17 The Upper Cutlery Basket is composed of two pieces; if you need to make space for the dishes in the upper bas- ket, you can take out the left or right part of the upper cutlery basket in order to obtain more space. Warning: Knives and other sharp objects must be placed horizontally in the cutlery basket. EN-17...
- Page 18 CHAPTER-5: LOADING YOUR DISHWASHER Alternative basket loads Lower Basket Top basket Faulty loads Important Note for Test Laboratories For detailed information on performance tests, please contact following address: “dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door.
- Page 19 CHAPTER -6: PROGRAMME DESCRIPTIONS Programme No Programme Jetwash 18’ 35°C Auto Auto Intense Dual Wash 65°C names and Delicate 30-50°C 50-70°C temperatures Type of food Fresh less dirty, Detects contamination level of Soups,sauces waste coffee, dishes and sets temperature and pasta, eggs, milk, tea amount of washing water and...
- Page 20 CHAPTER -6: PROGRAMME DESCRIPTIONS Programme items Programme No Programme Quick 30 min. 40°C ***Express 50 Hygiene 70°C names and min. 65°C temperatures Type of food Fresh coffee, Fresh coffee, Soup, sauce, Fresh coffee, waste milk, tea, cold milk, tea, cold pastry, egg, rice, milk, tea, meat, vegetables...
- Page 21 CHAPTER -7: SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME 3 3 3 3 3 3 3 3 15.b 15.c 15.d 15.a 1- On/Off Button 13- Salt Level Warning Display 2- Door Handle 14- Rinse Aid Level Warning Display 3- Start/Standby button 15- Program Phases Follow-up Display a-Washing 4- Half Load Button Phase Symbol...
- Page 22 CHAPTER -7: SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Power On/Off Button (1) When you press the on/off button, the machine is turned on and the display shows the last used program; in the off position, the LEDs on the display are off. Door Handle (2) Please use the door handle to open-close the door of your machine.
- Page 23 CHAPTER -7: SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Starting the Machine 1. Press Power On/Off switch. 1 2. Select the appropriate program for your dishes using the Program Button. 5 3. If you prefer, you can select additional functions. 4 6 7 9 4.
- Page 24 CHANGING A PROGRAMME WITH RESETTING Program Change If you want to change the program while another one is proceeding; Press on Start/Standby button. 3 • Select the new program using Program button. 5 • The newly selected program continues from where the previous one was left. •...
- Page 25 CHAPTER -8: MAINTENANCE AND CLEANING Cleaning the machine regularly prolongs the machine’s service life. Oil and limescale may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, run the machine at high temperature.
- Page 26 If the lamps “Wash/Dry” and “End” keep flashing • The water overflow alarm is active • Turn off your tap and contact the Sharp helpdesk. If the control lamps won’t go out after a wash operation Check if the Power On/Off button is released.
- Page 27 CHAPTER -10: PRACTICAL AND USEFUL INFORMATION If there are whitish stains on the dishes • insufficient detergent is being used • Rinse aid dosage setting at a very low level. • No special salt is being used despite the high degree of water hardness. •...
- Page 28 DISPOSAL OF YOUR OLD MACHINE This symbol on the product or package implies that the product should not be treated as domestic waste. Instead, it should be delivered to waste collection places recycling electrical and electronic equipment. You will help avoid damage to the environment and risks to public health. Recycling materials will help natural resources to be preserved.
- Page 29 Register your product here WWW.SHARPHOMEAPPLIANCES.COM, by registering with Sharp you become part of our For Life promise to always be there for you and your appliance. Visit our website: www.sharphomeappliances.com Or contact us: Service & Support %100 recycleable paper 52204444 R23...
