Page 2
Contents Page 1. Safety Instructions 2. Features 3. Specifications 4. Construction 5. Optional parts 10-11 6. Applicable S coupler (socket) 7. How to mount an extension nozzle to the blow gun (VMG series)
Page 3
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
Page 4
Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
Page 5
Selection ! Warning 1. Check the specifications. The product is designed for use only in compressed air systems. Do not operate at pressures or temperatures, etc., beyond the range of specifications, as this can cause damage or malfunction. ! Caution 1.
Page 6
3. Sealant tape When screwing piping or fittings into ports, ensure that Wrap this way. chips from the pipe threads or sealing material do not enter the blow gun. If sealant tape is used, leave 1.5 to 2 thread sealant tape ridges exposed at the end of the threads.
Page 7
2. Take appropriate measures to ensure air quality, such as by providing an aftercooler, air dryer, or water separator. Compressed air containing a lot of contaminants may cause operation failure of the blow gun or contamination/damage of the object to be blown. Therefore, take appropriate measures to ensure air quality, such as by providing an after cooler, water separator.
Page 8
6. If product is to be used in a public place, ensure product is not directed at people or used in a manner that could adversely affect the environment. 7. This product is not a toy. hook 8. After blowing, be sure to hang the product on a hook, etc. If leaving the product in a dusty place, particles will enter the product and may result in malfunction.
Page 9
2. Features 1. Constant operational force irrespective of supply pressure Due to the balanced design of the product, the operating force will not be affected by changes in the supply pressure. For example, when it is used in the production and work lines using different pressure from each other in a factory, it can provide the same operational force.
Page 10
4. Construction Grease is applied to the rubber parts and the sliding parts.
Page 11
5. Optional parts Nozzle with male thread/ KN Model Nozzle size KN-R02-100 ø1 KN-R02-150 ø1.5 KN-R02-200 ø2 KN-R02-250 ø2.5 VMG1-R02-300 ø3 VMG1-R02-350 ø3.5 VMG1-R02-400 ø4 High efficiency type nozzle/ KNH Model Nozzle size KNH-R02-100 ø1 KNH-R02-150 ø1.5 KNH-R02-200 ø2 Low noise type nozzle with male thread/ KNS Model Nozzle size KNS-R02-075-4...
Page 12
Nozzle cover with male thread Applicable Model Material Nozzle type VMG model Nozzle with P5670129-01 HNBR VMG1**-*-01 male thread to 04 P5670129-01F Fluororubber ø1 to ø2.5 Nozzle with P5670129-02 HNBR VMG1**-*-05 male thread to 07 P5670129-02F Fluororubber ø3 to ø4 Extended copper nozzle cover Applicable Model...
Page 13
7.How to mount an extended nozzle to the blow gun (VMG Series) 1. Check that the ferrule is mounted Extended nozzle ● inside the fitting as shown in figure on Ferrule Nozzle nut the right. Hand-tighten the nozzle nut. ● Body Ensure ferrule is aligned properly.
Page 14
Revision history A: Models added, Changes in the descriptions shown in "How to mount an extended nozzle to the Blow-Gun (Series VMG)", changes the torque. B: Safety Instructions added. C: Safety Instructions changed. Extended copper nozzle set corrected on page 10. 2023.12 D: Updated formats.
