Summary of Contents for SMC Networks VMG
- Page 1 Document No. VM-OMK0034-C PRODUCT NAME BLOW GUN MODEL/ Series/ Product Number...
-
Page 2: Table Of Contents
Contents Page 1. Safety Instructions 2. Features 3. Specifications 4. Construction 5. Optional parts 10-11 6. Applicable S coupler (socket) 7. How to mount an extension nozzle to the blow gun (VMG series) -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing business. Use in non-manufacturing business is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 8 to 12 N・m Nozzle tightening torque range Insufficient tightening may cause nozzle loosening. 4. When mounting the copper extension nozzle, follow the instructions "How to mount an extension nozzle to the blow gun (VMG series)" on page 12. Piping Caution ！...
- Page 6 3. Sealant tape When screwing piping or fittings into ports, ensure that Wrap this way. chips from the pipe threads or sealing material do not enter the blow gun. If sealant tape is used, leave 1.5 to 2 thread sealant tape ridges exposed at the end of the threads.
- Page 7 2. Take appropriate measures to ensure air quality, such as by providing an aftercooler, air dryer, or water separator. Compressed air containing a lot of contaminants may cause operation failure of the blow gun or contamination/damage of the object to be blown. Therefore, take appropriate measures to ensure air quality, such as by providing an after cooler, water separator.
- Page 8 6. If product is to be used in a public place, ensure product is not directed at people or used in a manner that could adversely affect the environment. 7. This product is not a toy. hook 8. After blowing, be sure to hang the product on a hook, etc. If leaving the product in a dusty place, particles will enter the product and may result in malfunction.
-
Page 9: Features
2. Features 1. Constant operational force irrespective of supply pressure Due to the balanced design of the product, the operating force will not be affected by changes in the supply pressure. For example, when it is used in the production and work lines using different pressure from each other in a factory, it can provide the same operational force. -
Page 10: Construction
4. Construction Components Description Material Remarks Body L Body R Main valve Valve guide Nozzle holder Aluminum alloy Anodized Port Aluminum alloy Anodized Elbow Used only for VMG12* Cover Stainless steel Ring Stainless steel 10 Arm 11 Spring Stainless steel 12 Main valve seal HNBR 13 Lever... -
Page 11: Optional Parts
VMG1-08-300-600 ø3 VMG1-08-350-600 ø3.5 Note) The extended copper nozzle and the self-align fitting are shipped together without being assembled. Refer to "How to mount an extension nozzle to the blow gun (VMG series)" on page 12 for the assembly instructions. -
Page 12: Applicable S Coupler (Socket)
Nozzle cover with male thread Applicable Model Material Nozzle type VMG model Nozzle with P5670129-01 HNBR VMG1**-*-01 male thread to 04 P5670129-01F Fluororubber ø1 to ø2.5 Nozzle with P5670129-02 HNBR VMG1**-*-05 male thread to 07 P5670129-02F Fluororubber ø3 to ø4... -
Page 13: How To Mount An Extension Nozzle To The Blow Gun (Vmg Series)
7.How to mount an extended nozzle to the blow gun (VMG Series) 1. Check that the ferrule is mounted Extended nozzle ● inside the fitting as shown in figure on Ferrule Nozzle nut the right. Hand-tighten the nozzle nut. ●... - Page 14 Revision history A: Models added, Changes in the descriptions shown in "How to mount an extended nozzle to the Blow-Gun (Series VMG)", changes the torque. B: Safety Instructions added. C: Safety Instructions changed. Extended copper nozzle set corrected on page 10.
