SMC Networks PSE-ST Series Operation Manual

Sensor set up tool
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
No.DOC1107270
PRODUCT NAME
PSE Sensor Set Up Tool
MODEL / Series / Product Number
PSE-ST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSE-ST Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks PSE-ST Series

Summary of Contents for SMC Networks PSE-ST Series

  • Page 1 No.DOC1107270 PRODUCT NAME PSE Sensor Set Up Tool MODEL / Series / Product Number PSE-ST...

  • Page 2: Table Of Contents

    Table of Contents Safety Instructions Model Indication and How to Order Summary of Product parts Definition and terminology Wiring Outline of Settings 3 Step Setting Mode All Settings Reference Mode All settings reference mode Function Selection Mode Function selection mode Default setting F 0 Display unit, switch output specification switching function F 1 Setting of OUT1...

  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.

  • Page 4: Limited Warranty And Disclaimer/Compliance Requirements

    Safety Instructions Caution SMC develops, designs, and manufactures products to be used for automatic control equipment, and provides them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not allowed. Products SMC manufactures and sells cannot be used for the purpose of transactions or certification specified in the Measurement Act of each country.
  • Page 5 Operator This operation manual is intended for those who have knowledge of machinery using pneumatic equipment, and have sufficient knowledge of assembly, operation and maintenance of such equipment. Only those persons are allowed to perform assembly, operation and maintenance. Read and understand this operation manual carefully before assembling, operating or providing maintenance to the product.
  • Page 6 Caution ■Do not touch the terminals and connectors while the power is on. Otherwise electric shock, malfunction or damage to the product can result. ■After maintenance is complete, perform appropriate functional inspections and leak tests. Stop operation if the equipment does not function properly or there is a leakage of fluid. When leakage occurs from parts other than the piping, the product might be faulty.
  • Page 7 ●Product handling Handling •Do not pull the lead wire forcefully. Do not lift or carry the product by pulling on the lead wire. (Tensile strength: 35 N maximum for products with a connector conversion). Hold the product by the body when handling. Otherwise damage to the internal parts can result, causing malfunction or for the connector to be disconnected.
  • Page 8 Adjustment and Operation •Turn on the power switch after connecting the pressure sensor. •Do not short circuit the pressure sensor. If the output of the pressure sensor is short-circuited, an error will be displayed, but there is a possibility that an overcurrent will flow and the product will be damaged.

  • Page 9: Model Indication And How To Order

    Model Indication and How to Order No.DOC1107270...

  • Page 10: Summary Of Product Parts

    Summary of Product parts ○Names of individual parts Operation light: Displays the switch operating condition. LCD display: Displays the current status of pressure, setting mode, selected display units and error code. The main display is normally a solid green colour, but when there is an error, it will turn red. The indication for the sub display is orange.

  • Page 11: Definition And Terminology

    ■Definition and terminology Term Definition The problem of the switch output turning ON and OFF repeatedly around the Chattering set value at high frequency due to the effect of pulsation. Copy function A function to copy a pressure setting value and function setting. The setting time from when the signal of the connected pressure sensor Delay time reaches the set value, to when the ON-OFF output actually begins working.
  • Page 12 Term Definition Abbreviation of full span and full scale; difference between the minimum and maximum rated pressure values. means the maximum fluctuation range of F.S. the product rated value. (full span/full scale) For example, when the rated pressure range is -0.100 to 1.000 [MPa]: F.S.
  • Page 13 Term Definition The pressure range within which the product will meet all published specifications. Rated pressure range Values outside of this range can be set as long as they are within the set pressure range, but the specifications cannot be guaranteed. Current read value For example, when the display value is 1.000[MPa], 5%R.D.

  • Page 14: Wiring

    Wiring ○Wiring connections ●Connections should be made with the power supply turned off. ●Use a separate route for the product wiring and any power or high voltage wiring. Otherwise, malfunction may result due to noise. ○How to use the connector Connector conversion parts attachment/detachment ●When connecting the connector conversion parts, insert it straight onto the pins, holding the lever and connector body, and lock the connector by pushing the lever hook into the concave groove on the housing.

  • Page 15: Internal Circuit And Wiring Example

    •M12-4pin connector Wiring Description Connector pin number Wire colour M12 Connector pin number Blue DC(-) N.C. N.C. Black OUT1 Brown DC(+) ○Internal circuit and wiring example -15- No.DOC1107270...

  • Page 16: Outline Of Settings

    Outline of Settings Power is supplied The product code is displayed for approximately 1 sec. after supplying power. After that, measurement mode is displayed. [Measurement mode] Detects the pressure after power is supplied, and indicates the display and switch operating status. This is the basic mode;...
  • Page 17 When [modE] is displayed, mode selection is possible by releasing the SET button. [Mode selection] Select the mode for this product Display Display Display [rEAd onLy] and [rEAd Writ] and [LoC Ator] and press the SET press the SET press the SET button.

  • Page 18: Step Setting Mode

    3 Step Setting Mode 3 step setting mode In this mode, the set values can be input in just 3 steps. Use this mode if the product is to be used straight away, after changing only the set values. (The current pressure value is displayed on the main display.) <Operation>...
  • Page 19 •When the UP and DOWN buttons are pressed and held simultaneously for 1 second or longer, the set value is displayed as [- - -], and the set value will be the same as the current pressure value automatically (snap shot function (Refer to page 39)). Afterwards, it is possible to adjust the value by pressing the UP or DOWN button.

  • Page 20: All Settings Reference Mode

    All Settings Reference Mode ■All settings reference mode In mode selection, when [rEAd onLy] is displayed, press the SET button to display [F 0]. [F□□] displays the mode for displaying the parameters set for each function. The settings cannot be changed. The following parameters can be confirmed.

  • Page 21: Function Selection Mode

    Function Selection Mode ■Function selection mode In mode selection, When [rEAd Writ] is displayed, press the SET button to display [F 0]. Select to display the function to be changed [F□□]. Press and hold the SET button for 2 seconds or longer in function selection mode to return to measurement mode.

  • Page 22: F 0 Display Unit, Switch Output Specification Switching Function

    ■[F 0] Display unit, switch output specification switching function ●Available display unit and minimum set value Pressure range Rated pressure Applicable sensor Negative pressure -101 kPa PSE541 0.001 PSE543 Compound pressure ±100 kPa 0.001 PSE573 PSE574 500 kPa 0.001 Positive pressure PSE540 1 MPa 0.001...

  • Page 23: F 1 Setting Of Out1

    ■[F 1] Setting of OUT1 Set the output mode of OUT1. Output turns on when the pressure is greater than the set value. Please refer to the "List of output modes" on page for the relationship between the set items and operation. <Operation>...
  • Page 24 Pressure setting Set the pressure based on the setting method on page 18. Hysteresis mode: [P_1] Window comparator mode: [P1L] [P1H] "P" is changed to "n" as [P_1] → [n_1] when reversed output is selected. The snap shot function can be used. (Refer to page 39) Press the SET button to set.
  • Page 25 Reversed output setting Press the UP or DOWN button to select the reversed output. Return to function selection Press the SET button to set. mode. [F 1] Setting of OUT1 completed 1: Selected item becomes valid after pressing the SET button. 2: After enabling the setting by pressing the SET button, it is possible to return to the measurement mode by keeping pressing the SET button for 2 seconds or longer.
  • Page 26 ●List of output modes If the point at which the switch output changes is outside of the set pressure range due to the selection of normal or reversed output, the hysteresis value is automatically adjusted. 1: For the error codes, please refer to the "Device Status Parameters" listed in the operation manual for the connected pressure sensor. : The figure above shows an operation at OUT 1.

  • Page 27: F 2 Setting Of Out2

    ■[F 2] Setting of OUT2 Set the output mode of OUT2. Output turns on when the pressure is greater than the set value. Please refer to the "List of output modes" on page for the relationship between the set items and operation. <Operation>...
  • Page 28 Pressure setting Set the pressure based on the setting method on page 18. Hysteresis mode: [P_2] Window comparator mode: [P2L] [P2H] "P" is changed to "n" as [P_2] → [n_2] when reversed output is selected. The snap shot function can be used. (Refer to page 39) Press the SET button to set.
  • Page 29 Reversed output setting Press the UP or DOWN button to select the reversed output. Return to function selection Press the SET button to set. mode. [F 2] Setting of OUT2 completed 1: Selected item becomes valid after pressing the SET button. 2: After enabling the setting by pressing the SET button, it is possible to return to the measurement mode by keeping pressing the SET button for 2 seconds or longer.

  • Page 30: F 3 Digital Filter Setting

    ■[F 3] Digital filter setting The digital filter can be selected to filter the pressure measurement. Output chattering or flicker in the measurement mode display can be reduced by setting the digital filter. The Digital filter can be set in 0.01 sec. increments in the range of 0.00 to 30.00 sec. <Operation>...

  • Page 31: F 6 Fine Adjustment Of Measurement Value

    ■[F 6] Fine adjustment of measurement value This function is used to manually perform a fine adjustment of the pressure measurement value. Pressure can be adjusted in the range of 5% R.D. <Operation> Press the UP or DOWN button in function selection mode to display [F 6]. Press the SET button.

  • Page 32: F14 Zero Cut-Off Setting

    ■[F14] Zero cut-off setting When the pressure display value is close to zero, the product rounds the value and zero will be displayed. The zero cut-off range is 0.0 to 10.0% F.S., and can be set in 0.1% F.S. increments. This setting will also be reflected in the output.

  • Page 33: F94 Other Function Settings

    ■[F94] Other function settings The power saving function and operation light target can be selected. Power saving function: If the button is not operated for 10 minutes, this product will switch to a mode that reduces power consumption. Operation light target selection: When setting PSE54#-L, the OUT2 operation light can be linked to the process data.

  • Page 34: F96 Measurement Process Data Display, Sw Output Point Display

    ■[F96] Measurement process data display, SW output point display •Display the current process data of the connected sensor. •Display the number of output points of the connected sensor. <Operation> Press the UP or DOWN button in function selection mode to display [F96]. Move on to measurement process data display.

  • Page 35: F97 Selection Of Copy Function

    ■[F97] Selection of copy function The set values of a sensor can be copied. Copy is possible when the pressure range and output specifications are the same. <Operation> In this section, the pressure sensor that is the source of the copy is referred to as pressure sensor (A), and the pressure sensor that is the destination of the copy is referred to as pressure sensor (B) and (C).
  • Page 36 Copy pressure sensor (B) Copy the settings of settings by changing them To end copy ready pressure sensor (A) to to the pressure sensor (C) status pressure sensor (C) settings Remove pressure sensor Press the SET button to Turn the power (B) and connect pressure return to measurement switch off.

  • Page 37: F99 Reset To Initial Settings

    ■[F99] Reset to initial settings If the pressure sensor settings are uncertain, the initial values can be restored. If the output specification of the pressure sensor is switch output, please note that changing the set value will result in operation that differs from the set value indicated on the nameplate of the pressure sensor. <Operation>...

  • Page 38: Locator Mode

    Locator Mode ■Locator mode This is the mode for setting the start and end of the locator function. Press and hold the SET button for 2 seconds or longer in locator mode to return to measurement mode. ○Locator function The locator function can be used to make the operation indicator light of the connected pressure sensor to flash (for 10 minutes).

  • Page 39: Other Settings

    Other Settings ○Snap shot function The current pressure value can be stored to the switch output ON/OFF set point. When the items of the sub display (left) are selected in 3 step setting mode or function selection mode, ([F 1] Setting of OUT1, [F 2] Setting of OUT2), by pressing the UP and DOWN buttons simultaneously for 1 second or longer, the value of the sub display (right) indicates [- - -], and the values corresponding to the current pressure values are automatically displayed.

  • Page 40: Troubleshooting

    Troubleshooting ○Troubleshooting When any failure occurs with this product, the following chart can be used to identify the cause of the failure. If a cause applicable to the troubles cannot be identified and normal operation is recovered by replacement with a new product, this indicates that the product itself was faulty. Problems with the product may be due to the operating environment (installation etc).
  • Page 41 The display is Refer to Problem No.7 Displayed value is not unstable. correct Refer to Problem No.9 The display turns OFF. Refer to Problem No.9 The display is missing. Refer to Problem No.10 Display flashes. Applied voltage does Refer to Problem No.8 not match with the displayed pressure value.

  • Page 42: Troubleshooting List

    ○Troubleshooting list Problem Problem possible Problem Investigation method Countermeasures causes •The pressure (1) Check the set pressure value. sensor output (2) Check the settings of the (1) Adjust the set pressure stays ON. comparator output, hysteresis and value. The operation Incorrect output type.
  • Page 43 Problem Problem possible Problem Investigation method Countermeasures causes (1) Check if the output current is 80 (1)(2) Connect the mA or more. Excess current appropriate load. (2) Check if the connected load was applied to (3) Use a relay with a surge complies with the specification.
  • Page 44 Problem Problem possible Problem Investigation method Countermeasures causes Applied voltage Check the pressure range setting. Incorrect does not match Check if the connected pressure Select the correct pressure pressure range with the displayed sensor and the set pressure range range. setting pressure value.
  • Page 45 ○Error indication function This function is to display the error location and content when a problem or error has occurred. Error Error displayed Description Countermeasures Over current Turn the power off and remove The switch output load current is 80 mA error the cause of the over current.

  • Page 46: Specifications

    Specifications Product No. PSE-ST series PSE543- PSE540- PSE541- PSE574- PSE575- PSE576- PSE577- Applicable pressure sensor PSE573- PSE570- 0 to -100 to 0 to 0 to 0 to 0 to 0 to Rated pressure range -101 kPa 100 kPa 500 kPa...

  • Page 47: Dimensions

    ■Dimensions ○Body •PSE-ST -47- No.DOC1107270...
  • Page 48 ○Connector conversion parts (Part No: D-LH03B) Conductor area 0.15 mm (AWG26) Outside diameter 1.0 mm Insulator Colour Brown, Blue, Black (3 core) 3.4 Sheath Outside diameter ○Connector conversion parts (Part No: D-LH03C) Conductor area 0.15 mm (AWG26) Outside diameter 1.0 mm Insulator Colour Brown, Blue, Black (3 core)
  • Page 49 Revision history Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved No.DOC1107270...
