2024-12-16 05:02
1/14
Victron & Freedom Won LiFePO4 batteries -
Freedom Lite
Installers Note
Important: It is very important to read this documentation in full and carefully. Freedom Won battery
warranties require that you have configured the battery correctly.
Please take special and careful note of the section below on "DC bus pre-charging".
Introduction
Freedom Won (www.freedomwon.co.za) produces two ranges of LiFePO4 batteries for 48V systems:
Freedom Lite Home and Business: Eight models available ranging from the smallest 5kWh
model (Freedom Lite Home 5/4) up to the 80kWh model (Freedom Lite Business 80/56)
Freedom Lite Commercial: Ten models available ranging from the 100kWh model (Freedom Lite
Commercial 100/70) up to the 700kWh model (Freedom Lite Commercial 700/490).
Note: Refer to Freedom Won website for detailed specification sheets covering all models
These Freedom Lite batteries are fully compatible with the Victron MultiPlus, MultiPlus II, MultiPlus II
GX, and Quattro inverter/chargers, Solar charge controllers (VE.Direct and VE.CAN), and
controllers (Color Control
The Freedom Lite batteries contain an advanced battery management system (BMS) that
communicates via a CAN Bus protocol with the Victron GX device. The GX device in turn connects and
manages the other compatible devices in the system.
All Freedom Lite models can be connected in parallel with other models of the same capacity, where
one Lite (Master) communicates with the GX device as well as all the other Lite's in the system
(Slaves). The Victron and Freedom Won integration has been extensively developed and tested and is
certified and supported by both companies.
The system is suitable for all applications, namely:
Grid Connected with solar and storage including continued operation in grid outage
consumption mode)
Backup storage or UPS mode
Off Grid plant with storage and solar
Figure 1 Typical Installation: Freedom Lite 60/42 with Victron 15kVA Quattro and 3x Ve Direct MPPT's
Victron Energy - https://www.victronenergy.com/live/
GX, Venus GX, Octo GX,
Victron & Freedom Won LiFePO4 Batteries - Freedom Won LiTE and eTower
Cerbo
GX, CANvu GX, Maxi GX).
system
(ESS
or self-

Advertisement

loading
Need help?

Need help?

Do you have a question about the Lite Business 80/56 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Freedom Won Lite Business 80/56

Summary of Contents for Freedom Won Lite Business 80/56

  • Page 1 Freedom Lite Installers Note Important: It is very important to read this documentation in full and carefully. Freedom Won battery warranties require that you have configured the battery correctly. Please take special and careful note of the section below on “DC bus pre-charging”.
  • Page 2 Last update: 2020-08-02 battery_compatibility:freedomwon https://www.victronenergy.com/live/battery_compatibility:freedomwon?rev=1596401700 22:55 Figure 2 Typical Installation: 7 x Freedom Lite Commercial 200/140 with Victron 12 x 15kVA Quattro and 10 x Ve Direct MPPT’s and 6 x Fronius ECO 27kW https://www.victronenergy.com/live/ Printed on 2024-12-16 05:02...
  • Page 3 2024-12-16 05:02 3/14 Victron & Freedom Won LiFePO4 Batteries - Freedom Won LiTE and eTower This Manual This manual is intended to offer Victron specific guidance when designing, installing, and commissioning a Victron – Freedom Lite system. For further details pertaining to the setup of the Victron equipment not pertaining directly to the Freedom Lite interface please refer to the various manuals available on the Victron Energy website eg.
  • Page 4 55.0V and 55.8V. This advanced feature is only available from Freedom Won and allows superior system control and optimal battery management. The GX-device uses this set-point to control the real time operating or target voltage of the inverter/charger devices and the MPPTs.
  • Page 5 The inrush current when switching on the battery breaker onto the DC bus is huge. This can cause damage to the breaker over time. So it is a Freedom Won requirement that the DC bus is pre-charged before switching on the battery. This is achieved by switch on the AC input to the inverters – the inverters will use the AC power to pre-charge their capacitors.
  • Page 6 CAN Bus from the devices on Victron's VE.CAN bus. The Color Control GX has a single CAN bus and thus this split cannot be achieved. Therefore, CCGX cannot be used in systems with multiple Freedom Won batteries. In such cases, MPPTs must be swapped out for VE.Direct versions and additional ports can be provided with a USB hub (See “Extending USB ports by...
  • Page 7 2024-12-16 05:02 7/14 Victron & Freedom Won LiFePO4 Batteries - Freedom Won LiTE and eTower ☛ Set the Low Shut-Down, Low Restart, and Low Pre-alarm voltages. The Low Pre-alarm only activates the low battery LED on the inverter and serves no other purpose in this setup. The Low Shut Down and Low Restart voltage settings are usually overridden by the commands from the Lite but offer...
  • Page 8 Lite. Note: only adjust these values after selecting Lithium battery as the defaults entered by VE.Configure when selecting the Lithium battery type are not suitable to Freedom Won batteries. https://www.victronenergy.com/live/...
  • Page 9 2024-12-16 05:02 9/14 Victron & Freedom Won LiFePO4 Batteries - Freedom Won LiTE and eTower ✔️ Lithium batteries Absorption voltage: 55.80 V Float voltage : 55.80 V Absorption time : 1 Hr ☛ When setting up the ESS Assistant select LiFePO4 battery and enter the Ah value for the Lite (or the combination of Lite’s for a parallel battery system) as per the Ah rating provided in the Lite...
  • Page 10 Last update: 2020-08-02 battery_compatibility:freedomwon https://www.victronenergy.com/live/battery_compatibility:freedomwon?rev=1596401700 22:55 ☛ Select – Do not change battery type ☛Sustain Voltage = 50V https://www.victronenergy.com/live/ Printed on 2024-12-16 05:02...
  • Page 11 2024-12-16 05:02 11/14 Victron & Freedom Won LiFePO4 Batteries - Freedom Won LiTE and eTower  ☛ Enter Dynamic Cut-off values as below (usually the Lite will override these values, however they should be entered correctly for redundancy) ☛ Restart Offset = 2.0V...
  • Page 12 ☛ Settings → Services → CAN-bus Profile → CAN-bus BMS (500kbit/s) Note: For systems with VE Can MPPT’s, select 250kbit/s and ensure Lite profile is also set for 250kbit/s (check with Freedom Won or your Freedom Won distributor). https://www.victronenergy.com/live/ Printed on 2024-12-16 05:02...
  • Page 13 2024-12-16 05:02 13/14 Victron & Freedom Won LiFePO4 Batteries - Freedom Won LiTE and eTower ☛ Confirm that the Freedom Lite is showing in the device list as per below ☛ Settings → System Setup → Switch on DVCC and SVS, check that BMS Control is “On”...
  • Page 14 Last update: 2020-08-02 battery_compatibility:freedomwon https://www.victronenergy.com/live/battery_compatibility:freedomwon?rev=1596401700 22:55 disabled. In order to do this on the Ve CAN MPPT’s select the User Defined option 8 battery type as this allows adjustment of the charge voltage setpoints. Adjust the maximum current on the MPPT’s to ensure that the combined total charge power cannot exceed the maximum rated charge current for the Lite or Lite’s in the system.
