Installation and User's Manual
12V LiFePO4 Battery Range
Manufactured By Freedom Won (Pty) Ltd
Kimbult Industrial Park, Unit C3 & C4
9 Zeiss Road
Laser Park, Honeydew
2040
South Africa
www.freedomwon.co.za
Technical and Installation Assistance – Contact:
Please contact your Freedom Won Distributor or Reseller Installer for technical and installation
support. A directory of Distributors and Reseller Installers is available at www.freedomwon.co.za.
Revision 2 – 15 September 2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Freedom Won 12V General Purpose
Summary of Contents for Freedom Won 12V General Purpose
- Page 1 South Africa www.freedomwon.co.za Technical and Installation Assistance – Contact: Please contact your Freedom Won Distributor or Reseller Installer for technical and installation support. A directory of Distributors and Reseller Installers is available at www.freedomwon.co.za. Revision 2 – 15 September 2021...
-
Page 2: Product Description
8. Lite Commercial HV and HV+ 9. Lite Industrial HV and HV+ This manual covers the 12V General Purpose range. Please refer to the manuals specific to the other ranges where required. The Freedom Won 12V General Purpose batteries are available in various standard sizes to meet most 12V applications, ranging from 7.5Ah up to 200Ah. - Page 3 12V Installation Manual Revision 1 Figure 2.1 Image of the Freedom Won 12V General Purpose range All models operate at a nominal voltage of 12,8V, which suits the most commonly available residential battery inverters and is also matched to vehicle 12V alternators.
-
Page 4: Packaging And Transport
12V Installation Manual Revision 1 Table 2.1 Freedom Won 12V General Purpose Range Model FW-12-7.5 FW-12-10 FW-12-20 FW-12-40 FW-12-100 FW-12-200 Max Energy [Wh] 1280 2560 Current Capacity [Ah] Standard Charge Current [A] Max Charge Current [A] Max Pulse Discharge 15A (<3s) 20A (<3s) -
Page 5: Operating Configuration
Connection Size [mm^2] Operating Configuration The Freedom Won 12V General Purpose battery range is primarily intended for use in a standalone configuration only i.e. where only one battery is connected in any one system. However parallel and series operation is permissible. -
Page 6: Connected Equipment
Figure 5.1 Example of Victron Battery Balancer Configuration Connected Equipment The 12V General Purpose battery range is protected internally using solid state electronics. These electronics will not resist extreme operation or abuse outside of the limits given in this document. It is thus important to connect these batteries to suitable equpment. The... -
Page 7: Application Notes
Operating Environment and Orientation The 12V General Purpose batteries are suitable for use in the following environments: 1. Vibration – vibration experienced on vehicles driving on poor dirt roads will not damage the battery provided it is securely fastened to the vehicle. -
Page 8: Long Term Storage
Fitment of the battery in an upside-down position is not recommended. Long Term Storage The Freedom Won 12V batteries should be charged to 14,2V before being placed in storage. They should be discharged to 11.5V and recharged to 14,2V every 6-12 months or if the voltage drops below 12V. - Page 9 Requirements to be specified with order. 10. Warranty For the detailed warranty information please refer to the separate Freedom Won 12V LiFePO4 battery warranty document. In summary, the 12V batteries are guaranteed for 5 years of unlimited cycles provided that the battery is operated within the specifications and guidelines provided in this manual.
