Owner's Manual
Home Series
1330 Pigeon Rd
Bad Axe, MI 48413
Toll Free: 866-712-0606
Fax: 989-269-5902
www.globalpool-products.com
Page | 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Home Series and is the answer not in the manual?

Questions and answers

Summary of Contents for global lift corp Home Series

  • Page 1 GLOBAL POOL PRODUCTS Owner’s Manual Home Series 1330 Pigeon Rd Bad Axe, MI 48413 Toll Free: 866-712-0606 Fax: 989-269-5902 www.globalpool-products.com Page | 1...
  • Page 2 HOME SERIES POOL LIFTS TABLE OF CONTENTS INTRODUCTION PAGE – 3 ADA GUIDELINES FOR PLACEMENT PAGE – 4 24 VOLT BATTERY SYSTEM/WITH CONTROLS PAGE – 5 HOME SERIES OPERATING INSTRUCTIONS PAGE – 6 UNIT MAINTENANCE AND CARE PAGE – 7 TROUBLESHOOTING PAGE –...
  • Page 3 INTRODUCTION Your Number One Choice for Commercial Pool Access Equipment Global Pool Products is located in Mid-Michigan, Global Pool Products prides itself in manufacturing top of line quality aquatic access equipment. Global Pool Products’s key staff has a century of combined industry experience and we take pride in each and every product that we build.
  • Page 4 ADA GUIDELINES FOR POOL LIFT PLACEMENT 1. Pool Lift Location. Pool lifts shall be located where the water level does not exceed 48 inches (1220 mm). 2. Seat Location. In the raised position, the centerline of the seat shall be located over the deck and 16 inches (405 mm) minimum from the edge of the pool.
  • Page 5 24 VOLT BATTERY SYSTEMS WITH CONTROLS All of Global Pool Products's Home Series Lifts are equipped with a sealed 24 volt battery that is rechargeable. Along with a charging unit, hand held controller and control compartment. The 24 volt battery mounts right in the control compartment and the battery simply snaps in.
  • Page 6 Prior to using the Home Series Pool Lift perform a test run of the lift empty. Once that is completed and the lift is back to original position, make sure that the arm lifts are in...
  • Page 7: Maintenance

    Maintenance Regular servicing will help prolong the life of your lift. Routine maintenance and cleaning is very important. The following is a routine maintenance you should follow. Daily Check and charge battery if needed Test for normal operations Inspect your lift Clean and dry the lift and seat with clean water Cover lift after use Weekly...
  • Page 8: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Before any troubleshooting commences make sure the battery has a full charge! (1) Does the lift raise or lower (a) Check the battery connection and reconnect (b) Insure the emergency stop red button is turned clockwise in the up position (c) Check hand controls, make sure it is connected properly and fully seated in the far right connection port...
  • Page 9 Global Pool Produc Warranty Information The Home series lift has a 2 year structural limited warranty. Global Pool Products warrants to the retail end user only products manufactured by Global Pool Products, when properly installed in accordance to the assembly and installation instructions, and when the equipment is properly used and...
  • Page 10 To commence the warranty claim process of a Global Pool Products product, in writing provide place of purchase along with the product name and description, date of installation, and a detailed description of the defect, along with a photo of the entire product and claimed defect. Prior to a 30 day period after receiving the written warranty claim by Global Pool Products and barring any unforeseen delays, the claimant will be notified of Global Pool Products’s decision regarding the claim.
  • Page 11 Warranty Procedure Warranty Claims shall be submitted to Global Pool Products by the distributor which originated the sale with Global Pool Products or directly to Global Pool Products. All RMA (Return Materials Authorization) documents shall be requested by and issued only to the distributor which originated the sale or directly to Global Pool Products.
  • Page 12 GLOBAL POOL PRODUCTS WARRANTY REGISTRATION PURCHASED BY: Company Name:__________________________________Contact:____________________ City: ______________________________ State: ___________ Zip: ___________ Phone: (_____) ______________________________ DEALER: Name: ____________________________Phone Number ___________________ City: __________________________ State: _______________ Zip: ___________ Phone: (_____) ______________________________ Model: __________________________ Serial Number: ____________________ Color: _______________ Purchase Price: $ _______ Date Purchased: ___________ I have read and I accept the warranty terms.
  • Page 13 Drop in Anchor Home Series Pre-drilled holes on the base of the L-325 Hole for bonding wire and screw to attach bonding wire to base Position the lift in the location to be installed. Locate the 4 pre-drilled holes on the base of the lift.
  • Page 14 HOME SERIES LIFTS TABLE OF CONTENTS 1. 4-Point Anchor System 2. 4-Point Paver Instruction Anchor Method November 2016...
  • Page 15 HOME SERIES LIFTS H-300/350 4-POINT ANCHORING SYSTEM New Construction or Saw Cut INSTALLATION MANUAL Patent Pending November 2016...
  • Page 16: Parts List

    HOME SERIES H-300/350 4-POINT ANCHORING SYSTEM INSTALLATION Patent Pending PARTS LIST 1 - Anchor Plate with bonding Lug & bolt  4 - 5/8” x 1” Stainless Steel Bolts  4 - 6” Anchoring Rods  4 – Plastic Caps ...
  • Page 17 ANCHORING PLATE, ANCHORS & BONDING LUG 5/8” x 1” Bolts November 2016...
  • Page 18 ADA GUIDELINES FOR POOL LIFT PLACEMENT •Pool Lift Location. Pool lifts shall be located where the water level does not exceed 48 inches (1220 mm). Seat Location. In the raised position, the centerline of the seat shall be located over the deck and 16 inches (405 mm) minimum from the edge of the pool.
  • Page 19 HOME SERIES – 4 POINT ANCHORING SYSTEM Water Pool Wall Front of Anchor Plate can be placed 12” to 17” from water’s edge depending on you application 3’ Overview Anchor Plate Section Detail 3’ 3’ 6” Threaded Anchor’s Cold Pin 6”...
  • Page 20 Step 1: Determine the location for installation (Make sure all ADA requirements are met). ***NOTE: The installation of Global Lift Corp’s anchor system’s are a guideline of minimum requirements. In some states or municipalities they may require additional steps due to their local codes or ordinances.*** Step 2: Make sure that all the parts are present (Refer to the parts list) 1 - Anchor Plate with Bonding Lug &...
  • Page 21 Plate is 12” to 17” from the water’s edge and that the decal’s arrow on the anchor plate is pointing to the water’s edge (refer to overview). A key element is to make sure that the Anchor Plate is level and square with the pool so that your Home Series Lift sits properly on the deck.
  • Page 22 GLOBAL LIFT CORP INSTALLATION MANUAL Home Series Lifts...
  • Page 23 Home Series Assembly Steps Main Components – Lift Seat tube 1. Insert the seat tube into the upper hole on the lift, ensuring the tube is inserted into the side with the protruding tube as shown above. 2. The seat tube will have to be cranked in a clockwise direction to thread thru the brass bushings.
  • Page 24 4. Tighten nut until snug against the bushing. Do not over tighten. 5. Locate the seat stabilizer bar, and raise it up and behind the triangle so that the bar is situated in between the triangle, and the main beam. 6. Insert the bolt that is pre-attached, ensuring that the 3 nylon washers are spaced in between the nut, the triangle and bar, and the bolt head.
  • Page 25 GLOBAL POOL PRODUCTS INSTALLATION MANUAL (Footrest Optional) SEAT AND FOOT REST PARTS LIST  1 - Seat  1 - Foot Rest  2 – Arm Rests  1 - Seat Belt & Buckle  3 – 5/16 x 3” Attaching Pin with lock nut ...
  • Page 26: Installation Steps

    INSTALLATION STEPS Picture A Step 1: Unpack your custom seat (picture A). Optional Items will consist of: • Foot Rest and Tube • 3 - 5/16” x 3” Bolt with Lock nut...
  • Page 27 INSTALLATION STEPS Picture A Picture B Step 2: Align your custom seat (Picture A), With 3 pre-drilled holes as shown. Step 3: Once you have the seat in place, take one 5/6” x 3” bolt and slide it through the pre-drilled Holes (Picture B).
  • Page 28 INSTALLATION STEPS Step 4: Locate the other 2- 5/16 x 3” securing bolts (supplied), insert the bolt through the pre-drilled Seat and tube holes (As shown Above). Also insert the bolt in the back of the seat. Once you have the bolts inserted, secure the installation with the lock nuts that are provided and tighten down.
  • Page 29 Slot. In picture B, locate the 5/16” x 2” bolt and insert into the pre-drilled holes to secure the foot rest to the lift. Place the lock nut on the bolt and tighten down. Once that is complete, you are ready to enjoy your Global Lift Corp pool lift.
