Elkay LZ Series Installation & Use Manual

Elkay LZ Series Installation & Use Manual

Bottle filling stations & coolers
Hide thumbs Also See for LZ Series:

Advertisement

Quick Links

Download this manual
ENKLZS8WS_1A
Enhanced
INSTALLATION & USE MANUAL
LZ
Series Bottle Filling Stations & Coolers
™
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
Page 1
2000001774 (Rev. A - 06/24)

Advertisement

loading
Need help?

Need help?

Do you have a question about the LZ Series and is the answer not in the manual?

Questions and answers

Related Manuals for Elkay LZ Series

Summary of Contents for Elkay LZ Series

  • Page 1 Enhanced INSTALLATION & USE MANUAL Series Bottle Filling Stations & Coolers ™ Patent zurn-elkay.com/patents WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov Page 1...
  • Page 2 ENKLZS8WS_1A Fig. 1 2000001774 (Rev. A - 06/24) Page 2...
  • Page 3 ENKLZS8WS_1A HANGER BRACKET INSTALLATION 1) Remove hanger bracket fastened to back of cooler by removing one (1) screw. 2) Mount the hanger bracket as shown in Figure 1 (Pg. 2). NOTE: Hanger Bracket MUST be supported securely. Add fixture support carrier if wall will not provide adequate support. Anchor hanger securely to wall using all six (6) 1/4 in.
  • Page 4 ENKLZS8WS_1A Secure cooler frame to wall by installing (2) screws and washers (not supplied). FIG. 2 FIG. 3 Lay gasket along back of bottle filler mounting plate. Align BF and lay on cooler basin. Fig. 4 Attach the 3/8 water line into the bulkhead fitting. (Gasket removed from bottle filler for clarity) Fig.
  • Page 5 ENKLZS8WS_1A Fig. 7 Connect the bottle filler electrical harness. (Gasket removed from bottle filler for clarity) Fig. 6 MOUNTING BOLT HOLES (6) WALL MOUNTING PLATE BOTTLE FILLING UNIT Fig. 8 Page 5 2000001774 (Rev. A - 06/24)
  • Page 6 ENKLZS8WS_1A 115V Refrigerated Wiring Diagram with Alpha/Numeric Display Enhanced Bottle Filling Station Electrical Diagram LZSTL8WSSP LZSTL8WSSP-PF Fig. 9 WARNING • INGESTION HAZARD: This product contains a button cell or coin battery. • DEATH or serious injury can occur if ingested. •...
  • Page 7 When installing replacement bubbler and pedestal, tighten nut only to hold parts snug in position. Do Not Overtighten. 3/8” Water Inlet Scan for trouble shooting and to sign up for auto replenishment of authentic Elkay filters. Fig. 13 Filter Detail FILTER PARTS LIST ITEM NO. PART NO. DESCRIPTION 51300C Filter Assy - 3000 Gal.
  • Page 8 ENKLZS8WS_1A Service Instructions Lower and Upper Shroud To access the refrigeration system and plumbing connections, remove four screws from bottom of cooler to remove the lower shroud. To remove the upper shroud for access to the pushbars, regulator, solenoid valve or other components located in the top of the unit, remove lower shroud, disconnect drain, remove four screws from tabs along lower edge of upper shroud, unplug two wires and water tube.
  • Page 9 ENKLZS8WS_1A Page 9 2000001774 (Rev. A - 06/24)
  • Page 10 ENKLZS8WS_1A Enhanced EZH2O Error Codes Error Error Description Corrective Action Code Bottle filler area obstructed • Remove obstruction. • Clean lens on IR sensor • Unplug unit for at least 30 seconds and restart • If error repeats, replace IR sensor E013 Missing or Incomplatible Filter •...
  • Page 11 ENKLZS8WS_1A Pictured is unit only without bottle filler. Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Uses HFC-134A refrigerant Filter Location See Fig. 12 12 or 13 See Fig. 14 21, 24 Fig. 15 Page 11 2000001774 (Rev. A - 06/24)
  • Page 12 FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.834.4816 REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640 PRINTED IN U.S.A. ELKAY MANUFACTURING Co • 1333 BUTTERFIELD ROAD SUITE 200. DOWNERS GROVE, IL 60515 USA - 630.574.8484 • www.elkay.com 2000001774 (Rev. A - 06/24) Page 12...
