  • Page 1 EZSDWS*1F EZS8WS*1F, 2F, 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F INSTALLATION, CARE & USE MANUAL Manual de Instalación, Cuidado y Utilización Manuel d’installation/entretien/utilisation EZ & LZ Series Bottle Filling Stations & Coolers EZ & LZ Serie Botella Bombas y Enfriadores EZ &...
  • Page 2 EZSDWS*1F EZS8WS*1F, 2F 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F Pictured is unit only without bottle filler. Uses HFC-134A refrigerant Usa refrigerante HFC-134A Utilise du fluide frigorigéne HFC-134A See Fig. 13 See Fig. 3 Fig. 1 1000001731 (Rev. C - 01/15) Page 2...
  • Page 3 EZSDWS*1F EZS8WS*1F, 2F, 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F Fig. 2 Page 3 1000001731 (Rev. C - 01/15)

  • Page 4: Entretien

    EZSDWS*1F EZS8WS*1F, 2F 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F HANGER BRACKETS & TRAP INSTALACIÓN DE LOS SOPORTES INSTALLATION DES SUPPORTS INSTALLATION FIJADORES Y EL PURGADOR DE SUSPENSION ET DU SIPHON 1) Remove hanger bracket fastened to back of Retire el soporte fijador que se encuentra conectado 1) Retirez le support de suspension fixé...

  • Page 5: Service Instructions

    EZSDWS*1F EZS8WS*1F, 2F, 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F Service Instructions Lower and Upper Shroud To access the refrigeration system and plumbing connections, remove four screws from bottom of cooler to remove the lower shroud. To remove the upper shroud for access to the pushbars, regulator, solenoid valve or other components located in the top of the unit, remove lower shroud, disconnect drain, remove four screws from tabs along lower edge of upper shroud, unplug two wires and water tube.

  • Page 6: Top Cover

    EZSDWS*1F EZS8WS*1F, 2F 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F 7/16” BOLT HOLES FOR MOUNTING FASTENING UNIT TO WALL TOP COVER SCREWS UNIT CENTER LINE Fig. 4 Fig. 5 BRACKET, WASHERS, Fig. 6 Fig. 7 & SCREWS Bottle Filler Installation Instructions 1) Remove two (2) mounting screws with 5/32”...
  • Page 7 EZSDWS*1F EZS8WS*1F, 2F, 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F BF11 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE Continued from below: 1) To verify the software program of the control board the unit will 2) When the display changes to “SETTINGS”, depress the button again. need to be shut down and restarted.

  • Page 8: Wall Mounting Plate

    EZSDWS*1F EZS8WS*1F, 2F 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F OVERLOAD WALL MOUNTING PLATE COLD CONTROL NOISE SUPPRESSOR PURPLE TO BOTTLE FILLER SOLENOID VALVE RELAY Fig. 10 115V Refrigerated Wiring Diagram Diagrama de Cableado Refrigerados de 115 Voltios Schéma Frigorifique de 115 Volts SWITCHES NOISE SUPPRESSOR...
  • Page 9 EZSDWS*1F EZS8WS*1F, 2F, 3F LZSDWS*1F, 2F, 3F LZS8WS*1F, 2F, 3F Basin Estanque Bassin Locknut Tuerca de Fijación Écrou de Blocage BUBBLER DETAIL VANDAL RESISTANT BUBBLER DETAIL DETALLE DEL GRIFO DETALLE DEL GRIFO RESISTENTE AL VANDALISMO DETAIL DU BARBOTEUR DESCRIPTION DU BARBOTEUR RESISTANT AU VANDALISME Fig.
  • Page 10 POUR OBTENIR DES PIÈCES, CONTACTEZ VOTRE DISTRIBUTEUR LOCAL OU COMPOSEZ LE 1.800.834.4816 PRINTED IN U.S.A. IMPRESO EN LOS E.E.U.U. IMPRIMÉ AUX É.-U. ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484 1000001731 (Rev. C - 01/15) Page 10...
