Summary of Contents for Gree GRS-CP11Pd/NhA-S
- Page 1 Owner's Manual Original Instructions Heat Pump Pool Heater Models: GRS-CP11Pd/NhA-S GRS-CP18Pd/NhA-S...
- Page 2 To Users Thank you for selecting Gree product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and...
- Page 3 Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons: (1) Damage the product due to improper use or misuse of the product; (2) Alter, change, maintain or use the product with other equipment without abiding by the instruction manual of manufacturer;...
- Page 4 Contents 1 Safety Notices (Please be Sure to Abide Them) ············ 1 2 Product Introduction ················································· 5 2.1 Working Principle and Characteristics ........5 2.2 Parameters ................6 2.3 Introduction of Components ...........8 2.4 Dimensions ................8 2.5 List of Accessories ..............9 3 Installation ······························································· 9 3.1 Installation Safety Precautions ..........9 3.2 Unit Installation Diagram ............
- Page 5 Heat Pump Pool Heater 1 Safety Notices (Please be Sure to Abide Them) SPECIAL WARNING: Be sure to comply with national gas regulations. Do not pierce or burn. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
- Page 6 Heat Pump Pool Heater PROHIBITED! The unit should be grounded to avoid electric shock. Do not connect the ground wire to gas pipe, water pipe, lightning arrester or telephone wire. It is forbidden to change the power cord, socket or grounding mode without authorization. Please cut off the power supply immediately in case of abnormal conditions (such as burning smell).
- Page 7 Heat Pump Pool Heater WARNING! (12) Be sure to adopt independent power circuit. If the power cord is damaged, it must be repaired by the manufacturer, service agent or other professional agents. (13) The unit can be cleaned only after it is turned off and power-disconnected, otherwise electric shock may occur.
- Page 8 Heat Pump Pool Heater NOTES! Do not put a finger or other objects into the air inlet or air return grill. Please adopt safety protection measures before touching the refrigerant pipe, otherwise your hands may be hurt. Please arrange the drain pipe according to the instruction manual. Never stop the unit by directly cutting off the power.
- Page 9 Heat Pump Pool Heater 2 Product Introduction 2.1 Working Principle and Characteristics The pool heat pump heater is a new, efficient, energy-saving and environmentally friendly product. It uses the principle of heat pump to drive the compressor with electric energy. Through the thermal cycle, the heat absorbed in the air is transferred to the water-side heat exchanger for water supply (hot water), or the heat absorbed by the water-side heat exchanger (cold water) is released into the air through the thermal cycle.
- Page 10 Heat Pump Pool Heater 2.2 Parameters 2.2.1 Heat Pump Technical Data Model GRS-CP11Pd/NhA-S GRS-CP18Pd/NhA-S High-temperature & Heating 2.2~11.8 5.5~18.8 high-humidity heating: capacity ambient temperature: Energy 27°C/80%, 26°C water — 13.0~5.8 11.0~5.2 efficiency inlet Medium-temperature & Heating 2.0~8.8 3.0~15.1 medium-humidity capacity...
- Page 11 Heat Pump Pool Heater NOTES: The above maximum power or maximum current don’t include the power ① or current of external engineering water pump. The noise data is the average sound pressure value measured under high ② temperature and high humidity heating conditions (Dry air 27°C -Relative humidity 80% - Water inlet temperature 26°C) with a distance of 1m away from the unit.
- Page 12 Heat Pump Pool Heater 2.3 Introduction of Components Fig. 2.3-1 Unit components 2.4 Dimensions Fig. 2.4-1 Dimensions...
- Page 13 2(m) Tapping Screw ST2.9(mm)×6.5(mm) Magnetic ring(for GRS-CP11Pd/NhA-S) M93RS 26×14.9×29 Magnetic ring(for GRS-CP18Pd/NhA-S) M93RS 26×14.9×29 High temperature wire tie(for GRS-CP11Pd/NhA-S) 200(mm) High temperature wire tie(for GRS-CP18Pd/NhA-S) 200(mm) Quick connector assembly Chassis rubber plug (for GRS-CP11Pd/NhA-S) Chassis rubber plug (for GRS-CP18Pd/NhA-S) 3 Installation 3.1 Installation Safety Precautions...
- Page 14 Heat Pump Pool Heater For the product to be installed, moved and repaired, please contact the local technical service personnel and seek the support of professional institutions. Otherwise, our company may not be able to assume the relevant legal liability in case of any damage.
- Page 15 Heat Pump Pool Heater shall be full-pole open, with the contact breaking distance of at least 3 mm. (16) According to the relevant laws, regulations and electrical standards, special branch leakage devices shall be installed. (17) The connection method of the unit and the power cord and the interconnection method of each independent component shall be subject to the circuit diagram attached to the unit body.
- Page 16 Heat Pump Pool Heater Unit: mm Fig. 3.3-1 Dimensions of unit installation space 3.4 Unit Installation Requirements (1) Ensure that the sound and air flow of unit operation will not affect others or animals and plants. (2) Ensure that the unit has good ventilation. If a canopy is installed to protect the unit, the heat dissipation and absorption shall not be affected.
- Page 17 Heat Pump Pool Heater (8) If the unit is installed in the designated place with drainage requirements, choose the drain pipe mounting hole as shown in the following figure to clamp into the drainage joint to guide the drainage, other drainage holes are sealed with drain caps.
- Page 18 Heat Pump Pool Heater 3.5.2 Water Supply Pipeline Connection The heat pump unit is equipped with two pipe joints (PVC Ф50mm), which are used to connect the pipeline from the filter pump and the water outlet pipeline, and connect to the circulating hot water system of the swimming pool. To guarantee the safe usage of unit, a reduction valve should be installed in the water inlet pipe if the water inlet pressure exceeds 0.5MPa.
- Page 19 Circuit Breaker Model Power Type ² Capacity (A) Power Cord(mm GRS-CP11Pd/NhA-S 220-240V ~ 50/60Hz GRS-CP18Pd/NhA-S 220-240V ~ 50/60Hz 3.6.1.2 Wiring Diagram The external wiring diagram of the unit is as follows. For the internal wiring diagram, please refer to the circuit diagram attached on the machine.
- Page 20 (Refer to Mark 3 in the figure below). Fig.3.6-3 Installation diagram for power cord with buckle magnetic ring (for GRS-CP11Pd/NhA-S) For GRS-CP18Pd/NhA-S, both the power cord and the water pump power cord should be equipped with magnetic rings. For the installation process, see the third point in Section 3.6.2 for steps to install a magnetic ring on an...
- Page 21 Heat Pump Pool Heater 3.6.3 Engineering Load Installation 3.6.3.1 Water Pump Connection The water supply of the pool machine is realized through the access of the engineering water pump, which can be installed according to the actual engineering needs. This unit provides the power control signal for the engineering water pump. Please connect if needed.
- Page 22 Heat Pump Pool Heater 4.1 Inspection before Commissioning After the heat pump unit, wire controller, water system and electrical wiring have been installed, be sure to check the unit according to the following table. Tab. 4.1-1 Unit installation checklist Items to be Checked Possible Situation in Case of Improper Installation Check whether the water pipeline system is System protection caused by pipeline leakage.
- Page 23 Heat Pump Pool Heater 5 Non-Fault Phenomenon Phenomenon Cause Analysis In order to protect the unit, start the unit immediately Start up immediately after shutdown. after shutdown, and the microcomputer control will delay its operation for about 5 min. In heating mode, the outdoor ambient temperature is low and frosting is a normal operation process.
- Page 24 Heat Pump Pool Heater Fig. 6.2-1 Schematic diagram of removing the pipes of water outlet and water inlet for water drainage 6.3 Control Board Description & Fault Code 6.3.1 Main Control Board Silk-Screen Introduction Silk-Screen Introduction Power supply zero line(only CN99 Water flow switch for GRS-CP18Pd/NhA-S)
- Page 25 Heat Pump Pool Heater 6.3.2 Drive Control Board (a) GRS-CP11Pd/NhA-S (b) GRS-CP18Pd/NhA-S Silk-Screen Introduction Silk-Screen Introduction Ambient temperature, Power input zero line T-SEN discharge and pipe temperature sensor Power input fire wire T-SEN1 Suction temperature sensor Main control board power...
- Page 26 Heat Pump Pool Heater 6.4 Main Control Fault Information Error Error Name Possible Causes Solution Code Insufficient water flow; Poor contact caused by loose pressure switch wire; Abnormal pressure switch; High-pressure protection Main board fault; Abnormal heat exchange of After the fault is water-side heat exchanger;...
- Page 27 Heat Pump Pool Heater 6.5 Fault Information Table (Drive Board) Error Error Error Name Error Name Code Code AC current protection (input EPROM memory chip fault side) of variable frequency external fan Drive IPM module protection of Start failing of variable variable frequency compressor frequency external fan Drive PFC protection of variable...
- Page 28 Heat Pump Pool Heater Error Error Error Name Error Name Code Code Drive communication fault of Drive memory chip fault of main control & variable variable frequency external fan frequency compressor Temperature sensor fault of drive Drive PFC protection of module of variable frequency variable frequency external fan compressor...
- Page 29 Heat Pump Pool Heater 6.6.1.5 Presence of Fire Extinguisher If any hot work is to be conducted on the refrigeration equipment or any associated parts, appropriate fire extinguishing equipment shall be available to hand. Have a dry powder or CO fire extinguisher adjacent to the charging area.
- Page 30 Heat Pump Pool Heater checked for the presence of refrigerant. Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected. Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components, unless the components are constructed of materials which are inherently resistant to being corroded or are suitably protected...
- Page 31 Heat Pump Pool Heater Ensure that apparatus is mounted securely. Ensure that seals or sealing materials have not degraded such that they no longer serve the purpose of preventing the ingress of flammable atmospheres. Replacement parts shall be in accordance with the manufacturer’s specifications. 6.6.3 Repair to Intrinsically Safe Components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current...
- Page 32 Heat Pump Pool Heater refrigerant used. Leak detection equipment shall be set at a percentage of the LFL of the refrigerant and shall be calibrated to the refrigerant employed, and the appropriate percentage of gas (25% maximum) is confirmed. Leak detection fluids are also suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine can react with the refrigerant and corrode the copper pipe-work.
- Page 33 Heat Pump Pool Heater oxygen-free nitrogen charge is used, the system shall be vented down to atmospheric pressure to enable work to take place. This operation is absolutely vital if brazing operations on the pipework are to take place. Ensure that the outlet for the vacuum pump is not close to any potential ignition sources and that ventilation is available.
- Page 34 Heat Pump Pool Heater Pump down refrigerant system, if possible. If a vacuum is not possible, make a manifold so that refrigerant can be removed from various parts of the system. Make sure that cylinder is situated on the scales before recovery takes place. Start the recovery machine and operate in accordance with manufacturer's instructions.
- Page 35 When oil is drained from a system, it shall be carried out safely. 6.7 After-Sales Services Any quality or other issues encountered in the purchased units, please contact the local Gree after-sales service department.
