AEG BPK355060M User Manual

AEG BPK355060M User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
BPK355060M
BPS355060M
BPK35506HM
USER
MANUAL
EN
User Manual
Oven

Advertisement

loading
Need help?

Need help?

Do you have a question about the BPK355060M and is the answer not in the manual?

Questions and answers

Related Manuals for AEG BPK355060M

Summary of Contents for AEG BPK355060M

  • Page 1 BPK355060M User Manual Oven BPS355060M BPK35506HM USER MANUAL...
  • Page 2 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3 SAFETY INFORMATION 9.2 Automatic switch-off.......24 11.7 How to replace: Lamp....31 9.3 Cooling fan........24 12. TROUBLESHOOTING......32 10. HINTS AND TIPS........24 12.1 What to do if.........32 10.1 Moist Fan Baking......24 12.2 Service data.........33 10.2 Moist Fan Baking - 13. ENERGY EFFICIENCY......34 recommended accessories....25 13.1 Product Information Sheet 10.3 Cooking tables for test institutes..25...
  • Page 4 SAFETY INFORMATION Keep all packaging away from children and dispose of it • appropriately. WARNING: Keep children and pets away from the appliance • when it operates or when it cools down. Accessible parts become hot during use. If the appliance has a child safety device, it should be •...
  • Page 5 SAFETY INSTRUCTIONS Always use oven gloves to remove or insert accessories or • ovenware. To remove the shelf supports first pull the front of the shelf • support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. Do not use a steam cleaner to clean the appliance.
  • Page 6 SAFETY INSTRUCTIONS Width of the front of the appliance 595 mm Width of the back of the appliance 559 mm Depth of the appliance 567 mm Built in depth of the appliance 546 mm Depth with open door 1027 mm Ventilation opening minimum size.
  • Page 7 SAFETY INSTRUCTIONS 2.3 Use WARNING! Risk of injury, burns and electric shock or explosion. • Do not change the specification of this appliance. • Make sure that the ventilation openings are not blocked. • Do not let the appliance stay unattended during operation. •...
  • Page 8 SAFETY INSTRUCTIONS • Clean the appliance with a moist soft cloth. Use only neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects. • If you use an oven spray, follow the safety instructions on its packaging. 2.5 Pyrolytic cleaning WARNING! Risk of Injury / Fires / Chemical Emissions (Fumes) in Pyrolytic Mode.
  • Page 9 PRODUCT DESCRIPTION 2.8 Disposal WARNING! Risk of injury or suffocation. • Contact your municipal authority for information on how to dispose of the appliance. • Disconnect the appliance from the mains supply. • Cut off the mains electrical cable close to the appliance and dispose of it. •...
  • Page 10 HOW TO TURN OVEN ON AND OFF 3.2 Accessories Wire shelf For cookware, cake tins, roasts. Grill- / Roasting pan To bake and roast or as a pan to collect fat. Trivet For roasting and grilling. Use the trivet only with the Grill- / Roasting pan. 4.
  • Page 11 BEFORE FIRST USE When the knob for the heating functions is in the off position, the display goes to standby. When you cook, the display shows the set tem‐ perature, time of day and other available op‐ tions. The display with the maximum number of func‐ tions set.
  • Page 12 DAILY USE 5.1 Initial cleaning Before the first use clean the empty oven and set the time: 00:00 Set the time. Press 5.2 Initial preheating Preheat the empty oven before the first use. Step 1 Remove all accessories and removable shelf supports from the oven. Step 2 Set the maximum temperature for the function: Let the oven operate for 1 h.
  • Page 13 DAILY USE Steam cooking Make sure that the oven is cold. Step 1 Step 2 Step 3 Step 4 Preheat the empty oven for 10 min to create humidity. Put food in the oven. Set the steam Fill the cavity embossment with tap Set the tem‐...
  • Page 14 DAILY USE Heating function Application To bake and roast food on one shelf position. Conventional Cooking To add humidity during the cooking. To get the right colour and crispy crust during baking. To give more juiciness during reheating. To preserve fruit or vegetables.
  • Page 15 DAILY USE When you use this function the lamp automatically turns off after 30 sec. For the cooking instructions refer to "Hints and tips" chapter, Moist Fan Baking. For general energy saving recommendations refer to "Energy Efficiency" chapter, Energy Saving. 6.4 How to set: Assisted Cooking Every dish in this submenu has a recommended function and temperature.
  • Page 16 DAILY USE Dish Weight Shelf level / Accessory Duration time Beef Roast Beef, 40 min rare 1 - 1,5 kg; 4 2; baking tray Roast Beef, - 5 cm thick 50 min Fry the meat for a few minutes on a hot medium pieces pan.
  • Page 17 DAILY USE Dish Weight Shelf level / Accessory Duration time Veal roast 0,8 - 1,5 kg; 80 min 2; roasting dish on wire shelf (e.g. shoulder) 4 cm thick Use your favourite spices. Add liquid. pieces Roast covered. Pork Pork roast 1,5 - 2 kg 120 min 2;...
  • Page 18 DAILY USE Dish Weight Shelf level / Accessory Duration time Chicken 180 - 200 g 25 min 2; casserole dish on wire shelf breast per piece Use your favourite spices. Fry the meat for a few minutes on a hot pan. Chicken legs, 30 min 3;...
  • Page 19 DAILY USE Dish Weight Shelf level / Accessory Duration time Apple tart 40 min 2; pie form on wire shelf Apple pie 60 min 100 - 150 ml; 22 cm pie form on wire shelf Brownies 2 kg 30 min 3;...
  • Page 20 CLOCK FUNCTIONS Dish Weight Shelf level / Accessory Duration time Potato gratin 1 - 1,5 kg 50 min 1; casserole dish on wire shelf Pizza fresh, 100 ml; baking tray lined 15 min thin with baking paper Pizza fresh, 100 ml; baking tray lined 25 min thick with baking paper...
  • Page 21 CLOCK FUNCTIONS 7.2 How to set: Clock functions How to set: Time of day Step 1 Step 2 Step 3 To change the time of day enter the menu Set the clock. Press: and select Settings, Time of day. How to set: Minute minder Step 1 Step 2 Step 3...
  • Page 22 HOW TO USE: ACCESSORIES How to set: Time Delay Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 The dis‐ The dis‐ play play shows: shows: the time --:-- of day Select Press re‐ Set the Set the STOP Press: Press:...
  • Page 23 HOW TO USE: ACCESSORIES Wire shelf, Deep pan: Push the tray between the guide bars of the shelf support and the wire shelf on the guide bars above. 8.2 Using Trivet and Grill- / Roasting pan WARNING! Be careful when you remove the accessories from a hot oven. There is a risk of burns.
  • Page 24 ADDITIONAL FUNCTIONS 9. ADDITIONAL FUNCTIONS 9.1 Lock This function prevents an accidental change of the oven function. Turn it on when the oven works - the set cooking continues, the control panel is locked. Turn it on when the oven is off - the oven cannot be turned on, the control panel is locked. - press and hold to turn on - press and hold to turn it off.
  • Page 25 HINTS AND TIPS (°C) (min) Pasta gratin 200 - 220 45 - 55 Potato gratin 180 - 200 70 - 85 Moussaka 170 - 190 70 - 95 Lasagne 180 - 200 75 - 90 Cannelloni 180 - 200 70 - 85 Bread pudding 190 - 200 55 - 70...
  • Page 26 HINTS AND TIPS BAKING ON ONE LEVEL. Baking in tins (°C) (min) Fatless sponge cake True Fan Cooking 140 - 150 35 - 50 Fatless sponge cake Conventional Cook‐ 35 - 50 Apple pie, 2 tins Ø20 cm True Fan Cooking 60 - 90 Apple pie, 2 tins Ø20 cm Conventional Cook‐...
  • Page 27 CARE AND CLEANING MULTILEVEL BAKING. Biscuits (°C) (min) Short bread / Pastry strips True Fan Cooking 25 - 45 1 / 4 Small cakes, 20 per tray, True Fan Cooking 23 - 40 1 / 4 preheat the empty oven Fatless sponge cake True Fan Cooking 35 - 50...
  • Page 28 CARE AND CLEANING 11.1 Notes on cleaning Clean the front of the oven with a soft cloth with warm water and a mild deter‐ gent. Use a cleaning solution to clean metal surfaces. Cleaning Clean stains with a mild detergent. Agents Clean the cavity after each use.
  • Page 29 CARE AND CLEANING Step 1 Turn off the oven and wait until it is cold. Step 2 Pull the front of the shelf sup‐ port away from the side wall. Step 3 Pull the rear end of the shelf support away from the side wall and remove it.
  • Page 30 CARE AND CLEANING Pyrolytic Cleaning C3 - Thorough cleaning Step 2 - press to select the cleaning programme. Step 3 - press to start the cleaning. Step 4 After cleaning, turn the knob for the heating functions to the off posi‐ tion.
  • Page 31 CARE AND CLEANING Step 1 Fully open the door. Step 2 Lift and press the clamping levers (A) on the two door hinges. Step 3 Close the oven door to the first opening position (approximately 70° angle). Hold the door at both sides and pull it away from the oven at an upwards angle. Put the door with the outer side down on a soft cloth on a stable surface.
  • Page 32 TROUBLESHOOTING Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven. Wait until Disconnect the oven from the Put a cloth on the bottom of the oven is cold. mains. the cavity. Top lamp Step 1 Turn the glass cover to remove it.
  • Page 33 TROUBLESHOOTING The oven does not turn on or does not heat up The oven does not heat up. The Child Lock is off. Components Problem Check if... The lamp is turned off. Moist Fan Baking - is turned on. The lamp does not work. The lamp is burnt out.
  • Page 34 ......... Serial number (S.N.) ......... 13. ENERGY EFFICIENCY 13.1 Product Information Sheet according to UK Ecodesign and Energy Labelling Regulations Supplier's name BPK355060M 944188614 Model identification BPS355060M 944188611 BPK35506HM 944188618 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conventional 1.09 kWh/cycle...
  • Page 35 MENU STRUCTURE BS EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance. 13.2 Energy saving The oven has features which help you save energy during everyday cooking. Make sure that the oven door is closed when the oven operates. Do not open the oven door too often during cooking.
  • Page 36 ENVIRONMENTAL CONCERNS Adjust the value Select the Menu, Select the set‐ Confirm setting. Confirm setting. Settings. ting. and press Settings Time of day Change Display brightness 1 - 5 Key tones 1 - Beep Buzzer volume 1 - 4 2 - Click 3 - Sound off Uptimer On / Off...
  • Page 37 37/40...
  • Page 38 38/40...
  • Page 39 39/40...
  • Page 40 www.aeg.com/shop...

This manual is also suitable for:

Bps355060mBpk35506hm
