HP Tower Server tc2100
Service Manual
Online Version 1.0
Printed August 2001
Download from Www.Somanuals.com. All Manuals Search And Download.

Advertisement

loading
Need help?

Need help?

Do you have a question about the tc2100 and is the answer not in the manual?

Questions and answers

Related Manuals for HP tc2100

Summary of Contents for HP tc2100

  • Page 1 HP Tower Server tc2100 Service Manual Online Version 1.0 Printed August 2001 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 2 Notice The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 2 Controls, Ports, and Indicators ......................11 Front Panel Control and Indicators ......................11 Additional Front Panel Controls and Indicators ..................12 Rear Panel Ports and Features ......................13 Applying Power to the HP Server ......................14 Powering-Up the HP Server .......................14 Powering-Down the HP Server ......................14 Multiple-Server Configurations ......................15 Sleep States (ACPI)..........................15...
  • Page 4 Contents HP DiagTools Capabilities ........................37 About Error Messages ........................38 Advantages and Limitations of Hardware Diagnostics ...............38 7 Maintenance and Troubleshooting .....................41 Preventive Maintenance Procedures ......................41 Troubleshooting ............................41 Troubleshooting Checklist ........................41 Server Does Not Power On ........................42 Server Powers On, but Fails POST ....................43 Server Passes POST, but Does Not Function..................43...
  • Page 5 Contents Removing the Upper Bezel .........................72 Replacing the Upper Bezel .........................73 Removing the Lower Bezel .........................74 Replacing the Lower Bezel .........................75 Status Panel Assembly ...........................75 Removing the Status Panel Assembly....................75 Replacing the Status Panel Assembly....................76 Mass Storage Devices ..........................77 Removing the Flexible Disk Drive.......................77 Replacing the Flexible Disk Drive .......................78 Removing the CD-ROM ........................78 Replacing the CD-ROM ........................79...
  • Page 6 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 7 1 Specifications Technical Specifications The specifications listed below for HP Tower Server tc2100 may vary if you install a mass storage device in your server that has more stringent environmental limits. Ensure the operating environment for your server is suitable for all of the mass storage devices being used.
  • Page 8 Specification Characteristics Processors This HP Server supports Intel Celeron or Intel Pentium III processors (system board automatically detects processor FSB and changes accordingly): Intel Celeron - 850 MHz and above with 100 MHz FSB and Integrated 128K L2 cache on processor Intel Pentium III - 1.13 GHz and above with 133 MHz FSB and Integrated 512K L2 cache on...
  • Page 9 Chapter 1 Specifications System Board Layout Processor, Connector Heatsink Heatsink Fan & Fan DIMM Slots Power Mouse (U) Keyboard (L) LAN (U) 2 USB (L) Com 1 (L) Parallel (U) IDE-2 Video (L) IDE-1 Com 2 Connector Chassis Fan SCSI Controller PCI Slot P1 PCI Slot P2...
  • Page 10 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 11 2 Controls, Ports, and Indicators Front Panel Control and Indicators The HP Tower Server tc2100’s controls, indicators, and user-serviceable internal components are shown in the following illustrations. Flexible Disk Drive (FDD) CD-ROM Drive Backup Tape Drive (Optional) 3rd Hard Drive...
  • Page 12 * Flashing at 4 Hz rate ** Pulsing at 2 Hz rate NOTE For more information on the HP Tape Drive and its error codes, refer to the documentation provided with the tape drive or refer to Hewlett-Packard's web site, at: http://www.hp.com/...
  • Page 13 HP Server – Rear View • The power connector accepts a standard power cable to connect the HP Server tc2100 with the site power source. • The input voltage selector switch is used to adapt the power supply to the input line voltage. The two switch settings are 115 volts or 230 volts, and 230 volts is the default setting.
  • Page 14 2. Follow instructions in your network operating system (NOS) documentation to gracefully shut down all networking software and applications. 3. Press the power switch on the HP Server's control panel when prompted by the operating system. Normally this completes the power down procedure.
  • Page 15 The HP Server’s power button can be configured to initiate a graceful shutdown or "soft off" of the NOS, rather than an immediate shutdown of the power supply. The power button configurations are dependent on the user interface provided by the ACPI-compliant NOS.
  • Page 16 If the power button override is used; there is a strong possibility of corrupted or lost data. Refer to the BIOS Setup Utility in Chapter 8, “Configuring the HP Server” and your NOS documentation for instructions on setting up Sleep States and transitioning into and out of the various states.
  • Page 17 3 Connector Pinouts Unless otherwise noted, the following features apply to all models. Some features are factory installed; others are optional. Mini-DIN (PS/2) Connectors Mini-DIN Connector (female) for the Mouse and Keyboard Mini-DIN Connector Pinouts for the Mouse and Keyboard Pin Number Signal Description Data signal...
  • Page 18 Chapter 3 Connector Pinouts Parallel Port Connector Parallel Connector Parallel Port Connector (female) Pinouts Pin Number Signal Description Pin Number Signal Description Strobe5 Acknowledge b Data bit 06 Busy Data bit 1 a Paper end Data bit 2 a Select Data bit 3 a Auto line feed b Data bit 4 a...
  • Page 19 Chapter 3 Connector Pinouts USB Connector USB Connector Universal Serial Bus Connector Pinouts Pin Number Signal Description VBUS NOTE Use of the USB port is supported for printers, scanners, and external modems. Video Connector The embedded video uses the standard 15-pin analog display pinout configuration. The pinouts for your monitor may vary.
  • Page 20 Chapter 3 Connector Pinouts 68-Pin LVD SCSI Port Connector (Low Voltage Differential) LVD SCSI Connector (Male) Pin 1 Pin 68 68-Pin SCSI Port Connector Shown as pin matching Pin Number Signal Signal Description Number Description +DB(12) -DB(12) +DB(13) -DB(13) +DB(14) -DB(14) +DB(15) -DB(15)
  • Page 21 Chapter 3 Connector Pinouts 50-Pin Narrow SCSI Port Connector – Accessory Board Position 25 Position 1 Position 50 Position 26 SCSI Port Connector 50-Pin Narrow SCSI Port Connector Pinouts Pin Number Signal Description Pin Number Signal Description 1-11 Ground Reserved Reserved Termpwr Open...
  • Page 22 Chapter 3 Connector Pinouts Pin Number Signal Description Ground Power (+5 V dc) Clock signal Not used Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 23 DIMM memory, accessory boards, and processors. Mass Storage The HP Server tc2100 comes standard with one IDE CD-ROM and one flexible disk drive with various possible configurations of SCSI or IDE hard disk drives, depending on the model (SCSI or IDE). The Server is limited to six internal mass storage devices (including a tape back up drive), four in the front shelves (or common trays) and two in the removable drive cage accessed from the side of the Server.
  • Page 24 Boot Priority The HP Server tc2100 is provided in two models, IDE or SCSI, and the model type affects the boot priority. The HP Server searches for bootable devices in a specific order, which is set up in the BIOS Utility.
  • Page 25 This section provides the configuration of the SCSI mass storage devices, if you have selected a SCSI version of the HP Server tc2100. The base SCSI model configuration has at least one SCSI hard drive (shelf 6) located in the removable drive cage and connected to the factory installed SCSI controller.
  • Page 26 Therefore, you can not connect external SCSI devices to the external connector when there are active internal SCSI devices connected to the internal SCSI connector. The HP Server tc2100 will support an HP NetRAID 1M controller board, separate from the SCSI controller board.
  • Page 27 External SCSI Connector The HP Server tc2100, SCSI model, has an external SCSI connector at the rear of the Server. This SCSI port cannot be used if there are active internal SCSI devices. The SCSI controller provided with the SCSI model of the Server is a single channel controller and cannot support internal and external SCSI devices at the same time.
  • Page 28 Tested PCI Boards For a list of tested PCI boards, check for compatibility under the Hardware Tested Products list for the HP Server tc2100 under the Technical Support topic for the specific NOS used in the Server at HP’s web site: http://Server.hp.com/Server/support/compatibility/compatibility.asp CAUTION Some accessory board outputs may exceed U.S.
  • Page 29 • The HP Server tc2100 only supports 100 MHz and 133 MHz FSB speeds. Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 30 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 31 If the POST routines cannot display messages when an error occurs before the video display is initialized, the HP Server emits a series of beeps. If you get a blank screen on boot, but hear beeps, refer to the table below to interpret the meaning of the beeps.
  • Page 32 The Server BIOS is not responding due to a possible battery (low battery power) discharge. If the HP Server was unplugged for a long period of time, the battery will discharge and not provide enough current to keep the system date and time current.
  • Page 33 System timer error The Server BIOS is not responding due to a possible battery discharge. If the HP Server was unplugged for a long period of time, the battery will discharge and not provide enough current to keep the system date and time current.
  • Page 34 Chapter 5 Error Messages 0280 Previous boot incomplete The HP Server configuration has been cleared or has not been initialized and the Default configuration has been used instead. • Run the Setup Utility to re-configure your system. 0281 DIMM size boot error The system memory (DIMMs) size detected during POST is smaller than previously detected.
  • Page 35 Chapter 5 Error Messages 0231 Shadow Ram Failed POST has detected an incorrectly installed DIMM or the (at offset) failure of one or more DIMMs. To correct this: 1. If additional memory was just installed in your Server, please verify the installation conforms to the description in the Installation Guide.
  • Page 36 Chapter 5 Error Messages Code Description Problem/Solution (System Monitor Errors) 0A01 Emergency shutdown occurred The Server has performed an emergency shutdown to prevent (system initiated) damage to system board. • To prevent unstable behavior, or a system hang during the boot process, do not skip this error message or continue with Server operation.
  • Page 37 When the Server boots, a series of tests are displayed on the screen. The number of tests displayed depends on the configuration of the Server. The following are the types of errors a user might get with the HP Server.
  • Page 38 DiagTools is an off-line diagnostic. Off-line diagnostics do not use the main network operating system (NOS) of the HP Server. The alternate DiagTools OS has far fewer features than the full-fledged NOS. Thus, its capabilities are limited to a set of basic tests and a series of advanced tests. In addition, DiagTools does not use any tests, which might write over and thus destroy user data.
  • Page 39 Chapter 6 Diagnostics • No access to operating system error logs, since the OS is not operating at the same time as the diagnostic tools • Limited ability to test only a single component at a time • Inability to indicate problems with wrongly configured Servers or the network Download from Www.Somanuals.com.
  • Page 40 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 41 These chemicals could damage the keyboard's plastic surfaces. ) HP recommends the periodic cleaning of tape heads, capstans, and guides on HP tape drive units and those products using high-density data cartridges and mini-data cartridges. These maintenance procedures prolong tape and head life and helps reduce read/write errors due to dust and oxide.
  • Page 42 3. Remove the Server's left side cover. 4. Simplify the HP Server configuration to the minimum required: The minimum configuration would include a monitor, one flexible disk drive, one CD-ROM drive, one hard disk drive, keyboard, mouse, and embedded NIC.
  • Page 43 BIOS reset, recovery, or update to correct the condition. A BIOS update/recovery diskette is created when the most current BIOS is downloaded from the HP web site to be used in flashing the BIOS into the Server. To perform a reset, an update, or a BIOS recovery, perform one of the following procedures.
  • Page 44 3. Press F10 to save changes and exit the BIOS Setup Utility. BIOS Update Use this procedure if you need to update your server BIOS with the latest BIOS version. HP regularly posts a new version of the HP Server tc2100 BIOS on the website to improve the Server’s performance.
  • Page 45 Chapter 7 Maintenance and Troubleshooting 1. Turn off power to the Server and remove the left side cover. 2. Move the jumper from its “Normal” position (Pins 1 & 2) on the system board to the “Clear CMOS” position (Pins 2 & 3) and leave it there for five seconds as shown in the figures below. Pin 3 Pin 1 Battery Spring...
  • Page 46 Chapter 7 Maintenance and Troubleshooting 1. Verify the power is good and available. 2. Ensure the Server is turned on (the power-on light should be green and the fans should be on). 3. Turn the Server off and unplug the power cord. a.
  • Page 47 6. Verify the DIMMs are all of the same (specified) speed. 7. Verify the DIMMs are installed and configured correctly: a. Make sure only HP-supported DIMMs are used. b. Remove the questionable DIMM and install a known good DIMM, and reboot.
  • Page 48 Chapter 7 Maintenance and Troubleshooting Typically, all fans run when power is turned on and all fans are off when the power is turned off. 5. With the power supply connected to the system board, check the power supply's voltages. 6.
  • Page 49 Ø When most EGA and VGA monitors are disconnected from the video connector, if the monitor is working, the screen is white. Ø When some monitors (such as HP high-resolution monitors) are disconnected from the video connector, the monitor may be working, although the screen is black.
  • Page 50 Chapter 7 Maintenance and Troubleshooting 17. If the customer has installed a video board instead of using the embedded video, ensure all jumpers and switches are set properly on the installed video board. Refer to the user manual provided with the video board. 18.
  • Page 51 Chapter 7 Maintenance and Troubleshooting Symptom: • The configuration information is frequently lost and the battery is good. If the battery is good and you cannot save system configuration, do the following 1. Review the Troubleshooting Checklist before you continue. BIOS configuration information is saved in the CMOS memory.
  • Page 52 • The mouse does not work or is intermittent The HP Server automatically detects a mouse when one is installed. If the mouse or other input device is not working, perform the following: 1. Review the Troubleshooting Checklist before you continue.
  • Page 53 Chapter 7 Maintenance and Troubleshooting 4. Select the Setup Utility (press [F2] during the boot process and verify the Server's mass storage configuration is correct. a. If for some reason you cannot run the Setup, you can clear CMOS and reconfigure the Server. b.
  • Page 54 • The CD-ROM drive is not working properly The CD-ROM drive provided with this HP Server (SCSI or IDE models) is IDE CD-ROM. If the CD-ROM drive does not work, do the following: 1. Review the basic IDE installation guidelines to ensure a proper configuration.
  • Page 55 If the SCSI controller does not work after installation, do the following: 1. Review the Troubleshooting Checklist and Mass Storage Guidelines before you continue. 2. Run the HP DiagTools Utility and verify the following items: o The integrity of the SCSI bus o Ensure the switch settings on the internal SCSI devices are correct (no termination and manually set SCSI IDs).
  • Page 56 Use only HP SCSI cables for the SCSI devices, as these have terminators at the end of the cable. 18. Disconnect all SCSI devices except the SCSI controller board and the drive at SCSI address 0, and try again.
  • Page 57 8. Verify the external SCSI bus is terminated at both ends. By default, HP SCSI controllers in external enclosures are terminated. When a device is connected to a connector on the SCSI bus of the controller, bus termination for that connector is disabled. Verify the last device on the bus is terminated.
  • Page 58 "warm" restart (as it does when you press Ctrl+Alt+Del). 3. Check the BIOS event log (available on certain Server models) for messages indicating memory errors. 4. Run the HP DiagTools Utility memory test. 5. Reseat the memory modules.
  • Page 59 Chapter 7 Maintenance and Troubleshooting c. If the error goes away, add another DIMM and reboot again. d. Continue this process until you have installed all DIMMs or you experience a failure. e. Replace the defective DIMM. 7. Once a suspect part has been found, verify the cause of the problem by reinstalling the part and attempting to duplicate the error.
  • Page 60 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 61 8 Parts and Illustrations Exploded View – Covers and Bezels Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 62 Chapter 8 Parts and Illustrations Exploded View – Mass Storage Devices Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 63 Chapter 8 Parts and Illustrations Exploded View – Chassis Fan, Power Supply, and System Board Rear View Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 64 Chapter 8 Parts and Illustrations Exploded View – System Board Components Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 65 The part numbers listed below were available at the time of publication. Part numbers may change after publication. Order parts by the number listed below; HP's parts price list database will generally contain a reference to the revised part number. If a system board needs to be replaced, remove processor modules, DIMMs, or adapter boards and transfer these to the new board.
  • Page 66 Chassis Rubber Foot P4648-63024 Chassis key for chassis lock P4648-63017 Nameplate, Bezel 5042-7255 HP Startup CD-ROM 5065-8577 This part is not on an exploded view This Part Number is revised with each new release Cables and Part Numbers Cable Description Replacement Part Nos.
  • Page 67 Chapter 8 Parts and Illustrations Language Part Number Language Part Number Polish D4950-63035 Swedish D4950-63012 Hungarian D4950-63037 D4950-63013 Turkish D4950-63035 Czech D4950-63036 Greek D4950-63032 Dutch D4950-63006 Power Cords Country Part Number Country Part Number Australia/New Zealand 8120-1369 India/South Africa 8120-4211 Canada/United States 8120-1751 Denmark...
  • Page 68 Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 69 NOTE These steps do not include the removal of the front bezel of the Server. You do not need to remove the front bezel of the HP Server tc2100 to install internal accessories, such as memory or mass storage. 1. If the Server is operating, log off all users and if necessary, backup mass storage devices.
  • Page 70 3. If necessary, unlock the left side cover, using the lock located on the rear of the Server. The locking mechanism is at the rear, as shown below. Initially, the keys are attached to the rear of the HP Server, similar to the view shown below. Turn Key...
  • Page 71 Chapter 9 Remove/Replace Procedures Removing the Left Side Cover 6. Place the left side cover in a safe place for re-installation later. Replacing the Left Side Cover To replace the left side cover, follow these steps: 1. If you have been installing accessories or servicing the Server, return the Server to its normal upright position.
  • Page 72 Chapter 9 Remove/Replace Procedures Latch Hinge Tabs Replacing the Left Side Cover Alternate Covers The other covers (top or right side) used on the Server are not essential when accessing components in or on the Server. However, if for some reason you need to replace one of these covers you can find both covers illustrated in some detail in the exploded view of Chapter 8, “Parts and Illustrations.”...
  • Page 73 Chapter 9 Remove/Replace Procedures This action will swing the upper front bezel open on its hinge teeth. 6. Swing the upper bezel completely open and remove it from the front of the Server. Release Tabs (2) Removing the Upper Front Bezel Replacing the Upper Bezel The upper front bezel uses hinge teeth, instead of a normal hinge assembly, to engage each side of the hinge and pivots on these when opening or closing the upper bezel.
  • Page 74 Chapter 9 Remove/Replace Procedures Hinge Teeth (4) Replacing the Upper Bezel Removing the Lower Bezel 1. If the Server is operating, power down the Server. Refer to Chapter 2, “Controls, Ports, and Indicators” for instructions. 2. Disconnect the power cord and any external cables connected to the Server. If necessary, label each one to expedite re-assembly.
  • Page 75 Chapter 9 Remove/Replace Procedures Removing the Lower Bezel Replacing the Lower Bezel 1. If the Server is operating, power down the Server. Refer to Chapter 2, “Controls, Ports, and Indicators” for instructions. 2. Disconnect the power cord and any external cables connected to the Server. If necessary, label each one to expedite re-assembly.
  • Page 76 Chapter 9 Remove/Replace Procedures 2. Disconnect the power cord and any external cables connected to the Server. If necessary, label each one to expedite re-assembly. 3. Remove the left side cover. 4. Remove the upper bezel. 5. Remove the lower bezel. 6.
  • Page 77 Chapter 9 Remove/Replace Procedures 8. Restore power to the Server and verify the status panel assembly is working properly. Mass Storage Devices Shelf 1 (FDD) Shelf 2 (CD-ROM) Shelf 3 (Backup Tape Drive) (Optional) Latch Release (Drive Cage) Shelf 5 (2nd Hard Drive) (Optional) Mass Storage Device Locations Removing the Flexible Disk Drive...
  • Page 78 Chapter 9 Remove/Replace Procedures Removing the Flexible Disk Drive (FDD) 7. Rotate the FDD mounting assembly off of the flexible disk drive. 8. Place the flexible disk drive in an anti-static bag. Replacing the Flexible Disk Drive 1. If not already mounted, place the two hooks in the screw holes on the right side of the FDD and rotate the FDD mounting assembly onto the flexible disk drive.
  • Page 79 Chapter 9 Remove/Replace Procedures 4. Remove the upper bezel. 5. At the rear of the CD-ROM, carefully disconnect the power and data cables. 6. Remove the CD-ROM by: a. Pressing in on both release tabs to release the CD-ROM tray assembly. b.
  • Page 80 10. Power on the Server as described in Chapter 2, “Controls, Ports, and Indicators.” Removing a Backup Tape Drive This procedure is used to remove the optional HP Backup Tape Drive mounted in the third shelf. 1. If the Server is operating, power down the Server.
  • Page 81 5. At the rear of the backup tap drive tray, carefully connect the power and data cables. The optional HP backup tape drive comes with a 50-to-68-pin adapter to connect to a 68-pin SCSI cable used for connection of backup tape drive.
  • Page 82 Chapter 9 Remove/Replace Procedures Removing Hard Disk Drive (HDD) and Tray Replacing a Hard Disk Drive (Tray Mounted) This procedure is used to replace the third hard disk drive (HDD) mounted in the fourth shelf. The second and third drive trays are identical, but the forth drive tray is reserved for a hard drive (IDE or SCSI). The fourth drive tray provides four raised mounting posts to mount hard drives without the use of any mounting brackets.
  • Page 83 Chapter 9 Remove/Replace Procedures 7. Replace the left side cover. 8. Replace the external cables and power cord. 9. Power on the Server as described in Chapter 2, “Controls, Ports, and Indicators.” Removing a Hard Disk Drive (Drive Cage Mounted) The replacement of the mass storage cage mounted drives is the same for IDE or SCSI drives.
  • Page 84 Longer screws may cause internal damage to the mass storage device. Damage caused by incorrect mounting screws is not covered by the HP warranty. 6. If you have installed all of the drives into the drive cage, reinstall drive cage into the chassis.
  • Page 85 3. Remove the left side cover. WARNING The power supply will continue to provide standby current to the HP Server until the power cord is disconnected from the AC power source. 4. Lay the Server on its side (components showing).
  • Page 86 DIMM sizes may be mixed on the system board and may be loaded in any order (1 through 3). However, HP recommends starting at slot 1 and filling the slots in order: 1, 2, and 3. Empty slots between DIMMs are permitted.
  • Page 87 Processor The procedures listed here for removing and replacing a processor and its heatsink-cooling fan are the same for all of the processors used in this HP Server. CAUTION Wear a wrist-strap and use a static-dissipating work surface connected to the chassis when handling components.
  • Page 88 Chapter 9 Remove/Replace Procedures WARNING The power supply will continue to provide standby current to the HP Server until the power cord is disconnected from the AC power source. 4. Lay the Server on its side (components showing). 5. Disconnect the cooling fan power cable from the connector on the system board.
  • Page 89 Chapter 9 Remove/Replace Procedures Pin-1 Marker Processor Socket Base Lever Removing the Processor 3. Grasp the processor by its edges and lift it out of the processor socket. 4. Place the processor on a static-dissipating work surface or into an anti-static bag. Replacing the Processor 1.
  • Page 90 Chapter 9 Remove/Replace Procedures Pin-1 Marker Processor Socket Base Lever Replacing the Heatsink-Cooling Fan Once the processor is installed, the heatsink-cooling fan must be installed on top of the processor. Each processor requires a heatsink, with its cooling fan attached, and a thermal bonding between the processor and the heatsink, provided with a thermal patch.
  • Page 91 Chapter 9 Remove/Replace Procedures Method A a. Position the heatsink over the processor socket and lower it squarely onto the processor, as shown in the following illustration. There are two ridges on the heatsink to help align the heatsink to the processor. The heatsink can only be installed in one direction, with the metal step to the right of processor socket, as shown in the following illustration.
  • Page 92 Chapter 9 Remove/Replace Procedures Hook Latch (hidden) Step A Thumb Latch Step C Step B Processor Socket Base Replacing Heatsink-Cooling Fan on the Processor CAUTION Ensure you have made good contact with the processor to avoid thermal overheating. If you have not made good contact with the processor, it will overheat within 20 seconds of power on, possibly causing a system crash before completing the boot process and causing damage to the processor.
  • Page 93 If necessary, label each one to expedite re-assembly. 3. Remove the left side cover. WARNING The power supply will continue to provide standby current to the HP Server tc2100 until the power cord is disconnected from the AC power source. CAUTION Wear a wrist-strap and use a static-dissipating work surface connected to the chassis when handling components.
  • Page 94 Chapter 9 Remove/Replace Procedures Slot Cover Latch Latch Retainer Removing Slot cover Latch 7. Lift the accessory board up and away from the slot. 8. Place the accessory board and any cables in an anti-static container. Replacing Accessory Boards 1. Read the documentation included with the accessory board and follow any special instructions. 2.
  • Page 95 Chapter 9 Remove/Replace Procedures Slot Cover Removing the Slot Cover Slot Cover Chassis Cross- Section View Inserting an Accessory Board 7. Replace the slot cover latch to ensure the accessory board is held in place. 8. Replace the left side cover. 9.
  • Page 96 Chapter 9 Remove/Replace Procedures Power Supply Removing the Power Supply The low voltage ON/OFF switch on the front panel controls the power supply and the voltage selector switch on the rear panel adapts the power supply to the input AC voltage. To remove the power supply from the chassis, perform the following procedure.
  • Page 97 3. Remove the cover and turn in the Server feet, so the Server will lie flat on its side. WARNING The power supply will continue to provide standby current to the HP Server until the power cord is disconnected from the AC power source.
  • Page 98 Chapter 9 Remove/Replace Procedures View Rotated 90 Degrees CCW Removing the Battery Replacing the Battery 1. Insert the new battery with the positive sign (+) facing out, and ensure that it is seated completely. Ensure the retaining latch is in place, and holds the battery firmly. 2.
  • Page 99 Chapter 9 Remove/Replace Procedures 2. Disconnect the power cord and any external cables connected to the Server. If necessary, label each one to expedite re-assembly. 3. Disconnect the chassis fan’s power connector from the system board. 4. Remove the fan by placing a sharp flat object (screwdriver or knife) under the edge of the mounting snap rivet.
  • Page 100 Chapter 9 Remove/Replace Procedures 4. Repeat Step 3 for the three-remaining snap rivet housings and snap rivets. 5. Connect the chassis fan’s power connector. 6. If necessary, replace any accessory boards removed to allow clear access to the fan. 7. Replace the left side cover. 8.
  • Page 101 Chapter 9 Remove/Replace Procedures Replacing the System Board 1. Remove the replacement system board and any cables from the anti-static shipping container. 2. Place the system board on an anti-static pad and set all jumper connections as recorded during the system board removal.
