MV7X
PODCAST MICROPHONE
Overview
The Shure MV7X is a professional-quality XLR dynamic microphone, ideal for close mic applications that require vocal
intelligibility with a balanced tone. Voice Isolation Technology ensures the microphone is laser-focused on your voice
and does not capture any unwanted background noise to give you perfect recordings in imperfect rooms. The attractive
and durable all-metal design features an adjustable yoke that can be mounted onto a variety of microphone stands for
flexible placement options.
Features
• XLR output allows digital or analog recording
• Highly directional dynamic element and Voice Isolation Technology
• Optimized frequency response for rich and natural vocal reproduction
• Rugged, all-metal construction for outstanding reliability
• Adjustable integrated yoke for easy positioning on standard 5/8"-27 threaded stands or booms
Specifications
(subject to change)
Type
Polar Pattern
Frequency Response
XLR Sensitivity
at Minimum Gain, Flat Mode
XLR Output Impedance
Connector Type
Mounting Type
Housing
Net Weight
Dimensions
Available SKUs
MV7X
MV7X-CHN
MV7X-J
Accessories and Replacement Parts
95B41550
AMV7-K-WS
www.shure.com
Dynamic (moving coil)
Unidirectional (cardioid)
50 Hz to 16,000 Hz
-55 dBV/Pa (1.78 mV) at 1 kHz
1 Pa = 94 dB SPL
252 Ω at 1 kHz
XLR
5/8"-27 thread mount
All-metal construction
0.55 kg (1.21 lbs)
Microphone: Length 53.6 mm; Diameter 66.5 mm
Mic in Yoke: 164 x 153.6 x 90.2 mm H × L x D
XLR Dynamic Podcasting Microphone
XLR Dynamic Podcasting Microphone
XLR Dynamic Podcasting Microphone
Black Replacement Grille
Black Windscreen
All information and specifications are subject to change.
© 2021 Shure Incorporated. All rights reserved. See shure.com/trademarks.
MV7X
MV7X BACK
Advertisement
Related Manuals for Shure MV7X-CHN
Summary of Contents for Shure MV7X-CHN
- Page 1 PODCAST MICROPHONE Overview The Shure MV7X is a professional-quality XLR dynamic microphone, ideal for close mic applications that require vocal intelligibility with a balanced tone. Voice Isolation Technology ensures the microphone is laser-focused on your voice and does not capture any unwanted background noise to give you perfect recordings in imperfect rooms. The attractive and durable all-metal design features an adjustable yoke that can be mounted onto a variety of microphone stands for flexible placement options.
- Page 2 MV7X Podcast Microphone Online user guide for MV7X. Version: 1.2 (2021-J)
- Page 3 Shure Incorporated Table of Contents Windscreen MV7X Podcast Microphone Specifications General Description MV7X Yoke Assembly Features Accessories The MV7X Microphone Furnished Accessories Replacement Parts MV7X Output Certifications Mounting Instructions...
- Page 4 Shure Incorporated MV7X Podcast Microphone General Description The Shure MV7X is a professional-quality dynamic microphone, ideal for close mic applications that require vocal intelligibility with a balanced tone. The attractive and durable all-metal design features an adjustable yoke that can be mounted onto a vari- ety of microphone stands for flexible placement options. Features Voice Isolation Technology Highly directional cardioid pattern isolates your voice and removes unwanted background noise...
- Page 5 Shure Incorporated Mounting Instructions The MV7X microphone comes equipped with a 5/8"-27 threaded mount, the thread size most commonly found on microphone stands. This mount can be used with a microphone stand or hung from a boom. Note: Be very careful not to unloosen the screws all the way.
- Page 6 Shure Incorporated Polarity Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3 Housing All metal construction Mounting Type 5/8-27 thread mount Net Weight 0.55 kg (1.21 lbs) [1] 1 Pa=94 dB SPL Typical Frequency Response Typical Polar Pattern Overall Dimensions...
- Page 7 Shure Incorporated MV7X Yoke Assembly The MV7X yoke allows a podcaster to be flexible with mic placement. Loosen the yoke knobs and you can adjust the micro- phone in a variety angles. If the microphone becomes detached from the yoke, these are the steps to put it together in the cor- rect order to ensure that your microphone is secure. Each side uses one thin gray spring washer, one shiny silver brass wash- er, two black plastic washers and the yoke and threaded yoke knob. Start with the threaded knob flat side down on your tabletop. Stack the washers on the threaded knob. ◦ Place a black plastic washer on the knob.
- Page 8 Black Windscreen AMV7-K-WS Certifications This product meets the Essential Requirements of all relevant European directives and is eligible for CE marking. The CE Declaration of Conformity can be obtained from: www.shure.com/europe/compliance Authorized European representative: Shure Europe GmbH Global Compliance Jakob-Dieffenbacher-Str. 12...
