Yamaha GRIZZLY 700 FI YFM7FGPZ 2009 Owner's Manual
  1. Manuals
  2. Brands
  3. Yamaha Manuals
  4. Offroad Vehicle
  5. GRIZZLY 700 FI YFM7FGPZ 2009
  6. Owner's manual
Yamaha GRIZZLY 700 FI YFM7FGPZ 2009 Owner's Manual

Yamaha GRIZZLY 700 FI YFM7FGPZ 2009 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
READ THIS MANUAL CAREFULLY!
It contains important safety information.
LIRE ATTENTIVEMENT CE MANUEL!
Il comprend d'importantes informations de sécurité.
¡LEA ESTE MANUAL ATENTAMENTE!
Contiene indicaciones importantes acerca de la seguridad.
MANUEL DU PROPRIÉTAIRE
MANUAL DEL PROPIETARIO
OWNER'S MANUAL
YFM7FGPZ
YFM7FGPHZ
YFM700FAPZ
43P-28199-62

Advertisement

loading
Need help?

Need help?

Do you have a question about the GRIZZLY 700 FI YFM7FGPZ 2009 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha GRIZZLY 700 FI YFM7FGPZ 2009

Summary of Contents for Yamaha GRIZZLY 700 FI YFM7FGPZ 2009

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. LIRE ATTENTIVEMENT CE MANUEL! Il comprend d’importantes informations de sécurité. ¡LEA ESTE MANUAL ATENTAMENTE! Contiene indicaciones importantes acerca de la seguridad. OWNER’S MANUAL MANUEL DU PROPRIÉTAIRE MANUAL DEL PROPIETARIO YFM7FGPZ YFM7FGPHZ YFM700FAPZ 43P-28199-62...
  • Page 2 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN IMPRIMÉ SUR PAPIER RECYCLÉ 2009.02-0.4×1 CR IMPRESO EN PAPEL RECICLADO (E,F,S)
  • Page 3 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YFM7FGPZ YFM7FGPHZ YFM700FAPZ 43P-28199-62-E0...
  • Page 4 Read this manual carefully before operating this vehicle. This manual should stay with this ve- hicle if it is sold. EC Declaration of Conformity conforming to Directive 98/37/EC, 2006/42/EC We, YAMAHA MOTOR CO., LTD. 2500 Shingai, Iwata, Japan, declare in sole responsibility, that the product YFM700FWAD (YFM7FGP) (JY4AM09W090027076–)
  • Page 5 Congratulations on your purchase of the Yamaha YFM7FGPZ/YFM7FGPHZ/YFM700FAPZ. This ATV rep- resents the result of many years of Yamaha experience in the production of fine sporting, touring, and pac- esetting racing machines. With the purchase of this Yamaha, you can now appreciate the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
  • Page 6 EBU17330 IMPORTANT MANUAL INFORMATION EBU17342 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERIOUS IN- JURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential per- sonal injury hazards.
  • Page 7 Please check your local riding laws and regulations before operating this ATV. EBU17390 YFM7FGPZ/YFM7FGPHZ/YFM700FAPZ OWNER’S MANUAL ©2009 by Yamaha Motor Co., Ltd. 1st edition, February 2009 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.
  • Page 8 EBU17420 TABLE OF CONTENTS LOCATION OF THE WARNING AND Storage compartments ......4-18 SPECIFICATION LABELS ......1-1 Front carrier ..........4-21 Rear carrier ..........4-21 SAFETY INFORMATION ......2-1 Adjusting the front and rear shock absorber assemblies .......4-21 DESCRIPTION ..........3-1 Auxiliary DC jack ........4-23 Left view ............
  • Page 9 Parking ............6-5 Removing and installing panels ....8-8 Parking on a slope ........6-5 Removing the radiator grills ......8-19 Accessories and loading ......6-6 Checking the spark plug ......8-20 Engine oil and oil filter cartridge ....8-22 RIDING YOUR ATV ........7-1 Final gear oil ..........8-26 GETTING TO KNOW YOUR ATV....
  • Page 10 Checking and lubricating the brake pedal ............8-51 Checking the wheel hub bearings .... 8-52 Checking the stabilizer bushes ....8-52 Lubricating the rear knuckle pivots ... 8-52 Lubricating the steering shaft ....8-52 Battery ............8-53 Replacing a fuse ........8-56 Replacing a headlight bulb .......
  • Page 11 Read and understand all of the labels on your ATV. These labels contain important information for safe and proper operation. Never remove any labels from your ATV. If a label becomes difficult to read or comes off, request a replace- ment label from your Yamaha dealer. For Europe...
  • Page 12 < 5880 N < 600 kgf < < 45 kg 1322 lbf < 147 N < 15 kgf ( 99 lbs) < 33 lbf 43P-2817S-00 43P-2817R-00 35.0 kPa 30.0 kPa 43P-2816P-00 0.35 kgf/cm² 0.30 kgf/cm² 5.0 psi 4.4 psi 28P-2816M-M0 <...
  • Page 13 YEAR OF CONSTRUCTION : 2009 YAMAHA MOTOR CO., LTD. 2500 SHINGAI, IWATA, JAPAN 5PG-2817L-10 < 0.5 kg ( 1 lb ) 4D3-2816L-20 43P-2816N-00...
  • Page 14 43P-2816S-00 43P-2816R-00...
  • Page 15 Familiarize yourself with the following pictograms and read the explanatory text, then make sure to check the pictograms that apply to your model. Read the Owner’s manual. NEVER permit children under age 12 to operate this ATV. Operation of this ATV by children under the age of 12 increases the risk of severe injury or death.
  • Page 16 NEVER use with drugs or alcohol. Adjust tire pressure. Improper tire pressure can cause loss of control. Loss of control can result in severe injury or death. **.* kPa **.* kPa *.** kgf/cm² *.** kgf/cm² *.* psi *.* psi NEVER store fuel or flammable liquids. Turning 4WD-LOCK (“DIFF.LOCK”) takes more effort.
  • Page 17 This pictogram shows trailer Hitch Tow weight limit. (Combined weight of the trailer and all cargo in the trailer.) Overloading can cause loss of control. Loss of control can result in severe injury or death. This pictogram shows trailer Hitch Tongue weight limit.
  • Page 18 For Oceania...
  • Page 19 MAXIMUM LOADING LIMIT LOAD LIMIT PULLING LOAD: 5880 N (600 kgf) 1322 lbf 45 kg{99 lbs} TONGUE WEIGHT: 147 N ( 15 kgf) 33 lbf 3GC-24877-A0 43P-2151K-00 WARNING NEVER ride as a passenger. Passengers can cause a loss of control, resulting in SEVERE INJURY or DEATH.
  • Page 20 1-10...
  • Page 21 1-11...
  • Page 22 EBU17431 SAFETY INFORMATION EBU27251 Never carry a passenger on an ATV. Always avoid operating an ATV on any paved AN ATV IS NOT A TOY AND CAN BE HAZARD- surfaces, including sidewalks, driveways, park- OUS TO OPERATE. ing lots and paved streets. An ATV handles differently from other vehicles, in- Never operate an ATV on any paved street, cluding motorcycles and cars.
  • Page 23 Always inspect your ATV each time you use it to Always follow proper procedures for climbing make sure it is in safe operating condition. Al- hills as described in this manual. Check the ter- ways follow the inspection and maintenance rain carefully before you start up any hill.
  • Page 24 steady speed when climbing a hill. If you stall or Always be sure there are no obstacles or people roll backwards, follow the special procedure for behind you when you operate in reverse. When braking described in this manual. Dismount on it is safe to proceed in reverse, go slowly.
  • Page 25 and you can quickly be overcome and unable to save yourself. Also, deadly levels of carbon monoxide can linger for hours or days in en- closed or poorly ventilated areas. If you experi- ence any symptoms of carbon monoxide poisoning, leave the area immediately, get fresh air, and SEEK MEDICAL TREATMENT.
  • Page 26 EBU17680 DESCRIPTION EBU17690 EBU17700 Left view Right view 1. Radiator cap 1. Rear shock absorber assembly spring preload adjusting ring 2. Battery 2. Rear storage compartment and tool kit 3. Fuses 3. Fuel tank cap cover 4. Air filter case 4.
  • Page 27 EBU17712 Controls and instruments The ATV you have purchased may differ slightly from the figures shown in this manual. 1. Drive select lever 2. Rear brake lever 3. Handlebar switches 4. Horn switch 5. Rear brake fluid reservoir 6. Multifunction display 7.
  • Page 28 EBU17733 INSTRUMENT AND CONTROL FUNCTIONS EBU17760 Main switch The positions of the main switch are as follows: All electrical systems are supplied with power. The headlights and taillight come on when the light switch is on, and the engine can be started. The key cannot be removed.
  • Page 29 “ON”, or if the warning light re- indicator “ ”/“ ” mains on, have a Yamaha dealer check the electri- 8. Engine trouble warning light “ ” cal circuit. 9. Coolant temperature warning light “...
  • Page 30 If the warning light does not come on initially when NOTICE the key is turned to “ON”, or if the warning light re- mains on, have a Yamaha dealer check the electri- The engine may overheat if the ATV is over- cal circuit.
  • Page 31 If the steering load is too heavy (i.e., excessive the indicator light continue to flash, the differen- steering use when the ATV is traveling at a slow tial is not locked. In this case, start moving to al- speed), the power assist is reduced to protect low time for the differential to lock.
  • Page 32 EBU27298 an hour meter (which shows the total time the Multi-function display engine has been running) a fuel meter a self-diagnosis device Odometer and tripmeter modes Pushing the “SELECT” button switches the display between the odometer mode “ODO” and the trip- meter modes “TRIP A”...
  • Page 33 2. Push the “SELECT” button and “RESET” but- ing indicator will start flashing. If this occurs, have ton together for at least three seconds. a Yamaha dealer check the electrical circuit. 3. When the hour digits start flashing, push the “RESET” button to set the hours.
  • Page 34 5. Horn switch “ ” If the multi-function display indicates an error code, EBU18080 note the code number, and then have a Yamaha Engine stop switch “ ” dealer check the vehicle. Set this switch to “...
  • Page 35 EBU18101 EBU18190 Start switch “ ” Override switch “OVERRIDE” Push this switch to crank the engine with the start- er. See the starting instructions on page 6-1 prior to starting the engine. EBU18152 Light switch “ /OFF” Set this switch to “ ”...
  • Page 36 In moving may cause the ATV to unexpectedly this case, take the ATV to a Yamaha dealer at the handle differently. This could distract the oper- first opportunity.
  • Page 37 “4WD” (four-wheel drive): Power is supplied to EBU18255 On-Command differential gear lock switch the rear and front wheels. “4WD”/“LOCK” To change from two-wheel drive to four-wheel EWB00131 drive, stop the ATV and push the switch in to the WARNING “4WD” position.
  • Page 38 control and have an accident if you cannot make a sharp enough turn for the speed you are traveling. This ATV is equipped with a switch allowing you to lock the differential gear when in four-wheel drive. Select the appropriate switch position according to the terrain and the conditions.
  • Page 39 LOCK 1. Differential gear lock lever 1. On-Command differential gear lock switch “4WD”/“LOCK” 2. On-Command four-wheel-drive switch “2WD”/“4WD” To release the differential gear lock, stop the ATV Stop the ATV, move the differential gear lock lever and push the switch to the “4WD” position. to position (a), and then push the differential gear lock switch in to the “LOCK”...
  • Page 40 Riding before the differential gear lock is proper- ly engaged (e.g., when the indicator and indica- tor light are flashing) will cause the vehicle speed to be limited until engagement is com- plete. When the ATV is in four-wheel-drive differential gear lock, the maximum traveling speed is limit- ed to 35 km/h (22 mi/h).
  • Page 41 crease the maximum engine power available EBU18391 Front brake lever and the maximum speed of the ATV, turn the The front brake lever is located on the right handle- adjusting screw in direction (b). Do not turn bar. To apply the front brake, pull the brake lever the adjusting screw out more than 12 mm toward the handlebar grip.
  • Page 42 EBU18611 Drive select lever The drive select lever is used to shift your ATV into the low-range, high-range, neutral, reverse and park positions. See the “Operating the drive select lever and driving in reverse” section on page 6-2 for the drive select lever operation. 1.
  • Page 43 To install the fuel tank cap Install the fuel tank cap by turning it clockwise until a click is heard, and then close the fuel tank cap cover. EBU18753 Fuel Make sure there is sufficient gasoline in the tank. EWB02521 WARNING Gasoline and gasoline vapors are extremely flammable.
  • Page 44 expands when it heats up, heat from the en- 3. Wipe up any spilled fuel immediately. gine or the sun can cause fuel to spill out of NOTICE: Immediately wipe off spilled fuel the fuel tank. with a clean, dry, soft cloth, since fuel may deteriorate painted surfaces or plastic parts.
  • Page 45 If knocking (or pinging) occurs, use a gasoline of a To install the seat different brand. Use of unleaded fuel will extend Insert the projections on the front of the seat into spark plug life and reduce maintenance costs. the seat holders and push down on the seat at the rear.
  • Page 46 ECB00830 NOTICE Do not store metal or sharply edged objects, like tools, in the storage compartments. If they must be stored, wrap them in appropriate cushion material to prevent damaging the stor- age compartments. The front storage compartment is located at the front right side of the ATV.
  • Page 47 When storing any documents in the storage com- partments, be sure to wrap them in a plastic bag so that they will not get wet. When washing the ATV, be careful not to let any water enter the storage compartments. Do not exceed the load limit of 0.5 kg (1 lb) for the front storage compartment or 2.0 kg (4 lb) for the rear storage compartment.
  • Page 48 EBU18962 Front carrier Do not exceed the load limit of 45.0 kg (99 lb) for the front carrier. Do not exceed the maximum load of 220.0 kg (485 lb) for the ATV. EBU18972 Rear carrier Do not exceed the load limit of 85.0 kg (187 lb) for the rear carrier.
  • Page 49 1. Special wrench Spring preload setting: Minimum (soft): Standard: 1. Spring preload adjusting ring Maximum (hard): 2. Position indicator A special wrench can be obtained at a Yamaha dealer to make this adjustment. 4-22...
  • Page 50 EBU19181 Auxiliary DC jack The auxiliary DC jack is located at the front right side of the ATV. The auxiliary DC jack can be used for suitable work lights, radios, etc. The auxiliary DC jack should only be used when the engine is running.
  • Page 51 If accessories are used without the engine running or with the headlights turned on, the battery will lose its charge and engine start- ing may become difficult. Do not use an automotive cigarette lighter or other accessories with a plug that gets hot because the jack can be damaged.
  • Page 52 Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 53 ITEM ROUTINE PAGE • Check operation. If soft or spongy, have Yamaha dealer bleed hy- draulic system. • Check brake pads for wear, and replace if necessary. Front brake 5-3, 8-43, 8-45, 8-46 • Check brake fluid level in reservoir, and add recommended brake fluid to specified level if necessary.
  • Page 54 They should move smoothly and there specified level. Add oil as necessary. (See page should be a firm feeling when the brakes are ap- 8-28.) plied. If not, have a Yamaha dealer check the brake system. EBU19631 Coolant Brake fluid level Make sure that the coolant is at the specified level.
  • Page 55 (See page 8-43.) pressures to the following specifications: EBU19761 Throttle lever Check the operation of the throttle lever. It must open smoothly and spring back to the idle position when released. Have a Yamaha dealer correct if necessary.
  • Page 56 Recommended tire pressure: Front 35.0 kPa (0.350 kgf/cm², 5.0 psi) Rear 30.0 kPa (0.300 kgf/cm², 4.4 psi) Minimum tire pressure: Front 32.0 kPa (0.320 kgf/cm², 4.6 psi) Rear 27.0 kPa (0.270 kgf/cm², 4.0 psi) Maximum tire seating pressure: 1. Low-pressure tire gauge Front 250 kPa (2.5 kgf/cm², 36 psi) Tire wear limit...
  • Page 57 The tires and rims that came with your ATV were After extensive tests, only the tires listed below designed to match the performance capabilities have been approved for this model by Yamaha and to provide the best combination of handling, Motor Co., Ltd.
  • Page 58 EBU19840 Chassis fasteners Make sure that all nuts, bolts and screws are prop- erly tightened. EBU19850 Instruments, lights and switches Check that all instruments, lights and switches are working properly. Correct if necessary.
  • Page 59 The corresponding indicator light should EBU27345 Starting the engine come on. If the indicator light does not come on, have a Yamaha dealer check the electrical ECB00150 NOTICE circuit. See the “Engine break-in” section on page 6-4 prior to operating the engine for the first time.
  • Page 60 The rear brake lever or brake pedal is applied EBU20441 Operating the drive select lever and with the drive select lever in any position. How- driving in reverse ever, it is recommended to shift into the neutral or park position before starting the engine. ECB00170 NOTICE 3.
  • Page 61 reverse, make sure there are no people or ob- stacles behind you. When it is safe to proceed, go slowly. 1. Bring the ATV to a complete stop. 2. Apply the brake pedal. The drive select lever cannot be shifted into or from reverse or park without applying the brake pedal.
  • Page 62 320 km (200 mi) or 20 should come on. If the indicator light does not hours. The various parts in the engine wear and come on, have a Yamaha dealer check the elec- polish themselves to the correct operating clear- trical circuit.
  • Page 63 If any engine trouble should occur during the steep you could not walk up them easily. engine break-in period, immediately have a 1. Bring the ATV to a stop by applying the Yamaha dealer check the ATV. brakes. 2. Stop the engine. EBU27321 Parking 3.
  • Page 64 Yamaha ability to control the ATV. vehicles. Yamaha is not in a position to test the Do not mount an accessory where it could inter- products that these aftermarket companies pro- fere with your ability to control the ATV.
  • Page 65 bulky object attached to the handlebars which Never exceed the weight limits shown. An over- could make steering difficult, an accessory that loaded ATV can be unstable. limits your ability to move around on the seat, or MAXIMUM LOADING LIMIT one that limits your view.
  • Page 66 just the load in the trailer, if necessary, to reduce the weight on the hitch. If you are carrying cargo and towing a trailer, include the tongue weight in the maximum ATV load limit. Load cargo on the carriers as close to the center of the ATV as possible.
  • Page 67 EBU21141 RIDING YOUR ATV...
  • Page 68 EBU27416 RIDE WITH CARE AND GOOD JUDGMENT Get training if you are inexperienced. GETTING TO KNOW YOUR ATV EWB01381 This ATV is mainly for utility use, but may also be WARNING used for recreation. This section, Riding your ATV, Do not operate this ATV or allow anyone else provides general ATV riding instructions for recre- to operate it without proper instruction.
  • Page 69 Riding your ATV requires skills acquired through practice over a period of time. Do not attempt to operate at maximum perfor- mance until you are totally familiar with the ATV’s handling and performance characteristics. Take the time to learn the basic techniques well before attempting more difficult maneuvers.
  • Page 70 Apparel Always wear the following to reduce risk of injury in an accident: Approved motorcycle helmet that fits properly Eye protection (goggles, helmet face shield, or protective eyewear) Over-the-ankle boots, gloves, long-sleeved shirt or jacket, and long pants An approved helmet and other personal protective equipment can reduce the severity of injuries in an accident.
  • Page 71 1. Protective clothing Pre-operation checks 2. Goggles Always inspect your ATV each time you use it to 3. Gloves make sure the ATV is in safe operating condition. 4. Boots 5. Helmet Perform the pre-operation checks listed on page 5-1. Always follow the inspection and maintenance Do not operate after or while consuming alco- procedures and schedules described in the Own- hol or drugs.
  • Page 72 opening, even when the throttle lever is pushed to EWB01461 WARNING the maximum. Turning in the adjusting screw limits the maximum engine power available and de- Improper loading or towing can increase the creases the maximum speed of the ATV. Turning risk of loss of control, an overturn, or other ac- in the adjusting screw decreases top speed, and cident.
  • Page 73 During operation MAXIMUM LOADING LIMIT Always keep your feet on the footboards during op- ATV loading limit (total weight of cargo, rider, eration; otherwise, they may contact the rear accessories, and tongue): wheels. WARNING! Removing even one hand 220.0 kg (485 lb) or foot can reduce your ability to control the Front carrier: ATV or could cause you to lose your balance...
  • Page 74 ATV should be during operation or after leaving the ATV, do not let genuine Yamaha or equivalent components de- brush, grass and other materials collect under the signed for use on this ATV and should be installed vehicle, near the muffler or exhaust pipe, or next to and used according to instructions.
  • Page 75 To prevent burns, avoid touching the exhaust sys- BE CAREFUL WHERE YOU RIDE tem. Park the ATV in a place where pedestrians or This ATV is designed for use on unpaved surfaces children are not likely to touch it. only. WARNING! Paved surfaces may seriously affect handling and control of the ATV, and may cause the ATV to go out of control.
  • Page 76 While riding on unpaved public streets or roads Know the terrain where you ride. Ride cautiously in may be legal in your area, such operation can in- unfamiliar areas. Stay alert for holes, rocks, or crease the risk of collision with other vehicles. roots in the terrain, and other hidden hazards Watch carefully for other vehicles.
  • Page 77 Do not operate on rough, slippery, or loose terrain When riding in an area where you might not easily until you have learned and practiced the skills nec- be seen, such as desert terrain, mount a caution essary to control the ATV on such terrain. Always flag on the ATV.
  • Page 78 Do not ride in areas posted “no trespassing”. The centrifugal clutch will engage and you will start Do not ride on private property without getting per- to accelerate. If the throttle is applied too abruptly, mission. the front wheels may lift off the ground, resulting in a loss of directional control.
  • Page 79 at faster speeds. Do not turn at speeds too fast for your skills or the conditions. ATV could go out of control, causing a collision or overturn. To achieve maximum traction on unpaved surfac- es, the two rear wheels turn together at the same speed.
  • Page 80 Improper riding procedures such as abrupt throttle Never go over the top of any hill at high changes, excessive braking, incorrect body move- speed. An obstacle, a sharp drop, or another ments, or too much speed for the sharpness of the vehicle or person could be on the other side turn may cause the ATV to tip.
  • Page 81 Do not attempt to climb hills until you have mas- tered basic maneuvers on flat ground. Always check the terrain carefully before attempting any hill. In all cases avoid inclines with slippery or loose surfaces, or obstacles that might cause you to lose control.
  • Page 82 If you are climbing a hill and you find that you have uphill. Turn the ATV around and remount, following not properly judged your ability to make it to the the procedure described in the Owner’s Manual. top, you should turn the ATV around while you still WARNING! Stalling, rolling backwards or im- have forward motion (provided you have the room properly dismounting while climbing a hill...
  • Page 83 Always check the terrain carefully before Use caution while descending a hill with loose or you start down any hill. slippery surfaces. Braking ability and traction may Never operate the ATV on hills too steep for be adversely affected by these surfaces. Improper the ATV or for your abilities.
  • Page 84 Shift your weight to the uphill side of the ATV. Never attempt to turn the ATV around on any hill until you have mastered the turning tech- nique as described in the Owner’s Manual on level ground. Be very careful when turning on any hill.
  • Page 85 The ATV can be used to cross slow moving, shal- low water of up to a maximum of 35 cm (14 in) in depth. Before entering the water, choose your path carefully. Enter where there is no sharp drop off, and avoid rocks or other obstacles which may be slippery or upset the ATV.
  • Page 86 ability. WARNING! Wet brakes may have re- duced stopping ability, which could cause loss of control. [EWB02621] 1. Air filter case check hose After riding your ATV in water, be sure to drain the trapped water by removing the check hoses at the bottom of the air filter case.
  • Page 87 1. V-belt case drain plug 1. Storage compartment drain plug RIDING OVER ROUGH TERRAIN EWB01651 WARNING Riding improperly over obstacles could cause loss of control or a collision. Before operating in a new area, check for obstacles. Never at- tempt to ride over large obstacles, such as large rocks or fallen trees.
  • Page 88 cident. Be sure to keep your feet firmly mounted on the footboards at all times. Avoid jumping the ATV as loss of control and damage to the ATV may re- sult. SLIDING AND SKIDDING EWB01662 WARNING Skidding or sliding improperly may cause you to lose control of this ATV.
  • Page 89 WHAT TO DO... If your ATV doesn’t turn when you want it to: Bring the ATV to a stop and practice the turning maneuvers again. Be sure you are putting your weight on the footboard to the outside of the turn.
  • Page 90 If your ATV is traversing a sloping surface: Be sure to ride with your weight positioned to- wards the uphill side of the ATV to maintain proper balance. If the ATV starts to tip, steer down the hill (if there are no obstacles in your way) to regain balance.
  • Page 91 If you are not fa- EBU27111 miliar with vehicle service, have a Yamaha Owner’s manual and tool kit dealer perform the service. Be sure to put this owner’s manual in the plastic bag and to always carry it as well as the owner’s...
  • Page 92 However, additional tools such as a torque wrench may be necessary to perform certain maintenance work correctly. If you do not have the tools or experience required for a particular job, have a Yamaha dealer perform it for you.
  • Page 93 However, keep in mind that if the ATV isn’t used for a long period of time, the month maintenance intervals should be followed. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 94 EBU21864 General maintenance and lubrication chart INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 first (mi) (200) (800) (1600) (1600) (3200) hours Every 20–40 hours (more often in wet or Air filter element • Clean and replace if necessary. dusty areas) •...
  • Page 95 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 first (mi) (200) (800) (1600) (1600) (3200) hours • Check for looseness or damage, and replace if √ √ √ √ Wheel hub bearings necessary. • Check for wear, cracks or other damage, and re- √...
  • Page 96 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 first (mi) (200) (800) (1600) (1600) (3200) hours • Change. √ √ Differential gear oil • Check ATV for oil leakage, and correct if neces- sary. •...
  • Page 97 EBU23071 Some maintenance items need more frequent service if you are riding in unusually wet, dusty, sandy or muddy areas, or at full-throttle. Hydraulic brake service • Regularly check and, if necessary, correct the brake fluid level. • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid.
  • Page 98 EBU23090 Removing and installing panels The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1. Panel E 2.
  • Page 99 Panel B To remove the panel 1. Remove panel A. 2. Remove the front carrier by removing the bolts. 1. Panel A To install the panel Place the panel in the original position. 1. Carrier bolt (under the fenders)
  • Page 100 1. Carrier bolt (top) 1. Front carrier stay bolt 3. Remove the front carrier stays by removing 4. Remove the quick fasteners, and then pull the the bolts. panel upward to remove it. 1. Front carrier stay 8-10...
  • Page 101 1. Panel B 2. Install the front carrier stays by installing the 2. Quick fastener bolts and tightening them to the specified torque. To install the panel 1. Place the panel in the original position, and Tightening torque: then install the quick fasteners. Front carrier stay bolt: 34 Nm (3.4 m·kgf, 24 ft·lbf) 3.
  • Page 102 Tightening torques: Carrier bolt (top): 26 Nm (2.6 m·kgf, 19 ft·lbf) Carrier bolt (under the fenders): 7 Nm (0.7 m·kgf, 5.1 ft·lbf) 4. Install panel A. Panel C To remove the panel 1. Remove the seat. (See page 4-18.) 1. Panel C 2.
  • Page 103 1. Panel D 2. Install panel A. 2. Quick fastener screw 3. Install the seat. Panels D and E To remove one of the panels 1. Remove panel C. 2. Remove the quick fastener screw and bolt, and then pull the panel upward to remove it. To ease removal of panel D, shift the drive select lever into the reverse position.
  • Page 104 To install one of the panels 1. Place the panel in the original position, and then install the bolt and quick fastener screw. 1. Panel E 2. Quick fastener screw 1. Bolt 2. Install panel C. 8-14...
  • Page 105 Panel F To remove the panel Pull outward on the areas shown. Panels G and H To remove one of the panels Remove the nut and bolts, and then pull the panel 1. Panel F downward while pushing the projection. To install the panel Place the panel in the original position.
  • Page 106 1. Panel G 1. Panel H 2. Nut 2. Nut 3. Bolt 3. Bolt 4. Projection 4. Projection To install one of the panels Place the panel in the original position, and then in- stall the bolts and nut. 8-16...
  • Page 107 2. Remove the rear carrier by removing the bolts. 1. Carrier bolt (under the fenders) Panel I To remove the panel 1. Carrier bolt (upper) 1. Remove the seat. (See page 4-18.) 8-17...
  • Page 108 1. Panel I 1. Carrier bolt (lower) 2. Quick fastener 3. Remove the quick fasteners, and then push inward on the areas shown. To install the panel 1. Place the panel in the original position, and then install the quick fasteners. 8-18...
  • Page 109 EBU28671 Removing the radiator grills The radiator grills can be removed to access the radiator for cleaning. To remove a radiator grill Remove the quick fastener, pull the radiator grill outward at the top, and then pull it upward. 2. Install the rear carrier by installing the bolts and tightening them to the specified torques.
  • Page 110 EBU23211 2. Remove the spark plug as shown, with the Checking the spark plug spark plug wrench included in the owner’s tool The spark plug is an important engine component, kit. which is easy to check. Since heat and deposits will cause any spark plug to slowly erode, the spark plug should be removed and checked in accor- dance with the periodic maintenance and lubrica-...
  • Page 111 If the spark plug shows a distinctly different color, the engine could be operating improperly. Do not attempt to diagnose such problems yourself. In- stead, have a Yamaha dealer check the ATV. 2. Check the spark plug for electrode erosion and excessive carbon or other deposits, and replace it if necessary.
  • Page 112 3. Remove panel F. (See page 8-8.) 4. Remove the engine oil dipstick, and then wipe If a torque wrench is not available when installing it off with a clean rag. a spark plug, a good estimate of the correct torque is 1/4–1/2 turn past finger tight.
  • Page 113 To change the engine oil (with or without oil fil- ter cartridge replacement) 1. Place the ATV on a level surface. 2. Remove panel F. (See page 8-8.) 3. Place an oil pan under the engine to collect the used oil. 4.
  • Page 114 Make sure that the O-ring is properly seated. 8. Install the new oil filter cartridge with an oil fil- ter wrench, and then tighten it to the specified An oil filter wrench is available at a nearby Yamaha torque with a torque wrench. dealer.
  • Page 115 11. Refill with the specified amount of the recom- mended engine oil, and then insert the dip- stick completely into the oil filler hole. Recommended oil: See page 10-1. Oil quantity: Without oil filter cartridge replacement: 2.00 L (2.11 US qt, 1.76 Imp.qt) With oil filter cartridge replacement: 2.10 L (2.22 US qt, 1.85 Imp.qt) 1.
  • Page 116 If any leakage is found, have 1. Final gear oil a Yamaha dealer check and repair the ATV. In ad- 2. Final gear oil level check bolt dition, the final gear oil level must be checked and 3.
  • Page 117 3. Remove the final gear oil filler bolt, final gear oil level check bolt, and the final gear oil drain bolt to drain the oil from the final gear case. 1. Final gear oil filler bolt 4. Install the oil level check bolt and oil filler bolt, and then tighten them to the specified torques.
  • Page 118 The differential gear case must be checked for oil leakage before each ride. If any leakage is found, have a Yamaha dealer check and repair the ATV. In addition, the differential gear oil level must be checked and the oil changed as follows at the in- tervals specified in the periodic maintenance and lubrication chart.
  • Page 119 2. Place an oil pan under the differential gear case to collect the used oil. 3. Remove the differential gear oil filler bolt and the differential gear oil drain bolt to drain the oil from the differential gear case. 1. Differential gear oil 2.
  • Page 120 5. Refill with the recommended differential gear Tightening torque: oil to the brim of the filler hole as shown. Differential gear oil filler bolt: NOTICE: Be sure no foreign material en- 23 Nm (2.3 m·kgf, 17 ft·lbf) ters the differential gear case. [ECB00411] 7.
  • Page 121 If water has been added to the coolant, have a Yamaha dealer check the antifreeze con- tent of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced.
  • Page 122 3. Place a container under the engine, and then Coolant reservoir capacity (up to the maximum remove the coolant drain bolt. (Use a trough level mark): or a similar object as shown to prevent coolant 0.24 L (0.25 US qt, 0.21 Imp.qt) from spilling on the engine guard.) The radiator fan is automatically switched on or off according to the coolant temperature in the...
  • Page 123 6. Remove the coolant reservoir cap. 7. Disconnect the hose on the coolant reservoir side, and then drain the coolant from the cool- ant reservoir. 1. Trough 4. Remove panel B. (See page 8-8.) 5. Remove the radiator cap. 1. Coolant reservoir hose 8.
  • Page 124 10. Connect the coolant reservoir hose. 13. Loosen the water pump air bleed bolt, without 11. Pour the recommended coolant into the radia- removing it, to allow all of the air to escape tor until it is full. from the air bleed bolt hole. 12.
  • Page 125 1. V-belt cooling duct 1. Cylinder head air bleed bolt 2. Clamp screw 18. When coolant begins to flow out of the bolt 17. Loosen the cylinder head air bleed bolt, with- hole, tighten the cylinder head air bleed bolt to out removing it, to allow all of the air to escape the specified torque.
  • Page 126 23. Start the engine, and then check for coolant leakage. If any leakage is found, have a Yamaha dealer check the cooling system. 24. Install the V-belt cooling duct, and then tighten the clamp screw.
  • Page 127 1. Air filter case check hose 1. Air filter case cover holder 2. Air filter case cover 1. Place the ATV on a level surface. 4. Remove the sponge material and the mesh 2. Remove panel C. (See page 8-8.) from the air filter case.
  • Page 128 2. Air filter mesh damaged. 5. Clean the mesh with solvent, and then wipe 9. Apply Yamaha foam air filter oil or other qual- the solvent off. ity foam air filter oil to the sponge material. 6. Wash the sponge material gently, but thor- oughly, in solvent.
  • Page 129 engine damage. Additionally, operation without the air filter element will affect the fuel injection system with subsequent poor performance and possible engine overheating. [ECB00761] 11. Insert the projections on the air filter case cov- er into the holders on the air filter case, and then install the air filter case cover by hooking the holders onto the cover.
  • Page 130 EBU27810 Cleaning the spark arrester Select a well-ventilated area free of combustible materials and make sure the exhaust and muffler are cool. 1. Remove the bolts. 1. Tailpipe 2. Spark arrester 3. Gasket 4. Install the gasket, and then insert the tailpipe into the muffler and align the bolt holes.
  • Page 131 9. Install the purging bolt and tighten it to the specified torque. If water drains from the V-belt case after removing Tightening torque: the plug, have a Yamaha dealer check the ATV as Purging bolt: the water may affect other engine parts. 27 Nm (2.7 m·kgf, 19 ft·lbf)
  • Page 132 3. To increase the throttle cable free play, turn the throttle cable free play adjusting bolt in di- rection (a). To decrease the throttle cable free play, turn the adjusting bolt in direction (b). 1. V-belt case drain plug EBU29700 Adjusting the throttle cable free play The throttle cable free play should be checked 1.
  • Page 133 Yamaha dealer at the inter- vals specified in the periodic maintenance and lu- EBU27470 brication chart.
  • Page 134 Each brake hose protector is provided with a wear indicator. If a protector wears to the point that its indicator be- comes visible, have a Yamaha dealer replace the protector. The wheels need to be removed to check the 1.
  • Page 135 Front brake 1. Rear brake hose protector 1. Minimum level mark 2. Wear indicator 3. Protector is normal. Rear brake 4. Protector is worn. EBU24251 Checking the brake fluid level Insufficient brake fluid may allow air to enter the brake system, possibly causing it to become inef- fective.
  • Page 136 EBU24291 Changing the brake fluid When checking the fluid level, make sure that Have a Yamaha dealer change the brake fluid at the top of the brake fluid reservoir is level. the intervals specified in the TIP after the periodic Use only the recommended quality brake fluid, maintenance and lubrication chart.
  • Page 137 Front brake EBU29072 Adjusting the brake pedal free play The brake pedal free play must be adjusted at the intervals specified in the periodic maintenance and lubrication chart. Always perform this maintenance completely in the following order whenever adjusting the rear brake.
  • Page 138 1. Brake pedal free play 1. Locknut 2. Brake pedal free play adjusting nut 1. Remove panel H. (See page 8-8.) 4. Tighten the locknut. 2. Loosen the locknut. 5. After adjusting, there should be slight play at 3. Turn the brake pedal free play adjusting nut in the brake pedal cable joint as shown.
  • Page 139 Check the axle boots for tears or damage. If any damage is found, have them re- placed by a Yamaha dealer. 1. Brake pedal cable joint 2. Slight play 6. Install the panel.
  • Page 140 If a cable is damaged or does not move The operation of the front and rear brake levers smoothly, have a Yamaha dealer check or replace should be checked before each ride, and the lever pivots should be lubricated if necessary.
  • Page 141 Front brake lever EBU28832 Checking and lubricating the brake pedal The operation of the brake pedal should be checked before each ride, and the pedal pivot should be lubricated if necessary. To access the brake pedal pivot, remove panel H. (See page 8-8.) Recommended lubricant: Lithium-soap-based grease...
  • Page 142 If there is play in a wheel hub or if a wheel does not turn smoothly, have a Yamaha dealer check the wheel hub bear- ings. EBU25021 Checking the stabilizer bushes The stabilizer bushes must be checked for cracks 1.
  • Page 143 EBU29045 Batteries produce explosive gases. Keep Battery sparks, flame, cigarettes or other sources of ig- This model is equipped with a VRLA (Valve Regu- nition away. Ventilate when charging or using lated Lead Acid) battery. There is no need to check in an enclosed space.
  • Page 144 4. Disconnect the negative battery lead first, To charge the battery then the positive battery lead by removing Have a Yamaha dealer charge the battery as soon their bolt. NOTICE: When removing the bat- as possible if it seems to have discharged. Keep in...
  • Page 145 ECB00940 NOTICE Always keep the battery charged. Storing a dis- charged battery can cause permanent battery damage. To install the battery Be sure the battery is fully charged. 1. Place the battery in its compartment. 1. Positive battery lead (red) 2.
  • Page 146 EBU27751 Replacing a fuse 1. Ignition fuse 2. Headlight fuse 1. Fuse box 3. Four-wheel-drive motor fuse 2. Main/EPS spare fuse 4. Radiator fan fuse 3. Main fuse 5. Signaling system fuse 4. EPS fuse 6. Auxiliary DC jack fuse 5.
  • Page 147 15.0 A EPS fuse: 40.0 A 3. Turn the key to “ON” and turn on the electrical circuits to check if the devices operate. 4. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 8-57...
  • Page 148 EBU27442 Replacing a headlight bulb If a headlight bulb burns out, replace it as follows. 1. Remove the cover at the rear of the headlight by pulling it off. 1. Headlight bulb cover 3. Disconnect the headlight coupler. 1. Cover at the rear of the headlight 2.
  • Page 149 Adjusting a headlight beam versely affected. Thoroughly clean off any ECB00690 dirt and fingerprints on the headlight bulb NOTICE using a cloth moistened with alcohol or It is advisable to have a Yamaha dealer make thinner. [ECB00651] this adjustment. 8-59...
  • Page 150 To raise a headlight beam, turn the headlight beam adjusting screw in direction (a). To lower a headlight beam, turn the adjusting screw in direction (b). 1. Tail/brake light bulb holder 3. Remove the burnt-out bulb by pushing it in and turning it counterclockwise.
  • Page 151 4. Insert a new bulb into the bulb holder, push it EBU25701 Installing a wheel in, and then turn it clockwise until it stops. 1. Place the ATV on a level surface. 5. Install the bulb holder (together with the bulb) 2.
  • Page 152 The following troubleshooting charts represent quick and easy procedures for checking these vital systems yourself. However, should your ATV re- quire any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, expe- 1. Tapered nut rience, and know-how to service the ATV properly.
  • Page 153 Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the ATV. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 154 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the rec- ommended coolant as soon as possible.
  • Page 155 EBU25860 CLEANING AND STORAGE EBU25881 tion of wheel bearings, brakes, transmis- Cleaning sion seals and electrical devices. Many Frequent, thorough cleaning of your ATV will not expensive repair bills have resulted from only enhance its appearance but will improve its improper high-pressure detergent applica- general performance and extend the useful life of tions such as those available in coin-oper-...
  • Page 156 EBU27261 3. Perform the following steps to protect the cyl- Storage inder, piston rings, etc. from corrosion. a. Remove the spark plug cap and spark Short-term plug. Always store your ATV in a cool, dry place and, if b. Pour a teaspoonful of engine oil into the necessary, protect it against dust with a porous spark plug bore.
  • Page 157 6. Cover the muffler outlet with a plastic bag to prevent moisture from entering it. 7. Remove the battery and fully charge it. Store it in a cool, dry place and charge it once a month. Do not store the battery in an exces- sively cold or warm place [less than 0 °C (30 °F) or more than 30 °C (90 °F)].
  • Page 158 EBU25960 SPECIFICATIONS Dimensions: Engine: Overall length: Engine type: 2065 mm (81.3 in) Liquid cooled 4-stroke, SOHC Overall width: Cylinder arrangement: 1180 mm (46.5 in) Forward-inclined single cylinder Overall height: Displacement: 1240 mm (48.8 in) 686 cm³ Bore × stroke: Seat height: 102.0 ×...
  • Page 159 Type: Quantity: SAE 5W-30 or SAE 10W-40 or SAE 20W-50 0.22 L (0.23 US qt, 0.19 Imp.qt) Cooling system: Coolant reservoir capacity (up to the maximum level mark): 0.24 L (0.25 US qt, 0.21 Imp.qt) 50 ˚C Radiator capacity (including all routes): 1.99 L (2.10 US qt, 1.75 Imp.qt) Air filter: SAE 5W-30...
  • Page 160 Transmission: Manufacturer/model: YFM700FAPZ CHENG SHIN/C828-4P Primary reduction system: YFM7FGPHZ DUNLOP/KT421 V-belt YFM7FGPZ DUNLOP/KT421 Secondary reduction system: Rear tire: Shaft drive Secondary reduction ratio: Type: 41/21 × 24/18 × 33/9 (9.544) Tubeless Transmission type: Size: V-belt automatic AT25 x 10-12 Operation: Manufacturer/model: Left hand operation YFM700FAPZ CHENG SHIN/C828-4P...
  • Page 161 Rim size: Spring/shock absorber type: 12 x 6.0AT Coil spring/oil damper Rear wheel: Wheel travel: 230 mm (9.1 in) Wheel type: Electrical system: Panel wheel Rim size: Ignition system: 12 x 7.5AT TCI (digital) Front brake: Charging system: AC magneto Type: Battery: Dual disc brake...
  • Page 162 Engine trouble warning light: Radiator fan fuse: 20.0 A EPS warning light: Park indicator light: On-Command four-wheel-drive/differential gear lock indicator: High-range indicator light: Low-range indicator light: Differential gear lock indicator light: Fuses: Main fuse: 40.0 A Fuel injection system fuse: 15.0 A EPS fuse: 40.0 A...
  • Page 163 Yamaha dealer or for ref- erence in case the ATV is stolen. KEY IDENTIFICATION NUMBER: VEHICLE IDENTIFICATION NUMBER: 1.
  • Page 164 EBU26050 Model label The model label is affixed at the location in the il- lustration. Record the information on this label in the space provided. This information will be need- ed when ordering spare parts from a Yamaha deal- 11-2...
  • Page 165 1. Model label 11-3...
  • Page 166 INDEX Drive select lever ............4-15 Drive select lever and driving in reverse ......6-2 Accessories and loading ..........6-6 Drive select lever safety system cable, adjusting ..8-43 Accessories, auxiliary jack ........... 4-23 Air filter element, cleaning ..........8-36 Axle boots ..............
  • Page 167 Key identification number ..........11-1 Safety information ............2-1 Seat ................4-18 Shock absorber assemblies, adjusting the front and Label locations ............... 1-1 rear ................4-21 Light switch ..............4-8 Spark arrester, cleaning ..........8-40 Low-range indicator light ..........4-4 Spark plug, checking ...........
  • Page 168 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2009.02-0.4×1 CR...

This manual is also suitable for:

Grizzly 700 fi yfm7fgphz 2009Grizzly 700 fi yfm700fapz 2009Grizzly 700 fi yfm700fwad 2009Grizzly 700 fi yfm7fgp 2009Grizzly 700 fi yfm7fgph 2009
