READ THIS MANUAL CAREFULLY!
It contains important safety information.
OWNER'S MANUAL
YFM7FGPY
WARNING
This ATV should not be ridden by anyone under 16 years of age.
LIT-11626-22-42
43P-28199-10

Advertisement

Table of Contents
loading

Related Manuals for Yamaha Grizzly 700FI

Summary of Contents for Yamaha Grizzly 700FI

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YFM7FGPY WARNING This ATV should not be ridden by anyone under 16 years of age. LIT-11626-22-42 43P-28199-10...
  • Page 2 EBU17092 Read this manual carefully before operating this vehicle. This manual should stay with this ve- hicle if it is sold.
  • Page 3 Yamaha experience in the production of fine sporting, touring, and pace-setting racing machines. With the purchase of this Yamaha, you can now appreciate the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.

  • Page 4: Important Manual Information

    EBU17330 IMPORTANT MANUAL INFORMATION EBU17342 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERIOUS IN- JURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential per- sonal injury hazards.

  • Page 5: Important Notice

    EBU17350 IMPORTANT NOTICE EBU17360 Welcome to the Yamaha world of motor sports! This ATV is designed and manufactured for OFF-ROAD use only. It is illegal and unsafe to operate this ATV on any public street, road or highway. This ATV complies with all applicable OFF-ROAD noise level and spark arrester laws and regulations in effect at the time of manufacture.

  • Page 6: Table Of Contents

    Speed limiter ..........4-14 EWB00010 WARNING Front brake lever ........4-15 Brake pedal and rear brake lever .....4-15 Indicates a potential hazard that could result in serious injury or death. Drive select lever ........4-16 Fuel tank cap ..........4-16 Fuel ............4-17 Seat ............4-19 EBU17420 Storage compartments ......4-19 TABLE OF CONTENTS...
  • Page 7 Instruments, lights and switches ....5-9 PERIODIC MAINTENANCE AND MINOR REPAIR ............8-1 OPERATION ..........6-1 Owner’s manual and tool kit .......8-1 Starting the engine ........6-1 Periodic maintenance chart for the Operating the drive select lever and emission control system ......8-3 driving in reverse ........
  • Page 8 Checking and lubricating the cables ..8-52 Noise regulation ........11-3 Checking and lubricating the front and Maintenance record ........11-4 rear brake levers ........8-53 YAMAHA MOTOR CORPORATION, Checking and lubricating the brake U.S.A. ATV LIMITED WARRANTY ..11-5 pedal ............8-53 YAMAHA EXTENDED SERVICE Checking the wheel hub bearings ....

  • Page 9: Safety Information

    EBU17430 SAFETY INFORMATION EBU27230 Never allow a child under age 16 to operate an ATV without adult supervision, and never allow AN ATV IS NOT A TOY AND CAN BE HAZARD- continued use of an ATV by a child if he or she OUS TO OPERATE.
  • Page 10 Always inspect your ATV each time you use it to Always follow proper procedures for climbing make sure it is in safe operating condition. Al- hills as described in this manual. Check the ter- ways follow the inspection and maintenance rain carefully before you start up any hill.
  • Page 11 steady speed when climbing a hill. If you stall or Always be sure there are no obstacles or people roll backwards, follow the special procedure for behind you when you operate in reverse. When braking described in this manual. Dismount on it is safe to proceed in reverse, go slowly.
  • Page 12 EWB02320 HOW TO AVOID THE HAZARD WARNING If you should swallow some gasoline or in- hale a lot of gasoline vapor, or get some gas- POTENTIAL HAZARD oline in your eyes, seek medical help Improper handling of gasoline. immediately. If gasoline spills on your skin, WHAT CAN HAPPEN wash with soap and water.

  • Page 13: Location Of The Warning And Specification Labels

    EBU17660 LOCATION OF THE WARNING AND SPECIFICATION LABELS...
  • Page 14 Read and understand all of the labels on your ATV. These labels contain important information for safe and proper operation. Never remove any labels from your ATV. If a label becomes difficult to read or comes off, request a replace- ment label from your Yamaha dealer. 187 lbs. (85 kg) 99 lbs. (45 kg)
  • Page 15 WARNING Improper tire pressure or overloading can cause loss of control. Loss of control can result in severe injury or death. OPERATING TIRE PRESSURE : Set with tires cold • Recommended : Front : 5.0 psi (35.0 kPa) 1 lb (0.5 kg). Rear : 4.4 psi (30.0 kPa) •...
  • Page 16 WARNING UNDER Operating this ATV if you are under the age of 16 increases your chance of severe injury or death. NEVER operate this ATV if you are under age 16. 4D3-2816L-00...

  • Page 17: Description

    EBU17680 DESCRIPTION EBU17690 EBU17700 Left view Right view 1. Radiator cap 1. Rear shock absorber assembly spring preload adjusting ring 2. Battery 2. Rear storage compartment and tool kit 3. Fuses 3. Fuel tank cap cover 4. Air filter case 4.

  • Page 18: Controls And Instruments

    EBU17712 Controls and instruments The ATV you have purchased may differ slightly from the figures shown in this manual. 1. Drive select lever 2. Rear brake lever 3. Handlebar switches 4. Rear brake fluid reservoir 5. Multifunction display 6. Front brake fluid reservoir 7.

  • Page 19: Instrument And Control Functions

    EBU17722 INSTRUMENT AND CONTROL FUNCTIONS EWB00010 WARNING Indicates a potential hazard that could result in serious injury or death. EBU17760 Main switch The positions of the main switch are as follows: All electrical systems are supplied with power. The headlights and taillight come on when the light 1.

  • Page 20: Indicator Lights And Warning Lights

    3. High-range indicator light “H” checked by turning the key to “ON”. If the warning 4. Neutral indicator light “N” light does not come on, have a Yamaha dealer 5. Reverse indicator light “R” check the electrical circuit. 6. Park indicator light “P”...
  • Page 21 “ON”. If the warning Start the engine after making sure that the light does not come on, have a Yamaha dealer warning light is out. Continuous use while check the electrical circuit. the warning light is on may cause damage to the engine.
  • Page 22 On-Command differential gear lock EBU18001 On-Command differential gear lock indicator indicator “ ” in the On-Command four-wheel- light “DIFF. LOCK” drive indicator also comes on when the On-Com- This indicator light and the On-Command differen- mand differential gear lock switch is set to the tial gear lock indicator in the display come on when “LOCK”...

  • Page 23: Multifunction Display

    EBU27293 a clock Multifunction display an hour meter (which shows the total time the engine has been running) a fuel meter a self-diagnosis device Odometer and tripmeter modes Pushing the “SELECT” button switches the display between the odometer mode “ODO” and the trip- meter modes “A”...
  • Page 24 1. Set the display to the clock mode. display segments and fuel level warning indicator 2. Push the “SELECT” button and “RESET” but- will start flashing. If this occurs, have a Yamaha ton together for at least three seconds. dealer check the electrical circuit.

  • Page 25: Handlebar Switches

    Set this switch to “ ” before starting the engine. Yamaha dealer check the vehicle. The engine stop switch controls the ignition and ECB00810 stops the engine when it is running. Use this switch NOTICE to stop the engine in an emergency situation.
  • Page 26 EBU18100 EBU18180 Start switch “ ” Override switch “OVERRIDE” Push this switch to crank the engine with the start- ECB00050 NOTICE See the starting instructions on page 6-1 prior to starting the engine. EBU18151 Light switch “ /OFF” Set this switch to “ ”...
  • Page 27 “2WD”/“4WD” indicate a malfunction in the electrical system. In This ATV is equipped with a switch to change from this case, take the ATV to a Yamaha dealer at the two-wheel drive to four-wheel drive and vice versa. first opportunity.
  • Page 28 To change from two-wheel drive to four-wheel WHAT CAN HAPPEN drive, stop the ATV and push the switch in to the The ATV handles differently in two-wheel “4WD” position. Then, four-wheel-drive drive than in four-wheel drive in some cir- indicator “ ”...
  • Page 29 “LOCK” (four-wheel drive with the differential gear locked): Power is supplied to the rear and front wheels and the differential gear is locked. Unlike in four-wheel drive, all wheels turn at the same speed. 1. Differential gear lock lever 2. On-Command four-wheel-drive switch “2WD”/“4WD” Stop the ATV, move the differential gear lock lever to position (a), and then push the differential gear lock switch in to the “LOCK”...
  • Page 30 WHAT CAN HAPPEN The ATV handles differently in four-wheel drive than in differential gear lock in some circumstances. Changing from four-wheel drive to differential gear lock or vice versa LOCK while moving may cause the ATV to handle differently unexpectedly. This could distract the operator and increase the risk of losing control and causing an accident.

  • Page 31: Throttle Lever

    HOW TO AVOID THE HAZARD EBU18270 Throttle lever Always ride at a slow speed when the ATV is Once the engine is running, movement of the throt- in differential gear lock, and allow extra time tle lever will increase the engine speed. and distance for maneuvers.

  • Page 32: Speed Limiter

    If it does not work smoothly, check for the cause. Correct the problem before riding the ATV. Consult a 1. Locknut Yamaha dealer if you can’t find or solve the 2. Adjusting screw problem yourself. 3. No more than 12 mm (0.47 in) 3.

  • Page 33: Front Brake Lever

    WHAT CAN HAPPEN The throttle cable could be damaged. Im- proper throttle operation could result. You could lose control, have an accident or be in- jured. HOW TO AVOID THE HAZARD Do not turn the adjusting screw out more than 12 mm (0.47 in). Always make sure the throttle lever free play is adjusted to 3.0–5.0 mm (0.12–0.20 in).

  • Page 34: Drive Select Lever

    EBU18611 Drive select lever The drive select lever is used to shift your ATV into the low-range, high-range, neutral, reverse and park positions. See the “Operating the drive select lever and driving in reverse” section on page 6-3 for the drive select lever operation. 1.

  • Page 35: Fuel

    To install the fuel tank cap Install the fuel tank cap by turning it clockwise until a click is heard, and then close the fuel tank cap cover. EBU18730 Fuel Make sure that there is sufficient fuel in the tank. Fill the fuel tank to the bottom of the filler tube as shown.
  • Page 36 HOW TO AVOID THE HAZARD Your Yamaha engine has been designed to use Do not overfill the fuel tank. Be careful not to regular unleaded gasoline with a pump octane...

  • Page 37: Seat

    EBU18880 Seat To remove the seat Pull the seat lock lever upward and pull up the seat at the rear. 1. Projection 2. Seat holder EBU27361 Storage compartments This ATV is equipped with two storage compart- ments. 1. Seat The front storage compartment is located at the 2.
  • Page 38 The rear storage compartment is located under the seat. (See page 4-19.) To access the storage com- partment, remove the storage compartment cover. 1. Front storage compartment cover 1. Rear storage compartment cover 1. Front storage compartment 4-20...
  • Page 39 Do not exceed the load limit of 0.5 kg (1 lb) for the front storage compartment or 2.0 kg (4 lb) for the rear storage compartment. Do not exceed the maximum load of 220.0 kg (485 lb) for the ATV. A drain plug is fitted at the bottom of each storage compartment.

  • Page 40: Front Carrier

    EBU19132 Adjusting the front and rear shock ab- sorber assemblies The spring preload can be adjusted to suit the rid- er’s weight and the riding conditions. Adjust the spring preload as follows. Turn the spring preload adjusting ring in direction (a) to increase the spring preload and thereby harden the suspension, and in direction (b) to de- crease the spring preload and thereby soften the...

  • Page 41: Auxiliary Dc Jack

    EWB00350 WARNING A special wrench can be obtained at a Yamaha POTENTIAL HAZARD dealer to make this adjustment. Improper shock absorber assembly adjust- ment. WHAT CAN HAPPEN Uneven adjustment can cause poor handling and loss of stability, which could lead to an accident.
  • Page 42 Maximum rated capacity for the auxiliary DC jack: DC 12 V, 10 A (120 W) 4. When the auxiliary DC jack is not being used, cover it with the cap. ECB00120 NOTICE Do not use accessories requiring more than the above maximum capacity. This may overload the circuit and cause the fuse to 1.

  • Page 43: Pre-Operation Checks

    Always follow the inspection and maintenance procedures and schedules described in the Own- er’s Manual. The maintenance of some items in the table has to be performed by a Yamaha dealer. Refer to the periodic maintenance charts on page 8-3 to determine which service should be performed by a Yamaha dealer.
  • Page 44 5-4, 8-31 • Check cooling system for leakage. Correct if necessary. • Check operation. If soft or spongy, have Yamaha dealer bleed hy- draulic system. • Check brake pads for wear, and replace if necessary. Front brake 5-5, 8-45, 8-47, 8-48 •...
  • Page 45 ITEM ROUTINE PAGE • Make sure that operation is smooth. Lubricate lever pivoting points if Brake levers 8-53 necessary. Axle boots • Check for cracks or damage, and replace if necessary. 8-51 Chassis fasteners • Make sure that all nuts, bolts and screws are properly tightened. Instruments, lights and •...

  • Page 46: Fuel

    EBU19530 EBU19590 Fuel Final gear oil Make sure that there is sufficient fuel in the tank. Make sure that the final gear oil is at the specified (See page 4-17.) level. Add oil as necessary. (See page 8-27.) EWB00500 WARNING EBU19600 Differential gear oil POTENTIAL HAZARD...

  • Page 47: Front And Rear Brakes

    Check the operation of the brake levers and the brake pads for wear. (See page 8-45.) pedal. They should move smoothly and there should be a firm feeling when the brakes are ap- plied. If not, have a Yamaha dealer check the brake system.

  • Page 48: Throttle Lever

    HOW TO AVOID THE HAZARD vided in this manual, have a Yamaha dealer The tires listed below have been approved check for the cause. by Yamaha Motor Co., Ltd. for this model.

  • Page 49: Measuring The Tire Pressure

    Rear: Tire pressure below the minimum speci- Manufacturer/model: fied could cause the tire to dislodge from DUNLOP/KT425 the rim under severe riding conditions. Size: Minimum tire pressure: AT25 x 10-12 Front: Type: 32.0 kPa (0.320 kgf/cm², 4.6 psi) Tubeless Rear: The tires should be set to the recommend- 27.0 kPa (0.270 kgf/cm², 4.0 psi) ed pressure:...

  • Page 50: Tire Wear Limit

    Recommended pressure: Front The low-pressure tire gauge is included as stan- 35.0 kPa (0.350 kgf/cm², 5.0 psi) dard equipment. Make two measurements of the Rear tire pressure and use the second reading. Dust or 30.0 kPa (0.300 kgf/cm², 4.4 psi) dirt in the gauge could cause the first reading to be Minimum: incorrect.

  • Page 51: Chassis Fasteners

    1. Tire wear limit EBU19840 Chassis fasteners Make sure that all nuts, bolts and screws are prop- erly tightened. EBU19850 Instruments, lights and switches Check that all instruments, lights and switches are working properly. Correct if necessary.

  • Page 52: Operation

    Read the Owner’s Manual carefully. If there is prior to operating the engine for the first time. a control or function you do not understand, ask your Yamaha dealer. 1. Turn the main switch to “ON” and the engine stop switch to “...
  • Page 53 The corresponding indicator light should crank the engine more than 10 seconds on each come on. If the indicator light does not come attempt. on, have a Yamaha dealer check the electrical 5. Continue warming up the engine until it idles circuit. smoothly.

  • Page 54: Operating The Drive Select Lever And Driving In Reverse

    EBU20430 Operating the drive select lever and driving in reverse ECB00170 NOTICE Before shifting, stop the ATV, otherwise the transmission may be damaged. Shifting: Neutral to High-range and High-range to Low-range 1. Bring the ATV to a complete stop. 1. Drive select lever 2.

  • Page 55: Engine Break-In

    For ATVs equipped with an odometer or an hour should come on. If the indicator light does not meter, follow the figures given in km (mi) or the come on, have a Yamaha dealer check the elec- figures given in hours. trical circuit.

  • Page 56: Parking

    There is never a more important period in the life of engine break-in period, immediately have a your engine than the first 320 km (200 mi) or 20 Yamaha dealer check the ATV. hours of riding. For this reason, you should read the following material carefully.

  • Page 57: Accessories And Loading

    However, 2. Stop the engine. it is not possible for Yamaha to test all non- 3. With the brake pedal applied, shift the drive Yamaha accessories, nor control over their qual- select lever to the park position.
  • Page 58 could make steering difficult, an accessory that MAXIMUM LOADING LIMIT limits your ability to move around on the seat, or ATV loading limit (total weight of rider, cargo, one that limits your view. accessories, and tongue): Use extra caution when riding an ATV with ac- 220.0 kg (485 lb) cessories.
  • Page 59 the weight on the hitch. If you are carrying cargo EWB00750 WARNING and towing a trailer, include the tongue weight in the maximum ATV load limit. POTENTIAL HAZARD Load cargo on the carriers as close to the center Overloading this ATV or carrying or towing of the ATV as possible.

  • Page 60: Riding Your Atv

    EBU21131 RIDING YOUR ATV...

  • Page 61: Getting To Know Your Atv

    EWB00010 ular attention to the safety information on pages WARNING 1-1–1-4. Please also read all notice and warning labels on your ATV. Indicates a potential hazard that could result in serious injury or death. EBU27393 GETTING TO KNOW YOUR ATV This ATV is mainly for utility use, but may also be used for recreation.

  • Page 62: Ride With Care And Good Judgement

    Beginners should get training from a certified in- course offered by Yamaha. They should then structor. regularly practice the skills learned in the Become familiar with this ATV at slow speeds first, course and the operating techniques de- even if you are an experienced operator.
  • Page 63 WHAT CAN HAPPEN Use by children of ATVs that are not recom- mended for their age can lead to severe inju- ry or death of the child. HOW TO AVOID THE HAZARD A child under 16 should never operate an ATV with engine size greater than 90 cc.
  • Page 64 This ATV is designed to carry operator and car- go only – passengers prohibited. EWB00910 WARNING POTENTIAL HAZARD Carrying a passenger on this ATV. WHAT CAN HAPPEN Greatly reduces your ability to balance and control this ATV. Could cause an accident, resulting in harm to you and/or your passen- ger.
  • Page 65 Apparel HOW TO AVOID THE HAZARD Always wear an approved motorcycle helmet EWB00920 WARNING that fits properly. You should also wear: POTENTIAL HAZARD eye protection (goggles or face shield) Operating this ATV without wearing an ap- gloves proved motorcycle helmet, eye protection boots and protective clothing.
  • Page 66 Do not operate after consuming alcohol or HOW TO AVOID THE HAZARD drugs. Never consume alcohol or drugs before or The operator’s performance capability is reduced while driving this ATV. by the influence of alcohol or drugs. Pre-operation checks Always perform the pre-operation checks listed on page 5-1 before riding for proper care of the ATV and to ensure safety.
  • Page 67 EWB00950 Do not operate at speeds too fast for your skills WARNING or the conditions. EWB00960 POTENTIAL HAZARD WARNING Operating this ATV with improper tires, or with improper or uneven tire pressure. POTENTIAL HAZARD WHAT CAN HAPPEN Operating this ATV at speeds too fast for Use of improper tires on this ATV, or opera- your skills or the conditions.
  • Page 68 Speed limiter Loading and accessories For riders less experienced with this model, the Use extra caution when riding the ATV with addi- throttle lever housing is equipped with a speed lim- tional loads, such as accessories or cargo. The iter. The speed limiter keeps the throttle from fully ATV’s handling may be adversely affected.
  • Page 69 EWB00970 WARNING POTENTIAL HAZARD Overloading this ATV or carrying or towing cargo improperly. WHAT CAN HAPPEN Could cause changes in ATV handling which could lead to an accident. HOW TO AVOID THE HAZARD Never exceed the stated load capacity for this ATV.
  • Page 70 During operation WHAT CAN HAPPEN Always keep your feet on the footboards during op- Removing even one hand or foot can reduce eration, otherwise they may contact the rear your ability to control the ATV or could wheels. cause you to lose your balance and fall off of the ATV.
  • Page 71 Never modify this ATV through improper in- stallation or use of accessories. All parts and accessories added to this ATV should be genuine Yamaha or equivalent compo- nents designed for use on this ATV and should be installed and used according to instructions.

  • Page 72: Be Careful Where You Ride

    Exhaust system The exhaust system on the ATV is very hot during and following operation. To prevent burns, avoid touching the exhaust system. Park the ATV in a place where pedestrians or children are not likely to touch it. EWB01010 WARNING POTENTIAL HAZARD Hot exhaust system.
  • Page 73 HOW TO AVOID THE HAZARD EWB01030 WARNING Always avoid paved surfaces, including sidewalks, driveways, parking lots and POTENTIAL HAZARD streets. Operating this ATV on public streets, roads or highways. WHAT CAN HAPPEN You can collide with another vehicle. HOW TO AVOID THE HAZARD Never operate this ATV on any public street, road or highway, even a dirt or gravel one.
  • Page 74 Know the terrain where you ride. Ride cautiously in unfamiliar areas. Stay alert for holes, rocks, or roots in the terrain, and other hidden hazards which may cause the ATV to upset. EWB01040 WARNING POTENTIAL HAZARD Failure to use extra care when operating this ATV on unfamiliar terrain.
  • Page 75 HOW TO AVOID THE HAZARD Do not operate on excessively rough, slip- pery or loose terrain until you have learned and practiced the skills necessary to control the ATV on such terrain. Always be especial- ly cautious on these kinds of terrain. 7-16...
  • Page 76 When riding in an area where you might not easily HOW TO AVOID THE HAZARD be seen, such as desert terrain, mount a caution Always mount a caution flag on the ATV to flag on the ATV. DO NOT use the flag pole bracket make you more visible.
  • Page 77 surfaces: the ATV is designed for off-road use ECB00250 NOTICE only, and handling maneuvers are more difficult to perform on pavement. Do not shift from drive position low-range to Shift to the park position and follow the instruction high-range or vice versa without coming to a on page 6-1 to start the engine.

  • Page 78: Turning Your Atv

    TURNING YOUR ATV HOW TO AVOID THE HAZARD To achieve maximum traction while riding off-road Always follow proper procedures for turning in 2WD or 4WD, the two rear wheels turn together as described in this Owner’s Manual. Prac- at the same speed. Furthermore, when riding in tice turning at low speeds before attempting 4WD-LOCK (“DIFF.
  • Page 79 Improper riding procedures such as abrupt throttle changes, excessive braking, incorrect body move- ments, or too much speed for the sharpness of the turn may cause the ATV to tip. If the ATV begins to tip over to the outside while negotiating a turn, lean more to the inside.

  • Page 80: Climbing Uphill

    CLIMBING UPHILL EWB01180 WARNING Use proper riding techniques to avoid ATV over- turns on hills. Be sure that you can maneuver your POTENTIAL HAZARD ATV well on flat ground before attempting any in- Climbing hills improperly. cline and then practice riding first on gentle slopes. WHAT CAN HAPPEN Try more difficult climbs only after you have devel- Could cause loss of control or cause the...
  • Page 81 7-22...
  • Page 82 If you are climbing a hill and you find that you have When crossing the side of a hill: not properly judged your ability to make it to the Always follow proper procedures as de- top, you should turn the ATV around while you still scribed in the Owner’s Manual.
  • Page 83 If you start to roll backwards, DO NOT apply either If you begin rolling backwards: brake abruptly. If you are in 2WD, apply only the Keep weight uphill. front brake. If you are in 4WD or 4WD-LOCK, be- 2WD: Never apply the rear brake while roll- cause all wheels are interconnected by the drive ing backwards.

  • Page 84: Riding Downhill

    RIDING DOWNHILL Whenever possible, ride your ATV straight down- When riding your ATV downhill, shift your weight hill. Avoid sharp angles which could allow the ATV as far to the rear and uphill side of the ATV as pos- to tip or roll over. Carefully choose your path and sible.
  • Page 85 7-26...

  • Page 86: Crossing A Slope

    CROSSING A SLOPE HOW TO AVOID THE HAZARD Traversing a sloping surface on your ATV requires Never attempt to turn the ATV around on any you to properly position your weight to maintain hill until you have mastered the turning tech- proper balance.
  • Page 87 7-28...

  • Page 88: Crossing Through Shallow Water

    CROSSING THROUGH SHALLOW WATER The ATV can be used to cross slow moving, shal- low water of up to a maximum of 35 cm (14 in) in depth. Before entering the water, choose your path carefully. Enter where there is no sharp drop off, and avoid rocks or other obstacles which may be slippery or upset the ATV.
  • Page 89 1. Air filter case check hose ECB00840 NOTICE After riding your ATV in water, be sure to drain the trapped water by removing the check hos- es at the bottom of the air filter case. Also, re- move the drain plugs from the front and rear storage compartments and the V-belt case to drain any water that may have accumulated.

  • Page 90: Riding Over Rough Terrain

    1. V-belt case drain plug 1. Storage compartment drain plug RIDING OVER ROUGH TERRAIN Riding over rough terrain should be done with cau- tion. Look out for obstacles which could cause damage to the ATV or could lead to an upset or ac- cident.

  • Page 91: Sliding And Skidding

    WHAT CAN HAPPEN Could cause loss of control or a collision. Could cause the ATV to overturn. HOW TO AVOID THE HAZARD Before operating in a new area, check for ob- stacles. Never attempt to ride over large obstacles, such as large rocks or fallen trees. When you go over obstacles, always follow proper procedures as described in the Owner’s Manual.

  • Page 92: What To Do If

    If the rear wheels of your ATV start to slide side- EWB01170 WARNING ways, control can usually be regained (if there is room to do so) by steering in the direction of the POTENTIAL HAZARD slide. Applying the brakes or accelerating is not Skidding or sliding improperly.

  • Page 93: What To Do

    WHAT TO DO... If your ATV is traversing a sloping surface: If your ATV doesn’t turn when you want it to: Be sure to ride with your weight positioned to- Bring the ATV to a stop and practice the turning wards the uphill side of the ATV to maintain maneuvers again.

  • Page 94: Periodic Maintenance And Minor Repair

    Safety is an obligation of the owner. Periodic in- nance unless otherwise specified. Have a spection, adjustment and lubrication will keep your Yamaha dealer perform the service if you are ATV in the safest and best operating condition not familiar with maintenance work.
  • Page 95 Yamaha ATV dealer. additional tools such as a torque wrench may be necessary to perform certain maintenance work correctly. If you do not have the tools or experience required for a particular job, have a Yamaha dealer perform it for you.

  • Page 96: Periodic Maintenance Chart For The Emission Control System

    However, keep in mind that if the ATV isn’t used for a long period of time, the month maintenance intervals should be followed. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.

  • Page 97: General Maintenance And Lubrication Chart

    EBU21864 General maintenance and lubrication chart INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 first (mi) (200) (800) (1600) (1600) (3200) hours Every 20–40 hours (more often in wet or Air filter element • Clean and replace if necessary. dusty areas) •...
  • Page 98 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 first (mi) (200) (800) (1600) (1600) (3200) hours • Check for looseness or damage, and replace if √ √ √ √ Wheel hub bearings necessary. • Check for wear, cracks or other damage, and re- √...
  • Page 99 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 first (mi) (200) (800) (1600) (1600) (3200) hours • Change. √ √ Differential gear oil • Check ATV for oil leakage, and correct if neces- sary. •...
  • Page 100 EBU23070 The air filter needs more frequent service if you are riding in unusually wet or dusty areas. Hydraulic brake service • Regularly check and, if necessary, correct the brake fluid level. • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid.

  • Page 101: Removing And Installing Panels

    EWB00010 WARNING Indicates a potential hazard that could result in serious injury or death. EBU23090 Removing and installing panels The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed.
  • Page 102 1. Panel A 1. Panel E 2. Panel H To install the panel 3. Panel I Place the panel in the original position. EBU27382 Panel A To remove the panel Pull upward on the areas shown.
  • Page 103 Panel B To remove the panel 1. Remove panel A. 2. Remove the front carrier by removing the bolts. 1. Carrier bolt (top) 3. Remove the front carrier stays by removing the bolts. 1. Carrier bolt (under the fenders) 1. Front carrier stay 8-10...
  • Page 104 1. Front carrier stay bolt 1. Panel B 2. Quick fastener 4. Remove the quick fasteners, and then pull the panel upward to remove it. To install the panel 1. Place the panel in the original position, and then install the quick fasteners. 8-11...
  • Page 105 Tightening torques: Carrier bolt (top): 26 Nm (2.6 m·kgf, 19 ft·lbf) Carrier bolt (under the fenders): 7 Nm (0.7 m·kgf, 5.1 ft·lbf) 4. Install panel A. Panel C To remove the panel 1. Remove the seat. (See page 4-19.) 2. Install the front carrier stays by installing the 2.
  • Page 106 1. Panel C 2. Install panel A. 2. Quick fastener screw 3. Install the seat. To install the panel Panels D and E 1. Place the panel in the original position, and then install the quick fastener screws. To remove one of the panels 1.
  • Page 107 1. Panel D 1. Panel E 2. Quick fastener screw 2. Quick fastener screw 1. Bolt 1. Bolt 8-14...
  • Page 108 To install one of the panels Panel F 1. Place the panel in the original position, and To remove the panel then install the bolt and quick fastener screw. Pull outward on the areas shown. 1. Panel F To install the panel Place the panel in the original position.
  • Page 109 1. Panel G Panels G and H 2. Nut 3. Bolt To remove one of the panels 4. Projection Remove the nut and bolts, and then pull the panel downward while pushing the projection. 8-16...
  • Page 110 1. Panel H 2. Nut 3. Bolt 4. Projection To install one of the panels Place the panel in the original position, and then in- stall the bolts and nut. Panel I To remove the panel 1. Remove the seat. (See page 4-19.) 8-17...
  • Page 111 2. Remove the rear carrier by removing the bolts. 1. Carrier bolt (lower) 3. Remove the quick fasteners, and then push 1. Carrier bolt (under the fenders) inward on the areas shown. 1. Carrier bolt (upper) 8-18...
  • Page 112 1. Panel I 2. Install the rear carrier by installing the bolts 2. Quick fastener and tightening them to the specified torques. To install the panel Tightening torques: 1. Place the panel in the original position, and Carrier bolt (upper): then install the quick fasteners.

  • Page 113: Removing The Radiator Grills

    EBU28671 EBU23211 Removing the radiator grills Checking the spark plug The radiator grills can be removed to access the The spark plug is an important engine component, radiator for cleaning. which is easy to check. Since heat and deposits will cause any spark plug to slowly erode, the spark To remove a radiator grill plug should be removed and checked in accor- Remove the quick fastener, pull the radiator grill...

  • Page 114: To Check The Spark Plug

    (the ideal color when the ATV is ridden normally). If the spark plug shows a distinctly different color, the engine could be operating improperly. Do not attempt to diagnose such problems yourself. In- stead, have a Yamaha dealer check the ATV. 8-21...

  • Page 115: Engine Oil And Oil Filter Cartridge

    If a torque wrench is not available when installing a spark plug, a good estimate of the correct torque is 1/4–1/2 turn past finger tight. However, the spark plug should be tightened to the specified torque as soon as possible. 4.
  • Page 116 4. Remove the dipstick, and then wipe it off with a clean rag. 1. Maximum level mark 2. Minimum level mark 1. Dipstick 5. Insert the dipstick completely into the oil filler The engine oil should be between the minimum hole, and then remove it again to check the oil and maximum level marks.
  • Page 117 1. Oil filter cartridge 2. Oil filter wrench An oil filter wrench is available at a nearby Yamaha dealer. 7. Apply a thin coat of engine oil to the O-ring of the new oil filter cartridge.
  • Page 118 1. O-ring 1. Torque wrench Tightening torque: Oil filter cartridge: Make sure that the O-ring is properly seated. 17 Nm (1.7 m·kgf, 12 ft·lbf) 8. Install the new oil filter cartridge with an oil fil- ter wrench, and then tighten it to the specified 9.
  • Page 119 11. Refill with the specified amount of the recom- Make sure that no foreign material enters the mended engine oil, and then insert the dip- crankcase. stick completely into the oil filler hole. Recommended oil: See page 10-1. Oil quantity: Without oil filter cartridge replacement: 2.00 L (2.11 US qt, 1.76 Imp.qt) With oil filter cartridge replacement:...

  • Page 120: Final Gear Oil

    The final gear case must be checked for oil leak- age before each ride. If any leakage is found, have a Yamaha dealer check and repair the ATV. In ad- dition, the final gear oil level must be checked and the oil changed as follows at the intervals specified in the periodic maintenance and lubrication chart.
  • Page 121 3. Remove the final gear oil filler bolt, final gear oil level check bolt, and the final gear oil drain bolt to drain the oil from the final gear case. 1. Final gear oil filler bolt 4. Install the oil level check bolt and oil filler bolt, and then tighten them to the specified torques.

  • Page 122: Differential Gear Oil

    1. Final gear oil leakage before each ride. If any leakage is found, 2. Final gear oil level check bolt have a Yamaha dealer check and repair the ATV. 3. Correct oil level In addition, the differential gear oil level must be...

  • Page 123: Changing Differential Gear Oil

    2. Remove the differential gear oil filler bolt, and Tightening torque: then check the oil level in the differential gear Differential gear oil filler bolt: case. 23 Nm (2.3 m·kgf, 17 ft·lbf) To change the differential gear oil 1. Place the ATV on a level surface. 2.

  • Page 124: Coolant

    ECB00410 Tightening torque: NOTICE Differential gear oil drain bolt: Be sure no foreign material enters the differen- 10 Nm (1.0 m·kgf, 7.2 ft·lbf) tial gear case. 5. Refill with the recommended differential gear 6. Install the oil filler bolt, and then tighten it to the oil to the brim of the filler hole as shown.
  • Page 125 4. Remove the coolant reservoir cap, add cool- ant or distilled water to the maximum level The coolant level must be checked on a cold en- mark, install the reservoir cap, and then install gine since the level varies with engine tempera- the panel.

  • Page 126: Changing Coolant

    If water has been added to the coolant, have Wait for the engine to cool before removing a Yamaha dealer check the antifreeze con- the radiator cap. Always place a thick rag tent of the coolant as soon as possible, oth- over the cap.
  • Page 127 1. Coolant drain bolt 1. Radiator cap 6. Remove the coolant reservoir cap. 7. Disconnect the hose on the coolant reservoir side, and then drain the coolant from the cool- ant reservoir. 1. Trough 4. Remove panel B. (See page 8-8.) 5.
  • Page 128 12. Pour the recommended coolant into the reser- voir to the maximum level mark, and then in- stall the reservoir cap. Antifreeze/water mixture ratio: Recommended antifreeze: High-quality ethylene glycol antifreeze con- taining corrosion inhibitors for aluminum en- gines Coolant quantity: Radiator capacity (including all routes): 1.
  • Page 129 If water has been added to the coolant, have Tightening torque: a Yamaha dealer check the antifreeze con- Water pump air bleed bolt: tent of the coolant as soon as possible, oth- 10 Nm (1.0 m·kgf, 7.2 ft·lbf) erwise the effectiveness of the coolant will be reduced.

  • Page 130: Cleaning The Air Filter Element

    23. Start the engine, and then check for coolant leakage. If any leakage is found, have a Yamaha dealer check the cooling system. 24. Install the V-belt cooling duct, and then tighten 1. Cylinder head air bleed bolt the clamp screw.
  • Page 131 the panels.) Check the hoses periodically and, if dust or water collects in them, empty them and clean the air filter element and air filter case. 1. Air filter case check hose 1. Place the ATV on a level surface. 2.
  • Page 132 1. Sponge material 1. Air filter case cover holder 2. Air filter mesh 2. Air filter case cover 5. Clean the mesh with solvent, and then wipe 4. Remove the sponge material and the mesh the solvent off. from the air filter case. 6.
  • Page 133 12. Place the hoses in their original position as 8. Check the sponge material and replace it if shown. damaged. 9. Apply Yamaha foam air filter oil or other qual- ity foam air filter oil to the sponge material. 8-40...

  • Page 134: Cleaning The Spark Arrester

    ECB00760 NOTICE Make sure that the air filter element is prop- erly seated in the air filter case. Never operate the engine with the air filter el- ement removed. This will allow unfiltered air to enter the engine, causing rapid engine wear and possible engine damage.
  • Page 135 1. Bolt 1. Tailpipe 2. Spark arrester 2. Remove the tailpipe, by pulling it out of the 3. Gasket muffler, and then remove the gasket. 4. Install the gasket, and then insert the tailpipe 3. Tap the tailpipe lightly, and then use a wire into the muffler and align the bolt holes.

  • Page 136: V-Belt Case Drain Plug

    EWB01930 WARNING POTENTIAL HAZARD Improperly purging the exhaust system. Hot exhaust system. WHAT CAN HAPPEN Could injure the eyes. Could cause burns. Could cause carbon monoxide poisoning, possibly leading to death. Could start a fire. 1. Purging bolt HOW TO AVOID THE HAZARD When purging the exhaust system: 7.

  • Page 137: Adjusting The Throttle Cable Free Play

    If water drains from the V-belt case after removing ically check the throttle cable free play and, if nec- the plug, have a Yamaha dealer check the ATV as essary, adjust it as follows. the water may affect other engine parts.

  • Page 138: Valve Clearance

    To prevent this from occurring, the valve clearance The wheels need to be removed to check the must be adjusted by a Yamaha dealer at the inter- brake pads. (See page 8-64.) vals specified in the periodic maintenance and lu- brication chart.

  • Page 139: Checking The Rear Brake Hose Protectors

    Each brake hose protector is provided with a wear indicator. If a protector wears to the point that its indicator be- comes visible, have a Yamaha dealer replace the protector. The wheels need to be removed to check the 1.

  • Page 140: Checking The Brake Fluid Level

    Front brake 1. Rear brake hose protector 1. Minimum level mark 2. Wear indicator 3. Protector is normal. Rear brake 4. Protector is worn. EBU24251 Checking the brake fluid level Insufficient brake fluid may allow air to enter the brake system, possibly causing it to become inef- fective.

  • Page 141: Changing The Brake Fluid

    EBU24291 Changing the brake fluid When checking the fluid level, make sure that Have a Yamaha dealer change the brake fluid at the top of the brake fluid reservoir is level. the intervals specified in the TIP after the periodic Use only the recommended quality brake fluid, maintenance and lubrication chart.

  • Page 142: Adjusting The Brake Pedal Free Play

    Replacement of brake components requires professional knowledge. These procedures should be performed by a Yamaha dealer. EBU29021 Adjusting the brake pedal free play The brake pedal free play must be adjusted at the intervals specified in the periodic maintenance and lubrication chart.
  • Page 143 3. Turn the brake pedal free play adjusting nut in direction (a) to increase the free play, and in Always perform this maintenance completely in direction (b) to decrease it. the following order whenever adjusting the rear brake. Before adjusting the brake pedal free play, check the rear brake pads for wear.

  • Page 144: Axle Boots

    If the correct free play cannot be obtained, have a Replacement of brake components requires Yamaha dealer adjust it. professional knowledge. These procedures should be performed by a Yamaha dealer. When adjusting the rear brake pedal free play: Be sure not to step on the brake pedal. EBU24230...

  • Page 145: Checking And Lubricating The Cables

    If a cable is damaged or does not move smoothly, have a Yamaha dealer check or replace Recommended lubricant: Engine oil 1.

  • Page 146: Checking And Lubricating The Front And Rear Brake Levers

    EBU24912 Rear brake lever Checking and lubricating the front and rear brake levers The operation of the front and rear brake levers should be checked before each ride, and the lever pivots should be lubricated if necessary. Recommended lubricant: Silicone grease Front brake lever EBU28832 Checking and lubricating the brake...

  • Page 147: Checking The Wheel Hub Bearings

    If there is play in a wheel hub or if a wheel does not turn smoothly, have a Yamaha dealer check the wheel hub bear- ings. EBU25021 Checking the stabilizer bushes...

  • Page 148: Lubricating The Steering Shaft

    EBU25102 WHAT CAN HAPPEN Lubricating the steering shaft You could be poisoned. You could be se- The steering shaft must be lubricated at the inter- verely burned by the sulfuric acid in battery vals specified in the periodic maintenance and lu- electrolyte.
  • Page 149 To charge the battery their bolt. Have a Yamaha dealer charge the battery as soon as possible if it seems to have discharged. Keep in mind that the battery tends to discharge more quickly if the ATV is equipped with optional electri- cal accessories.
  • Page 150 Using a conventional bat- tery charger will damage the battery. If you do not have access to a constant-voltage battery charger, have a Yamaha dealer charge your battery. To store the battery 1. Positive battery lead (red) If the ATV will not be used for more than one 2.

  • Page 151: Replacing A Fuse

    EBU27580 Replacing a fuse 1. Ignition fuse 2. Headlight fuse 1. Fuse box 3. Four-wheel-drive motor fuse 2. Main/EPS spare fuse 4. Radiator fan fuse 3. Main fuse 5. Signaling system fuse 4. EPS fuse 6. Auxiliary DC jack fuse 5.
  • Page 152 ECB00640 Specified fuses: NOTICE Main fuse: To prevent accidental short-circuiting, turn off 40.0 A the main switch when checking or replacing a Headlight fuse: fuse. 15.0 A Ignition fuse: 2. Remove the blown fuse, and then install a 15.0 A new fuse of the specified amperage.

  • Page 153: Replacing A Headlight Bulb

    3. Turn the key to “ON” and turn on the electrical circuits to check if the devices operate. 4. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 1. Cover at the rear of the headlight EBU27430 2.
  • Page 154 1. Headlight coupler 1. Headlight bulb holder 2. Headlight bulb 4. Unhook the headlight bulb holder, and then EWB02180 remove the defective bulb. WARNING POTENTIAL HAZARD A headlight bulb is hot when it is on and im- mediately after it is turned off. WHAT CAN HAPPEN You can be burned, or a fire could start if the bulb touches something flammable.

  • Page 155: Adjusting A Headlight Beam

    9. Adjust the headlight beam if necessary. EBU25551 Adjusting a headlight beam ECB00690 NOTICE It is advisable to have a Yamaha dealer make this adjustment. 1. Do not touch the glass part of the bulb. To raise a headlight beam, turn the headlight beam ECB00650 adjusting screw in direction (a).

  • Page 156: Replacing The Tail/Brake Light Bulb

    1. Headlight beam adjusting screw 1. Tail/brake light bulb holder 3. Remove the defective bulb by pushing it in EBU25640 Replacing the tail/brake light bulb and turning it counterclockwise. If the tail/brake light bulb burns out, replace it as follows. 1.

  • Page 157: Removing A Wheel

    4. Insert a new bulb into the bulb holder, push it EBU25701 Installing a wheel in, and then turn it clockwise until it stops. 1. Place the ATV on a level surface. 5. Install the bulb holder (together with the bulb) 2.

  • Page 158: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems yourself. However, should your ATV re- quire any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, expe- 1. Tapered nut rience, and know-how to service the ATV properly.
  • Page 159 HOW TO AVOID THE HAZARD Do not smoke when checking the fuel sys- tem. Make sure there are no open flames or sparks in the area, including pilot lights from water heaters or furnaces. 8-66...

  • Page 160: Troubleshooting Charts

    EBU27681 Troubleshooting charts Starting problems or poor engine performance 1. Fuel 2. Compression 3. Ignition 4. Battery 8-67...
  • Page 161 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the rec- ommended coolant as soon as possible.

  • Page 162: Cleaning And Storage

    EBU25860 CLEANING AND STORAGE EBU25870 ed from improper high-pressure detergent Cleaning applications such as those available in coin- Frequent, thorough cleaning of your ATV will not operated car washers. only enhance its appearance but will improve its 4. Once most of the dirt has been hosed off, general performance and extend the useful life of wash all surfaces with warm water and mild, many components.

  • Page 163: Storage

    WHAT CAN HAPPEN Long-term Wet brakes may have reduced stopping abil- Before storing your ATV for several months: ity, increasing the chance of an accident. 1. Follow all the instructions in the “Cleaning” HOW TO AVOID THE HAZARD section of this chapter. Test the brakes after washing.
  • Page 164 e. Remove the spark plug cap from the spark plug, and then install the spark plug and the spark plug cap. 4. Lubricate all control cables and the pivoting points of all levers and pedals. 5. Check and, if necessary, correct the tire air pressure, and then block up the ATV so that all of its wheels are off the ground.

  • Page 165: Specifications

    EBU25960 SPECIFICATIONS Dimensions: Compression ratio: 9.20 :1 Overall length: Starting system: 2065 mm (81.3 in) Electric starter Overall width: Lubrication system: 1180 mm (46.5 in) Wet sump Overall height: Engine oil: 1240 mm (48.8 in) Seat height: Type: 905 mm (35.6 in) YAMALUBE 4 5W-30 or 10W-40 or 20W-50, SAE 5W-30 Wheelbase: or SAE 10W-40 or SAE 20W-50...
  • Page 166 Engine oil quantity: Fuel injection: Without oil filter cartridge replacement: Throttle body: 2.00 L (2.11 US qt, 1.76 Imp.qt) Type/quantity: With oil filter cartridge replacement: 44EIS/1 2.10 L (2.22 US qt, 1.85 Imp.qt) Manufacturer: Final gear oil: MIKUNI Type: Spark plug (s): SAE 80 API GL-4 Hypoid gear oil Manufacturer/model: Quantity:...
  • Page 167 Chassis: Minimum: Front: Frame type: 32.0 kPa (0.320 kgf/cm², 4.6 psi) Steel tube frame Rear: Caster angle: 27.0 kPa (0.270 kgf/cm², 4.0 psi) 5.0 ° Front wheel: Trail: 26.0 mm (1.02 in) Wheel type: Front tire: Panel wheel Rim size: Type: 12 x 6.0AT Tubeless...
  • Page 168 Front suspension: Tail/brake light: 12 V, 5.0/21.0 W Type: Meter lighting: Double wishbone Spring/shock absorber type: Neutral indicator light: Coil spring/oil damper Wheel travel: Reverse indicator light: 180 mm (7.1 in) Rear suspension: Coolant temperature warning light: Type: Double wishbone Engine trouble warning light: Spring/shock absorber type: Coil spring/oil damper...
  • Page 169 Headlight fuse: 15.0 A Signaling system fuse: 5.0 A Ignition fuse: 15.0 A Auxiliary DC jack fuse: 15.0 A Four-wheel-drive motor fuse: 15.0 A Radiator fan fuse: 20.0 A 10-5...

  • Page 170: Consumer Information

    Yamaha dealer or for ref- erence in case the ATV is stolen. KEY IDENTIFICATION NUMBER: VEHICLE IDENTIFICATION NUMBER: 1.
  • Page 171 EBU26050 Model label The model label is affixed at the location in the il- lustration. Record the information on this label in the space provided. This information will be need- ed when ordering spare parts from a Yamaha deal- 11-2...

  • Page 172: Noise Regulation

    EBU26060 Noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of de- sign incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ul- timate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 173: Maintenance Record

    EBU26080 Maintenance record Copies of work orders and/or receipts for parts you purchase and install will be required to document main- tenance done in accordance with the warranty. The chart below is printed only as a reminder to you that the maintenance work is required.

  • Page 174: Yamaha Motor Corporation, U.s.a. Atv Limited Warranty

    (6) months from the date of purchase. appropriate owner’s manual; YAMAHA MOTOR CORPORATION, U.S.A. MAKES NO 2. Give notice to an authorized Yamaha ATV dealer OTHER WARRANTY OF ANY KIND, EXPRESSED OR of any and all apparent defects within ten (10) days DURING THE PERIOD OF WARRANTY any authorized IMPLIED.
  • Page 175 Attention: Warranty Department 3. Each Yamaha ATV dealer is held responsible for his setup, service and war- ranty repair work. This will ensure that Yamaha Motor Corporation, U.S.A. has an up-to-date registration record in accordance with federal law.

  • Page 176: Yamaha Extended Service (Y.e.s.)

    Yamaha people who handle your warranty – and it Y.E.S. coverage is transferable to a new owner if you shows in the comprehensive coverage benefits. There sell or trade in your ATV. That can make your Yamaha are no mileage limitations. Coverage isn’t limited to much more valuable! “moving par ts”...
  • Page 177 Y.E.S. costs less within the first 90 days after you buy your Yamaha. See your dealer today! A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primar y ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 178 EBU26132 11-9...
  • Page 179 INDEX Drive select lever ............4-16 Drive select lever and driving in reverse ......6-3 Accessories and loading ..........6-6 Drive select lever safety system cable, adjusting ..8-45 Accessories, auxiliary jack ........... 4-23 Air filter element, cleaning ..........8-37 Axle boots ..............
  • Page 180 Label locations ............... 2-1 Safety information ............1-1 Light switch ..............4-8 Seat ................4-19 Low-range indicator light ..........4-4 Shock absorber assemblies, adjusting the front and rear ........4-22 Spark arrester, cleaning ..........8-41 Main switch ..............4-1 Spark plug, checking ............ 8-20 Maintenance and lubrication chart .........
  • Page 181 Wheel, installing ............8-64 Wheel, removing ............8-64...
  • Page 184 LOCATE AND READ OWNER’S MANUAL. FOLLOW ALL INSTRUCTIONS AND WARNINGS. (For replacement manual, call 1-800-532-1558) YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2008.05-4.0×1 CR...

This manual is also suitable for:

Grizzly yfm7fgpy

Table of Contents
