Audio quality without any compromise
•
Reference audio with ultra linear frequency response
•
Diversity Receiver with two matched antennas ensures reliable transmission
•
Stable signal due to a new reference radio electronic design with narrow filter
•
Quick frequency change function to support monitor engineers
•
Manual radio signal attenuator for a robust radio quality and more RF dynamic
IVM 4500 IEM Set
In-Ear Monitoring System
AKG IVM 4500 IEM in-ear monitoring provides higher level audio quality without compromising reference capability and caters
to all needs of engineers with leading edge reference audio technology.
IVM 4500 IEM offers a highly diversified system, which includes high-end radio electronic and a manual radio signal attenuator
for more RF dynamic. Antenna diversity, with two matched antennas and a new reference radio electronic design
contribute to the stable signals of the receiver.
The enhanced frequency setup shows the number of free channels, and new preset groups support TV channels. A quick
frequency change function supports monitor engineers throughout performances to make their projects easily adjustable.
With 30 MHz tuning range you can select 1200 frequencies and operate with up to 14 channels simultaneously within the
same frequency band. Receivers are powered by two AA size Alkaline (LR6), Lithium (FR6), AKG BP 4000 µC controlled
battery pack or Ni-MH rechargeable (HR6) battery and provide up to 10 hours of continuous operation.
Included in the IVM 4500 IEM system are the SPR 4500 IEM diversity receiver, the SST 4500 IEM transmitter and the IP 2
ear-channel headphones. The SPC 4500 antenna combiner, the SRA 2 W directional antenna and the RA 4000 W omni-
directional antenna complete the system.
Wireless In-Ear Monitoring System
Advertisement
Related Manuals for AKG IVM4500
Summary of Contents for AKG IVM4500
- Page 1 With 30 MHz tuning range you can select 1200 frequencies and operate with up to 14 channels simultaneously within the same frequency band. Receivers are powered by two AA size Alkaline (LR6), Lithium (FR6), AKG BP 4000 µC controlled battery pack or Ni-MH rechargeable (HR6) battery and provide up to 10 hours of continuous operation.
- Page 2 HUB 4000 Q communicating with Harman System Architect PC software shall be provided. The transmitter shall provide a lockable DC input for the supplied 12 V DC power supply. The transmitter shall measure 200 x 216 x 44 mm (W x D x H) and weigh 1070 g. The transmitter shall be the AKG SST...
- Page 3 The receiver shall operate off two AA size LR6 dry batteries, two AA size NiMH rechargeable batteries or a µC controlled battery pack or two AA size FR6 lithium batteries. The receiver shall measure 70 x 91 x 25 mm and weigh 165 g. The diversity bodypack receiver shall be the AKG SPR 4500 IEM or equivalent.
- Page 4 The antenna combiner shall operate from 12 VDC and provide a lockable DC input for the supplied 12 V DC power supply. The combiner shall measure 200 x 216 x 44 mm (7.8 x 8.5 x 1.7 in.), and weigh 1193 g (2.6 lbs.). The antenna combiner shall be the AKG SPC 4500 or equivalent.
-
Page 5: Power Supply
213 cables up to 20 m long. The antenna shall feature an integrated, swivelling 3/8" stand adapter thread, and 50-ohm BNC connectors. The carrier frequency range of the antenna shall be 500 MHz to 865 MHz, its antenna gain 4 dB. The passive directional antenna shall be the SRA 2 W from AKG. - Page 6 Wireless In-Ear Monitoring System 4 Channel IVM 4500 System SRA 2 W Directional Antenna PSU 4000 - Power Supply Unit SST 4500 – Transmitter SST 4500 – Transmitter Mixer SST 4500 – Transmitter SST 4500 – Transmitter 8 x XLR cable 4 Channel System Part List •...
