AKG CK 69-ULS User Instructions

AKG CK 69-ULS User Instructions

Condenser shotgun capsule
Hide thumbs Also See for CK 69-ULS:
Table of Contents
  • Technische Daten
  • Specifications
  • Caractéristiques Techniques
  • Dati Tecnici
  • Datos Técnicos

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 6

Quick Links

Download this manual
CK 69-ULS
Kondensator Richtrohrkapsel
Condenser Shotgun Capsule
Capsule canon électrostatique
Capsula a condensatore a tubo di fucile
Cápsula de condensador tipo ca˜ nón
Bedienungshinweise
User Instructions
Mode d'emploi
Istruzioni d'uso
Modo de empleo

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CK 69-ULS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AKG CK 69-ULS

Summary of Contents for AKG CK 69-ULS

  • Page 1 CK 69-ULS Kondensator Richtrohrkapsel Condenser Shotgun Capsule Capsule canon électrostatique Capsula a condensatore a tubo di fucile Cápsula de condensador tipo ca˜ nón Bedienungshinweise User Instructions Mode d’emploi Istruzioni d’uso Modo de empleo...
  • Page 2 C 480 B + CK 69-ULS combination to be about twice as far away from the sound source than one – CK 69-ULS, dos cápsulas tipo ca˜ n ón y un solo tubo de would place a hypercardioid microphone resulting in the same interferencia divisible.
  • Page 3 Technische Änderungen vorbehalten. Specifications subject to change without notice. Ces caractéristiques sont susceptibles de modifications. Ci riserviamo il diritto di effettuare modifiche tecniche. Nos reservamos el derecho de introducir modificaciones técnicas. AKG Akustische u. Kino-Geräte Gesellschaft m.b.H. JBL Professional Lemböckgasse 21–25, P.O.B. 158, A-1230 Vienna/AUSTRIA 8500 Balboa Blvd., Northridge, CA 91329, U.S.A.

  • Page 4: Technische Daten

    Technische Daten (gemessen mit Vorverstärker C 480 B) Wandlerprinzip: kombinierter Gradienten- und Interferenzempfänger Übertragungsbereich: 20 bis 18.000 Hz ± 2 dB von Sollkurve Leerlaufübertragungsfaktor bei 1000 Hz – Stellung 0 dB: 27 mV/Pa -31 dBV*) – Stellung +6 dB: 54 mV/Pa -25 dBV*) –...
  • Page 5 Dynamikbereich (A-bewertet) – Stellung 0 dB: 131 dB – Stellung +6 dB: 123 dB – Stellung -10 dB: 127 dB Steilheit des Baßabschwächungsfilters: 12 dB/Oktave, in allen Stellungen Vorabschwächung: +6 dB, 0 dB und -10 dB, schaltbar Speisespannung: P 48 (nach DIN 45 596 mit 48 V ± 4 V phantomgespeist) Stromaufnahme: 2 mA Abmessungen:...

  • Page 6: Specifications

    Specifications (measureed with C 480 B preamplifier) Type: Combined pressure gradient/interference microphone Frequency range: 20 to 18.000 Hz ± 2 dB from specified curve Sensitivity at 1000 Hz 0 dB position: 27 mV/Pa -31 dBV*) +6 dB position: 54 mV/Pa -25 dBV*) -10 dB position: 8.5 mV/Pa...
  • Page 7 Dynamic range (A weighted) 0 dB position: 131 dB +6 dB position: 123 dB -10 dB position: 127 dB Bass cut filter slope: 12 dB/octave, for all positions Gain: +6 dB, 0 dB und -10 dB, selectable Supply voltage: P 48 (phantom power to DIN 45 596 at 48 V ± 4 V) Current consumption: 2 mA Size (exclusive of C 480 B):...

  • Page 8: Caractéristiques Techniques

    Caractéristiques techniques (mesurées avec le préamplificateur C 480 B Principe: récepteur combiné à gradient de pression et interférences Gamme de fréquences: nominale: 20–18.000 Hz ± 2 dB de la courbe Sensibilité (1000 Hz): – position 0 dB: 27 mV/Pa -31 dBV*) –...
  • Page 9 Dynamique (pondérée A): – position 0 dB: 131 dB – position +6 dB: 123 dB – position -10 dB: 127 dB Pente du filtre d’atténuation des graves: 12 dB/octave, pour toutes les positions Pré-atténuation: commutable sur +6 dB, 0 dB et -10 dB Tension d’alimentation: P 48 (alimentation fantôme de 48 V ±...

  • Page 10: Dati Tecnici

    Dati tecnici (misurati con preamplificatore C 480 B) Funzionamento: trasduttore a gradiente di pressione/interferenza Risposta in frequenza: 20 fino a 18.000 Hz ± 2 dB dalla curva nominale Sensibilità a 1000 Hz – posizione 0 dB: 27 mV/Pa -31 dBV*) –...
  • Page 11 Gamma dinamica (ponderazione A) – posizione 0 dB: 131 dB – posizione +6 dB: 123 dB – posizione -10 dB: 127 dB Transconduttanza del filtro d’attenuazione dei bassi: 12 dB/ottava, in tutte le posizioni Amplificazione: +6 dB, 0 dB, -10 dB, commutabile Tensione di alimentazione: P 48 (seccondo DIN 45 596, alimentazione phantom di 48 V ±...

  • Page 12: Datos Técnicos

    Datos técnicos (medidos con el preamplificador C 480 B) Principio transductor: Recpetor combinado de gradiente e interferencia Gama de frecuencia: 20–18.000 Hz ± 2 dB de la curve de régimen Sensibilidad a 1000 Hz – Posición 0 dB: 27 mV/Pa -31 dBV*) –...
  • Page 13 Gama de volumen (pond. A) – Posición 0 dB: 131 dB – Posición +6 dB: 123 dB – Posición -10 dB: 127 dB Escarpadura del filtro de atenuación de graves: 12 dB/octava en todas las posiviones Amplitic ación: +6 dB, 0 dB y -10 dB, conmutable Tensión de alimentación: P 48 (según DIN 45 596 con 48 V ±...
