Summary of Contents for AKG Discreet Acoustics Modular PLUS Series
- Page 1 Discreet Acoustics Modular PLUS Series...
-
Page 2: Table Of Contents
Accessories ....................... 18 UWA9 M ......................18 W40 M ........................ 18 Application Examples ....................19 Dimensional Drawings ..................... 22 Comparison Chart ....................24 Notes ........................25 Discreet Acoustics Modular PLUS Series... -
Page 3: Safety And Environment
Only use the equipment for the applications described in this manual. AKG cannot accept any liability for damages resulting from improper handling or misuse. -
Page 4: Description
With just a few components on hand, the Discreet Acoustics Modular Series allows a nearly unlimited number of combinations. The Discreet Acoustics Modular Plus Series is the logical evolution of AKG’s Modular Series. It brilliantly fulfills all essential requirements for professional sound system applications. It is quick, reliable and available –... -
Page 5: Microphone Applications
Whether an omnidirectional, cardioid, or hypercardioid capsule will give the best results therefore depends on the specific application situation. OMNIDIRECTIONAL CAPSULES Omnidirectional capsules are primarily suited for recording use. NOTE Discreet Acoustics Modular PLUS Series... -
Page 6: Installation And Connection
Before replacing a Capsule Module, be sure to switch your sound system OFF in order to prevent unwanted noise. NOTE Choose the Phantom Power Adapter according to your application. PAESP M (page 13), PAE5 M (page 14) or PAE M (page 15). Discreet Acoustics Modular PLUS Series... -
Page 7: Modules Falling Into Place
Its special capsule is a further development of the legendary CK47 capsule. Like its predecessor, it is designed using AKG’s unique staple technology for brilliant studio-quality audio performance. -
Page 8: Ck43
Highly reliable capsule contacts prevent contact problems and ensure extra-long life Wide frequency range for a speech-optimized audio performance Included accessories: Windscreen Optional accessories: W40 M Wire-mesh windscreen Item Number: CK43 3165Z00020 Discreet Acoustics Modular PLUS Series... -
Page 9: Ck41
Highly reliable capsule contacts prevent contact problems and ensure extra-long life Wide frequency range for a speech-optimized audio performance Included accessories: Windscreen Optional accessories: W40 M Wire-mesh windscreen Item Number: CK41 3165Z00010 Discreet Acoustics Modular PLUS Series... -
Page 10: Gn15,30,50 M
Broad assortment of mounting accessories available for quick and hassle-free installation Included accessories: LED ring expander Item Number: GN15 M 3165H00080 165 mm (6.5 in) GN30 M 3165H00090 300 mm (11.8 in) GN50 M 3165H00100 500 mm (19.7 in) Discreet Acoustics Modular PLUS Series... -
Page 11: Gn155 M
Screw the Installation Module onto the supplied floor stand. Screw one of the three available phantom power adapters or MK150 M / MK150 ML onto the cable end. Connect the phantom power adapter to a microphone input with phantom power. Discreet Acoustics Modular PLUS Series... -
Page 12: Hm1000 M
Stretch a suitable length of fishing line horizontally across the room, passing the fishing line through the eye on the HM1000 M. Fix the fishing line to two opposite walls so as to create just enough downward pull to steady the microphone laterally. Discreet Acoustics Modular PLUS Series... -
Page 13: Paesp M
Accepts 9-52 V input for almost any available mixer inputs Feeds all Modular Plus Series capsules for highest flexibility Item Number: PAESP M 3165H00170 PAESP M Disconnect XLR-plug before changing settings! Discreet Acoustics Modular PLUS Series... -
Page 14: Pae5 M
The 5-pin XLR connector allows the audio signal and control voltage for the LED ring to be fed separately. Connector pin out: 1: Audio ground, 2: LED ring +, 3: Audio in phase, 4: LED ring –, 5: Audio return PAE5 M Discreet Acoustics Modular PLUS Series... -
Page 15: Pae M
Switchable bass roll off for reduction of body noise and proximity effect Highly reliable contacts to mounting modules prevent contact problems and ensure extra-long life Item Number: PAE M 3165H00150 PAE M Discreet Acoustics Modular PLUS Series... -
Page 16: Mounting Material, Cables And Accessories
PAESP M (powering module with programmable switch) in combination with GN15 M and GN30 M goosenecks modules. Required mounting hole: 53 mm (2.1 in). Item Number: H600 2426X00030 Discreet Acoustics Modular PLUS Series... -
Page 17: H500
ST45 6000H03080 SA60 The SA60 is a professional stand adapter for use with straight-shaft microphones. It perfectly fits all Modular Plus powering modules and is compatible with the ST45 table stand. Item Number: SA60 6000H60010 Discreet Acoustics Modular PLUS Series... -
Page 18: Cables
The MK150 ML is a reference connection cable to combine microphones of the Modular Plus Series with any AKG bodypack transmitter (except DPT70). It enables all Modular Plus microphones to be operated wirelessly. One side of the cable is equipped with the unique Modular Plus system connector, fitting all mounting modules of the series. -
Page 19: Application Examples
M GOOSENECK MODULE extremely slim and rugged PAESP M PROGRAMMABLE POWERING MODULE with integrated noiseless On/Off switch STANDADAPTER securely holds the gooseneck microphone in place REFERENCE TABLE STAND for easy installation and takedown Discreet Acoustics Modular PLUS Series... - Page 20 GN50 M EXTRA LONG GOOSENECK MODULE with two bends for easy positioning H500 SHOCK MOUNT MODULE designed to hold long gooseneck microphones PAE M PHANTOM POWER MODULE accepts 9-52 V input for almost any available mixer inputs Discreet Acoustics Modular PLUS Series...
- Page 21 GN155 M ELEGANT LOW PROFILE FLOOR STAND fitting ALL environments UWA9 M holds any AKG wireless bodypack transmitter (except DPT70) MK150 ML REFERENCE CONNECTION CABLE to connect any modular plus microphone with a wireless system QUICK-ABSORBING RUBBER SHOCK MOUNT...
-
Page 22: Dimensional Drawings
Dimensional Drawings 8 Dimensional Drawings Discreet Acoustics Modular PLUS Series... - Page 23 Dimensional Drawings Discreet Acoustics Modular PLUS Series...
-
Page 24: Comparison Chart
43 g Ohms Ohms (0.75 in) (2.58 in) (1.51 oz) PAESP M 150 Hz < 600 > 2000 9-52 V 4 mA 19,1 mm 100,5 mm 63 g Ohms Ohms (0.75 in) (3.96 in) (2.22 oz) Discreet Acoustics Modular PLUS Series... -
Page 25: Notes
Notes 10 Notes Discreet Acoustics Modular PLUS Series... - Page 26 Lemböckgasse 21–25, A-1230 Vienna/AUSTRIA, phone: (+43-1) 86654-0 e-mail: sales@akg.com For other products and distributors worldwide visit www.akg.com Technische Änderungen vorbehalten. Specifications subject to change without notice. Ces caractéristiques sont susceptibles de modifications. Ci riserviamo il diritto di effettuare modifiche tecniche. Nos reservamos el derecho de introducir modificaciones técnicas. Especificações sujeitas a mudanças sem aviso prévio.
