INSTALLATION AND MAINTENANCE MANUAL FOR
EXPLOSIONPROOF LIGHT FITTING
EXL210LED
1
No. Instr: I.EXL210LED.01
Release date: 06.09.2024
Edition: 2.2
Carefully
read
the
mounting the light fitting.
ATM Lighting sp. z o.o.,
ul. Maszynowa 30A,80-298 Gdańsk,
tel: +48 58 347 51 07, fax: +48 58 347 51 08
instructions before
Advertisement
Table of Contents
Related Manuals for ATM Lighting EXL210LED
Summary of Contents for ATM Lighting EXL210LED
- Page 1 EXPLOSIONPROOF LIGHT FITTING EXL210LED Carefully read instructions before mounting the light fitting. No. Instr: I.EXL210LED.01 ATM Lighting sp. z o.o., ul. Maszynowa 30A,80-298 Gdańsk, Release date: 06.09.2024 Edition: 2.2 tel: +48 58 347 51 07, fax: +48 58 347 51 08...
-
Page 2: Table Of Contents
TRANSPORT AND CONDITIOINS OF STORAGE ..............10 DISPOSAL OF WASTE EQUIPMENT ..................11 WARRANTY .......................... 11 No. Instr: I.EXL210LED.01 ATM Lighting sp. z o.o., ul. Maszynowa 30A,80-298 Gdańsk, Release date: 06.09.2024 Edition: 2.2 tel: +48 58 347 51 07, fax: +48 58 347 51 08... -
Page 3: General Information
1. GENERAL INFORMATION EXL210LED light fittings are designed to light indoor and outdoor areas in zone 2 of explosion hazard of gas, vapors, or clouds of flammable liquids mixed with air which belongs to IIA, IIB or IIC explosion group, T1-T5 temperature class. EXL210LED light fittings are also suitable to light areas in zones 21, 22 of explosion hazard of dust and flammable fibers mixed with air which self-ignition temperature is higher than 105°C, and the temperature of glowing layers of dust (5mm) is higher than 145°C. - Page 4 TECHNICAL INFORMATION Ex marking: • For version EXL210LED - **** - E* - *** - ** - ***** - GRP - PC II 3G Ex ec op is IIC T5 Gc II 2D Ex tb op is IIIC T60°C Db...
-
Page 5: Technical Information
62,2 W EXL210LED-1500-E6 46,9 W Type EXL210LED-0600 EXL210LED-1200 1300 EXL210LED-1500 1600 1000 No. Instr: I.EXL210LED.01 ATM Lighting sp. z o.o., ul. Maszynowa 30A,80-298 Gdańsk, Release date: 06.09.2024 Edition: 2.2 tel: +48 58 347 51 07, fax: +48 58 347 51 08... -
Page 6: Photometrical Data
• Failure to comply with rules of the installation and use can lead to personal injury or property loses. ATM Lighting sp. z o.o. company takes no responsibility in such cases. • Failure to comply with rules included in manual results with void of the manufacturer warranty. -
Page 7: Light Fitting Mounting
Light fitting is mounted with use of two brackets, designed for direct installation on a ceiling or on a wall. Spacing and size of the mounting holes are shown in point 2. The luminaire is equipped with a universal 8mm bolt-kit No. Instr: I.EXL210LED.01 ATM Lighting sp. z o.o., ul. Maszynowa 30A,80-298 Gdańsk, Release date: 06.09.2024 Edition: 2.2... -
Page 8: Electrical Connection
Use one wrench to tighten the sealing nut, while using the second wrench to block gland body against rotation, otherwise damage of the sealing can be caused and therefore sealing level will be decreased. No. Instr: I.EXL210LED.01 ATM Lighting sp. z o.o., ul. Maszynowa 30A,80-298 Gdańsk, Release date: 06.09.2024 Edition: 2.2... -
Page 9: Conditions Of Safety Use
Abnormalities found must be fixed. Rating and warning plates must be cleaned. Surfaces of insulating materials and covers must be clean. No. Instr: I.EXL210LED.01 ATM Lighting sp. z o.o., ul. Maszynowa 30A,80-298 Gdańsk, Release date: 06.09.2024 Edition: 2.2... -
Page 10: Cleaning
All parts considered as a spare parts must be ordered at manufacturer of light fitting. Additionally, the replacement of the light source may be performed by ATM Lighting Sp. z o.o and specially trained personnel, using original components supplied by ATM Lighting Sp. z o.o. -
Page 11: Disposal Of Waste Equipment
All specific information can be found in document „General terms and conditions warranty ATM Lighting sp. z o.o.” available at the website www.atmlighting.pl/en/ No. Instr: I.EXL210LED.01 ATM Lighting sp. z o.o., ul. Maszynowa 30A,80-298 Gdańsk, Release date: 06.09.2024 Edition: 2.2... - Page 12 ADDRESS: ATM Lighting sp. z o.o. ul. Maszynowa 30A 80-298 Gdańsk tel: +48 58 347 51 07 fax: +48 58 347 51 08 office@atmlighting.pl No. Instr: I.EXL210LED.01 ATM Lighting sp. z o.o., ul. Maszynowa 30A,80-298 Gdańsk, Release date: 06.09.2024 Edition: 2.2...
