Summary of Contents for Gigaset DESK 600
- Page 1 en<P> ru tr ar...
- Page 2 en<P> ru tr ar...
- Page 3 Overview Gigaset DESK 600 Overview Gigaset DESK 600 Keys Control key Display Hands-free/speaker key Menu/ Volume up key Direct dial keys Direct dial toggle key Last number redial key Hash key/lock key + upper/lower case key 10 Pause key 11 Volume down key...
- Page 4 Checking the package contents Check the package contents of your telephone before you start to use it. Your Gigaset DESK 600 telephone – referred to as the ‘telephone’ , is suit- able for making and receiving calls within a telephone network. Your Handset telephone is only suitable for private use in enclosed indoor spaces.
- Page 5 Connecting the telephone Connecting the telephone Insert the short end of the spiralled handset cable into the socket in Wall mounting the handset (6) and the long end into the socket (4) marked Warning! Danger of death from electric shock or gas the base of the device.
- Page 6 The telephone’s functions are activated and the menu is navigated using the control key. The The keypad and the display are available to operate your Gigaset DESK functions offered depend on the operating sit- 600 and view its functions and menus. In addition, the display menu uation.
- Page 7 Making/receiving calls Step-by-step instructions for menu operation Telephone directory, call list and redial list The user guide contains individual steps that are required for menu nav- The telephone directory, call list and redial list can be opened using the igation in abbreviated notation, e.g.: menu or keys.
- Page 8 Making/receiving calls Switching the handsfree function on/off Dialling from the call list The call list contains the telephone numbers of the last 50 incoming This telephone allows you to make calls and implement settings with the calls. handset replaced (hands-free). The optimum speaking distance from Prerequisite: Telephone number display is possible for incoming calls the microphone is approx.
- Page 9 Saving telephone numbers Deleting a dialled telephone number Incoming calls With the handset replaced: Press the control key or redial Incoming calls are signalled by the ring tone and shown on the display. key. With telephone number display ( p. 13), you can see the telephone number on the display.
- Page 10 You can switch between entering a name and entering a number by using You can save up to 100 entries to the telephone directory of the Gigaset Deleting telephone directory entries DESK 600 (max. 32 digits for the telephone number).
- Page 11 Using the call list (CLIP) Using the call list (CLIP) Telephone settings Incoming calls are saved if the number is transmitted ( p. 13). Up to 50 Basic settings entries are saved. The oldest call is automatically deleted when there are All basic settings are accessed via the menu Phone setup.
- Page 12 Telephone settings Setting the VIP melody Press the volume up or down key. You can set one of the ring tones as VIP Melody. When you have assigned a telephone number in the telephone directory VIP mode sta- Press the key.
- Page 13 Security settings Security settings Switching one-touch call (baby call) on/off If a telephone number is set for one-touch call, it is dialled automatically when you raise the handset (or press ) and then press any number key. You cannot dial another number, but you can answer incoming calls. Note: Security If you have changed the PIN, you must enter it again to access the Secu-...
- Page 14 Operation with PBX/routers Blocking numbers Changing the dialling mode You can block calls to specific dialling codes (e.g. chargeable codes), The telephone supports the following dialling modes: max. 3 numbers with 5 digits each. Tone dialling Pulse dialling Security Call block Depending on your PBX, you may need to change your telephone’s dial- Select Call block 1 (or 2 or 3).
- Page 15 Network services of public telephone systems Network services of public telephone Changing the CLIP format With the CLIP format, you define the procedure that your Gigaset DESK systems 600 uses to handle the information transmitted by the network, includ- ing the telephone number, name, date and time.
- Page 16 Network services of public telephone systems Deleting the ‘Message available’ indicator Switching call forwarding off NET services Call Divert Deactivate Some network operators offer services that allow caller messages to be saved (e.g. answer machine services). Select forwarding type All Calls, No Answer or When If one or more new messages have been left with the network operator, Busy.
- Page 17 Menu tree Automatic callback Switching automatic callback on For a caller on your line to use the automatic callback function while you If a dialled number is busy, you can activate the automatic callback func- are on the telephone, you must switch the function on. tion.
- Page 18 Menu tree Audio settings Ring tones p. 10 VIP Melody p. 10 Handset Volume p. 9 Speaker Volume p. 10 Headset Volume p. 10 Mute mode p. 6 Ringer mode p. 10 NET services Call Divert p. 14 CW Signal p.
- Page 19 Character sets Character sets Greek Taste 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x € £ ¥ ¤ The following characters can be entered using the keypad: Α Β Standard Δ Ε Φ 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x Γ...
- Page 20 Character sets Power adapter Manufacturer Salom Electric (Xiamen) Co. Ltd. Commercial register 91350200612003878C 31 Building, Huli Industrial District, Xiamen, Fujian 361006, P.R. China Model ID C39280-Z4-F204 Input voltage 230 V Input alternating current frequency 50 Hz Output voltage 6.5 V Output current 0.3 A Output power...
- Page 21 Economic Area (with the exception of Switzerland) depending on national type approval. Country-specific requirements have been taken into consideration. We, Gigaset Communications GmbH, declare that this device meets the essential requirements and other relevant regulations laid down in Directives 2014/30/EU and 2014/35/EU.
- Page 22 Issued by Gigaset Communications GmbH Frankenstraße 2, D-46395 Bocholt © Gigaset Communications GmbH 2023 All rights reserved. Subject to availability. Rights of modification reserved. www.gigaset.com A30350-M224-A701-1-X119 en<P> ru tr ar...
