R183-P90-AAJ1
Rack Arm Server - AmpereOne® Family - 1U DP 4-Bay Gen5 NVMe/SATA/SAS-4 Titanium
User Manual
Rev. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AmpereOne Series and is the answer not in the manual?

Questions and answers

Related Manuals for Gigabyte AmpereOne Series

Summary of Contents for Gigabyte AmpereOne Series

  • Page 1 R183-P90-AAJ1 Rack Arm Server - AmpereOne® Family - 1U DP 4-Bay Gen5 NVMe/SATA/SAS-4 Titanium User Manual Rev. 1.0...
  • Page 2 For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller portal: http://reseller.b2b.gigabyte.com For further technical assistance, please contact your GIGABYTE representative or visit https://esupport.gigabyte.com/ to create a new support ticket For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email: server.grp@gigabyte.com...
  • Page 3 Conventions The following conventions are used in this user's guide: NOTE! Gives bits and pieces of additional information related to the current topic. CAUTION! Gives precautionary measures to avoid possible hardware or software problems. WARNING! Alerts you to any damage that might result from doing or not doing specific actions.

  • Page 4: Server Warnings And Cautions

    Server Warnings and Cautions Before installing a server, be sure that you understand the following warnings and cautions. WARNING! To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature.

  • Page 5: Electrostatic Discharge (Esd)

    Electrostatic Discharge (ESD) CAUTION! ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE, PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT- TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER WHEN HANDLING PARTS.
  • Page 6 WARNING! The equipment should only be repaired, maintained or replaced by skilled personnel.

  • Page 7: Table Of Contents

    Table of Contents Chapter 1 Hardware Installation ...................10 Installation Precautions .................. 10 Product Specifications ..................11 System Block Diagram ................... 15 Chapter 2 System Appearance ..................16 Front View ...................... 16 Rear View ....................... 17 Front Panel LEDs and Buttons ............... 18 2-3-1 RoT LEDs .......................19 Rear System LAN LEDs .................
  • Page 8 Motherboard Components ................43 Jumper Setting ....................45 G-SC Module ....................46 4-3-1 CDCR115 .......................46 Backplane Board Storage Connector ............47 4-4-1 CBP1048 ........................47 Chapter 5 BIOS Setup ....................48 The Main Menu ....................50 Advanced Menu ..................... 53 5-2-1 Trusted Computing ....................54 5-2-2 S5 RTC Wake Settings ...................55 5-2-3...
  • Page 9 5-4-5 BMC Network Configuration ...................88 5-4-6 IPv6 BMC Network Configuration ................89 Security Menu ....................90 5-5-1 Secure Boot ......................91 Boot Menu ...................... 94 Save & Exit Menu ................... 96 BIOS Recovery ....................98 BIOS POST Beep code (AMI standard) ............99 5-9-1 PEI Beep Codes .....................99 5-9-2...

  • Page 10: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Installation Precautions The motherboard/system contain numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the service guide and follow these procedures: • Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.

  • Page 11: Product Specifications

    Product Specifications NOTE: We reserve the right to make any changes to the product specifications and product-related information without prior notice. System Š 438 x 43.5 x 815 (W x H x D, mm) Dimension Š Security Server Socket Operating Properties AmpereOne®...
  • Page 12 Expansion Slot Riser Card CRS101J: Š - 1 x FHHL x16 (Gen5 x16), from CPU_0 Riser Card CRS101K: Š Security Server Socket Operating Properties - 1 x FHHL x16 (Gen5 x16), from CPU_1 System fan System fan System fan Power Supply 1 x OCP NIC 3.0 (Gen5 x16), from CPU_0 Š...
  • Page 13 - Max 2000W/ 220-240V~ or 240Vdc Input +12.2V/ 164A +12.2Vsb/ 3A GIGABYTE offers PSUs with various efficiency ratings and power outputs. Full [Note] redundancy may depend on your server configuration, and alternative PSU options may be needed. Please contact our sales representatives for the best power solution...
  • Page 14 System Aspeed® AST2600 Baseboard Management Controller Š Management GIGABYTE Management Console web interface Š Dashboard Š Security Server cket Operating Properties HTML5 KVM Š Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Š System fan System fan System fan Power Supply Sensor Reading History Data Š...

  • Page 15: System Block Diagram

    System Block Diagram Hardware Installation - 15 -...

  • Page 16: Chapter 2 System Appearance

    Chapter 2 System Appearance Front View HDD0 HDD1 HDD2 HDD3 Description Front USB 3.2 Gen1 Ports Front Panel LEDs and Buttons 3.5"/2.5" Drive Bays NOTE! Drives with green latches support NVMe. • Please Go to Chapter 2-3 Front Panel LED and Buttons for detail description of function LEDs. System Appearance - 16 -...

  • Page 17: Rear View

    Rear View SLOT3 PSU2 SLOT4 PSU1 SLOT2 SLOT1 Description Mini DisplayPort ID LED USB 3.2 Gen1 Port x 2 Data LAN Port x 2 Management LAN Port OCP 3.0 Slot (Option/SFF) PCIe Card Slot • Remove the LAN Cable. See 3-12 Removing the LAN Cable on page 40. System Appearance - 17 -...

  • Page 18: Front Panel Leds And Buttons

    Front Panel LEDs and Buttons No. Name Color Status Description Reset Button Press the button to reset the system. Press the button server generates a NMI to the processor NMI button if the multiple-bit ECC errors occur, which effectively halt the server.

  • Page 19: Rot Leds

    2-3-1 RoT LEDs Status LED ID LED LED on Front panel (Note5) ID LED Status LED EC Firmware (FW) Authentication fail or not exit EC FW is broken or not exit (Note1) Authenticating/Recovering BMC/BIOS Images Authenticating Images Blinks Blue Blinks Green Recovering BMC Active Flash 4 times per 4 times per...
  • Page 20 Blinks Blue Blinks Green 2 times per 2 times per BMC : AUTH fail after doing recovery (Note3) second second [ON OFF OFF] [ON OFF OFF] Blinks Blue Blinks Amber 2 times per 2 times per BIOS : AUTH fail after doing recovery (Note3) second second...

  • Page 21: Rear System Lan Leds

    Rear System LAN LEDs Name Color Status Description Yellow 1 Gbps data rate 1GbE Green 100 Mbps data rate Speed LED 10 Mbps data rate Link between system and 1GbE Green network or no access Link/ Blink Data transmission or receiving is occurring Activity No data transmission or receiving is occurring...

  • Page 22: Power Supply Unit (Psu) Led

    Power Supply Unit (PSU) LED NOTE! The power supply may be vary based on the system configuration. PSU LED State Description No AC power to all power supplies 1Hz Green Blinking AC present / only standby on / Cold redundant mode 2Hz Green Blinking Power supply firmware updating mode AC cord unplugged or AC power lost;...

  • Page 23: Hard Disk Drive Leds

    Hard Disk Drive LEDs LED #1 LED #2 HDD Present RAID SKU LED #1 Locate Rebuilding HDD Access Fault (No Access) Green ON(*1) BLINK (*2) Disk LED (LED on Back Panel) Amber No RAID configuration Removed HDD Green ON(*1) (via PCH, HBA) Slot (LED on Amber Back Panel)

  • Page 24: Chapter 3 System Hardware Installation

    Chapter 3 System Hardware Installation Pre-installation Instructions Computer components and electronic circuit boards can be damaged by electrostatic discharge. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself. •...

  • Page 25: Removing Chassis Cover

    Removing Chassis Cover Before you remove or install the system cover • Make sure the system is not turned on or connected to AC power. Follow these instructions to remove the chassis cover: Remove the screws on both sides of the back chassis cover. (Note: For safe shipping, installation screws are added and should be removed before deployment/putting it in the server cabinet.) Remove the screw securing the back chassis cover.

  • Page 26: Removing And Installing The Fan Duct

    Removing and Installing the Fan Duct Follow these instructions to remove/install the fan duct: Lift up to remove the fan duct To install the fan duct, align the fan duct with the guiding groove. Push down the fan duct into chassis until it is firmly seated.

  • Page 27: Removing And Installing The Heat Sink

    Removing and installing the Heat Sink Read the following guidelines before you begin to remove/install the heat sink: • Always turn off the computer and unplug the power cord from the power outlet before installing the heat sink to prevent hardware damage. •...

  • Page 28: Installing The Cpu

    Installing the CPU Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.
  • Page 29 • Lock the CPU by using a Torx T20 screwdriver to tighten screw. • When installing the heatsink to CPU, use Torx T20 screwdriver to tighten 4 captive nuts in sequence as 1-6. • The ILM screw tightening torque: 1.5 kgf-cm •...

  • Page 30: Installing The Memory

    Installing the Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.

  • Page 31: Installing The Memory

    3-5-2 Installing the Memory Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. Be sure to install DDR5 DIMMs on this motherboard. Make sure your DIMM slots have a single latch or a double latch.

  • Page 32: Dimm Population Table

    3-5-3 DIMM Population Table Speed (MT/s); Voltage (V); Slots per Channel(SPC) and DIMM Capacity DIMM per Channel (DPC) (GB) Ranks Per DIMM and Type 1 Slot per Channel 2 Slots per Channel Data Width DIMM Density 1DPC 1DPC 2DPC 16Gb 1.1V 1.1V 1.1V...

  • Page 33: Installing The Pci Expansion Card

    Installing the PCI Expansion Card • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to installing a PCIe card.

  • Page 34: Installing The Mezzanine Card

    Installing the Mezzanine Card 3-7-1 OCP 3.0 Use of the following type of OCP 3.0 NIC is recommended: • OCP 3.0 SFF with Pull Tab • OCP 3.0 SFF with Ejector Latch Follow these instructions to install an OCP 3.0 mezzanine card: Remove the two screws securing the mezzanine card slot cover.

  • Page 35: Installing The Hard Disk Drive

    Installing the Hard Disk Drive Read the following guidelines before you begin to install the HDD: • Take note of the drive tray orientation before sliding it out. • The tray will not fit back into the bay if inserted incorrectly. •...
  • Page 36 Follow these instructions to install 2.5" hard disk drive into 3.5" HDD Tray: Press the release button. Extend the locking lever. Pull the locking lever in the direction indicated to remove the HDD tray. Align the hard disk drive with the positioning screw on the HDD tray. Secure the hard disk drive with five screws.

  • Page 37: Installing The M.2 Device And Heat Sink

    Installing the M.2 Device and Heat Sink CAUTION The position of the stand-off screw will depend on the size of the M.2 device. The stand-off screw is pre-installed for 22110 cards as standard. Refer to the size of the M.2 device and change the position of the stand-off screw accordingly.

  • Page 38: Replacing The Fan Assembly

    3-10 Replacing the Fan Assembly • Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power switch is in the off position. Ensure that the system is powered-down and all power sources have been disconnected from the server prior to replacing a system fan.

  • Page 39: Replacing The Power Supply

    3-11 Replacing the Power Supply CAUTION! • In order to reduce the risk of injury from electric shock, disconnect AC power from the power supply before removing the power supply from the system Follow these instructions to replace the power supply: Flip and then grasp the power supply handle.

  • Page 40: Removing The Lan Cable

    3-12 Removing the LAN Cable Follow these instructions to remove the LAN cable: Press the release latch while simultaneously pulling out the LAN cable. System Hardware Installation - 40 -...

  • Page 41: Cable Routing

    3-13 Cable Routing Motherboard: FP_1 Front Switch/LED Cable Front IO Board: FP_1 Motherboard: F_USB1 Front USB 3 Cable Front IO Board: F_USB3 System Hardware Installation - 41 -...
  • Page 42 CPU0 CPU1 Motherboard: SL_SATA1 SATA Cable Backplane Board: SATA0/ SATA1/ SATA2/ SATA3 Motherboard: MCIOP0_0AB1 NVMe 0-1 Cable Backplane Board: U.2 0/ U.2 1 Motherboard: MCIOP1_4AB1 NVMe 2-3 Cable Backplane Board: U.2 2/ U.2 3 Motherboard: BP_1 Backplane Board Signal Cable Backplane Board: BP_1 Motherboard: ATX1 Backplane Board Power Cable...

  • Page 43: Chapter 4 Motherboard Components

    Chapter 4 Motherboard Components Motherboard Components CPU0 CPU1 Item Description P12V Power Connector (P12V_INTE2) 2 x 7 Pin ATX Power Connector (ATX1) MCIO Connector (MCIOP1_3AB1/3CD1/PCIe Gen5) MCIO Connector (MCIOP1_4AB1/PCIe Gen5) SlimSAS Connector (SL_SATA1) 2 x 2 P12V Backplane Power Connector (12V_BP2) SlimSAS Connector (SL_SATA2) SlimSAS Connector (SL_SATA3) MCIO Connector (MCIOP1_2AB1/2CD1/PCIe Gen5)
  • Page 44 Item Description 2 x 4 Pin P12V GPU Power Connector (P12V_GPU2) 2 x 3 Pin ATX Power Connector (ATX3) Power Supply Connector#1 (Primary) IPMB Connector Riser Connector (SLOT1/PCIe Gen5) Riser Connector (SLOT2/PCIe Gen5) OCP 3.0 Connector (OCP1/PCIe Gen5 x16) M.2 Slot (PCIe Gen5 x4, NGFF-22110/Supports heatsink) TPM Module Connector (SPI Interface) System Battey Socket IO Card Connector...

  • Page 45: Jumper Setting

    Jumper Setting NCSI Sw ch G-SC MB SW.1 Onboard LAN ON OFF Slot#1 OCP3.0 Slot#2 OCP3.0 BIOS0 BMC1 BMC2 BIOS1 Clear CMOS CLR_CMOS Normal Opera on (Default) Clear CMOS data CPU0 CPU1 Motherboard Components - 45 -...

  • Page 46: G-Sc Module

    G-SC Module 4-3-1 CDCR115 BIOS0 BMC1 BMC2 BIOS1 Item Description 10/100/1000 Server Management LAN Port Data LAN Port x 2 USB 3.2 Gen1 Port x 2 Mini DisplayPort Motherboard Components - 46 -...

  • Page 47: Backplane Board Storage Connector

    Backplane Board Storage Connector 4-4-1 CBP1048 Item Description SlimSAS 4i Connector (SFF-8654 / SATA0) SlimSAS 4i Connector (SFF-8654 / SATA1) SlimSAS 4i Connector (SFF-8654 / SATA2) SlimSAS 4i Connector (SFF-8654 / SATA3) MCIO 4i (SFF-TA-1016 / U.2 0) MCIO 4i (SFF-TA-1016 / U.2 1) MCIO 4i (SFF-TA-1016 / U.2 2) MCIO 4i (SFF-TA-1016 / U.2 3) Motherboard Components...

  • Page 48: Chapter 5 Bios Setup

    Chapter 5 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the EFI on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters, loading the operating system etc. The BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.

  • Page 49: Server Management

     Main This setup page includes all the items of the standard compatible BIOS.  Advanced This setup page includes all the items of AMI BIOS special enhanced features. (ex: Auto detect fan and temperature status, automatically configure hard disk parameters.) ...

  • Page 50: The Main Menu

    The Main Menu Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter other sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the bottom line of the Main Menu.
  • Page 51 Parameter Description BIOS Information Access Level Displays the privileges level information. System Project Name Displays the system project name information. Project Name Displays the motherboard project name information Project Version Displays version number of the BIOS setup utility. Build Date and Time Displays the date and time when the BIOS setup utility was created.
  • Page 52 Parameter Description CPLD Information MB/SCM/location 2 Display CPLD information. System Language Option: English. System Date Sets the date following the weekday-month-day-year format. System Time Sets the system time following the hour-minute-second format. BIOS Setup - 52 -...

  • Page 53: Advanced Menu

    Advanced Menu The Advanced Menu displays submenu options for configuring the function of various hardware components. Select a submenu item, then press <Enter> to access the related submenu screen. BIOS Setup - 53 -...

  • Page 54: Trusted Computing

    5-2-1 Trusted Computing Parameter Description Configuration Enable/Disable BIOS support for security device. OS will not show security device. TCG EFI protocol and INT1A interface will not be Security Device Support available. Options available: Enabled, Disabled. Default setting is Enabled. BIOS Setup - 54 -...

  • Page 55: S5 Rtc Wake Settings

    5-2-2 S5 RTC Wake Settings Parameter Description Enable/Disable system wake on alarm event. Options available: Disabled, Fixed Time, Dynamic Time. When Fixed Time Wake System from S5 is selected, system will wake on the hr::min::sec specified. Default setting is Disabled. BIOS Setup - 55 -...

  • Page 56: Uefi Variables Protection

    5-2-3 UEFI Variables Protection Parameter Description Control the NVRAM Runtime Variable protection through system Password protection of Runtime admin password. Variables Options available: Enabled, Disabled. Default setting is Enabled. BIOS Setup - 56 -...

  • Page 57: Serial Port Console Redirection

    5-2-4 Serial Port Console Redirection Parameter Description Select whether to enable console redirection for specified device. Console COM1/Serial Over LAN redirection enables the users to manage the system from a remote Console Redirection (Note) location. Options available: Enabled, Disabled. Default setting is Enabled. Press [Enter] to configure advanced items.
  • Page 58 Parameter Description Parity Š – A parity bit can be sent with the data bits to detect some transmission errors. – Even: parity bit is 0 if the num of 1's in the data bits is even. – Odd: parity bit is 0 if num of 1's in the data bits is odd. –...

  • Page 59: Pci Subsystem Settings

    5-2-5 PCI Subsystem Settings Description Parameter Displays the PCI Bus Driver version information. PCI Bus Driver Version When enabled, this setting will initialize the device expansion ROM GENZ_SLOT1/2/3/4 for the related devices. OCP1/2 Options available: Disabled, Enabled. Default setting is Enabled. I/O ROM Enable/Disable the onboard LAN devices.
  • Page 60 Description Parameter Options available: Disabled, Enabled. Default setting is Disabled. VGA Palette Snoop Options available: Disabled, Enabled. Default setting is Disabled. PERR# Generation Options available: Disabled, Enabled. Default setting is Disabled. SERR# Generation If the system has SR-IOV capable PCIe devices, this item Enable/ Disable Single Root IO Virtualization Support.

  • Page 61: Info Report Configuration

    5-2-6 Info Report Configuration Description Parameter Post Report Enable/disable post report support. Post Report Options available: Enabled, Disabled. Default setting is Enabled. Options available: 0,1,2,3,4,5,6,7,8,9,10, Until Press ESC. Delay Time Default setting is 1. Error Message Report Enable/disable Info error message support. Info Error Message Options available: Enabled, Disabled.

  • Page 62: Usb Configuration

    5-2-7 USB Configuration Parameter Description USB Configuration USB Module Version Displays the USB module version information. USB Controllers Displays the supported USB controllers. USB Devices: Displays the USB devices connected to the system. Enable/Disable the XHCI (USB 3.0) Hand-off support. XHCI Hand-off Options available: Enabled, Disabled.

  • Page 63: Network Stack Configuration

    5-2-8 Network Stack Configuration Parameter Description Enable/Disable the UEFI network stack. Network Stack Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 PXE feature. Ipv4 PXE Support (Note) Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 HTTP feature. Ipv4 HTTP Support (Note) Options available: Enabled, Disabled.

  • Page 64: Nvme Configuration

    5-2-9 NVMe Configuration Parameter Description NVMe controller and Drive Displays the NVMe devices connected to the system information BIOS Setup - 64 -...

  • Page 65: Sata Configuration

    5-2-10 SATA Configuration Parameter Description Displays the installed HDD devices information. System will automatically SATA Configuration detect HDD type. BIOS Setup - 65 -...

  • Page 66: Graphic Output Configuration

    5-2-11 Graphic Output Configuration Parameter Description Graphic Output Configuration Selects output device type. Output Device Type Options available: First loaded Device, Onboard Device, External Device, Specific Device. Default setting is Onboard Device. Use Onboard graphics output under OS (BMC KVM requires onboard graphics output).

  • Page 67: Power Restore Configuration

    5-2-12 Power Restore Configuration Parameter Description Specifies what state when power is re-applied after a power failure (G3 state). Power Restore Options available: Power Off, Power On, Last State. Default setting is Last State. BIOS Setup - 67 -...

  • Page 68: Tls Auth Configuration

    5-2-13 Tls Auth Configuration Parameter Description Press [Enter] for configuration of advanced items. Enroll Cert Š – Press [Enter] to enroll a certificate • Enroll Cert Using File • Cert GUID Server CA Configuration Input digit character in 1111111-2222-3333-4444-1234567890ab format. –...

  • Page 69: Intel(R) I350 Gigabit Network Connection

    5-2-14 Intel(R) I350 Gigabit Network Connection BIOS Setup - 69 -...
  • Page 70 Description Parameter Press [Enter] to configure advanced items. Link Speed Š – Allows for automatic link speed adjustment. – Options available: Auto Negotiated, 10 Mbps Half, 10 Mbps Full, 100 Mbps Half, 100 Mbps Full. Default setting is Auto Negotiated. Wake On LAN NIC Configuration Š...

  • Page 71: Mac Ipv4 Network Configuration

    5-2-15 MAC IPv4 Network Configuration Parameter Description Indicates whether network address is configured successfully or not. Configured Options available: Enabled, Disabled. Default setting is Disabled. Options available: Enabled, Disabled. Default setting is Disabled. Enable DHCP (Note) Local IP Address Press [Enter] to configure local IP address. (Note) Press [Enter] to configure local NetMask.

  • Page 72: Mac Ipv6 Network Configuration

    5-2-16 MAC IPv6 Network Configuration Parameter Description Press [Enter] to configure advanced items. Displays the MAC Address information. Š Interface ID Š – The 64 bit alternative interface ID for the device. The string is colon separated. e.g. ff:dd:88:66:cc:1:2:3. DAD Transmit Count Š...

  • Page 73: Ram Disk Configuration

    5-2-17 RAM Disk Configuration Parameter Description Specifies the type of memory to use from available memory pool in system to create a disk. Disk Memory Type Options available: Boot Service Data, Reserved. Default setting is Boot Service Data. Creates a raw RAM disk. Size (Hex) Š...

  • Page 74: Driver Health

    5-2-18 Driver Health Parameter Description Driver Health Displays health status of the drivers/controllers if installed. BIOS Setup - 74 -...

  • Page 75: Chipset Setup Menu

    Chipset Setup Menu Chipset Setup menu displays submenu options for configuring the function of the chipset. Select a submenu item, then press <Enter> to access the related submenu screen. Parameter Description Memory Configuration Press [Enter] for configuration of advanced items. CPU Configuration Press [Enter] for configuration of advanced items.

  • Page 76: Memory Configuration

    5-3-1 Memory Configuration Parameter Description Memory Configuration Total Memory/ Effective Memory/ Displays the technical specifications for the installed memory module. Current Memory Speed Memory Operating Speed Options available: Auto, 3200, 3600, 4000, 4400, 4800, 5200, 5600. Default setting is Auto. Selection Force 2X Refresh Rate Options available: Disabled, Enabled.

  • Page 77: Cpu Configuration

    5-3-2 CPU Configuration Parameter Description CPU Configuration Processor version/ Number of processors/cores enabled/ Displays the technical specifications for the installed processor(s).. Processor clock/ L1 Cache ID/ L2 cache/ System level cache Options available: Monolithic, Hemisphere, Quadrant. Sub-NUMA Mode Default setting is Monolithic. Enable/Disable PPTT to indicate SLC as L3 Cache.

  • Page 78: Acpi Configuration

    5-3-3 ACPI Configuration Parameter Description ACPI Configuration Options available: Disabled, Enabled. Default setting is Enabled. CPPC Support CPPC AMU System Register Options available: Disabled, Enabled. Default setting is Disabled. Support Self-Hosted Trace Options available: Disabled, Enabled. Default setting is Disabled. Options available: Disabled, Enabled.

  • Page 79: Pcie Device Configuration

    5-3-4 PCIE Device Configuration Parameter Description PCIE Device Configuration Press [Enter] to configure advanced items. Max_Payload_Size/Max_Read_Request_Size mode Š – Options available: Auto Manual. Default setting is Auto. Max Payload Size Š – Options available: 512 bytes, 256 bytes, 128 bytes. Default PCIe Device# setting is 512 bytes.

  • Page 80: Pcie Root Complex Configuration

    5-3-5 PCIE Root Complex Configuration Parameter Description PCIE Root Complex Configuration PCIe Lanes Bifurcation Mode Options available: Manual, Default. Default setting is Default. Options available: Disabled, Enabled. Default setting is Disabled. SMMU PMU Root Complex # Press [Enter] to view advanced items. (Note) (Note) This item is configurable when PCIe Lanes Bifurcation Mode is set to Manual.

  • Page 81: Power Policy

    5-3-6 Power Policy Parameter Description Options available: Standard, Best Performance, Energy Efficient. Power Policy Quick Settings Default setting is Standard. BIOS Setup - 81 -...

  • Page 82: Server Management Menu

    Server Management Menu Parameter Description BMC Self Test Status/ BMC Device ID/ BMC Device Revision/ Displays the technical specification of the BMC controller. BMC Firmware Revision/ IPMI Version/ IPMI BMC Interface BMC Support Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable FRB-2 timer (POST timer).
  • Page 83 Parameter Description OS Wtd Timer Configures OS Watchdog Timer. The value is between 1 to 30 minutes. Timeout Default setting is 10 minutes. (Note) Configure OS Watchdog Timer Policy. OS Wtd Timer Options available: Reset, Do Nothing, Power Down, Power Cycle. Policy (Note) Default setting is Reset.

  • Page 84: System Event Log

    5-4-1 System Event Log Parameter Description Enabling / Disabling Options Change this item to enable or disable all features of System Event SEL Components Logging during boot. Options available: Enabled, Disabled. Default setting is Enabled. Erasing Settings Choose options for erasing SEL. Erase SEL Options available: No/Yes, On next reset/Yes, On every reset.

  • Page 85: View Fru Information

    5-4-2 View FRU Information The FRU page is a simple display page for basic system ID information, as well as System product information. Items on this window are non-configurable. (Note) The model name will vary depends on the product you purchased BIOS Setup - 85 -...

  • Page 86: Bmc Self Test Log

    5-4-3 Bmc self test log Parameter Description Log area usage = 00 out of 20 logs Erase Log Options available: Yes, On every reset/ No. Default setting is No. Options available: Clear Log, Do not log any more. Default setting is Do When log is full not log any more.

  • Page 87: Bmc Vlan Configuration

    5-4-4 BMC VLAN Configuration Description Parameter BMC VLAN Configuration Select to configure BMC VLAN ID. The valid range is from 0 to 4094. When BMC VLAN ID set to 0, BMC VLAN ID will be disabled. Select to configure BMC VLAN Priority. The valid range is from 0 to 7. BMC VLAN Priority When BMC VLAN ID is set to 0, BMC VLAN Priority will not be selected.

  • Page 88: Bmc Network Configuration

    5-4-5 BMC Network Configuration Parameter Description BMC network configuration Select NCSI and Dedicated Options available: Mode1 (Dedicated), Mode2 (NCSI), Mode3 (Failover). Default setting is Mode3 (Failover). Lan Channel 1 Selects to configure LAN channel parameters statically or dynamically (DHCP). Do nothing option will not modify any BMC network parameters Configuration Address source during BIOS phase.

  • Page 89: Ipv6 Bmc Network Configuration

    5-4-6 IPv6 BMC Network Configuration Parameter Description IPv6 BMC network configuration IPv6 BMC Lan Channel 1 Enable/Disable IPv6 BMC LAN channel function. When this item is disabled, the system will not modify any BMC network during BIOS IPv6 BMC Lan Option phase.

  • Page 90: Security Menu

    Security Menu The Security menu allows you to safeguard and protect the system from unauthorized use by setting up access passwords. There are two types of passwords that you can set: • Administrator Password Entering this password will allow the user to access and change all settings in the Setup Utility. •...

  • Page 91: Secure Boot

    5-5-1 Secure Boot The Secure Boot feature is applicable if supported by your Operating System. If your Operating System is not supporting Secure Boot, the system will hang when starting the Operating System. Parameter Description System Mode Displays if the system is in User mode or Setup mode. Enable/ Disable the Secure Boot function.
  • Page 92 Parameter Description Press [Enter] to configure advanced items. Please note that this item is configurable when Secure Boot Mode is set to Custom. Factory Key Provision Š – Allows to provision factory default Secure Boot keys when system is in Setup Mode.
  • Page 93 Parameter Description OsRecovery Signatures Š – Displays the current status of the OsRecovery Signature Database. Key Management – Press [Enter] to configure a new OsRecovery Signature or load (continued) additional OsRecovery Signature from storage devices. – Options available: Update, Append. BIOS Setup - 93 -...

  • Page 94: Boot Menu

    Boot Menu The Boot menu allows you to set the drive priority during system boot-up. BIOS setup will display an error message if the legacy drive(s) specified is not bootable. Parameter Description Boot Configuration Number of seconds to wait for setup activation key. 65535 (0xFFFF) Setup Prompt Timeout means indefinite waiting.
  • Page 95 Parameter Description Controls the placement of newly detected UEFI boot options. New UEFI OS Boot Option Policy Options available: Default, Place First, Place Last. Default setting is Place First. FIXED BOOT ORDER Priorities Press [Enter] to configure the boot priority. By default, the server searches for boot devices in the following sequence: Hard drive.

  • Page 96: Save & Exit Menu

    Save & Exit Menu The Save & Exit menu displays the various options to quit from the BIOS setup. Highlight any of the exit options then press <Enter>. Parameter Description Save Options Saves changes made and closes the BIOS setup. Save Changes and Exit Options available: Yes, No.
  • Page 97 Parameter Description Loads the default settings for all BIOS setup parameters. Setup Defaults are quite demanding in terms of resources consumption. If you are using low-speed memory chips or other kinds of low-performance components Restore Defaults and you choose to load these settings, the system might not function properly.

  • Page 98: Bios Recovery

    BIOS Recovery The system has an embedded recovery technique. In the event that the BIOS becomes corrupt the boot block can be used to restore the BIOS to a working state. To restore your BIOS, please follow the instructions listed below: Recovery Instruction: 1.

  • Page 99: Bios Post Beep Code (Ami Standard)

    BIOS POST Beep code (AMI standard) 5-9-1 PEI Beep Codes # of Beeps Description Memory not Installed. Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available...
