MPI Cath Ergometer Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Cath Ergometer
Owner's Manual
Cath Ergometer
Owner _____________________
Model _____________________
Serial # _____________________
Date _____________________
Medical Positioning, Inc.
9732 Pflumm Road, Lenexa, KS 66215 | T: 816-474-1555 | 1-800-593-3246
www.MedicalPositioning.com
Page 1 of 25
15340-F
DCR-01028

Advertisement

loading
Need help?

Need help?

Do you have a question about the Cath Ergometer and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MPI Cath Ergometer

Summary of Contents for MPI Cath Ergometer

  • Page 1 Cath Ergometer Owner’s Manual Cath Ergometer Owner _____________________ Model _____________________ Serial # _____________________ Date _____________________ Medical Positioning, Inc. 9732 Pflumm Road, Lenexa, KS 66215 | T: 816-474-1555 | 1-800-593-3246 www.MedicalPositioning.com Page 1 of 25 15340-F DCR-01028...
  • Page 2 Cath Ergometer Symbols and Definitions ..............4 European Union Representative ............5 Precautions ..................6 Intended Use ..................7 Set Up ....................7 Operation ..................8 Ergometer Quick Reference Guide ..........19 Preventative Maintenance ............... 20 Cleaning ..................21 Troubleshooting Guide ..............22 Warranty ..................
  • Page 3 Cath Ergometer MEDICAL POSITIONING, INC 9732 Pflumm Road Lenexa, KS 66215 Cath Ergometer Attribute Rating Voltage 120 VAC Amperage 2.6 Amps Cycle 50/60 Hz Duty Cycle 10%, 1 min. on/9 min. off Leakage Current < 100 µA UL 60601-1 CLASSIFICATIONS: •...
  • Page 4 In accordance with the DIRECTIVE 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE CONCIL on waste electrical and electronic equipment (WEEE), the Cath Ergometer electrical system and accessories should not be disposed as unsorted municipal waste. Consult your instructional policies and local regulations regarding disposal.
  • Page 5 Cath Ergometer European Union Representative MDSS GmbH Schiffgraben 41 30175 Hannover, Germany Page 5 of 25 15340-F DCR-01028...
  • Page 6 Cath Ergometer Precautions Your Ergometer has been pre-assembled and tested to ensure operation on day one. Please closely inspect it when you receive it to ensure no damage has occurred during shipment. Because it is a complex piece of equipment, make note of the following precautions.
  • Page 7 Cath Ergometer CAUTION, PRODUCT DAMAGE MAY RESULT. Always grasp the connector and not the cable. CAUTION, PRODUCT DAMAGE MAY RESULT. Do not over tighten the mounting screws. Over tightening may result in stripping threads. CAUTION, PRODUCT DAMAGE MAY RESULT. Do not use abrasives to clean surfaces.
  • Page 8 Cath Ergometer Operation Your Ergometer is shipped assembled and ready for use. Each function has been pre-tested to ensure perfect working order on day one. A “Troubleshooting Guide” is included in this manual to assist you in the event of a malfunction.
  • Page 9 Cath Ergometer Figure 1 Figure 2 CAUTION, PRODUCT DAMAGE MAY RESULT. The ergometer control cable must be disconnected from the Ergometer Controller before you install or remove the Ergometer Controller. Failure to do so may result in Ergometer Controller damage.
  • Page 10 Cath Ergometer programming information. Below the displays, the Ergometer Controller controls are used to setup, program, and operate the Ergometer Controller. The Operational Controls (green) on the left side are used to select protocols to control the operation of the Ergometer Controller. The programming Controls on the right side (blue) are used to create custom protocols or to control the manual operation of the ergometer.
  • Page 11 Cath Ergometer Display Description This display shows the programmed pedal rate in revolutions per minute at which the patient should be pedaling for a given stage in a protocol. When PEDAL RATE programming a new protocol, this display shows the pedal rate being set for a stage of a protocol.
  • Page 12 Cath Ergometer CONTROL Description This control is used to turn the cadence tone on or off. TONE If the cadence tone is on, press this control to turn it off. If the cadence tone is off, press this control to turn it on.
  • Page 13 Cath Ergometer CONTROL Description This control is used to program the desired patient pedaling rate in revolutions per minute for a protocol stage. Pressing the UP side will cycle to the next higher RPM UP/DN selection for RPM. Pressing the DN side will cycle to the next lower selection for RPM.
  • Page 14 Cath Ergometer STEP ACTION Press the RPM-UP/DN control to select the desired patient pedaling rate in revolutions per minute for the selected stage as shown in the PEDAL RATE display. Press the PROGRAM STAGE control to program or alter the next stage of the protocol.
  • Page 15 Cath Ergometer STEP ACTION Press the PROTOCOL-UP/DN control until the number of the desired protocol is shown in the PROTOCOL NUMBER display. This number is the exercise protocol that the patient will be using. If you will be using protocol 15, proceed to “Using Manual Protocol 15”...
  • Page 16 Cath Ergometer STEP ACTION To return the computer to the Ready mode, press the STOP control a second time after the protocol has stopped. The computer controller will then be ready to use the protocol that you just completed and the first stage will be selected.
  • Page 17 Cath Ergometer Patient Coach Please refer to Figure 4 for the display and controls described below. CONTROL Description These lights indicate patient pedaling speed. The left amber light indicates patient is pedaling too slow, green PEDAL SPEED light indicates correct speed, right amber light indicates INDICATOR LIGHT patient is pedaling too fast.
  • Page 18 Cath Ergometer Mounting the Patient Coach STEP ACTION Place the patient coach on top of the Ergometer Controller facing the patient’s head. The hook and loop fasteners on both units will secure them together. Secure the RS232 type wiring connector to the back of the patient coach and the bottom of the Ergometer Controller.
  • Page 19 Cath Ergometer Ergometer Quick Reference Guide TO BEGIN Connect ergometer power cord to an approved electrical • outlet, wait 10 seconds, then select exercise protocol. Attach monitoring equipment: blood pressure cuff, ECG, pulse • oximeter, etc. according to your lab’s protocol Explain stress procedure to patient •...
  • Page 20 Cath Ergometer Ergometer Storage Cart The Ergometer may be used with an optional Ergometer Storage Cart for storing the Ergometer. WARNING, POTENTIAL FOR INJURY. To reduce the risk of a potential injury, lock all casters before installing, adjusting, or removing the Ergometer.
  • Page 21 Cath Ergometer Cleaning WARNING, POTENTIAL FOR INJURY. Always read manufactures instructions and warnings before using any cleaning product or disinfectant. The plastic surfaces can be cleaned with normal cleaners and disinfectant. CAUTION, PRODUCT DAMAGE MAY RESULT. Do not use abrasives to clean surfaces.
  • Page 22 Cath Ergometer Troubleshooting Guide A “Troubleshooting Guide” is included to instruct you in the event of a malfunction. If you are experiencing any of the following symptoms, this guide may help you quickly solve the problem. If, after consulting this guide, you are still unable to operate your product, please contact Medical Positioning at 1-800- 593-3246.
  • Page 23 Cath Ergometer SYMPTOM PROBABLE CAUSE SUGGESTION • Cable is loose or • Firmly push connector on Patient Coach Does Not Turn disconnected at to Ergometer Controller Ergometer Controller • Ergometer power • Refer to symptom problem “Ergometer and No Pedal Resistance Ergometer Controller Do Not Turn On”...
  • Page 24 MPI’s specifications. If the product fails due to a manufacturing defect, MPI will, at its sole expense and discretion, repair the product, authorize repairs to the product, or replace the product. MPI will ship any replacement products or parts using standard shipping rates;...
  • Page 25 Cath Ergometer Return Policy MPI accepts returns of unused products within 30 days from the date of delivery, irrespective of any inspection period. Returns are subject to a 30% restocking fee, any applicable duties or taxes and quality inspection. No product may be returned without prior written authorization from MPI.
