- Page 1 Owner’s Manual UltraScan™ Table Owner _____________________ Model _____________________ Serial # _____________________ Date _____________________ Medical Positioning, Inc. 1146 Booth Street, Kansas City, Kansas 66103 | T: 816-474-1555 | 1-800-593-3246 www.MedicalPositioning.com...
-
Page 2: Table Of Contents
IV Pole Holder ................26 Patient Positioning Safe-T-Wedges™ ..........26 Preventative Maintenance ..............27 Cleaning ..................... 28 Troubleshooting Guide ..............30 UltraScan™ Table Parts List ............. 32 Specifications and Warranty .............. 34 Specifications ................. 34 Warranty ..................36 Page 2 of 36... - Page 3 UltraScan™ Table MEDCIAL POSITIONING, INC 1146 Booth Street Kansas City, KS 66103 UltraScan™ Table Attribute Rating Rating (120V Version) (230V Version) Voltage 120 VAC 230 VAC Amperage Cycle 50/60 Hz 50/60 Hz Duty Cycle 10%, 1 min. on/10 min. off 10%, 1 min.
-
Page 4: Symbols And Definitions
In accordance with the DIRECTIVE 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE CONCIL on waste electrical and electronic equipment (WEEE), the UltraScan™ electrical system and accessories should not be disposed as unsorted municipal waste. Consult your instructional policies and local regulations regarding disposal. -
Page 5: Precautions
UltraScan™ Table Precautions Your UltraScan™ Table has been pre-assembled and tested to ensure operation on day one. Please closely inspect it when you receive it to ensure no damage has occurred during shipment. Because it is a complex piece of equipment, make note of the following precautions. - Page 6 UltraScan™ Table WARNING, POTENTIAL FOR INJURY. To reduce the risk of a potential fall, do not use the product to transport patient between rooms or over thresholds. WARNING, POTENTIAL FOR INJURY. Avoid placing your hand in or near the drop section mechanism during operation WARNING, POTENTIAL FOR INJURY OR DEATH.
- Page 7 UltraScan™ Table designed to support full patient body weight. Never allow the patient to apply full body weight to the foot stirrup. WARNING, POTENTIAL FOR INJURY OR DEATH. Always verify the safety rail is securely latched in the up position before using the table with the safety rail raised.
-
Page 8: Intended Use
Set Up Your UltraScan™ Table has been shipped to you in “plug and play” condition. After unpacking the product, we recommend performing an initial test of your UltraScan™ Table to ensure that each function is in correct working order. After reviewing this manual you are ready to begin using your UltraScan™... -
Page 9: Safety Features
UltraScan™ Table Figure 2 Only select models have Trendelenburg functionality. Safety Features • This product is equipped with multiple automated safety features to prevent danger or damage during use. The entire system is electrically isolated to UL/IEC 60601-1 and CAN/CSA C22.2 No. 601.1 hospital safety standards •... -
Page 10: Operation
UltraScan™ Table Operation Your UltraScan™ Table is shipped assembled and ready for use. Each function has been pre-tested to ensure perfect working order on day one. A “Troubleshooting Guide” is included in this manual to assist you in the event of a malfunction. -
Page 11: Hand-Wand
UltraScan™ Table Hand-Wand The hand wand is a low voltage device. The cable begins at the hand wand and plugs into the control box on the other end. Select models offer Trendelenburg functionality. WARNING, POTENTIAL FOR INJURY OR DEATH. Once the table and... -
Page 12: Individual Locking Casters
UltraScan™ Table Individual Locking Casters The standard casters installed on your UltraScan™ Table are total locking casters. When in the locked position, the caster is prevented from both rolling and swiveling. WARNING, POTENTIAL FOR INJURY OR DEATH. To reduce the risk of a potential fall, lock all casters before using equipment. -
Page 13: Single Pedal Brake (Optional)
UltraScan™ Table Single Pedal Brake (optional) The casters installed on your UltraScan™ Table with the optional Single Pedal Break are total locking casters when in the locked position; the caster is prevented from both rolling and swiveling. When in the neutral position, all casters are free to roll and swivel. -
Page 14: Drop Sections (On Select Models)
UltraScan™ Table Drop Sections (on select models) The drop section is designed to be opened or closed easily with one hand. WARNING, POTENTIAL FOR INJURY. Avoid placing your hand in or near the drop section mechanism during operation WARNING, POTENTIAL FOR INJURY OR DEATH. After closing, always lift up on the drop section to assure that is totally locked before patient entry or exit. - Page 15 UltraScan™ Table STEP ACTION To open the imagining drop section remotely, locate the remote release on the patient’s right side just next to the left side drop section on the side toward the head of the table. (See Figure 8) Pulling the handle outward will release the latch mechanism and allow the drop section to swing open.
-
Page 16: Back Rest (On Select Models)
UltraScan™ Table Back Rest (on select models) Select models of the UltraScan™ Table that have drop sections also has a convenient patient support back rest on the patient’s right side. The back rest is part of a multi-functional feature that also operates as a drop section. -
Page 17: Non-Pinch Closure (On Select Models)
UltraScan™ Table Non-Pinch Closure (on select models) The non-pinch closure flap located at the back edge of the back rest is designed to reduce the possibility of the patient being pinched when the back rest is raised or lowered. WARNING, POTENTIAL FOR INJURY. Do not operate drop section or back rest if non-pinch closure flap is absent. -
Page 18: Manually Operated/Removable Foot-Drop Section
UltraScan™ Table Manually Operated/Removable Foot-Drop Section The UltraScan™ is provided with a foot drop section that is designed to comfortably and safely support the patient’s legs at times when the foot stirrups are not used. The Ultra DBI™ is provided with a retractable Patient Foot Rest to assist the patient in resting their feet when in the upright, seated position. -
Page 19: Foot Board (On Select Models)
Foot Board (on select models) The UltraScan™ is equipped with a foot board that can be opened for use in extreme reverse Trendelenburg (foot end down) positions and when the foot drop section is lowered as a foot rest. -
Page 20: Foot Stirrups
Foot Stirrups The foot stirrups are conveniently stored on the underside of the seat section of the UltraScan™ when not in use. When needed, they are horizontally adjustable and will lock in place anywhere along the travel of the support pars. -
Page 21: Accessories
• Patient Positioning Safe-T-Wedges™ Safety Rails The UltraScan™ can be equipped with optional safety rails. The safety rails lock in the raised position and removable without the use of tools. WARNING, POTENTIAL FOR INJURY OR DEATH. Always verify the safety rail is securely latched in the up position before using the table with the safety rail raised. - Page 22 UltraScan™ Table Release Knob Figure 10 Safety Rail Removal STEP ACTION Grab the center of the top section of the rail and pull upward while pulling the safety rail release knob until the safety rail has cleared the release knob. (See Figure 10)
-
Page 23: Sonographer's Extension
UltraScan™ Table Sonographer’s Extension The UltraScan™ can be equipped with an optional sonographer’s extension. The sonographer’s extension is designed to increase the usable sitting area and comfort for the sonographer for a right handed scanning sonographer. The sonographer’s extension is removable. -
Page 24: Padded Arm Board
UltraScan™ Table Padded Arm Board The UltraScan™ can be equipped with an optional padded arm board. WARNING, POTENTIAL FOR INJURY. Securely tighten the Hand Wheel for the padded arm board prior to performing any procedures utilizing the padded arm board. -
Page 25: Carotid Head Rest
UltraScan™ Table Carotid Head Rest The UltraScan™ can be equipped with an optional carotid head rest. WARNING, POTENTIAL FOR INJURY. Securely tighten the adjustment knobs for the carotid head rest prior to performing any procedures utilizing the carotid head rest. -
Page 26: Iv Pole Holder
UltraScan™ Table IV Pole Holder The UltraScan™ may be equipped with an optional IV pole holder for ½ inch diameter IV poles. The IV pole holder is located near the head end of the table. (See Figure 14) Figure 14 Patient Positioning Safe-T-Wedges™... -
Page 27: Preventative Maintenance
UltraScan™ Table Preventative Maintenance WARNING, POTENTIAL FOR INJURY OR DEATH. Do not modify this equipment without authorization of the manufacturer. The following Preventative Maintenance should be performed at a minimum annually: • Visually inspect all mechanical assemblies and moving parts on the product ensuring smooth, steady operation •... -
Page 28: Cleaning
UltraScan™ Table Cleaning NOTE: Substances such as imaging gels and alcohol will not damage the vinyl surface when immediately removed. Studies have shown that exposure for longer than a few minutes can damage the top coat and will eventually discolor vinyl. - Page 29 UltraScan™ Table STEP ACTION Remove excess spill with damp cloth. Clean with 1:1 mix of Ivory™ soap and water. Rinse with clean water and dry. Use straight application of concentrated cleaners such as Formula 409™ or Fantastik™ Spray Cleaner. Then wipe with clean cloth.
-
Page 30: Troubleshooting Guide
UltraScan™ Table Troubleshooting Guide A “Troubleshooting Guide” is included to instruct you in the event of a malfunction. If you are experiencing any of the following symptoms, this guide may help you quickly solve the problem. If, after consulting this guide, you are still unable to operate your table please contact Medical Positioning at 1-800- 593-3246. - Page 31 UltraScan™ Table Figure 15 24 VDC RECEPTICLE FOR HEIGHT COLUMN 24 VDC RECEPTACLE FOR TRENDELENBURG ACTUATOR AC Power Input 24 VDC RECEPTACLE LOW VOLTAGE FOR FOWLER ACTUATOR HAND WAND RECEPTACLE Figure 16 Page 31 of 36 14512-L DCR-00335...
-
Page 32: Ultrascan™ Table Parts List
UltraScan™ Table UltraScan™ Table Parts List Part Number Description 10220 SHAFT, TRENDELENBURG 10350 LATCH, COMPARTMENT LOCK, REVERSIBLE, ZN 10351 HANDLE,DROP SECTION 10373 FOW-3 COLUMN BRACKET 10454 FOW-6 HINGE PIN 10582 LEVER, MINI W/CABLE #FA3421000 10598 HINGE, DROP SECTION 10691 BRKT,500 SER.DUAL DS REL.LEVER... - Page 33 UltraScan™ Table 14222 Assembly, Stationary Frame 14668 UPHOLSTERY KIT, ULTRASCAN FC 14669 UPHOLSTERY KIT, ULTRASCAN 25TR-FC 14670 UPHOLSTERY KIT, ULTRASCAN 25TR 14671 UPHOLSTERY KIT, ULTRASCAN DUAL-FC 14672 UPHOLSTERY KIT, ULTRASCAN DUAL-25TR-FC 14673 UPHOLSTERY KIT, ULTRASCAN DUAL-25TR Page 33 of 36...
-
Page 34: Specifications And Warranty
UltraScan™ Table Specifications and Warranty Specifications ATTRIBUTE SPECIFICATION 25.5” to 34.5” Electrically Adjustable Height Electrically Adjustable Fowler 0° to 90° Positioning Electrically Adjustable Trendelenburg Positioning 8X87, 8X89 0° 8X91, 8X92, 8X94, 8X95 0° to 15° Electrically Adjustable Reverse Trendelenburg Positioning 8X87, 8X89 0°... - Page 35 UltraScan™ Table Standard and Optional Configurations Standard Attribute Option Individual Lock Casters X X X X X X X X X X X X Single Pedal Brake Drop Sections X X X X X X Back Rest X X X X X X...
-
Page 36: Warranty
MPI. MPI makes no other warranty, either expressed or implied, with respect to this product. MPI specifically disclaims the implied warranties of merchantability and fitness for a particular purpose.
