Page 1: Table Of Contents
GAS TANDOORI OVEN Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page INJECTOR CHANGE AND GAS SETTING Page GAS CONNECTION IMAGES Page SPARE PART LIST- EXPLODING DRAWING... -
Page 2: Ageneral Information
GAS TANDOORI OVEN Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
*The Professional Gas tandoori oven,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.TDR.01 706x1018x1440 760x1130x1441 TECHNICAL INFORMATION CODE EMP.TDR.01 POWER LPG / NG (KW) 39,7 / 64,8 GAS CONSUMPTİON (NG) -
Page 4: A4 Unpacking
GAS TANDOORI OVEN UNPACKING *Please unpack the package according to the security codes and ordinances of current Kasap Tip Dik Buzdolapları country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. *Please check that all the parts of appliance had come completely and if they are damaged or not during the shipping. -
Page 5: Csafety Instructions
GAS TANDOORI OVEN Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. *Do not operate the appliance when the machine is empty. -
Page 6: Doperation
GAS TANDOORI OVEN OPERATION Kasap Tip Dik Buzdolapları *Control Panel: A : ON/OFF B : IGNITION POSITION C : FULL FLAME POSITION D : HALF FLAME POSITION * Operating: • According to type of use,make gas entrance connection from behınd the grill.Because the machine is operated with LPG and NG. -
Page 7: Ecleaning & Maintenance
GAS TANDOORI OVEN Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Turn off the gas connection before cleaning. • Clean the outer surface of the appliance with a wet cloth and chrome shiner. •... -
Page 8: Ftroubleshooting
Check if it is operated at suitable gas THE APPLIANCE DOESN’T COOK WELL setting or not. EMP.TDR.01 the gas flow is stopped automatically when the flame is off due to having gas tap that has safety valve.In this situation the appliance is not operated. -
Page 9: Ginjector Change And Gas Setting
GAS TANDOORI OVEN Kasap Tip Dik Buzdolapları INJECTOR CHANGE AND GAS SETTING OVEN-BURNER INJECTOR CHANGE CHART EMP.TDR.01 Gas Group Injector mm 30 mbar 50 mbar 37 mbar 50 mbar Burner Injectors Change; Chage “B” injector with consideration of valve on table above .for this purpose first unscrew all ‘’F’’... -
Page 10: Hgas Connection Images
GAS TANDOORI OVEN GAS CONNECTION IMAGES Kasap Tip Dik Buzdolapları Image 1 Image 2... -
Page 11: Ispare Part List-Exploding Drawing
GAS TANDOORI OVEN Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING... - Page 12 GAS TANDOORI OVEN SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.TDR.01 PRODUCT NAME P.CODE 1/6*100 GN BATHTUB M.MTS-KNX-GNK-1/6-100 UPPER PAN SHEET M.MTS-JP-TDR-001 CHASSIS LARGE LAV STONE M.TAS-LAV-007 TRAYLATERAL SHEET YSC-KNX.TDR-LZ-0009 TRAYSHEET YSC-KNX.TDR-LZ-0008 PILOT GROUP TEAM M.GAZ-PLT-PLT-001 BRACKET JP.M.GAZ-TES-GLV-002...
- Page 13 GAS TANDOORI OVEN Kasap Tip Dik Buzdolapları BUTTON SOCKET 8 MM M.AKS-DGM-SKT-001 BUTTON BUFFER M.AKS-DGM-EMP-016 BUTTON M.AKS-DGM-EMP-024 HANDLE PIPEWATER (465mm) YBR-KNX.KFR-KS-0052 HANDLE BODY YTL-KNX.KFR-KS-0104 HANDLE FOOT YTL-KNX.KFR-KS-0105 GAS FLEX Ø6 MM 120 CM M.GAZ-TES-SPR-022 GAS PIPE YBR-KNX.TDR-KS-0001 PIOZE LIGHTER Ø:18 M.GAZ-CKM-PIEZ-001 TICKET M.AKS-OZL-MTL-006...
