Summary of Contents for EMPERO EMP.9FRE01

  • Page 1: Table Of Contents

    SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    SET-SIX-OVEN-ELECTRIC SET ALTI FIRIN - ELEKTRİKLİ Kasap Tip Dik Buzdolapları A GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION * The Professional Machine ,that provides high efficiency has been designed to be used in industrial kitchens Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.9FRE01 800x847x565 840X940X670 EMP.9FRE02 1200x847x565 1230X940X670 EMP.9FRE03 1200x847x565 1230X940X670 EMP.7FRE01...

  • Page 4: A3 Transportation

    SET-SIX-OVEN-ELECTRIC SET ALTI FIRIN - ELEKTRİKLİ A3 TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials.  *Do not operate the appliance when the machine is empty.

  • Page 6: Doperation

    SET-SIX-OVEN-ELECTRIC SET ALTI FIRIN - ELEKTRİKLİ OPERATION Kasap Tip Dik Buzdolapları * Control Panel: Oven OFF position Oven upper heating Oven lower heating Oven upper-lower heating heating setting lamp Lower –upper setting lamp Oven heat setting button * Operating:  Plug in the appliance.

  • Page 7: Ecleaning & Maintenance

    SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE  CLEANING AND MAINTENANCE AFTER EVERY USE  Always turn off the appliance and disconnect from the power supply before cleaning.  Clean the outer surface of the appliance with a wet cloth and chrome shiner. ...

  • Page 8: Ftroubleshooting

    SET-SIX-OVEN-ELECTRIC TROUBLESHOOTING SET ALTI FIRIN - ELEKTRİKLİ Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. Check if it is operated at required heat THE APPLIANCE DOESN’T COOK WELL or not.

  • Page 9: Gspare Part List-Exploding Drawing

    SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.9FRE01-7FRE01...
  • Page 10 SET-SIX-OVEN-ELECTRIC SET ALTI FIRIN - ELEKTRİKLİ SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.9FRE01 NUMBER PRODUCT NAME PRODUCT CODE FLUE Y.EMP.9FRE01.001 CHASSIS Y.EMP.9FRE01.002 SHELF Y.EMP.9FRE01.003 SUPPOSITORY Y.EMP.9FRE01.004 HINGE Y.EMP.9FRE01.005 COVER Y.EMP.9FRE01.006 HANDLE Y.EMP.9FRE01.007 LIGHTER Y.EMP.9FRE01.008 BUTTON Y.EMP.9FRE01.009 PANEL Y.EMP.9FRE01.010...
  • Page 11 SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.7FRE01 NUMBER PRODUCT NAME PRODUCT CODE FLUE Y.EMP.7FRE01.001 CHASSIS Y.EMP.7FRE01.002 SHELF Y.EMP.7FRE01.003 SUPPOSITORY Y.EMP.7FRE01.004 HINGE Y.EMP.7FRE01.005 COVER Y.EMP.7FRE01.006 HANDLE Y.EMP.7FRE01.007 LIGHTER Y.EMP.7FRE01.008 BUTTON Y.EMP.7FRE01.009 PANEL Y.EMP.7FRE01.010 THERMOSTAT Y.EMP.7FRE01.011 COMMUTATOR Y.EMP.7FRE01.012 LOCK Y.EMP.7FRE01.013...
  • Page 12 SET-SIX-OVEN-ELECTRIC SET ALTI FIRIN - ELEKTRİKLİ SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.9FRE02-7FRE02...
  • Page 13 SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.7FRE02 NUMBER PRODUCT NAME PRODUCT CODE FLUE Y.EMP.7FRE02.001 CHASSIS Y.EMP.7FRE02.002 SHELF Y.EMP.7FRE02.003 SUPPOSITORY Y.EMP.7FRE02.004 HINGE Y.EMP.7FRE02.005 COVER Y.EMP.7FRE02.006 HANDLE Y.EMP.7FRE02.007 LIGHTER Y.EMP.7FRE02.008 BUTTON Y.EMP.7FRE02.009 PANEL Y.EMP.7FRE02.010 THERMOSTAT Y.EMP.7FRE02.011 COMMUTATOR Y.EMP.7FRE02.012 LOCK Y.EMP.7FRE02.013...
  • Page 14 SET-SIX-OVEN-ELECTRIC SET ALTI FIRIN - ELEKTRİKLİ SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.9FRE02 NUMBER PRODUCT NAME PRODUCT CODE FLUE Y.EMP.9FRE02.001 CHASSIS Y.EMP.9FRE02.002 SHELF Y.EMP.9FRE02.003 SUPPOSITORY Y.EMP.9FRE02.004 HINGE Y.EMP.9FRE02.005 COVER Y.EMP.9FRE02.006 HANDLE Y.EMP.9FRE02.007 LIGHTER Y.EMP.9FRE02.008 BUTTON Y.EMP.9FRE02.009 PANEL Y.EMP.9FRE02.010 THERMOSTAT...
  • Page 15 SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.9FRE03-7FRE03...
  • Page 16 SET-SIX-OVEN-ELECTRIC SET ALTI FIRIN - ELEKTRİKLİ SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.9FRE03 NUMBER PRODUCT NAME PRODUCT CODE FLUE Y.EMP.9FRE03.001 CHASSIS Y.EMP.9FRE03.002 SHELF Y.EMP.9FRE03.003 SUPPOSITORY Y.EMP.9FRE03.004 HINGE Y.EMP.9FRE03.005 COVER Y.EMP.9FRE03.006 HANDLE Y.EMP.9FRE03.007 LIGHTER Y.EMP.9FRE03.008 BUTTON Y.EMP.9FRE03.009 PANEL Y.EMP.9FRE03.010 THERMOSTAT...
  • Page 17 SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.7FRE03 NUMBER PRODUCT NAME PRODUCT CODE FLUE Y.EMP.7FRE03.001 CHASSIS Y.EMP.7FRE03.002 SHELF Y.EMP.7FRE03.003 SUPPOSITORY Y.EMP.7FRE03.004 HINGE Y.EMP.7FRE03.005 COVER Y.EMP.7FRE03.006 HANDLE Y.EMP.7FRE03.007 LIGHTER Y.EMP.7FRE03.008 BUTTON Y.EMP.7FRE03.009 PANEL Y.EMP.7FRE03.010 THERMOSTAT Y.EMP.7FRE03.011 COMMUTATOR Y.EMP.7FRE03.012 LOCK Y.EMP.7FRE03.013...

  • Page 18: Helectric Circuit Schema

    SET-SIX-OVEN-ELECTRIC SET ALTI FIRIN - ELEKTRİKLİ ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.7FRE-9FRE01-02 L1.L2 Oven Plate 0-3 gradual Oven Terminal Thermostat upper komutatör Trıfaze Resistance signal (50-300ºC) resistance şalter 4500W lamp 4500W...
  • Page 19 SET-SIX-OVEN-ELECTRIC Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.FRE-9FRE03 L1.L2 Oven Plate 0-3 gradual Oven Terminal Thermostat upper komutatör Trıfaze Resistance signal (50-300ºC) resistance şalter 4500W lamp 4500W...

This manual is also suitable for:

Emp.9fre02Emp.9fre03Emp.7fre01Emp.7fre02Emp.7fre03
