Page 1: Table Of Contents
COMBI OVEN Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page 6 CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page... -
Page 2: Ageneral Information
COMBI OVEN Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
PRODUCT DESCRIPTION *The Professional Combi Oven , that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.PFE.4+5.Y-B 1043x1151x1203 1120x1270x1370 EMP.PFE.4+5.Y-K 1040x961x1203 1120x1070x1370 TECHNICAL INFORMATION Convection Pizza Oven... -
Page 4: A3 Transportation
COMBI OVEN TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
COMBI OVEN Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ... -
Page 6: Doperation
COMBI OVEN OPERATION Kasap Tip Dik Buzdolapları * Control Panel: A : Top oven signal lamp B : Top oven digital indicator C : Heat increase button C : Heat reduce button D : Time indicator signal lamp E-M : Time Indicator F-N : Time adjustment buton (up) F-N : Time adjustment buton (down) G : Top oven ON/OFF button... - Page 7 COMBI OVEN Kasap Tip Dik Buzdolapları * Operating; • Clean the iner and outer surface of the appliance with warm moist cloth and dry before operating the appliance. • Make the clean water connection to the appliance and turn on the tap. •...
-
Page 8: Cleaning And Maintenance
COMBI OVEN CLEANING & MAINTENANCE Kasap Tip Dik Buzdolapları ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Always turn off the appliance and disconnect from the power supply before cleaning. • After every use,clean the iner surfaces of the oven with oil solvent spray and soft cloth before the appliance is not cooled exactly. -
Page 9: Ftroubleshooting
COMBI OVEN Kasap Tip Dik Buzdolapları TROUBLESHOOTING Check if the appliance is plugged in or not. Check the electric connections. THE APPLIANCE IS NOT OPERATED Check if the fuse is on or off. Check the resistances. The appliance is not operated if the lid of patisserie oven’s lid is opened. -
Page 10: Gspare Part List- Exploding Drawing
COMBI OVEN SPARE PART LIST- EXPLODING DRAWINGS Kasap Tip Dik Buzdolapları EMP.PFE.4+5-Y-B... - Page 11 COMBI OVEN Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE: EMP.PFE.4+5-Y-B PRODUCT NAME P.CODE PANEL SHEET YSC-KNX.KMB-LZ-0017 LEKSAN LABEL MANUAL (136*836 MM) M.AKS-ETK-LKS-092 OVEN BUTTON METAL M.AKS-DGM-MUH- SOCKET RED SIGNAL LAMP (Q10,0.8-3MM)TM2.103 M.ELK-LMB-SNY-002 EV3301J7VRX01 SINGLE RELAY THERMOSTAT WITH 2 DIGITAL INPUT TCJ 230V VIT M.ELK-EDM-DGT-001 19 MM MOMENTARY 220V GREEN LIGHT METAL BUTTON M.ELK-SLT-BTL-003...
- Page 12 COMBI OVEN 915*305*18 MM PIZZA STONE YELLOW M.TAS-FRN-PZ-003 108513 RESISTANT PIZZA OVEN 940 W M.ELK-RZS-BRU-PZ5- Kasap Tip Dik Buzdolapları UPPER RESISTANCE HOLDER YSC-KNX.KMB-PN- 0015 HOOD TOP SHEET YSC-KNX.KMB-PN- 0031 HOOD CHIMNEY OUTLET SHEET YSC-KNX.KMB-PN- 0032 COMBI FLUE OUTLET PIPE 180 MM WITH SHORT YBR-KNX.KMB-KS- 0003 COMBI TOP OVEN CHIMNEY OUTLET PIPE LONG 600 MM (CUT)
- Page 13 COMBI OVEN Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS EMP.PFE.4+5.Y-K...
- Page 14 COMBI OVEN SPARE PART LIST- EXPLODING DRAWINGS Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.PFE.4+5.Y-K PRODUCT NAME P.CODE PANEL SHEET YSC-KNX.KMB-LZ-0017 TICKET M.AKS-ETK-LKS-092 BUTTON JP.M.AKS-DGM-MUH-005 SIGNAL LAMP M.ELK-LMB-SNY-002 DIGITAL THERMOSTAT JP.M.ELK-EDM-DGT-001 BUTTON JP.M.ELK-SLT-BTL-003 BUTTON M.ELK-SLT-BTL-011 GLASS WICK HCN-ELY-KZ-001 580MM*140MM*6MM GLASS M.CAM-TMP-012 DIGITAL TIMER 230V M.ELK-EDM-DGT-012 3LF0122-4AC00 0-1 3*20A SWITCH...
- Page 15 COMBI OVEN Kasap Tip Dik Buzdolapları CHASSIS 615*606*18 MM PIZZA STONE M.TAS-FRN-PZ-001 940 W RESISTANCE M.ELK-RZS-BRU-PZ5-002 RESISTANCE SHEET METAL YSC-KNX.EPZ-PN-0006 HOOD SHEET YSC-KNX.KMB-PN-0046 HOOD CHIMNEY SHEET YSC-KNX.KMB-PN-0032 FLUE PIPE 180 MM YBR-KNX.KMB-KS-0003 FLUE PIPE 600 MM YBR-KNX.KMB-KS-0001 CHIMNEY FLANGE YSC-KNX.KFR-PN-0090 FLUE PIPE 40 MM YBR-KNX.KMB-KS-0002 32*2MM ELBOW...
-
Page 16: Helectric Circuit Schema
COMBI OVEN ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.PFE.4+5-Y-B ON OFF MAIN SWITCH 0-1 THREE PHASES TOP RESISTANCE CONTACTOR 20A (220V) BOTTOM RESISTANCE CONTACTOR 20A (220V) TOP HEATER RESISTANCE GROUP 875W 230V BOTTOM HEATER RESISTANCE GROUP 875W 230V TOP (TC-M06-L 150-K01.K) BOTTOM THERMOCOUPLE (TC-M06-L 150-K01.K) - Page 17 COMBI OVEN Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.PFE.4+5.Y-K ON OFF MAIN SWITCH 0-1 THREE PHASES TOP RESISTANCE CONTACTOR 20A (220V) BOTTOM RESISTANCE CONTACTOR 20A (220V) TOP HEATER RESISTANCE GROUP 875W 230V BOTTOM HEATER RESISTANCE GROUP 875W 230V TOP (TC-M06-L 150-K01.K) BOTTOM THERMOCOUPLE (TC-M06-L 150-K01.K)
