EMPERO EMP.9FRE01 User Manual

Under bench oven-electric
Hide thumbs Also See for EMP.9FRE01:
Table of Contents

Advertisement

Quick Links

UNDER BENCH OVEN-ELECTRIC
Kasap Tip Dik Buzdolapları
CONTENTS
1
Page
2
Page
3
Page
3
Page
4
Page
4
Page
4
Page
5
Page
6
Page
7
Page
8
Page
9
Page
18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMP.9FRE01 and is the answer not in the manual?

Questions and answers

Related Manuals for EMPERO EMP.9FRE01

Summary of Contents for EMPERO EMP.9FRE01

  • Page 1: Table Of Contents

    UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ A GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION * The Professional Machine ,that provides high efficiency has been designed to be used in industrial kitchens Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.9FRE01 800x847x565 840X940X670 EMP.9FRE02 1200x847x565 1230X940X670 EMP.9FRE03 1200x847x565 1230X940X670 EMP.7FRE01...

  • Page 4: A3 Transportation

    UNDER BENCH OVEN-ELECTRIC A3 TRANSPORTATION Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ...

  • Page 6: Doperation

    UNDER BENCH OVEN-ELECTRIC OPERATION Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ * Control Panel: Oven OFF position Oven upper heating Oven lower heating Oven upper-lower heating heating setting lamp Lower –upper setting lamp Oven heat setting button * Operating: •...

  • Page 7: Ecleaning & Maintenance

    UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Always turn off the appliance and disconnect from the power supply before cleaning. • Clean the outer surface of the appliance with a wet cloth and chrome shiner. •...

  • Page 8: Ftroubleshooting

    UNDER BENCH OVEN-ELECTRIC TROUBLESHOOTING Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. Check if it is operated at required heat THE APPLIANCE DOESN’T COOK WELL or not.

  • Page 9: Gspare Part List-Exploding Drawing

    UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.9FRE01-7FRE01...
  • Page 10 UNDER BENCH OVEN-ELECTRIC SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ PRODUCT CODE: EMP.9FRE01 PRODUCT NAME P.CODE CHIMNEY HOOD Y.EMP.9FRE01.001 BASE FRAME Y.EMP.9FRE01.002 SHELF Y.EMP.9FRE01.003 LID GASKET Y.EMP.9FRE01.004 HINGE Y.EMP.9FRE01.005 Y.EMP.9FRE01.006 HANDLE Y.EMP.9FRE01.007 WARNING LAMP Y.EMP.9FRE01.008...
  • Page 11 UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.7FRE01 PRODUCT NAME P.CODE CHIMNEY HOOD Y.EMP.7FRE01.001 BASE FRAME Y.EMP.7FRE01.002 SHELF Y.EMP.7FRE01.003 LID GASKET Y.EMP.7FRE01.004 HINGE Y.EMP.7FRE01.005 Y.EMP.7FRE01.006 HANDLE Y.EMP.7FRE01.007 WARNING LAMP Y.EMP.7FRE01.008 BUTTON Y.EMP.7FRE01.009 TRIPHASE SWITCH 0-1 Y.EMP.7FRE01.010 THERMOSTAT 50-300 Y.EMP.7FRE01.011...
  • Page 12 UNDER BENCH OVEN-ELECTRIC SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ EMP.9FRE02-7FRE02...
  • Page 13 UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.9FRE02 PRODUCT NAME P.CODE CHIMNEY HOOD Y.EMP.9FRE02.001 BASE FRAME Y.EMP.9FRE02.002 SHELF Y.EMP.9FRE02.003 LID GASKET Y.EMP.9FRE02.004 HINGE Y.EMP.9FRE02.005 Y.EMP.9FRE02.006 HANDLE Y.EMP.9FRE02.007 WARNING LAMP Y.EMP.9FRE02.008 BUTTON Y.EMP.9FRE02.009 TRIPHASE SWITCH 0-1 Y.EMP.9FRE02.010 THERMOSTAT 50-300 Y.EMP.9FRE02.011...
  • Page 14 UNDER BENCH OVEN-ELECTRIC SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ PRODUCT CODE: EMP.7FRE02 PRODUCT NAME P.CODE CHIMNEY HOOD Y.EMP.7FRE02.001 BASE FRAME Y.EMP.7FRE02.002 SHELF Y.EMP.7FRE02.003 LID GASKET Y.EMP.7FRE02.004 HINGE Y.EMP.7FRE02.005 Y.EMP.7FRE02.006 HANDLE Y.EMP.7FRE02.007 WARNING LAMP Y.EMP.7FRE02.008 BUTTON Y.EMP.7FRE02.009...
  • Page 15 UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.9FRE03-7FRE03...
  • Page 16 UNDER BENCH OVEN-ELECTRIC SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ PRODUCT CODE: EMP.9FRE03 PRODUCT NAME P.CODE CHIMNEY HOOD Y.EMP.9FRE03.001 BASE FRAME Y.EMP.9FRE03.002 SHELF Y.EMP.9FRE03.003 LID GASKET Y.EMP.9FRE03.004 HINGE Y.EMP.9FRE03.005 Y.EMP.9FRE03.006 HANDLE Y.EMP.9FRE03.007 WARNING LAMP Y.EMP.9FRE03.008 BUTTON Y.EMP.9FRE03.009...
  • Page 17 UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.7FRE03 PRODUCT NAME P.CODE CHIMNEY HOOD Y.EMP.7FRE03.001 BASE FRAME Y.EMP.7FRE03.002 SHELF Y.EMP.7FRE03.003 LID GASKET Y.EMP.7FRE03.004 HINGE Y.EMP.7FRE03.005 Y.EMP.7FRE03.006 HANDLE Y.EMP.7FRE03.007 WARNING LAMP Y.EMP.7FRE03.008 BUTTON Y.EMP.7FRE03.009 TRIPHASE SWITCH 0-1 Y.EMP.7FRE03.010 THERMOSTAT 50-300 Y.EMP.7FRE03.011...

  • Page 18: Helectric Circuit Schema

    UNDER BENCH OVEN-ELECTRIC ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları SET ALTI FIRIN - ELEKTRİKLİ EMP.7FRE-9FRE01-02 L5.L6 Plate Oven upper Thermostat Resistance resistance 0-3 gradual Oven signal Trıfaze komutatör (50-300ºC) 3x1500 W 230 3x1500 W lamp şalter 230 V.
  • Page 19 UNDER BENCH OVEN-ELECTRIC Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.FRE-9FRE03 L5.L6 Oven Plate upper Thermostat Resistance 0-3 gradual Oven Trıfaze resistance komutatör (50-300ºC) 5x1500 W signal lamp şalter 5x1500 W 230 V. 230 V.
