Eizo FLEXSCAN SX3031W User Manual
Hide thumbs
Also See for FLEXSCAN SX3031W:
- User manual (33 pages) ,
- Brochure & specs (25 pages) ,
- Specifications (2 pages)
Table of Contents
Advertisement
Quick Links
Important
Please read PRECAUTIONS, this User's
Manual and Setup Manual (separate volume)
carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
The latest User's Manual is available for
download from our site:
http://www.eizo.com
CONTENTS
Chapter 1 Features and Overview
1-1 Features
1-2 Buttons and Indicators
1-3 Functions and Basic Operation
Chapter 2 Settings and Adjustments
2-1 Utility Disk
2-2 Display Mode Selection
2-3 Color Adjustment
2-4 Off Timer/Power Saving Settings
2-5 Screen Size Selection
2-6 Power Indicator/EIZO Logo Display Settings
2-7 Locking Buttons
2-8 Setting Adjustment Menu Display
2-9 Setting Orientation
2-10 Viewing Information/Setting Language
2-11 Beeper Setting
2-12 Selecting Input Signal
2-13 Resumption of Default Setting
Chapter 3 Connecting Cables
3-1 Connecting Peripheral USB Devices
Chapter 4 Troubleshooting
Chapter 5 Reference
5-1 Attaching an Arm
5-2 Cleaning
5-3 Specifications
5-4 Glossary
How to Setup
Please read the Setup Manual (separate volume)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eizo FLEXSCAN SX3031W
Summary of Contents for Eizo FLEXSCAN SX3031W
- Page 1 Chapter 2 Settings and Adjustments 2-1 Utility Disk 2-2 Display Mode Selection 2-3 Color Adjustment 2-4 Off Timer/Power Saving Settings Important 2-5 Screen Size Selection 2-6 Power Indicator/EIZO Logo Display Settings Please read PRECAUTIONS, this User’s 2-7 Locking Buttons Manual and Setup Manual (separate volume) 2-8 Setting Adjustment Menu Display carefully to familiarize yourself with safe and 2-9 Setting Orientation 2-10 Viewing Information/Setting Language effective usage.
- Page 2 VESA is a registered trademark of Video Electronics Standards Association. Windows and Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries. EIZO, EIZO Logo, FlexScan, i•Sound and ScreenManager are registered trademarks of EIZO NANAO CORPORATION in Japan and other countries.
-
Page 3: Notice For This Monitor
Notice for this monitor In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in lower brightness is recommended. The LCD panel is manufactured using high-precision technology. However, missing pixels or lit pixels may appear on the LCD panel, this is not malfunction. Percentage of effective pixels: 99.9994% or higher. The backlight of the LCD panel has a fixed life span. When the screen becomes dark or begins to flicker, please contact your dealer. Do not press on the panel or edge of the frame strongly, as this may result in the display malfunction, such as the interference patterns, etc. If pressure is continually applied to the LCD panel, it may deteriorate or damage your LCD panel. (If the pressure marks remain on the LCD panel, leave the monitor with a white or black screen. The symptom may disappear.) Do not scratch or press on the panel with any sharp objects, such as a pencil or pen as this may result in damage to the panel. Do not attempt to brush with tissues as this may scratch the LCD panel. When the screen image is changed after displaying the same image for extended periods of time, an afterimage may appear. Use the screen saver or timer to avoid displaying the same image for extended periods of time. When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may occur inside and outside the monitor. In that case, do not turn the monitor on and wait until dew condensation disappears, otherwise it may cause damage to the monitor. To use the monitor comfortably An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to the environmental conditions. Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour. -
Page 4: Table Of Contents
[Border Intensity] ..........11 ● To modify blurred characters/lines Glossary ............24 [Smoothing] ............11 Power Indicator/EIZO Logo Display Settings 12 ● To turn off the Power indicator while a screen is displayed [Power Indicator] ......12 ● To display EIZO logo [EIZO Logo Appearing Function] ...... -
Page 5: Chapter 1 Features And Overview
Chapter 1 Features and Overview Thank you very much for choosing an EIZO color LCD monitor. 1-1 Features • 29.8 inch class wide screen format LCD • WQXGA (2560 × 1600) display compliant (SIGNAL1) • HDCP signal (SIGNAL2) compliant • Dual-display compliant by introducing dual-input system (DVI-D × 2 connectors) • DVI digital input (TMDS) compliant • Horizontal scan frequency: 31 - 100 kHz NOTE • This monitor supports the Portrait/ • Vertical scan frequency: 59 - 61 Hz (VGA TEXT: 69 - 71 Hz) Landscape display. This function • Resolution: 2560 dots × 1600 lines allows you to change the orientation • Compatible with frame synchronization mode (59 - 61 Hz) of the Adjustment menu when using • Portrait/Landscape display available (rotate 90 degrees clockwise) the monitor screen in vertical display position. (Refer to “2-9 Setting • Smoothing (soft - sharp) function Orientation” on page 14.) -
Page 6: Functions And Basic Operation
1-3 Functions and Basic Operation To adjust the screen and color Main menu (Refer to page 5 for operation) Screen Adjustment Page 11 ● To modify blurred characters/lines [Smoothing] • The Adjustment menu and the FineContrast menu cannot be displayed at the same time. Color Adjustment Page 8 Advanced Adjustment FineContrast menu Color adjustment Page 7 Simple adjustment [FineContrast mode]... -
Page 7: Basic Operation Of Adjustment Menu
Beeper setting EIZO Logo Display Setting ● To set the beeper [Beep] …………… see page 15 ● To display EIZO logo [EIZO Logo Appearing Setting Adjustment Menu Display Function] ………………………… see page 12 ● To update menu settings [Menu Size/Menu Position/ Locking Buttons Menu Off Timer/Translucent] …………... -
Page 8: Chapter 2 Settings And Adjustments
Chapter 2 Settings and Adjustments 2-1 Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the application software programs. ● Disk contents and software overview The disk includes color profiles, application software programs for adjustment, and User’s Manual. Refer to “Readme. txt” or the “read me” file on the disk for software startup procedures or file access procedures. -
Page 9: Color Adjustment
2-3 Color Adjustment Simple Adjustment [FineContrast Mode] This function allows you to select the best display mode for monitor brightness, etc. ● FineContrast mode An appropriate display mode is selectable out of five modes. Mode Purpose Custom Available for making desired setting. Suitable for color matching with sRGB compatible sRGB peripherals. Suitable for displaying texts for word processing or Text spreadsheets. Suitable for displaying images such as photos or picture Picture images. -
Page 10: Advanced Adjustments [Adjustment Menu]
Attention Advanced Adjustments [Adjustment Menu] • The FineContrast mode cannot be Independent setting and saving of color adjustment are available for each changed during color adjustment. Set the FineContrast mode in advance FineContrast mode. with • Wait 30 minutes or more from ● To select an appropriate mode for images monitor power on before starting the : Adjustment available −: Invalid for adjustment √ color adjustment. • Choose <Reset> in the <Color> menu Icon Function FineContrast mode to revert to the default settings (factory Custom sRGB Text Picture Movie settings) of hue of the color mode √ √... -
Page 11: To Set/Adjust Color
Menu Description Adjustment range Gain To adjust red, green, and 0 to 100% blue to a desired color tone Adjust the respective brightness of respectively red/green/blue to make a desired color tone. Display an image with white or gray background for adjustment. -
Page 12: Off Timer/Power Saving Settings
2-4 Off Timer/Power Saving Settings ● To set monitor power-off time [Off Timer] This function allows the monitor to automatically turn off after a specified time Attention • The Off Timer functions even in the has passed. This function serves to reduce afterimages caused when the monitor power saving mode, but the advance screen is left on for a long time period without use. Use this function when an notice is disabled. The monitor power image is displayed throughout the day. is turned off without advance notice. [Off Timer System] Timer Monitor Power Indicator ON time (1H - 23H) Operating Blue Last 15 min. in “ON time” Advance Notice* Flashing blue “ON time”... -
Page 13: Screen Size Selection
2-5 Screen Size Selection ● To change screen size [Screen Size] The image with the resolution other than the recommended resolution is displayed in full screen automatically. You can change the screen size by using <Screen Size> from <Others> menu. Menu Function Displays an image in full screen. Images are distorted in Full Screen some cases because the vertical rate is not equal to the (default setting) horizontal rate. -
Page 14: Power Indicator/Eizo Logo Display Settings
[Power Indicator] power on with the default setting. This function enables to turn off the Power indicator (blue) while a screen is displayed. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Power Indicator> from the <Others> menu, and press The <Power Indicator> menu appears. (3) Select “Disable” with or , and press The Power Indicator setting is completed. ● To display EIZO logo [EIZO Logo Appearing Function] NOTE • The logo appears with the default When this unit is turned on, the EIZO logo appears at the center of the screen. setting. Selection to display or not to display the logo is available with this function. (1) Press to turn off the unit. (2) Press again while pressing to turn on the unit. The EIZO Logo display/non-display function is toggled. 2-7 Locking Buttons ●... -
Page 15: Setting Adjustment Menu Display
2-8 Setting Adjustment Menu Display ● To update menu settings [Menu Size/Menu Position/Menu Off Timer/Translucent] Menu Size Change the Adjustment menu size using the following procedure. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Menu Settings> from the <Others> menu, and press (3) Choose <Menu Size> from the <Menu Settings> menu, and press The <Menu Size> menu appears. (4) Select “Normal” or “Enlarged” with or , and press The menu size setting is completed. Menu Position Adjust the menu position using the following procedure. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Menu Settings> from the <Others> menu, and press (3) Choose <Menu Position> from the <Menu Settings> menu, and press The <Menu Position> menu appears. (4) Select a menu position with , and press The menu position setting is completed. -
Page 16: Setting Orientation
2-9 Setting Orientation ● To set the orientation of the Adjustment menu [Orientation] NOTE • If you use the monitor with “Portrait” This function allows you to change the orientation of the Adjustment menu position, the setting may be required when using the monitor screen in vertical display position. to change depending on the graphics board used in your PC. Refer to the (1) Choose <Others> from the Adjustment menu, and press manual of the graphics board for (2) Choose <Menu Settings> from the <Others> menu, and press details. (3) Choose <Orientation> from the <Menu Settings> menu, and press Attention The <Orientation> menu appears. • Be sure to turn the monitor screen (4) Select “Portrait” with or , and press after pulling up the screen to the The orientation setting is completed. uppermost position of the stand and (5) Turn the monitor screen 90° in clockwise direction. -
Page 17: Beeper Setting
2-11 Beeper Setting ● To set the beeper [Beep] Set the beeper on/off for operation tone of the switches, connection error, etc. Sound type Conditions for beeping Short beep • When is pressed. • When an item is selected with • When a maximum or minimum value is set with the control switches. •... -
Page 18: Resumption Of Default Setting
2-13 Resumption of Default Setting ● To reset color adjustment [Reset] NOTE • For default settings, refer to “Main The hue in the color mode currently set will revert to the default settings (factory default settings (factory settings)” on settings). page 21. (1) Choose <Color> from the Adjustment menu, and press (2) Choose <Reset> from the <Color> menu, and press The <Reset> menu appears. (3) Select Reset with or , and press “ ” The reset operation is completed. ● To reset all settings [Reset] Reset all adjustments/settings to the factory default settings. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Reset> from the <Others> menu, and press The <Reset> menu appears. -
Page 19: Chapter 3 Connecting Cables
For USB compatibility of peripheral ● Required System Environment devices, contact their manufactures. (1) A PC equipped with a USB port or another USB hub connected to a USB • If the monitor is in the power saving mode, or if the monitor is connected compatible PC to the power outlet with the monitor (2) Windows 2000/XP/Vista or Mac OS 9.2.2 and Mac OS X 10.2 or later turned off, all the devices connected (3) EIZO USB cable (MD-C93) to the USB ports (upstream and downstream) work. Therefore, power ● consumption of the monitor varies Connection Procedure (Setup of USB Function) with connected devices even in the (1) Connect the monitor first to a PC using the signal cable, and run the PC. power saving mode. (2) Connect the supplied USB cable between the downstream USB port of a USB compatible PC (or another USB hub) and the monitor’s upstream USB port. (3) When the USB function setup is completed, the monitor functions as a USB hub allowing connection to various peripheral USB devices through its downstream USB ports. -
Page 20: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • No-picture problems → See No.1 - No.2. • Imaging problems → See No.3 - No.9. • Other problems → See No.10 - No.12. • USB problems → See No.13. Problems Possible cause and remedy 1. No picture • Check whether the power cord is connected correctly. • Power indicator does not light. • Press • Power indicator is lighting blue. •... - Page 21 Problems Possible cause and remedy Afterimages appear. • Use a screen saver or off timer function for a long-time image display. • Afterimages are particular to LCD monitors. Avoid displaying the same image for a long time. Green/red/blue/white dots or defective dots remain •...
-
Page 22: Chapter 5 Reference
Chapter 5 Reference 5-1 Attaching an Arm The stand can be removed and replaced with an arm (or another stand) to be Attention • When attaching an arm or stand, attached to the monitor. follow the instructions of their user’s manual. [Attaching] • When using another manufacturer’s arm or stand, confirm the following in advance and select one conforming to Lay the LCD monitor on a soft cloth spread over on a stable the VESA standard. Use M4 × 12 mm surface with the panel surface facing down. screws supplied with the monitor. -
Page 23: Specifications
5-3 Specifications LCD Panel 29.8-inch (76 cm) TFT color LCD with anti-glare hard coating Viewing angle: Horizontal 178°, Vertical 178° (CR: 10 or more) Dot Pitch 0.2505 mm Horizontal Scan Frequency 31 - 100 kHz Vertical Scan Frequency 59 - 61 Hz (VGA TEXT: 69 - 71 Hz) Resolution 2560 dots ×... -
Page 24: Outside Dimensions
Outside Dimensions (Main unit and height adjustable stand (Portrait display available)) 628(24.7) unit : mm (inch) 588(23.1) 240(9.4) SWIVEL 322.8(12.7) 405.6(16) 347.7(13.7) 689(27.1) 643.3(25.3) (0.06) (0.06) 22.9 294.5(11.6) 294.5(11.6) (3.9) 254.7(10) Outside Dimensions (Main unit with i•Sound L3 and height adjustable stand (Portrait display available)) 361.2(14.2) 347.7(13.7) TILT... - Page 25 Hot Plug Detect T.M.D.S. Clock- (NC*: No Connection) • USB port Upstream Downstream Contact No. Signal Remarks Cable power – Data Serial data + Data Serial data Ground Cable ground Option List Cleaning Kit EIZO ScreenCleaner Speaker Unit i•Sound L3 Chapter 5 Reference...
-
Page 26: Glossary
5-4 Glossary DVI (Digital Visual Interface) DVI is a digital interface standard. DVI allows direct transmission of the PC’s digital data without loss. This adopts the TMDS transmission system and DVI connectors. There are two types of DVI connectors. One is a DVI-D connector for digital signal input only. The other is a DVI-I connector for both digital and analog signal inputs. DVI DMPM (DVI Digital Monitor Power Management) DVI DMPM is a digital interface power-saving function. The “Monitor ON (operating mode)” and “Active Off (power-saving mode)” are indispensable for DVI DMPM as the monitor’s power mode. HDCP (High-bandwidth Digital Contents Protection) Digital signal coding system developed to copy-protect the digital contents, such as video, music, etc. This helps to transmit the digital contents safely by coding the digital contents sent via DVI terminal on the output side and decoding them on the input side. Any digital contents cannot be reproduced if both of the equipments on the output and input sides are not applicable to HDCP system. Gain This is used to adjust each color parameter for red, green and blue. An LCD monitor displays the color by the light passing through the panel color filter. Red, green and blue are the three primary colors. All the colors on the screen are displayed by combining these three colors. The color tone can be changed by adjusting the light intensity (volume) passing through each color’s filter. Gamma Generally, the monitor brightness varies nonlinearly with the input signal level, which is called “Gamma Characteristic”. A small gamma value produces a low-contrast image, while a large gamma value produces a high-contrast image. Resolution The LCD panel consists of numerous pixels of specified size, which are illuminated to form images. This monitor consists of 2560 horizontal pixels and 1600 vertical pixels. At a resolution of 2560 × 1600, all pixels are illuminated as a full screen (1:1). - Page 27 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.
-
Page 28: Fcc Declaration Of Conformity
For U.S.A. , Canada, etc. (rated 100-120 Vac) Only FCC Declaration of Conformity We, the Responsible Party EIZO NANAO TECHNOLOGIES INC. 5710 Warland Drive, Cypress, CA 90630 Phone: (562) 431-5011 declare that the product Trade name: EIZO Model: FlexScan SX3031W is in conformity with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 29 Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß muß den nachfolgenden Anforderungen entsprechen: a) D er Standfuß muß eine ausreichende mechanische Stabilität zur Aufnahme des Gewichtes vom Bildschirmgerät und des spezifizierten Zubehörs besitzen. Das Gewicht des Bildschirmgerätes und des Zubehörs sind in der zugehörenden Bedienungsanleitung angegeben. b) D ie Befestigung des Standfusses muß derart erfolgen, daß die oberste Zeile der Bildschirmanzeige nicht höher als die Augenhöhe eines Benutzers in sitzender Position ist. c) I m Fall eines stehenden Benutzers muß die Befestigung des Bildschirmgerätes derart erfolgen, daß die Höhe der Bildschirmmitte über dem Boden zwischen 135 – 150 cm beträgt. d) D er Standfuß muß die Möglichkeit zur Neigung des Bildschirmgerätes besitzen (max. vorwärts: 5°, min. nach hinten ≥ 5°).
