- Page 1 SXF115 Subwoofers User Guide...
- Page 2 It is suggested that you keep the original packaging so that the system can be repacked at a future date if necessary. Please note that neither Martin Audio nor its distributors can accept any responsibility for damage to any returned product which arises through the use of non-approved packaging.
- Page 3 Introduction The SX Series subwoofers are a range of sub bass enclosures designed to complement any of Martin Audio’s full range systems. The range encompasses ultra-compact sub-miniature subs perfect as a discreet, unobtrusive installation partner to the ADORN or CDD ranges, right up to very high output twin 18”...
- Page 4 Introduction The SXF115 is a passive subwoofer designed to extend the performance of Martin Audio WPM and MLA Mini systems down to 42Hz. Featuring a powerful, long excursion 15” (380mm)/4” (100mm) voice coil driver in a very compact bass reflex enclosure, it can be flown as part of a WPM or MLA Mini array, or ground-stacked separately.
- Page 5 With the sub on the floor under the desired position for its final deployment, attach the frame to the chain or motor hoist(s) and raise so it is just above the SXF115. Remove the four flying pins on the bottom of the flying frame to release the drop-down rigging links. Copyright © 2024 Martin Audio Ltd.
- Page 6 Remove the flying pins in the bottom drop-down rigging links in the first sub and lower it onto the second ensuring that the rigging links engaging all four rigging slots in the second sub exactly as you did with the frame and first cabinet. Copyright © 2024 Martin Audio Ltd.
- Page 7 More cabinets can be added as required or transition frames connected to enable flying of either MLA Mini or WPM arrays under the SXP115. For more details see the User Guides for MLA Mini and WPM. Copyright © 2024 Martin Audio Ltd.
- Page 8 SXF115 USER GUIDE SXF115 Wheelboard The SXF115 uses a front mounted wheelboard and travels face-down. The transit cover drops over the top of the cabinet once it is on the wheelboard. Copyright © 2024 Martin Audio Ltd.
- Page 9 SXF115 Weather Kit The WRKIT for non-powered SX Series subwoofers is a glanded cover which fits over the connection panel to prevent water ingress protecting the NL4 speaker connection. The cable entry may be through one of two knock-out positions depending the angle from which you wish the cable to enter. First remove the knock-out blank that you wish to use and fit the cable gland in position.
- Page 10 (W) 500mm x (H) 510mm x (D) 575mm (725mm incl wheelboard) input, using band limited pink noise, then referred to 1 (W) 19.7in x (H) 20.1in x (D) 22.6in (28.5in incl wheelboard) metre. WEIGHT 45kg (99lbs) 52kg (115lbs) incl wheelboard Technical Drawing Copyright © 2024 Martin Audio Ltd.
- Page 11 During the warranty period Martin Audio will, at its discretion, either repair or replace products which prove to be defective provided that the product is returned in its original packaging, shipping prepaid, to an authorised Martin Audio service agent or distributor.
- Page 12 All information is Copyright © 2024 Martin Audio Ltd. Martin Audio, the Martin Audio logo and Hybrid are registered trademarks of Martin Audio Ltd. in the United Kingdom, United States and other countries; all other Martin Audio trademarks are the property of Martin Audio Ltd.
