Eizo FLEXSCAN T1501 Specifications
Eizo FLEXSCAN T1501 Specifications

Eizo FLEXSCAN T1501 Specifications

15" сolor touch panel monitors
Hide thumbs Also See for FLEXSCAN T1501:

Advertisement

T
he FlexScan T1501 and FlexScan T1502
are equipped with an analog resistive
touch panel which offers a fast touch
response, long touch life, low energy
consumption, and acceptance of finger,
glove, and touch pen input.
• 1024 × 768 native resolution
• 700:1 contrast ratio
• 195 cd/m
brightness
2
• 160°, 150° viewing angles
• Digital/analog inputs
F E A T U R E S
Advanced Touch Panel
The touch panel is built into the monitor and utilizes
analog resistive technology for fast touch response
and a long life of 10 million touches minimum. Finger,
glove, and touch pen input are accepted, making these
monitors ideal for a variety of environments. For us-
ers requiring a touch pen, EIZO offers its TP1 touch
panel pointer (sold separately).
RS-232C and USB Communication Protocols
The FlexScan T1501 offers a touch interface through
a RS-232C serial port connection and the FlexScan
T1502 through a USB port.
Color Control
Gain, saturation, and color temperature in 500 K
increments from 4,000 – 10,000 K are all user adjust-
able. An sRGB mode is also included for color match-
ing with other applications and peripherals that also
support this color space.
Analog/Digital Flexibility
D-Sub mini 15 pin and DVI-D 24 pin inputs allow the
monitor to accept signals from both analog and digital
sources. Two computers can be connected, with easy
switching between them via a front panel button.
1 5 " C o l o r T o u c h P a n e l M o n i t o r s
Optimized Brightness
EIZO's BrightRegulator function keeps the screen at
the ideal brightness level under all lightning condi-
tions. A sensor on the front panel takes readings of the
ambient brightness and signals the backlight to adjust
the screen brightness accordingly. Should you want to
make the screen a little brighter or darker, the manual
adjustment in the OSD menu is still an option.
Built-in Speakers
Two 0.5 watt speakers are hidden away at the bottom of
the monitor bezel for audio confirmation of touch input.
Product Information Display
The product name, serial number, and total usage time
can all be confirmed in the on-screen display menu.
Free Mount Capability
Panel can be removed from its stand and can be
mounted on VESA-compliant arms or stands. The
power supply unit is panel-integrated so there is no
separate power brick or cord.
Security Lock Support
To guard against theft in a public environment, a slot
for connection of a security lock (sold separately) is
included.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLEXSCAN T1501 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eizo FLEXSCAN T1501

  • Page 1 For us- the screen brightness accordingly. Should you want to ers requiring a touch pen, EIZO offers its TP1 touch make the screen a little brighter or darker, the manual panel pointer (sold separately).
  • Page 2 Audio1 Dual 0.5 W built-in speakers, input/headphone jacks Certifications and Standards TÜV/GS, C-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC-B, Canadian ICES-003-B, TÜV/S, VCCI-B, RoHS, WEEE, EIZO Eco Products 2006 Supplied Accessories AC power cord, user’s manual, signal cable (D-Sub mini 15 pin – D-Sub mini 15 pin), touch panel cable (T1502 / USB, T1501 / RS-232C), audio cable.

This manual is also suitable for:

Flexscan t1502
