cMT Series

Quick Start Guide

Your Industrial Control Solutions Source

Maple Systems, Inc. | 808 134

_____________________

www.maplesystems.com

St. SW, Suite 120, Everett, WA 98204 | 425.745.3229

For use with the following:

 cMT-SVR models

 cMT3000 models

 cMT-iV5

Need help?

Do you have a question about the cMT Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Maple Systems cMT Series

Page 1 Series Quick Start Guide Your Industrial Control Solutions Source _____________________ www.maplesystems.com For use with the following:  cMT-SVR models  cMT3000 models  cMT-iV5 Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229...
Page 2 Series Quick Start Guide Table of Contents ........................1 COPYRIGHT NOTICE ..........................3 WARRANTY............................3 TECHNICAL SUPPORT ..........................3 Introduction ..............................4 How It Works ............................4 cMT-SVR Models ............................5 cMT3000 Models ............................5 The cMT-iV5 Display..........................5 The cMT-iV5 Stand ..........................
Page 3 Update cMT-iV5 OS and/or Firmware ....................35 COPYRIGHT NOTICE This manual is a publication of Maple Systems, Inc., and is provided for use by its customers only. The contents of the manual are copyrighted by Maple Systems, Inc.; reproduction in whole or in part, for use other than in support of Maple Systems equipment is prohibited without the specific written permission of Maple Systems.
Page 4 Series Quick Start Guide Introduction cMT = Control and Monitor. The cMT series of products are programmable operator interfaces that can be accessed on the Local Area Network (LAN) via Wi-Fi and Ethernet devices with the free cMT Viewer application.
Page 5 Series Quick Start Guide cMT-SVR Models The cMT-SVR models are human-machine interfaces (HMI) without built-in display. cMT-SVR devices are configured with EasyBuilder Pro and store the screens and related logic in a small DIN rail mountable form factor. The programmed screens can be viewed externally over the LAN with the cMT Viewer application.
Page 6 Series Quick Start Guide Connecting the cMT-iV5 display to a cMT server device The cMT-iV5 is initially configured to “Obtain IP address automatically.” In order for it to connect to a cMT device directly without a switch, you must go into the Settings window of the cMT-iV5 and configure it with a static IP address.
Page 7 Series Quick Start Guide Configure the cMT Server (cMT-SVR & 3000 models) cMT Server models have a built-in web server that displays configuration settings. When shipped, cMT models have the following Ethernet Port settings: Ethernet1 Ethernet2 DHCP IP: 192.168.100.1 Subnet Mask: 255.255.255.0...
Page 8 Series Quick Start Guide Ethernet 1 is a WAN port. Select Obtain IP Address Automatically to configure the port for DHCP; or specify the IP Address, Subnet Mask, Gateway, and DNS addresses. Click the Save button to save changes to the IP settings.
Page 9 Series Quick Start Guide Date/Time Configuration The Date/Time page allows you to set the local date and time on the cMT device. Set the date and time from the calendar and clock objects, or check the Sync with host box to set the cMT device to the same date and time as the PC.
Page 10 Series Quick Start Guide HMI Identification The HMI Name page identifies the cMT device. A unique name can be assigned to the cMT device. This name will be available in the EasyBuilder Pro software to provide another method (in addition to the IP address) for identifying which unit is being configured.
Page 11 Series Quick Start Guide Historical Data Files The History page allows the clearing and retrieving of historical data stored on the cMT device. On the Clear tab, check the boxes for the history files to be deleted. Then click the Clear button to delete the data.
Page 12 Configure the SMTP settings as required for the email server. Due to the variability of email settings, Maple Systems is unable to provide specific data on these settings. Configure the Sender Information so that the recipient sees who the email is from.
Page 13 Series Quick Start Guide Project Management The Project Management page allows the application in the cMT device to be restarted, updated remotely, or backed up to your PC. In the Restart Project tab, the Restart EB Project button allows you to stop and restart the application.
Page 14 Series Quick Start Guide cMT Series Quick Start Guide...
Page 15 Series Quick Start Guide System Password The System Password page allows you to change the System Settings, Update, History, and User passwords for the cMT device. There are four passwords that can be set from this page. Click the System Setting dropdown to select...
Page 16 Series Quick Start Guide Enhanced Security The Enhanced Security page allows you to modify user accounts stored on the cMT device. If the security database is being used by the application, a “The database is locked. This page allows only one user at a time.” message will be displayed.
Page 17 Series Quick Start Guide EasyAccess 2.0 EasyAccess 2.0 is a secure method of remote monitoring to the cMT device from anywhere in the world. For specific information on implementing EasyAccess 2.0, please see the EasyAccess 2.0 section of the Maple Systems website, or view/download the EasyAccess 2.0 Manual...
Page 18 Series Quick Start Guide cMT Series Quick Start Guide...
Page 19 (.emtp).  The cMT series has 2 new Local address types, PLW and PLB. While connected display devices share the LW and LB addresses, the PLW and PLB address types are unique for each display device. The PLW and PLB addresses reside in the display device, not in the cMT server.
Page 20 Series Quick Start Guide The cMT Application A common application for a cMT server product is to allow monitoring of an existing network of Maple Systems HMI products and the PLCs to which they are connected. Network Connection Most cMT models are equipped with 2 separate Ethernet connections. Ethernet 1 is a WAN port, and allows connection across a gateway to another network.
Page 21 Series Quick Start Guide HMI/RMI5001 Requesting Register Data from a cMT Device If an HMI or RMI5001 needs to collect register data from a cMT device, the setup is similar. The cMT server (and any connected PLCs) need to be added to the HMI/RMI5001 EasyBuilder Pro project as a...
Page 22 Series Quick Start Guide cMT Viewer cMT Viewer is an application that runs on a Windows PC or tablet, and on Apple iOS (v6 or later) and Android (v4.1 or later) devices. The cMT Viewer application connects to and interacts with the project in the cMT server device.
Page 23 Series Quick Start Guide Settings Menu Touch the ‘gear’ icon at the top right part of the screen to open the Settings menu. The ‘closed’ padlock on the Setting tab indicates that security is in place, and only the System password can be changed.
Page 24 Series Quick Start Guide To change settings such as the Date/Time, IP information, and the unit name, you must log in with the System password. Press the ‘closed’ padlock icon on the Setting tab. Enter the System password and press OK.
Page 25 Series Quick Start Guide Connect Menu History tab Shows the projects that have been recently loaded. Search tab Shows cMT server devices currently browsable on the network Search menu Touch the ‘Search’ tab to open the Search menu. The Search menu displays all of the cMT devices on the current network.
Page 26 Series Quick Start Guide  Touch the cMT-SVR image to identify the unit. The green LED on the unit will blink 3 times. (Only available on cMT-SVR models)  Touch the Go button to connect to the corresponding cMT device and load the project. A password may be required.
Page 27 Series Quick Start Guide  Touch the Setup button to open the configuration page for the selected cMT device. The password may be required. These are the same configuration settings that are shown in the web browser (see page 4).
Page 28 Series Quick Start Guide shown. The image on the cMT-iV5 will now look like this:  Touch the Setup button to open the configuration page for the selected cMT device. The password may be required. These are the same configuration settings that are shown in the web browser (see page 4).
Page 29 Series Quick Start Guide Using cMT Viewer on a Windows PC To start the cMT Viewer on a PC, click on the Tools menu in EasyBuilder Pro and select cMT Viewer, or open the Utility Manager, select the Maintenance tab and click cMT Viewer.
Page 30 Series Quick Start Guide Settings Menu Click the ‘Gear’ icon at the top right corner of the cMT Viewer main page to open the Settings menu. The Settings menu controls how the cMT Viewer application looks and feels. ...
Page 31 Series Quick Start Guide Monitor Mode Monitor Mode was created to enable real-time viewability of values using the cMT Viewer program. Monitor Mode is only available in the PC version of cMT Viewer. Monitor Mode is off by default, but is be easily enabled.
Page 32 Series Quick Start Guide Enabling Monitor Mode Visualization in cMT Viewer To enable Monitor Mode in the cMT Viewer application: 1. From the main cMT Viewer window, enter the Settings menu. 2. Select the “closed lock” icon and enter the System Password (default is 111111).
Page 33 Series Quick Start Guide  Touch the Edit button to bring up the Edit menu, where adjustments to the viewability of the Monitor Mode can be made (see Edit Menu) below.  Touch the Play button to begin the AutoPlay function. The AutoPlay function scrolls through the Monitor Mode pages at a pre-set interval.
Page 34 Series Quick Start Guide  Press the Add Page button to add a page to the Monitor Mode display. Up to 9 pages can be created, and a single page can show one or more cMT projects.  Press the Delete Page button to delete the selected page (the current page is shown by the page indicator at the bottom of the screen).
Page 35 Series Quick Start Guide Update cMT-iV5 OS and/or Firmware The Utility Manager included with EasyBuilder Pro includes a mechanism to update the cMT-iV5 operating system and/or firmware. Updating of the cMT-iV5 operating system (OS) is not normally something that needs to be done by the end user. However, in certain situations, updates in the field may be necessary.
Page 36 Series Quick Start Guide Enter the correct IP address for the cMT-iV5. With Runtime (firmware) selected, click the Update button to update the firmware. The utility will locate the proper firmware file and transfer it to the cMT-iV5. Note: Please do not attempt to update the Operating System (OS) without first contacting Maple Systems Technical Support.
Page 37 Series Quick Start Guide Your Industrial Control Solutions Source _____________________ www.maplesystems.com 1010-1026 Rev. 04 Maple Systems, Inc. | 808 134 St. SW, Suite 120, Everett, WA 98204 | 425.745.3229 cMT Series Quick Start Guide...
