Delfield 6000XLG Specifications

Delfield
™
®
6000XL
Glass Door Reach-in Refrigerators
Models
• 6025XL-G Single section Full height doors
• 6051XL-G Two section Full height doors
• 6076XL-G Three section Full height doors
• 6025XL-GR Remote Full height doors
• 6051XL-GR Remote Full height doors
• 6076XL-GR Remote Full height doors
6051XL-G

Specifications

Exterior: Top and bottom are constructed of 24-gauge
galvanized steel. Exterior sides are 0.032 aluminum. Front
housing is 22-gauge stainless steel.
Doors: Unit is provided with hinged glass front door(s).
Doors are provided with magnetic gaskets, self-closing,
edgemount hinges; and quick grip long length door handle(s).
Doors are field reversible with no drilling required.
Interior: Liner is constructed of seamless, one piece ABS
material with 15 molded shelf supports spaced 3.00" (7.6cm)
apart. Three epoxy coated wire shelves, rated at 250 lb. load
capacity each, are provided per section. Shelf supports are
also capable of holding two 12" x 20" pans (by others) or one
18" x 26" pan (by others) per level. Liner comes with a limited
lifetime warranty.
Units are completely insulated with a minimum of 2.00"
(5.08cm) high density foamed in place polyurethane.
Interior is lit by one 15-watt fluorescent light on one door
models, one 40-watt fluorescent lights on two door models
and three 15-watt fluorescent lights on three door models.
Lights are located outside of the food zone. Fluorescent
lights are operated with a manual on/off switch.
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858

Standard Features

•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Refrigeration system: All components are mounted to
the exterior cabinet ceiling, outside the food zone and are
assembled as one piece and can be removed as one piece.
Environmentally friendly R404A refrigerant is used. System
has the capability of maintaining between 27˚F and 40˚F in
heavy use food service operations. Refrigerant is metered
using a highly responsive thermostatic expansion valve.
System is controlled using Delfield's ACT-Advanced Control
Technology electronic temperature control, which provides
improved pull down times, reducing compressor cycling and
longer compressor life with lower energy consumption.
Control system uses adaptive defrost to assure evaporator
coil is free of ice and operating at optimum efficiency.
Evaporator condensate is eliminated using an energy efficient
hot gas system.
Others: Unit is supplied standard with a 10' cord and plug,
attached.
Units are standard with legs. Legs are constructed of painted
metal and are 6" high with 1" adjustability to compensate
for installation location factors. Shipped loose for field
installation.
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
• 6025XL-GH Single section Half height door
• 6051XL-GH Two section Half height door
• 6076XL-GH Three section Half height door
• 6025XL-GHR Remote Half height door
• 6051XL-GHR Remote Half height door
• 6076XL-GHR Remote Half height door
Stainless steel front shroud
Aluminum sides
Seamless, Delrite® ABS interior liner
Top mounted refrigeration system
High performance Delflow refrigeration,
designed to maintain 27˚F to 40˚F
Easy to adjust epoxy shelves (three per
section)
Easy to read digital thermometer with
visual high/low temp alarms
10' cord and plug attached
Edgemount door hinges
All doors are fully field rehingable
Environmentally friendly R404a refrigerant
One year parts and labor, 5 year compressor
warranty, limited lifetime liner warranty
Accepts 18" x 26" sheet pans
Standard glass door handles
6" adjustable legs (field installed)
Self closing doors with stay open feature at
120˚
www.delfield.com
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
Options &
Accessories
o Extra shelves
o Non standard hinging
