OSP furniture DesignLab CDE 30 Assembly Instructions Manual

OSP furniture DesignLab CDE 30 Assembly Instructions Manual

Battle station gaming desk

Advertisement

Quick Links

OSP FURNITURE LIMITED PRODUCT WARRANTY
Design Lab Products
• 3 years on gaming desks and chairs
• Upholstery is not warranted against routine scratching and scuffing
*All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 250 lbs. or less.
This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event
beyond the control of Office Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential
damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a two year warranty on
all parts applies. Fabric and foam is warranted for one year. This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state.
It is the customer's responsibility to prepay freight on any components returned to the factory. Return freight on components covered by warranty will be paid by
Office Star Products.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts are damaged or missing. Our
Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail parts.department@officestar.net by Fax 1-909-930-5629, or
toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 3:30 p.m. Pacific Time.
CDE30
BATTLESTATION GAMING DESK
ASSEMBLY INSTRUCTIONS
WARNING
1. Do not use this product unless all bolts, screws, and knobs are securely tightened.
2. Check that all bolts, screws, and knobs are tight every three months or as needed.
3. Dispose of packing material properly. Do not use plastic cover as head covering as it may
cause suffocation.
4. Do not use product as stepladder.
5. Use product for its intended purpose only.
6. Use mild detergent only for cleaning.
© Office Star Products – September 2023
