Medion erazer Manual

Package contents

Check whether all the items in the delivery are present. Contact us within 14 days after purchase if any items are missing. Always specify the serial number when making enquiries.
The following components are supplied with your PC:

PC and connection cable
Keyboard (optional)
Mouse (optional)
WLAN antennas (optional)
Software package (OEM operating system; antivirus software) (optional)
Documentation

Risk of choking and suffocation!
Packaging film can be swallowed or used improperly, creating a risk of choking and suffocation!

Keep packaging material such as plastic film or plastic bags away from children.

Important information about the illustrations

information Connectors marked with an asterisk* in the overview have dual assignment. The respective configuration is controlled via the software. If the connectors are covered by a protective cap, these are not available in the respective configuration.

Overview of the connectors

POS	Description of components	POS	Description of components
1	On/off switch	24	HDMI connection - optional
5	Power supply (mains cable socket & mains switch - optional)	27	LAN network (RJ45)
11	USB 2.0-ports - optional	30	WLAN antenna connection - optional
14	Audio input / Speaker RS (rear out)*	40	USB 3.2 ports (Type-C) - optional
15	Headphones socket / Speaker FS (front out)*	41	USB 3.2 ports (Type-A) - optional
16	Microphone socket / Speaker CC/SS (center/subwoofer out)*	52	Audio combi connection (mic-in, headphones)
23	Display Port - optional	53	Button for switching the RGB lighting of the built-in fans Take a paperclip which has been bent upwards at the tip, carefully insert this into the hole and briefly press the button.
