Summary of Contents for Hoover HO6 H3T1CTX
- Page 1 FULL USER MANUAL www.hoover-home.com CANDY HOOVER GROUP Via Comolli 16 Brugherio - Italy...
- Page 2 English Deutsch Français Italiano E s p a ñ o l Ελληνικά Nederlands Português Slovenčina Slovenščina Српски Polski Čeština Dansk Suomi Norsk Svenska Қазақ Русский Українська Български Hrvatski Română Türkçe العربية 中文 Magyar עברית Lietuvių Eesti Latviešu...
- Page 3 WELCOME Thank you for choosing our product. To ensure your safety and get the best results, please read this manual carefully, including the safety instructions, and keep it for future reference. Before installing the oven note the serial number, which you might need for repairs.
-
Page 4: Table Of Contents
SUMMARY SAFETY INFORMATION PRODUCT INTRODUCTION 2.1. Overview of the product 2.2. Accessories 2.3. Control panel BEFORE STARTING 3.1. Information to start 3.2. First usage 3.3. Preliminary cleaning OPERATION OF PRODUCT 4.1. How the product works 4.2. Cooking functions 4.2.1. Standard functions COOKING GUIDELINES 5.1. -
Page 5: Safety Information
1.SAFETY INFORMATION GENERAL WARNINGS • Do not use a steam cleaner for cleaning operations. • During use the appliance become hot. Care should be taken to avoid touching heating elements inside the oven. Use in accordance with attendend use • Only use the oven for its intended purpose, that is only for the cooking of foods: any other use, for example as a heat source, is considered improper and therefore dangerous. -
Page 6: Installation Warnings
INSTALLATION WARNINGS • The oven can be located high in a column or under a worktop. Before fixing, you must ensure good ventilation in the oven space to allow proper circulation of the fresh air required for cooling and protecting the internal parts. Make the openings specified on the illustrations according to the type of fitting. -
Page 7: Electrical Warnings
ELECTRICAL WARNINGS • The socket must be suitable for the load indicated on the tag and must have ground contact connected and in operation. The earth conductor is yellow-green in colour. This operation should be carried out by a suitably qualified professional. Connection to the power source can be made by plug or by fixed wiring placing an omnipolar breaker, with contact separation compliant to the requirements for overvoltage category III, between... - Page 8 appliance and do not tamper with it. NOTE: • as the oven could require maintenance work, it is advisable to keep another wall socket available so that the oven can be connected to this if it is removed from the space in which it is installed.
- Page 9 oven reaches the cooking temperature. • Cook the vegetables in a container with a lid instead of an open tray. • Avoid leaving food inside the oven after cooking for more than 15/20 minutes. • A long power supply failure during an occurring cooking phase may cause a malfunction of the monitor.
-
Page 10: Product Introduction
2.PRODUCT INTRODUCTION 2.1. OVERVIEW OF THE PRODUCT 1. Control panel 2. Shelf positions (lateral wire grid if included) 3. Metal grids 4. Tray 5. Fan cover 6. Oven door 7. Lateral wire grids (if present: only for flat cavity) 8. Serial number & QR Code Write here your serial number for future reference. - Page 11 Telescopic Guides Softclose/Softopen Hinges (only if present*) Telescopic oven rails are shelves that can be Soft close and open hinges control the door’s extended, making it easier to place or remove motion, ensuring smooth movement and items, without the need to reach deep inside a preventing slamming.
-
Page 12: Control Panel
2.3. CONTROL PANEL Functions and function ranking can be changed depending on the model. 1. Function selector knob 2. Main menu 3. Timer 4. LED display 5. Plus button (+) 6. Minus button (-) 7. Temperature selector knob MAIN FUNCTIONS The display has 3 main functions: Symbol Function... -
Page 13: Before Starting
3.BEFORE STARTING 3.1. INFORMATION TO START When you first turn on the oven, you might notice some smoke. Don’t worry, just wait for the smoke to clear before using the oven. How illumination works The oven cavity is illuminated by one or more light bulbs, typically activated each time a cooking function begins. -
Page 14: Operation Of Product
4.OPERATION OF PRODUCT 4.1. HOW THE PRODUCT WORKS SWITCHING ON/OFF THE OVEN To turn ON the oven rotate the function knob (clockwise/counterclockwise) and select a program. To turn it OFF, set the function knob to the ‘0’ position. SET COOKING PROGRAM Turn the function knob to select the desired program and turn the temperature selector knob to set the temperature. - Page 15 MAIN MENU Access the Main menu by pressing . To navigate into tap as many times as is needed to enter in the following settings: CHILD LOCK This function allows you to lock the screen to prevent any unwanted use by minors. To activate the screen lock, press “Main menu”...
-
Page 16: Alarm Volume
ALARM VOLUME Allows to change the volume of the warning tone. Press to enter in the Main menu. Tap as many times (x3) as you need to select “Alarm volume”. On the display will appears “b-01”. The numbers represent the level of sound intensity, editable using “+/-“. -
Page 17: Timer Menu
TIMER MENU Access the Timer menu by pressing . To navigate into tap as many times as is needed to enter in the following settings: COOKING DURATION Allows to preset the cooking time required for the recipe chosen. ACTIVATION: press to enter in the Timer menu. -
Page 18: Minute Minder
MINUTE MINDER Allows to use the oven as alarm clock. ACTIVATION: press to enter in the Timer menu. Tap as many times (x2) as you need to select “Minute minder” . Then use “+/-“ to regulate the value. To confirm wait 5 secs or press “Timer menu”. WAIT 5 SEC TO CONFIRM OR PRESS PRESS x2 TIMER MENU... -
Page 19: Cooking Functions
4.2. COOKING FUNCTIONS 4.2.1. STANDARD FUNCTIONS NOTE: for function that require preheating, ensure all accessories are removed during this phase. Follow instructions in the table below for what regards preheating. “YES” means that preheating is required; “NO” means that preheat is not suggested and foods must be inserted with cold oven. -
Page 20: Cooking Guidelines
5. COOKING GUIDELINES 5.1. GENERAL COOKING TABLE Cooking time N° of Cooking Cooking Shelf Category Recipe T°C Preheat after preheating levels program accessory position *(min) Conventional 170°C 20-30 Multilevel 155°C Deeper tray 30-40 Fan assisted 140°C 25-35 Small cakes / Deeper + Multilevel 150°C... - Page 21 Cooking time N° of Cooking Cooking Shelf Category Recipe T°C Preheat after preheating levels program accessory position *(min) Toast bread Supergrill Metal grid 8-10 Breads Focaccia Conventional 200°C Deeper tray 25-35 Flatbread Bread, whole Conventional 200°C Deeper tray 30-50 Metal grid + Salty cakes / Conventional 200°C...
- Page 22 Cooking time N° of Cooking Cooking Shelf Category Recipe T°C Preheat after preheating levels program accessory position *(min) Metal grid + 220°C Ovenproof 50-70 Roasted dish Turkey** Fan assisted 200°C Deeper tray 45-60 Metal grid + Pork ribs Conventional 200°C Ovenproof 80-100 (1000-1200g)
-
Page 23: Care And Cleaning
6. CARE & CLEANING 6.1. GENERAL RECOMMENDATIONS Regular cleaning can extend the lifecycle of your appliance. Wait for the oven to cool before carrying out manual cleaning • After each use of the oven, a minimum of cleaning will help keep the oven perfectly clean. •... -
Page 24: Outside The Oven: Removal And Cleaning The Glass Door
6.2.2. OUTSIDE THE OVEN: removal and cleaning the glass door Open the door at 90°, rotate the hinge locking tabs outward from the oven. Position the door at 45°. Simultaneously press the two buttons on both the sides of the door’s lateral shoulders and pull towards yourself to remove the upper glasses’... -
Page 25: Cleaning Of Accessories
Insert the glass panels, making sure that the “LOW-E/PYRO” label is correctly readable and positioned on the lower left side of the door, PYRO near the left-side hinge. This way, the printed label on the first glass will remain on the inside of the door. LOW-E Reattach the upper glasses’... -
Page 26: Maintenance
6.4. MAINTENANCE COMPONENTS REPLACEMENT Changing the bulb on top: 1. Disconnect the oven from mains supply. 2. Undo the glass cover, disassemble the bulb and replace it with a new bulb of the same type. 3. Once the defective bulb is replaced, replace the glass cover. Step 1 Step 2 Step 3... -
Page 27: Troubleshooting
7. TROUBLESHOOTING If, during oven use, an error occurs, the display will show the code "ER" followed by two digits, which will identify the error. Proceed by turn off the oven and un-plug it, wait for a few minutes, and then reconnect it. If the error disappears, you can resume using the oven. -
Page 28: Environmental Protection & Disposal
8. ENVIRONMENTAL PROTECTION & DISPOSAL 8.1. APPLIANCE DISPOSAL This appliance is labelled in accordance with European Directive 2012/19/EU regarding electric and electronic appliances (WEEE). The WEEE contain both polluting substances (that can have a negative effect on the environment) and base elements (that can be reused). It is important that the WEEE undergo specific treatments to correctly remove and dispose of the pollutants and recover all the materials. -
Page 29: Installation
9. INSTALLATION power cord 1100 8 , 5 4 , 5 power cord 1100 EN 29... - Page 30 8 , 5 0 x 4 x . 5 0 x 4 8 , 5 0 x 4 EN 30...
- Page 31 x . 5 8 , 5 EN If the furniture is coverade with a bottom at the back part, provide an opening for the power supply cable. EN 31...
- Page 32 Bumper Bumper EN 32...
- Page 33 70050185...
