- Page 1 Welcome Sensor LCSENSE (Sensor) LCSENSE/HB (High Bay Sensor) WE’RE HERE TO HELP: 1 ( 844 ) LIGHTCLOUD 1 ( 844 ) 544-4825 support@lightcloud.com...
-
Page 2: Product Features
Hello The Lightcloud Sensor is a remotely-configurable passive infrared occupancy sensor that can switch and Product Features dim both hardwired circuits Passive Infrared Sensing and remote circuits using Secure Cloud Control & Configuration Lightcloud Controllers. Retrofit-Friendly Local Control Light Sensor Power Monitoring 0-10V Dimming Patented... - Page 3 Contents Lightcloud Sensor or Surface-Mount Adapter Wire nuts & Screws High Bay Sensor Accessories (optional) Height Adjuster (optional, includes 2 screws and 1 locknut) (optional, must use in conjunction with Arm)
-
Page 4: Specifications
Specifications PART NUMBER OPERATING TEMPERATURE - 20°C to 40°C LCSENSE (Sensor) LCSENSE/HB (High Bay Sensor) OVERALL DIMENSIONS INPUT 4 3/8" Diameter, 1 9/16" Height 120 - 277VAC, 50/60Hz, WIRELESS RANGE <1W (Standby) – 2W (Active) Line-of-Sight: 1000 feet MAXIMUM SWITCHED LOAD RATINGS Obstructions: 100 feet Incandescent: 220VAC, 3000W RATINGS... -
Page 5: Setup And Installation
Setup & Installation Turn off power WARNING Find a Suitable Location Use these guidelines when installing devices: • If there is a clear line of sight between two Lightcloud devices, they can be placed up to 1000 feet apart. • If the two devices are separated by ordinary drywall construction, try to keep them within 100 ft. - Page 6 Find a Suitable Location (cont’d) Add an additional Lightcloud Device to extend network range around corners B R I C K , C O N C R E T E O R D R Y WA L L M E TA L WA L L O R S I M I L A R Lightcloud Gateway or Hub...
- Page 7 Setup & Installation Setup & Installation (cont’ d ) (cont’ d ) Install your Lightcloud Sensor at a Junction Box (Indoor/Outdoor) The Sensor can control other Lightcloud devices, wirelessly. If you don’t need to hard-wire a switched circuit to the Sensor, no problem—just cap off...
- Page 8 Setup & Installation (cont’ d ) Flush mount sensor to ceiling Sensor attached to wired junction box JUNCTION CEILING SENSOR SCREW COVER Any wires not in use must be capped o or otherwise insulated. This product should only be installed by a quali ed electrician and in compliance with local and national electrical codes.
- Page 9 Setup & Installation (cont’ d ) Surface mount adapter to ceiling Sensor attached to wired junction box through surface mount adapter JUNCTION CEILING SURFACE MOUNT ADAPTER SENSOR SCREW COVER Any wires not in use must be capped o or otherwise insulated. This product should only be installed by a quali ed electrician and in compliance with local and national electrical codes.
- Page 10 Setup & Installation (cont’ d ) Installing Accessories (Optional) Arm: mount sensor to EXTRUDED TUBE fixture using ½" NPS threaded nipple SET SCREW LOCKNUT ½" NPS THREADS SENSOR Height Adjuster: adjust height by loosening set screw, moving sensor up or down along extruded tube, then tightening set screw.
- Page 11 Setup & Installation (cont’ d ) Labeling your device When installing devices, it’s important to keep track of their Device IDs, installation locations, panel/circuit #s, dimming function, and any additional notes. To organize this information, use the Lightcloud Installer Application (A) or Device Table (B).
-
Page 12: Device Table
Device Scanner Device Info Device Scanner Devices Device ID Office Light - ID 0013A20040B62A4A 0013A20040B62A4A Controller Location Office Light - ID 0013A20040B62A4B O ce Sensor Zone Name Office Light - ID 0013A20040B62A4C O ce Lights Dimmer PLACE RECTANGLE TO FIT CODE ON LABEL PLACE RECTANGLE TO FIT CODE ON LABEL Dimmable Office Light - ID 0013A20040B62A4D... - Page 13 Power up To add new devices to your Lightcloud network, contact RAB: Verify power and local control Confirm status indicator LED (see below) is blinking red. If the Sensor is wired for local control, double press the device button to toggle the load on and off.
- Page 14 Commission & Configure Your Devices All Lightcloud products can be commissioned and configured by: • Logging on to control.lightcloud.com • Calling RAB at 1 (844) LIGHTCLOUD • Emailing us at support@lightcloud.com Confirm Device Connectivity Confirm status indicator LED (see below) is solid green. If it is not, make sure your device is within range of another Lightcloud AC-powered device.
- Page 15 Functionality Overview STATUS INDICATOR/ DEVICE BUTTON SENSOR...
- Page 16 The Device Button also lights up and acts as a Status Indicator. STATUS INDICATOR/BUTTON: • Solid GREEN when connected to your Lightcloud network. • Blinking RED when not connected. The device will automatically continue trying to connect to a network in Setup Mode. •...
- Page 17 Functionality (cont’ d ) Features: Passive Infrared Motion Detection SENSOR HIGH BAY SENSOR 8.2' 16.4' SIDE VIEW SIDE VIEW TOP VIEW TOP VIEW...
- Page 18 Features OCCUPANCY & VACANCY SENSING: The Lightcloud Sensor can operate in either Occupancy or Vacancy Sensor modes, selectable via the Lightcloud application. In Occupancy mode, the attached circuit will be switched on when motion is detected, and off (or dimmed) when the timeout expires.
- Page 19 Features 0 10V DIMMING: 0-10V is a common method of low-voltage control of dimmable drivers and ballasts. Purple: 0-10V positive | Gray or Pink: 0-10V common Note: The National Electrical Code requires that low-voltage wiring used in the same enclosure as high voltage wiring have an equal or better insulation rating. You may need to complete your low-voltage wiring in another enclosure or use a partition.
- Page 20 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. CAUTION: Changes or modi cations to this equipment not expressly approved by RAB Lighting may void the user’s authority to operate this equipment.
- Page 21 Lightcloud is a commercial wireless lighting control system. It’s powerful and flexible, yet easy to use and install. Learn more at lightcloud.com 1 (844) LIGHTCLOUD 1 (844) 544-4825 support@lightcloud.com © 2024 RAB Lighting, Inc Cranbury, NJ 08512 USA...
