Summary of Contents for RAB Lighting Lightcloud PIR40/LCB
- Page 1 Welcome Lightcloud High Bay Low-Voltage Passive Infrared Sensor PIR40/LCB, PIR40B/LCB Low Bay Low-Voltage Passive Infrared Sensor PIR20/LCB, PIR20B/LCB WE’RE HERE TO HELP: 1(844) LIGHTCLOUD 1(844) 544-4825...
-
Page 2: Product Specifications
Hello The Lightcloud Blue High Bay/Low Bay Low-Voltage Passive Infrared (PIR) Sensor is a sensor with 12V AUX supply and intergrated with dual-techology motion detector and daylight sensor that can switch and dim both local and remote circuits. The Lightcloud Blue High Bay/Low Bay Low-Voltage Sensor can be quickly and easily installed on compatible LED xtures. -
Page 3: Setup And Installation
Setup & Installation Turn o power WARNING • Place the wall switch in the o position. • Turn o the main power at the breaker panel or remove the fuse from the fuse box. Find a suitable location • Lightcloud Blue devices should be positioned within 60 ft. - Page 4 Setup & Installation (Cont’d) OUTDOOR Add an additional Lightcloud Blue Device to extend network range < 18ft. <=60 ft. around corners < 18ft. <=60 ft. Lightcloud DRYWALL OR SIMILAR Blue APP Recommend <30ft (varies based on mobile device's BLE capability)
-
Page 5: Wiring Diagram
Setup & Installation (Cont’d) Wiring Diagram PIR Sensor The Lightcloud Blue Low-Voltage installs in compatible sensor ports using a 3-pogo pin connection. Black White +12V 12VDC input Pink GND 0/1-10V DIM Purple DIM+ 0/1-10V DIM+ GND/DIM- DIM+ LED+ LED- Install Luminaire Low-Voltage PlR Sensor is onlycompatible with select sensor-ready fxtures. - Page 6 Setup & Installation (Cont’d) Mount the Low-Voltage PlR Sensor to a compatible fxture. Unscrew the 1/2" knockout out with a screwdriver and screw on the Low-Voltage PlR Sensor. 1/2” knockout sensor Mount using the Right Angle Arm Support (RAAS): Connect the Low-Voltage PIR Sensor to the RAAS by turning clockwise.
-
Page 7: Restore To Factory Settings
Setup & Installation (Cont’d) Restore to Factory Settings To restore your Lightcloud Blue Low-Voltage PIR Sensor to factory settings, you can reset it using the following methods: Method 1: Delete from app If the sensor was previously paired, open the mobile app and access the device settings for the paired device. - Page 8 Controlling your Lightcloud Blue Device Confirm your devices are powered on. Download the Lightcloud Blue app from the Apple® App Store or Google® Play store. Launch the App and create an account. Tap the "add device" icon in the app to start connecting devices.
- Page 9 Sensor Coverage Highest ceiling mounted height PIR20x/LCB - 20ft. PIR40x/LCB - 39ft. walking towards walking across...
- Page 10 FCC Information: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 11: We're Here To Help
CAUTlON: Changes or modifcations to this equipment not expressly approved by RAB Lighting may void the user's authority to operate this equipment. WE’RE HERE TO HELP:... - Page 12 Lightcloud Blue mobile app. Each device in a system can communicate with any other device, eliminating the need for a Gateway or Hub and maximizing the control system’s reach. Learn more at www.rablighting.com 1(844) LIGHTCLOUD 1(844) 544-4825 ©2024 RAB LIGHTING Inc. P-100851...
