- Page 1 BUILT TO LAST LONGER Operating Instructions DRYER CABINET DC 7191...
- Page 2 ASKO offers you all these features. When you buy an ASKO product you can be sure that the inside is just as good as the outside and that the ethics and morality that go into building this product are just as high as the quality and function you are getting.
-
Page 3: Table Of Contents
CONTENTS START-UP IMPORTANT SAFETY INFORMATION OPERATION FOR A GOOD ENVIRONMENT STARTING PACKAGING MATERIALS POSITIONING OF WASHING MANAGEMENT OF END-OF-LIFE USER TIPS DRYING CABINET AIR FLOW DESCRIPTION OF THE CONTROLS DRYING CABINET CARE INSTALLATION CLEANING UNPACKING SERVICE FITTING OF DOOR HANDLE REPLACEMENT PARTS REHANGING OF DOOR TROUBLE SHOOTING... -
Page 4: Important Safety Information
If the mains lead is damaged it must be immediately re- placed, and this work must only be performed by the ma- nufacturer, the manufacturer’s service agent or similarly qualified persons in order to avoid danger. Follow ASKO instructions when repairing and replacing parts. Operating Instructions... -
Page 5: For A Good Environment
FOR A GOOD ENVIRONMENT PACKAGING MATERIALS MANAGEMENT OF END-OF-LIFE DRYING CABINET The packaging protecting the drying cabinet against damage in transit has been chosen When the drying cabinet has reached the with concern for the environment in mind and end of its life it must be taken to a recycling is therefore recyclable. -
Page 6: Description Of The Drying Cabinet
DESCRIPTION OF THE DRYING CABINET Air intake Moist air exhaust Hole for connecting lead Control panel Three removable hanging sections Door, alternatively right-hung or left-hung version Adjustable feet (4x) Service module Heating and fan components are combined on a removable service module Operating Instructions... -
Page 7: Installation
INSTALLATION UNPACKING ___________________________________ __________________________________ NOTE: The drying cabinet must be handled After unpacking, check that the product is fee of carefully if it is only standing on its pallet. faults. Damage, defects and any missing parts RISK OF TIPPING OVER. must be immediately reported to the dealer. -
Page 8: Fitting Of Door Handle
FITTING OF DOOR HANDLE Fit the door handle using the fixing screws supplied. REHANGING OF DOOR The door may be hung to the right or the left. Lower hinge is pre-installed on both sides L a y t h e d r y i n g cabinet down on its back. - Page 9 B Lower hinge missing on opposite side Rehanging of door when the cabinet is Some models do not have a lower hinge fit- lying on its back ted on both sides. In such cases the existing hinge must be moved to the correct side. Detach the hinge with the screws (3).
-
Page 10: Positioning
ECO DRYER MAN 40° 2:30 START STOPP 40° 60° POSITIONING _____________________________________ The drying cabinet is intended solely for place- ment indoors in a dry place. ___________________________________________ ______________________________________ The drying cabinet must not be placed in an environment in which high-pressure water is used for cleaning. -
Page 11: Evacuation / Air Supply
EVACUATION / AIR SUPPLY When the cabinet is on, 45 m³ moist air per hour is evacuated. It must therefore be ensured that air can enter the room to replace the moist air that is vented out. CONNECTION TO EVACUATION The drying cabinet is connected to an exhaust ventilation unit in accordance with standard. - Page 12 2. PERMANENTLY FITTED TO MECHANICAL EXHAUST AIR VENTILATION UNIT When the cabinet is permanently connected ___________________________________ to a ventilation duct, the whole room is ven- Adapter is not supplied. tilated thought the drying cabinet. _______________________________________ Connect the hose to the adapter between __________________________________ the hose and ventilation duct.
-
Page 13: Electrical Connection
ELECTRICAL CONNECTION The drying cabinet should be connected to a 230 V single-phase 50-60 Hz and earthed wall socket. The drying cabinet is supplied ready for connection with a cable with an earthed plug. ___________________________________ __________________________________ The drying cabinet should be connected Do not connect the drying cabinet to the using the connecting cable supplied to an power supply with an extension lead as the... -
Page 14: Start-Up
START-UP __________________________________ __________________________________ CAUTION: Read the safety instructions Read this Use and Care Guide before using the drying cabinet on page 4 before using the cabinet for the for the first time. first time. _______________________________________ _______________________________________ Check that the cabinet is firmly attached to the wall. See page 10. Check that no packaging material has been left behind. -
Page 15: Operation
OPERATION STARTING USER TIPS Position the items to be dried in the SETTING OF CONTROLS Set the heat and time knobs for the most drying cabinet and close the door. See sensitive item of washing. also section ‘Positioning of washing’. The temperature is changed by turning Set a suitable temperature and drying ... -
Page 16: Controls
CONTROLS The drying cabinet is equipped with two knobs for different settings. The left-hand knob controls heat with set- tings on a steplessly adjustable scale. The right-hand knob controls drying time steplessely up to four hours. If a fast drying result is wanted, turn the heat Heat Drying time knob to max and set the timer to two hours. -
Page 17: Care
This information can be found on the iden- tification plate located inside the cabinet. Identification plate (inside) DC 7191 Name of drying cabinet Article number Serial number (12 digits) Operating Instructions... -
Page 18: Trouble Shooting
TROUBLE SHOOTING Trouble Cause What to do The cabinet does not pro- Is the plug connected? Check. duce any heat despite the heater knob being set to Is the fuse intact? Check. fast and the fan being in operation Is the right fuse being Change to slow-acting used? fuse. -
Page 19: Service Module
SERVICE MODULE Heating and fan components are combined on a removable Service Module. __________________________________ Caution: Remove plug from socket. _______________________________________ Detach the service module locking screws. The screws are accessible if the door is opened. Pull out the service module. 1. -
Page 20: Technical Data
TECHNICAL DATA Capacity: approx. 4.0 kg washing (cotton) Drainage capacity: 17 g/min. Electrical connections: single-phase 230 V, 50-60 Hz Motor: 35 W Heating element: 1500 W Overheating protection: Timer: Can be set up to 4 hr. Fan capacity: 180 m³/h Hanging length: 16 metres Dimensions:... - Page 24 Doc. No: 427000959 / 03 We reserve the right to make alterations.
