NOZOMI NETWORKS NSG-L Series Quick Start Manual

1. Unpacking the System
You should inspect the box chassis if it was damaged
in any way.
If you f ind any damages, please contact Nozomi
Networks support at support@nozominetworks.com.
BOX CONTENTS
• Nozomi Networks NSG-L Guardian appliance
• RJ45 to DB9 serial adapter for console access
• USB console cable
• RJ45 network cable
• Rail mounting brackets and appliance-side screws
• Rubber feets for desktop mounting
NSG-L Series
Nozomi Networks NSG-L Guardian Appliance
2. Setup precautions and considerations
Decide a suitable location for the appliance.
It should be situated in a clean, dust-free area
that is well ventilated. Avoid areas where heat,
electrical noise and electromagnetic fields are
generated.
Use a regulating uninterruptible power supply
(UPS) to protect the appliance f rom power surges,
voltage spikes and to keep your system operating
in case of a power failure.
A reliable ground must be maintained at all times.
To ensure this, the rack itself should be grounded.
Particular attention should be given to power
supply connections.
The appliance should be mounted into a rack or
otherwise placed so that the amount of airflow
required for safe operation is not compromised.
The appliance should be mounted into a rack so
that a hazardous condition does not arise due to
uneven mechanical loading.
Q U IC K STA RT G U ID E
3. Rack mounting instructions
Unbox the appliance, the Rack mounting brackets
and their mounting screws:
Fix each bracket to the appliance, using three of
the provided screws as shown below:
x3
