NOZOMI NETWORKS NSG-M Series Quick Start Manual

1. Unpacking the System
Inspect the chassis if it was damaged in any way. If you
find any damages, please contact Nozomi Networks
support at support@nozominetworks.com.
BOX CONTENTS
• Nozomi Networks NSG-M Guardian appliance
• RJ45 to DB9 serial adapter for console access
• USB cable for console access
• Appliance grounding cable
• RJ45 network cable (1)
• Rail mounting bracket
• Rubber feet for desktop mounting
NSG-M Series
Nozomi Networks NSG-M Guardian Appliance
2. Setup precautions and considerations
Observe the following precautions to help prevent
potential for property damage, personel injury or death.
• Do not use damaged equipment, including exposed,
frayed or damaged power cables.
• Do not operate the appliance with any covers
removed.
• Choose a suitable location for the appliance:
· It should be situated in a clean, dust-free area that
is well ventilated. Avoid area where heat, electrical
noise and electromagnetic fields are generated.
· Avoid areas where it can get wet. Protect the
appliance from liquid intrusion. If the appliance
gets wet disconnect power to the appliance.
• Use a regulating uninterruptible power supply (UPS)
to protect the appliance from power surges, voltage
spikes and to keep your system operating in case of
a power failure.
• A reliable ground must be maintained at all times. To
ensure this, the rack itself should be grounded and the
appliance chassis should be connected for grounding
to the rack via the provided appliance grounding
cable.
• It should be mounted into a rack or otherwise placed
so that the amount of airflow required for safe
operation is not compromised.
• If mounted into a rack it should be placed so that a
hazardous condition does not arise due to uneven
mechanical loading.
Q U IC K STA RT G U ID E
3. Rack mounting instructions
Unbox the appliance. Rack mounting brackets and their
mounting screwsare included in the pizza box on the
upper shelf of the package.
Affix each bracket to the appliance, using three of the
provided (grey) screws as shown below:
x3
2-posts rack mounting
You can now mount the appliance in a standard 19" rack.
Nuts and bolts for square holes are included in the box.
