TREADMILL
OWNER'S MANUAL
Read the TREADMILL GUIDE before using this OWNER'S MANUAL.

Advertisement

loading
Need help?

Need help?

Do you have a question about the T202 and is the answer not in the manual?

Questions and answers

Summary of Contents for Horizon Fitness T202

  • Page 1 TREADMILL OWNER’S MANUAL Read the TREADMILL GUIDE before using this OWNER’S MANUAL.
  • Page 2 ENGLISH...
  • Page 3 ASSEMBLY WARNING There are several steps during the assembly process where special attention must be paid. It is very important to follow the assembly instructions and to ensure the product is assembled correctly to reduce the risk of injury. Make sure all parts are firmly tightened before using the treadmill to ensure that the treadmill is stable and structurally sound.
  • Page 4 CONSOLE WATER BOTTLE HOLDER SPEAKERS TABLET/READING RACK CONTROL PANEL AND DISPLAY WINDOWS WATER BOTTLE HOLDER PULSE GRIP HANDLEBARS CONSOLE FAN CROSSBAR PULSE GRIP HANDLEBARS SAFETY KEY PLACEMENT CONSOLE MAST ON/OFF SWITCH POWER CORD MOTOR COVER RUNNING BELT/RUNNING DECK FOOT LOCK LATCH (UNDERNEATH DECK) SIDE RAIL ROLLER END CAP TRANSPORT WHEEL...
  • Page 5: Pre-Assembly

    PRE ASSEMBLY TOOLS INCLUDED: 6 mm T-Wrench 6 mm L-Wrench UNPACKING 5 mm L-Wrench Place the treadmill carton on a level flat surface. It is recommended that you place a protective covering on your floor. Take CAUTION when handling and transporting this unit.
  • Page 6 UNBOXING Cut the yellow banding straps and remove console masts and other components from the box. After the treadmill is placed on a level floor, cut off the BANDING STRAPS (A) on the left and right sides. Cut the RED STRAP (B) to release the deck from being strapped to the folding frame.
  • Page 7: Assembly Step

    ASSEMBLY STEP 1 HARDWARE FOR STEP 1 PART TYPE DESCRIPTION BOLT Open HARDWARE FOR STEP 1. Attach the LEFT CONSOLE MAST (1) to the BASE FRAME (2) using 3 BOLTS (A). NOTE: Do not fully tighten bolts until the end of STEP 4.
  • Page 8 ASSEMBLY STEP 2 HARDWARE FOR STEP 2 PART TYPE DESCRIPTION BOLT Open HARDWARE FOR STEP 2. Pull the CONSOLE CABLE (3) away from the treadmill base frame. Connect the CONSOLE CABLE (3) from the MAIN FRAME (2) to the CONSOLE CABLE (3) in the bottom of the RIGHT CONSOLE MAST (4).
  • Page 9 ASSEMBLY STEP 3 HARDWARE FOR STEP 3 PART TYPE DESCRIPTION BOLT Open HARDWARE FOR STEP 3. Attach LEFT SIDE of the CROSSBAR (6) to the UPRIGHT MAST (1) loosely using 2 BOLTS (A). Attach RIGHT SIDE of the CROSSBAR (6) to the UPRIGHT MAST (4) loosely using 2 BOLTS (A).
  • Page 10 ASSEMBLY STEP 4 HARDWARE FOR STEP 4 PART TYPE DESCRIPTION BOLT ∅8.2 SPRING WASHER ∅8.2 NOTE: Be careful not to pinch any wires FLAT WASHER while assembling the console. Open HARDWARE FOR STEP 4. Gently place the CONSOLE (5) on top of the (STEP E) CONSOLE MASTS (1&4).
  • Page 11 ASSEMBLY COMPLETE! Before the first use, lubricate the treadmill deck by following the instructions in the MAINTENANCE section in the TREADMILL GUIDE. PRODUCT WEIGHT 87 kg / 191 lbs. USER WEIGHT CAPACITY 147 kg / 325 lbs. DIMENSIONS (L×W×H) 192 x 84 x 146 cm / 76” x 33” x 57”...
  • Page 13: Treadmill Operation

    TREADMILL OPERATION This section explains how to use your treadmill’s console and programming. The BASIC OPERATION section in the TREADMILL GUIDE has instructions for the following: • LOCATION OF THE TREADMILL • USING THE SAFETY KEY • FOLDING THE TREADMILL •...
  • Page 14 KCAL KM/H...
  • Page 15 CONSOLE OPERATION Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. A) LCD DISPLAY: Time, RPM, Distance, Watts, Calories, Incline, Speed, Heart Rate, Fan Speed. B) LED DISPLAY: Time, Speed, Distance, Calories, Incline, Heart Rate. C) WORKOUT INDICATORS: indicates what workout is set for the current program.
  • Page 16 KCAL DISPLAY WINDOWS • TIME: Shown as minutes : seconds. View the time remaining or the time elapsed in your workout. • SPEED: Shown as km/h. Indicates how fast your walking or running surface is moving. • DISTANCE: Shown as kilometers. Indicates distance traveled or distance remaining during your workout. •...
  • Page 17 GETTING STARTED 1) Check to make sure no objects are placed on the belt that will hinder the movement of the treadmill. 2) Plug in the power cord and turn the treadmill ON. (The ON/OFF switch is next to the power cord.) 3) Stand on the side rails of the treadmill.
  • Page 18 WORKOUT PROFILES P1) MANUAL: Adjust your speed and incline manually during your workout. P2) FAT BURN: A workout designed specifically to target fat. Promotes weight loss by increasing and decreasing the speed and incline, while keeping you in your fat burning zone. Includes 10 levels. Speed and Incline changes, segments repeat every 30 seconds.
  • Page 19 Segment Warm Up Time 4:00 Mins 30 Sec 30 Sec 30 Sec 30 Sec 30 Sec 30 Sec 30 Sec 30 Sec Incline Speed (mph) Level 9 Speed (km/h) 10.4 11.2 12.8 11.2 10.4 Incline Level 10 Speed (mph) Speed (km/h) 10.4 11.2 12.8...
  • Page 20 P4) DISTANCE: Push yourself and go further during your workout with 13 distance workouts. Choose from 1 mile, 2 miles, 5k, 5 miles, 10k, 8 miles, 15k, 10 miles, 20k, half marathon, 15 miles, 20 miles and marathon goals. User sets starting speed levels. P5) CALORIES: Set goals for burning calories.
  • Page 21 Horizon MODEL NUMBER in the list and select connect. The Bluetooth led will be lit when connected. Waste Disposal HORIZON Fitness products are recyclable. At the end if its useful life please dispose of this article correctly and safely (local refuse sites).
  • Page 22 Horizon T202 | Rev. 1.0 E ©2021 Horizon Fitness...
