FireFlex TotalPac 3 Manual

Description
®
This T P 3 integrated fire protection system by
OTAL AC
FireFlex Systems Inc. consists of a deluge system trim totally
pre-assembled, pre-wired and factory tested. All electrical
and mechanical components of the system are contained in
one single unit.
®
T P 3 deluge system is built around the Viking trim
OTAL AC
using deluge valve model F-1.
Electrically controlled deluge system requires an electric
normally closed solenoid valve controlled by an approved
system releasing control panel with compatible detection
devices. In fire condition, when the detection condition is
satisfied the system releasing control panel energizes the
solenoid valve, causing the deluge valve to open allowing
water to enter the system piping. Water will flow from any
open sprinklers and/or spray nozzles on the system.
Activation of a releasing device alone or operation of a
sprinkler alone will sound an alarm but will NOT cause the
system to fill with water.
All the valves are rated up to a maximum of 250 PSI WWP
(1724 kPa) max. and are available in the following diameters:
 
1½" (40mm) 3" (80mm)
 
2" (50mm) 4" (100mm)
FM-076D-0-83G

6" (150mm)

8" (200mm)
Deluge System, Electric Release
Standard features
 cULus Listed & FM Approved as an assembled unit
 Factory assembled, programmed and tested under
ISO-9001 Standards
 Prewired to the Viking VFR-400 releasing control panel
 Easy and compact installation
 Viking conventional trim rated at 250 PSI (1724 kPa)
 Galvanized trim piping
 Serial number for easy reference
 Corrosion resistant cabinet with flush type handle and
lock
 No open drain cup inside the unit
 Releasing circuit disconnect switch
 Numerous modular options to meet the most
demanding jobsite requirements
 Inlet & outlet hydrostatic test ports
 User-friendly standardized operation & installation
manual
 Free interactive simulator available
®
T P 3
OTAL AC
Self-contained Unit
(Optional)
1 of 16
