• direction
When installing the CPE device, please adjust its front panel
to face the cover. You can use Google Maps and
the horizontal lobe width to roughly determine the direction of the CPE.
The horizontal beam width of CPE is shown in the following table:
model
horizontal lobe width
As shown below
The white fan-shaped area is the signal coverage of the CPE.
,
shenzhen
horizontal lobe width
B
Make sure the receiving device is
,
Tools such as GPS
TL-CPE200 TL-CPE500
65°
sight range
top view
,
And combined with CPE equipment
45°
A
