Machine Translated by Google
tp-link.aliexpress.com
Installation Manual
Outdoor wireless CPE
TL-CPE200/TL-CPE500

Advertisement

loading
Need help?

Need help?

Do you have a question about the TL-CPE200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TP-Link TL-CPE200

  • Page 1 Machine Translated by Google tp-link.aliexpress.com Installation Manual Outdoor wireless CPE TL-CPE200/TL-CPE500...
  • Page 2 Machine Translated by Google Table of contents product description Hardware connection Select installation location Connection and installation Software configuration Log in to the web management interface Typical application scenario configuration • peer to peer • Point-to-multipoint • Hot spots Antenna alignment Technical parameters and specifications Frequently Asked Questions twenty one...
  • Page 3 Machine Translated by Google product description TP-LINK outdoor wireless CPE products are committed to providing effective solutions for outdoor wireless transmission. solution. Here we take TL-CPE200 as an example. • List of items Installation Manual Outdoor wireless CPE Power Adapter...
  • Page 4 Machine Translated by Google CPE: LAN1 LAN0 DC port Reset button RJ45 port RJ45 port (PoE input) Passive PoE adapter: DC POE LAN DC power interface P o E power supply port RJ45 port...
  • Page 5 Machine Translated by Google Hardware connection This is Class A This product may cause radio in living environment product interference. Users may be required to take practical action against interference measures in this case. 1. Select installation location • high Obstacles such as trees, tall buildings and large steel structures can weaken Wireless signal during Prevent signal blockage...
  • Page 6 Tools such as GPS And combined with CPE equipment the horizontal lobe width to roughly determine the direction of the CPE. The horizontal beam width of CPE is shown in the following table: TL-CPE200 TL-CPE500 model 65° 45° horizontal lobe width The white fan-shaped area is the signal coverage of the CPE.
  • Page 7 Machine Translated by Google 2. Connection and installation Please refer to the figure below for connection and installation. Please open the sliding cover on the CPE shell first. To facilitate the completion of the network cable connection To ensure that it is not easy to slide the cover when CPE is working outdoors tight and will fall off if opened.
  • Page 8 Machine Translated by Google Power on (Powered by Passive PoE power supply) Power outlet DC POE LAN LAN0 Connect the LAN port of the P o E power supply to the PC, IPC or switch according to the network topology The steps to connect CPE and PassivePoE power supply are as follows: Connect the other end of the network cable connected to the CPELAN0 port to the POE port of the PassivePoE power supply.
  • Page 9 Machine Translated by Google Power on (DC power supply) DC LAN Connect According to network topology the LAN port of the CPE to the PC, IPC or switch. The steps to connect the CPE to the power adapter are as follows: Plug the other end of the power adapter connected to the CPEDC port into the power socket.
  • Page 10 Machine Translated by Google Software configuration Main contents of this chapter: 1) Introduce the method of logging into the Web management interface of wireless CPE. 2) Combine its software configuration methods with three That is, point-to-point, point-to-multipoint and hotspot introduce typical application scenarios.
  • Page 11 Machine Translated by Google 2) Open the browser, enter http://192.168.1.254 in the address bar and press Enter to log in. Record the Web management interface. To ensure a better experience of Web page display, push it is recommended to use the latest version of Chrome/Safari/Firefox browser. 3) Wireless CPE’s first login page Fill in the parameters as follows: •...
  • Page 12 Machine Translated by Google 2. Typical application scenario configuration This section will introduce the configuration methods of three typical application scenarios: point-to-point, point-to-multipoint and hotspot. Please refer to the corresponding content based on your network structure. • Point-to-point The point-to-point model is mainly used to establish a network connection between two wireless devices that are relatively far apart. We will take the following figure as an example to introduce its configuration method.
  • Page 13 Machine Translated by Google 2) Enter the quick settings page 3) Working mode • Select “Access Point” • Click <Next> button 4) LAN settings: Click the <Next> button...
  • Page 14 Machine Translated by Google 5) AP settings: • SSID: Enter a string (1 ~ 3 2 characters) to name your wireless network • Encryption algorithm: Select "WPA-PSK/WPA2-PSK" • PSK Key: Set a password for your wireless network, required It is 8 ~ 6 4 hexadecimal characters or 8 ~ 63 ASCII characters •...
  • Page 15 Machine Translated by Google Client configuration method 1) Log in to the web management interface 2) Enter the quick settings page 3) Working mode • Select “Client” • Click <Next> button 4) LAN settings: • IP address: 192.168.1.252 (in the same network segment as Access Point) •...
  • Page 16 Machine Translated by Google 5) Client settings: • SSID of the remote AP: Click the <Scan> button and select the Access Point SSID and click the <Connect> button • Encryption algorithm: Select "WPA-PSK/WPA2-PSK" • PSK key: Enter the PSK key of Access Point • Distance setting: Enter the same distance as in AccessPoint configuration •...
  • Page 17 Machine Translated by Google • Point-to-multipoint The point-to-multipoint model is mainly used when wireless devices in several different areas need to communicate with a central The network connection established by the access point in the area. Client LAN: 192.168.1.2 Client AccessPoint LAN: 192.168.1.3 LAN: 192.168.1.254...
  • Page 18 Machine Translated by Google • PSK key: Set a password for your wireless network, requiring 8 ~ 6 4 hexadecimal characters or 8 ~ 63 ASCII characters • Distance setting: Enter the distance between the AP and the farthest access device . If difficult suggest entering a minimum integer greater than the distance Accurate measurement •...
  • Page 19 Machine Translated by Google • Hotspot The hotspot model is mainly used to provide network access to wireless clients such as smartphones, tablets, and laptops. If the front-end device of the wireless CPE is in It is recommended to configure CPE as Access router Point mode.
  • Page 20 Machine Translated by Google 6) Complete: Click the <Finish> button...
  • Page 21 Machine Translated by Google Antenna alignment Precisely adjust the direction of the You can use the system status of the Web management interface CPE for optimal wireless transmission performance. Rotate the CPE slightly Until the signal-to-noise ratio reaches the maximum value in the system state.
  • Page 22 Technical parameters and specifications Hardware parameters Dimensions (L×W×H) 224.34*79*60.3mm LAN0: 10/100Mbps RJ45 port (PoE input) LAN1: 10/100Mbps RJ45 port interface DC input port RESET: reset button 9V/0.85A DC (TL-CPE200) Input power 12V/1A DC (TL-CPE500) -30ÿ ~70ÿ Operating temperature 10%~90% Working humidity Wireless parameters...
  • Page 23 Machine Translated by Google Frequently Asked Questions Question 1. How to restore factory settings? When the CPE is powered on, press and hold the RESET button of the CPE for about 8 seconds until the wireless signal The indicator light starts to flash and then the system will automatically restart and restore to factory settings. method 1: RESET key Press and hold for about 8 seconds to activate wireless signal...
  • Page 24 Machine Translated by Google Question 2. How to calculate the minimum installation height of the equipment? We first need to introduce the concept of "Fresnel zone". Large buildings or trees between the sender and receiver During the transmission of wireless signals, This causes signal fading.
  • Page 25 Machine Translated by Google The acceptable radius is 8.485m. Assuming that the obstacle height h is 10 m, the then wireless Calculate all obstacles CPE erection height should be higher than. Similarly 1 8 . 4 8 5 m is the result at The maximum value is the final result.
  • Page 26 Machine Translated by Google vertical side by side vertical back to back twenty four...
