The product model shown in this QIG is TL-WN851N, as an example.
Note
1.
Power down your computer and unplug its power cord;
2.
Open the case and locate an available PCI slot on the motherboard;
3.
Insert the PCI Adapter into the PCI slot. Make sure that all of its pins are
touching the slot's contacts. You may have to apply a bit of pressure to slide the
adapter all the way in. After the adapter is firmly in place, secure its fastening
tab to your computer's chassis with a mounting screw;
4.
Close the case and insert the power cable into the computer, then turn on the
computer.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TL-WNB51N and is the answer not in the manual?

Questions and answers

Summary of Contents for TP-Link TL-WNB51N

  • Page 1 The product model shown in this QIG is TL-WN851N, as an example. Note Power down your computer and unplug its power cord; Open the case and locate an available PCI slot on the motherboard; Insert the PCI Adapter into the PCI slot. Make sure that all of its pins are touching the slot's contacts.
  • Page 2 This is the default setup wizard of Windows XP. For a smoother installation, please click “Cancel” and insert the provided TP-LINK Resource Click Cancel After inserting the provided Resource CD into your CD-ROM drive, the Setup Wizard will automatically pop up on your computer’s screen.
  • Page 3 Click Next Choose Install Driver Only Click Next Follow the step-by-step instructions to finish the driver installation. If prompted to ‘The software has not passed Windows Logo testing to verify its compatibility with Windows XP’, click Continue Anyway to continue. Click Finish...
  • Page 4 Connecting to the Wireless Router/Access Point If the Wirless Router/Access Point supports Wi-Fi Protected Setup (WPS) Note function, you are recommanded to use the QSS (Quick Secure Setup) to quickly connect to your wireless network. Please refer to the Appendix Connecting to the Wireless Router by QSS.
  • Page 5 You have now successfully connected to your wireless network. If your network is an unsecured network, you will not be prompted to input the Note Network key. It will connect to your network automatically.
  • Page 6 This is the default setup wizard of Windows Vista. For a smoother installation, please click “Cancel” and insert the provided TP-LINK Resource Click Cancel After inserting the provided Resource CD into your CD-ROM drive, the Setup Wizard will automatically pop up on your computer’s screen.
  • Page 7 Click Next Follow the step-by-step instructions to finish the driver installation. If prompted to ‘Windows can’t verify the publisher of this driver software’, click Install the driver software Anyway to continue. Click Finish...
  • Page 8 Connecting to the Wireless Router/Access Point If the Wirless Router/Access Point supports Wi-Fi Protected Setup (WPS) Note function, you are recommanded to use QSS (Quick Secure Setup) to quickly connect to your wireless network. Please refer to the Appendix Connecting to the Wireless Router by QSS.
  • Page 9 If you don’t know the wireless network key, please consult the network Note administrator or log on to the setup page of your Wireless Router/Access Point with an Ethernet cable to check the wireless security settings. Please refer to the manual of your Wireless Router/Access Point or consult the manufactory’s technical support for more details.
  • Page 10 Installing the QSS Driver Click Install QSS Follow the step-by-step instructions to finish the QSS installation. Click Finish...
  • Page 11 Connecting to the Wireless Router Double click the icon on the desktop to open the QSS Utility, and this page will display. Click Next Select Enter the PIN from my access point Input the PIN printed on the back of the Router Click Next...
  • Page 12 Wait for the Adapter to connect to the Wireless Router. Click Finish to complete the connection. Click Finish...
  • Page 13: Technical Support

    Global Australia & New Zealand Tel: +86 755 26504400 Tel: AU 1300 87 5465 E-mail : support@tp-link.com NZ 0800 87 5465 Service time:24hrs, 7days a week E-mail: support@tp-link.com.au Service time: Monday to Friday 9:00 AM to 9:00 PM AEST...
