- Page 1 User Guide TL-SM321A / TL-SM321B 1000Base-BX WDM Bi-Directional SFP Module Rev:1.0.3 7106503185...
- Page 2 No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2009 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
-
Page 3: Fcc Statement
FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 4 is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
-
Page 5: Table Of Contents
CONTENTS Package Contents..............1 Chapter 1. Introduction ............1 Chapter 2. Features of the product........3 Chapter 3. Installation Guide ..........3 Specifications ................4... -
Page 6: Package Contents
1.25Gbit/sec. It can effectively extend the diameter and bandwidth of the workgroup. TL-SM321 Series SFP Module can be installed inside the Switch which supplies power directly, it can cooperate with TP-LINK products as the table below:... - Page 7 SFP Module Cooperated TP-LINK products Managed Gigabit Switch TL-SG3109 TL-SL3428 TL-SL3452 Web Smart Gigabit Switch TL-SG2109WEB TL-SG2216WEB TL-SG2224WEB TL-SL2210WEB TL-SM321A TL-SL2218WEB TL-SM321B TL-SL2428WEB TL-SL2452WEB Unmanaged Gigabit-Uplink Switch TL-SL1351 SMB Broadband Router TL-R4199G TL-R4299G Gigabit Media Converter MC220L Note: If any abnormal status occurs when the light modules of the device are hot-switched between 1000Mbps and 100Mbps, please try to power on the device again.
-
Page 8: Chapter 2. Features Of The Product
The following will take the installation procedure in the switch for example. Push the SFP Module into Switch along the track smoothly Plug fiber into the module, without any configuration manually, the SFP Module can work. 10km TP-LINK Switch TP-LINK Switch TL-SM321B TL-SM321A Fiber Warning: In order to avoid ESD (ElectroStatic Discharge), do not touch the output pins on the module with your hand. -
Page 9: Specifications
Specifications Normal TL-SM321A TL-SM321B Tx:1550nm Tx:1310nm Wave Length Rx:1310nm Rx:1550nm IEEE 802.3ah 1000Base-BX, Standards and Protocols CSMA/CD, TCP/IP Cable Single-mode Fiber Fiber Type 9/125 um Single-mode Max. Cable Length 10km Data Rate 1.25Gbps Port Type Power Support 3.3V Safety & Emission...
