S2 Low Profile 2-Pocket Discriminator
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO S2 and is the answer not in the manual?

Questions and answers

Related Manuals for Cassida PRO S2

Summary of Contents for Cassida PRO S2

  • Page 1 S2 Low Profile 2-Pocket Discriminator USER MANUAL...
  • Page 4 Battery Warning: (1) Keep out of the reach of children. Swallowing may lead to serious injury or death in as little as 2 hours due to chemical bums and potential perforation of the esophagus. See a doctor immediately and ask them to call (202) 625-3333.
  • Page 5 This equipment has been tested and complies with the limits to a Class A digital device, pursuant to Part 15 of the FCC Rules. If you have questions about the operation of the Cassida Pro S2, please contact your Cassida licensed reseller or refer to Cassida’s user portal at www.CassidaPro.com.

  • Page 6: Important Safety Instructions

    Prior to and during cleaning, unplug the unit from the wall. Follow the cleaning instructions and maintenance schedule contained in this manual. • Do not service your unit. Contact your authorized Cassida technician, distributor or sales representative for technical assistance.

  • Page 7: Table Of Contents

    Table of Contents: 1. INTRODUCTION About the Cassida Pro S2 _________________________________________________ 1 Box Contents _____________________________________________________________ 1 Views of the Cassida Pro S2 _______________________________________________ 2 Control Panel Overview ___________________________________________________ 3 Glossary of Terms _________________________________________________________ 4 2. OPERATION Getting Started ___________________________________________________________ 4...

  • Page 8: Introduction

    About the Cassida Pro S2 Thank you for choosing the most innovative 2-pocket currency discriminator, the Cassida Pro S2. The S2 is a professional grade, compact, high performance value counter and sorter combined with the industry’s leading suspect counterfeit currency detection technology.

  • Page 9: Views Of The Cassida Pro S2

    Views of the Cassida Pro S2...

  • Page 10: Control Panel Overview

    Control Panel Overview Description 1. Selection of desired currency. 2. Used as ”+1” function in the menu interface. BATCH 1. Batch function ON/OFF, and set batch number. 2. Used as ”-1” function in the menu interface. DISPLAY 1. View the counting detail. 2.

  • Page 11: Glossary Of Terms

    Glossary of Terms Bills: Refers to any currency or denomination to be counted. Hopper: Location where user places bills to be counted. May refer to either the S2 infrared sensors, or infrared features built into modern currencies. May refer to either the S2 magnetic sensors, or magnetic features built into modern currencies.

  • Page 12: Loading Bills

    Loading Bills Before loading bills into S2, ensure the desired currency and operation modes are selected. Proper alignment of bills into the hopper reduces feed errors, jamming, and identification reject errors caused by misaligned bills. Bills should be stacked neatly prior to loading, and placed between the hopper bill guides at the center of the hopper.

  • Page 13: Main Screen Overview

    Main Screen Overview Currency Selection Press CUR key to select the desired currency. Or tap the “AUTO” area on the display to enter the currency selection interface. Note: “AUTO” currency means machine will detect which currency automatically.

  • Page 14: Counting Modes

    Couning Modes Tap the MODE ICON or press MODE key to select the desired counting mode. There are 6 counting modes available on Cassida Pro S2. • MIX Mode Tap the MODE ICON or press MODE key to select the MIX mode. MIX mode is the default sorting mode for the S2.
  • Page 15 • SORT Mode Tap the MODE ICON or press MODE key to select the SORT mode. SORT mode is intended to sort out a single denomination from a mixed stack of bills while running all selected counterfeit detection features. This mode is also used for ‘rogue’ or ‘stranger’...
  • Page 16 • COUNT Mode Tap the MODE ICON or press MODE key to select the COUNT mode. COUNT mode is intended to count the number of physical pieces placed in the hopper. In this mode counterfeit detection is disabled. Only the count will update. This mode may be used to count the number of pieces of any article that will pass through the S2, including tickets, tags, barcodes, papers, etc.
  • Page 17 • ORIENTATION (ORT) Mode Tap the MODE ICON or press MODE key to select the ORIENTATION mode. ORIENTATION mode is similar to FACE mode in that the S2 is sorting bills by the physical orientation each bill is scanned. In orientation mode, the S2 accounts for all 4 possible rotations as follows: 1.

  • Page 18: Function

    Function ADD Function • The ADD function on the S2 is used to keep a continuous count through various different counting events. Tap the ADD ICON or press ADD key to select the ADD function. The S2 will sum the total denomination and count of all bills being counted until the user clears the sum or turns off ADD function by tapping ADD ICON or pressing ADD key.

  • Page 19: Post Count Summary And Detail

    Strapping is available in all modes, though some are more intuitive than others. In general, strapping or Batching is most commonly used in SORT or MIX modes. Press BATCH key and select the most standard number of bills (100, 50, 25, 20, 10) desired in the strap.

  • Page 20: Reject Pocket Capacity

    Reject Pocket Capacity Press the MENU button and tap screen to toggle between 20, 30, 40, 50. If the pocket capacity is set too high dependent on the type of bills being used (circulation vs new), there is a risk of bills being ejected from the reject pocket. Batch Add Mode Tap screen to toggle between on or off.

  • Page 21: Date & Time

    Date & Time Press the MENU button and tap screen to modify Date & Time. This feature allows user to select the date format for S2. Here you can select the Date Format DD-MM-YY, MM-DD-YY or YY-MM-DD. By double tapping date or time set up, user can set up date and time.

  • Page 22: Beep Setup

    Beep Setup Thie feature enables users to control when the S2 beeps. By default, every key stroke or tap on screen produces a beep sound to give user feedback of the action. In this menu, you can turn on and off beep settings that calls for Alarm events like a reject and/or for keystrokes.

  • Page 23: Technical Specifications

    TECHNICAL SPECIFICATIONS Counterfeit Detection Sensors Dual CIS, MG, Dual-Wavelength IR, UV Value Count Speed 1000 notes/minute Free Count Speed 1200 notes/minute Hopper Capacity 500 notes Stacker Capacity 200 notes Power Supply 100-240V AC, 50/60Hz Interface RJ9, DB9, USB Dimensions 10.6”x10.2”x10.4” (W)x(H)x(D) Net Weight 18.3 lbs...

  • Page 24: Appendix Error Messages

    APPENDIX ERROR MESSAGES Self-Test error messages and solutions Error message Solutions 1. Put the machine to a suitable place to avoid UV Fault strong light on the top cover. 2. Remove the banknote from the machine and/ or remove dust from UV sensor. Right Counting Fault Remove the banknote and/or remove dust from Middle Counting Fault...
  • Page 25 Reject error messages and possible solutions Deno Diff The denomination of this banknote is different from the first detected denomination of this counting batch. Ver Diff The issued version of this banknote is different from the first detected issued version of this counting batch. Face Diff The face direction of this banknote is different from the first detected face direction of this counting batch.
  • Page 26 MG3-Error 1. Count Again. 2. If problem persists, capture the image data to your sales for further check. IR-Error 1. Count Again. 2. Do a sensor calibration. 3. If problem persists, capture the image data to your sales for further check. Width 1.
  • Page 27 Old Ver Check if the banknotealready out of circulation. Others 1. Count Again. 2. If problem persists, record the operational details before and after the problem occured, then capture the image data to your sales for further check . Alarm Messages and possible solutions Error message Solutions Batch Reached...

  • Page 28: Maintenance, Contacts And Specifications

    • Do not use solvents or harsh chemical cleaning solutions. • Clean the unit daily. • Clean sensors with a damp cloth or an air duster, soft bristled brush, or the Cassida Cleanbill Pro cleaning card. • Clean the rubber rollers with the Cassida Cleanbill Pro cleaning card.

  • Page 29: Contact Information

    Contact Information Technical support contact information: Tel: (888) 800-0303 www.CassidaPro.com 6.3 Specifications Feeding System Type: Roller Friction Counting Speed: 1200 Notes/Min Hopper Capacity: 500 Note Reject Pocket Capacity: 50 Notes Stacker Capacity: 200 Notes Dimensions: 10.6” x 10.2” x 10.4” (271 x 260 x 264mm) Display: 3.5”...
  • Page 32 Cassida Corporation 2024 Cassida Corporation. All rights reserved. Specifications subject to change without notice. ValuSort is a registered trademark of Cassida Corporation. FN S2REV 1124...
