- Page 1 ® 6600 Plus moving money forward CASSIDA 6600 PLUS USER MANUAL PROFESSIONAL CURRENCY COUNTER...
- Page 2 This manual contains important information on safety measures and operational features. Please read it carefully before operating your currency counter, and keep it for future reference.
- Page 3 • Take the machine to a qualified technician when service or repairs is required. Do not try to replace any parts yourself. Supplied spare parts are intended for use by qualified personnel only. Cassida 5520 Digital Currency Counter Cassida 6600 Plus Digital Currency Counter...
- Page 4 Table of contents: Introduction 1.1 About the Cassida 6600 PLUS ________________________________________ 5 1.2 Box contents ______________________________________________________ 5 1.3 Front view ________________________________________________________ 6 1.4 Rear view ________________________________________________________ 7 1.5 Control panel _____________________________________________________ 8 1.6 Display __________________________________________________________ 9 1.7 Specifications ____________________________________________________ 10 Getting Started 2.1 Powering up _____________________________________________________ 11...
- Page 5 INTRODUCTION 1.1 About the Cassida 6600 PLUS Thank you for choosing the Cassida 6600 PLUS currency counter. We hope you enjoy using it. The Cassida 6600’s uniquely engineered mechanism combines the benefits of both backloading and frontloading machines, ensuring precise counting of even worn bills.
- Page 6 1.3 Front view 1. Control panel - programs and operates the Cassida 6600 PLUS 2. Stacking rollers - transports counted bills into the stacker 3. Stacker - holds counted bills 4. Stacker sensors - signals presence of bills in the stacker 5.
- Page 7 (narrow for fresh, new bills - wide for worn out bills) Note: Please do not adjust unless the machine displays recurrent DBL or Chn error messages. When adjusting, be sure both screws are adjusted equally Cassida 5520 Digital Currency Counter Cassida 6600 Plus Digital Currency Counter...
- Page 8 1.5 Control panel Cassida 6600 UV Cassida 6600 UV/MG MG / CUR Activates MG counterfeit detection on UVMG model / Switches currency type on UV model Activates UV counterfeit detection. The screen will display the type of detection active PRT/+...
- Page 9 Counterfeit Detection Active/Inactive Selected Currency Number of Bills Counted Displays Batch Complete or Incomplete Total Value of Bills Counted in VALUE Mode or Total Bills Counted in ADD Mode only Cassida 5520 Digital Currency Counter Cassida 6600 Plus Digital Currency Counter...
- Page 10 Batch Range: 1-999 banknotes Feeding System: Roller Friction System Counting Display: TFT 2.8” (71 mm) Counterfeit detection: UV (6600 PLUS UV model) UV and MG (6600 PLUS UVMG model) Ambient Temperature: C-40 C (32 F-104 Operating humidity: 40%-90% Size: 9.8” X 10.6” X 10.2” (250 X 270 X 260 mm) Weight: 11.7 lb.
- Page 11 It is important to load the hopper correctly to avoid jams and ensure the proper operating speed of the machine. Before loading bills into the 6600 PLUS, ensure the desired currency and operation modes are selected. Proper placement of bills into the hopper reduces feed errors, jamming, and identification reject errors caused by misaligned bills.
- Page 12 To reduce rejects: • Place the bills evenly arranged as shown below • Adjust bill guides to fit the size of the bills. • Correct the bills if they are severely wrinkled or damaged. Correct Incorrect ®...
- Page 13 When placing additional bills in the hopper, be sure the stacker does not accumulate more bills than it can hold (approximately 300 new bills or 150 old bills), as this will cause jamming and may lead to a motor failure. Cassida 5520 Digital Currency Counter Cassida 6600 Plus Digital Currency Counter...
- Page 14 3.3 Batch mode To switch to batch mode, press the BAT button. The default batch quantity is set to 100. Use the BAT button to select other preset quantities (50, 20, or 10). To increase or decrease the batch quantity to your desired amount, press the PRT/+ button or the AUTO/- button.
- Page 15 To activate this mode, press both the ADD and BATCH buttons. Both “ADD” and “BATCH” will be displayed on the screen. To reset the count, press the CLEAR button. Cassida 5520 Digital Currency Counter Cassida 6600 Plus Digital Currency Counter...
- Page 16 After selecting the desired denomination, load the bills to be counted into the hopper, ensuring that the denomination of the bills matches the selected denomination. The 6600 PLUS will count the stack and display both the total value and the number of bills counted on the screen.
- Page 17 3.8 Report + Print function The Cassida 6600 PLUS provides the capability to view reports on its screen and to print them when connected to an external printer (please note: printer not included). The report feature is available only when the value count mode is active. Follow the instructions in section 3.6, “Value Mode,”...
- Page 18 This feature allows the user to continue operation without losing count and saves considerable time when used with the add mode activated. Please note that the 6600 PLUS series counters, like all other bill counters with integrated counterfeit detection sensors on the market, cannot guarantee that a counted bill is genuine or counterfeit.
- Page 19 4.3 Half note detection The Cassida 6600 PLUS incorporates infrared (IR) light sensors that notify the user if a half bill passes through the counting mechanism. This feature is activated automatically in all modes for your convenience.
- Page 20 4.4 Chain note detection The Cassida 6600 PLUS utilizes a self-checkin system that alerts the user in rare cases when several bills pass through the counting mechanism at once. This feature is activated automatically in all modes for user`s convenience.
- Page 21 Use a Cassida CleanPro swab to clean all counting sensors. The rubber rollers can be cleaned with a cloth that is slightly dampened with a small amount of isopropyl alcohol.
- Page 22 1. Hopper sensor 2. Stacker sensor 3. Counting sensors ®...
- Page 23 See section 1.5 “Rear view” to locate adjustment screws. Adjust 1 turn and retest. Repeat until the gap is properly adjusted Cassida 5520 Digital Currency Counter Cassida 6600 Plus Digital Currency Counter...
- Page 24 There are bills in Remove the bills from the hopper to allow the the hopper machine to complete its self-check HOPPER Hopper sensor Clean the sensor with soft bristle brush and SENSOR may have compressed air. Refer to section 5.1 to locate the collected dust hopper sensor Issue with the...
- Page 25 See section 1.4,”Rear view” to locate adjustment screws. Adjust 1 turn and retest. Repeat until the gap is properly adjusted Cassida 5520 Digital Currency Counter Cassida 6600 Plus Digital Currency Counter...
- Page 26 To activate your warranty in the USA, please register your product online by visiting www.cassidausa.com/warranty-registration. The Cassida 6600 PLUS is warranted for period of one year from the date of purchase. In most cases, a malfunction can easily be resolved by cleaning the machine. Please refer to section 5.1,”Maintenance”...
- Page 27 Cassida 5520 Digital Currency Counter Cassida 6600 Plus Digital Currency Counter...
- Page 28 Cassida Corporation - North America Printed in China ©2024 Cassida Corporation. All rights reserved. Specifications subject to change without notice. Cassida is a registered trademark of Cassida Corporation. FN 6600PLUS REV 061824...
